Audix VX5 User manual

VX5
OVERVIEW
The VX5 is a professional vocal condenser microphone designed for a wide variety
of live, studio and broadcast applications. With an ability to duplicate studio quality
sound on stage, the VX5 is known for its smooth and accurate frequency response,
resistance to feedback and ability to handle very high sound pressure levels without
distortion.
The VX5 is characterized with a tight and uniformly controlled supercardioid polar
pattern which helps to isolate the vocals from the rest of the instruments on stage.
With a wide frequency range of 40 Hz - 16.5 kHz, the VX5 has a very clean and natural
sound with exceptional transient response. This mic requires 9 - 52 volts phantom
power.
Other features include a 14 mm gold vapor diaphragm, an acoustically ported steel
mesh grill with multi-stage pop filter and a -10 dB pad and bass roll-off filter. The VX5
will handle sound pressure levels in excess of 140 dB (with pad and roll-off engaged)
and will provide over 20 dB of ambient noise rejection on live stages.
In addition to vocal applications, the VX5 is ideally suited to capture acoustic
instruments such as guitar, woodwinds, brass, percussion toys, drum overheads,
hi-hat and piano. It is a very versitile mic for home studio recording. The VX5 is well
balanced, comfortable to hold, durable, and designed with very high standards and
tight tolerances.
The VX5 is manufactured with a precision die cast zinc alloy body, durable black
E-coat finish and gold plated XLR connector.
SUPPLIED ACCESSORIES
MC1 - Heavy-duty nylon molded clip with brass insert
P1 - Carrying pouch
OPTIONAL ACCESSORIES
WS357 - Optional high quality external foam windscreen for reducing
wind, sibilance, and pop noise.
SMT25 - Optional low profile shock mount system with nylon cable
and thumbscrew for positioning.
APS2 - Two-channel 48 V phantom power supply for condenser microphones.
110 V switchable to 240 V. Detachable power cord.
CBL20 - 20’ premium XLR-XLR balanced mic cable. Quad conductor, twisted pair
with braided shield for maximum conductivity. 6mm PVC jacketed.
CBLDR25 - 25’ premium right angle XLR-XLR balanced mic cable. Quad conductor,
twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.
Condenser Vocal
Microphone
VX5
FEATURES
·Premium electret condenser for vocals
and acoustic instruments
·Smooth accurate frequency response
·Switches for -10 dB pad and bass roll-off
·Suited for acoustic music as well as loud stages
·Designed, assembled & tested in the USA
·3 year warranty
APPLICATIONS
·Stage or studio
·Lead or background vocals
·Speech
·Acoustic instrumentals
MC1 P1 WS357 SMT25 APS2 CBL20 CBLDR25

Hi
Lo
FREQUENCY RESPONSE
POLAR PATTERNS
ARCHITECT AND ENGINEER SPECIFICATIONS
The microphone shall be a back plate pre-polarized condenser with a
supercardioid polar pattern. The microphone shall operate on 9-52 Volts
phantom power and the nominal output impedance shall be equal to 150
ohms at 1 kHz. The microphone shall have switches for -10 dB pad and bass
roll-off filter and shall have a sensitivity of 5 mV / Pa at 1 kHz. The microphone
shall have a maximum SPL level of ≥140 dB (with pad) with a THD of 0.5%. The
microphone shall have a steel mesh grill and a body of die cast zinc alloy with
dimensions of 23 mm in diameter at the base and 181 mm in length.
OPERATION AND MAINTENANCE
The VX5 is a low impedance microphone and should be plugged into a “mic
level” input on your console, mixer or recording device. The VX5 requires
phantom power and will NOT operate without phantom power voltage which
is available on most professional mic preamps and mixing devices. Phantom
power will be needed on your equipment (such as the Audix APS2).
Avoid plugging or unplugging the microphone from a PA system unless the
channel is muted or the volume of the system is turned down. Failure to do so
may result in a loud“popping” noise which could seriously damage the speakers
in the PA system.
The VX5 is manufactured to exacting specs with roadworthy construction.
However, the capsule is highly sensitive and should be handled with care. Avoid
extreme temperatures and be sure to store your microphone in the pouch
provided when not in use. Moisture of any kind can adversely effect the sound
and performance of your microphone.
USER TIPS
The VX5, an excellent choice for lead and background vocals, has a supercardioid
pick-up pattern which helps to minimize sound from other instruments on
stage from “bleeding” into the microphone. The VX5 is highly sensitive and will
accommodate working distances of 1-12 inches from the performers mouth.
Depending on the instrumentation and volume on stage, the vocalist may have
to experiment to find the optimum working range.
When using stage monitors, avoid pointing the back of the microphone directly
into the stage monitor. Instead, set the microphone at an angle parallel to the
floor, putting the angle of the mic on a different plane with the angle of the
monitor. Allow a distance of 2-3 feet between microphones to avoid phase
cancellation issues.
Further miking techniques may be found at www.audixusa.com.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
www.audixusa.com
503.682.6933 Fax: [phone]
Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070
ver 3.0 05-16
PRODUCT REGISTRATION: Please register your product online at www.audixusa.com/docs_12/about/product_registration.shtml.
SERVICE AND WARRANTY: This microphone is under warranty for a period of 3 years to be free of defects in material and workmanship. In the event of a product failure due to materials or
workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes
any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No
Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any,
for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of
any kind. Should your microphone fail in any way, please contact the Audix Service department at 503.682.6933. A Return Authorization is required before returning any product. OTHER THAN
THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUCTS. AUDIX SHALL
NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S
SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
DIMENSIONS (mm)
SPECIFICATIONS
VX5
Transducer Type Pre-Polarized Condenser
Frequency Response 40 Hz - 16.5 kHz
Polar Pattern Supercardioid
Output Impedance 150 ohms
Sensitivity 5 mV / Pa @ 1k
Equivalent Noise Level 26 dB (A-weighted)
Signal to Noise Ratio 68 dB
Off Axis Rejection >20 dB
Maximum SPL ≥140 dB (w/ -10 pad)
Power Requirements 9-52 V
Connector 3-pin XLRm
Polarity Positive pressure on diaphragm
produces positive voltage on
pin 2 relative to pin 3 of output
XLR connector
Materials / Finish Zinc Alloy & Machined Brass /
Black Finish
Weight 277 g / 8 oz
Length 181 mm / 7.1 in
