August MR260 User manual

August International Ltd
United Kingdom
Tel: [phone]
www.augustint.com
Transmetteur & Récepteur Bluetooth Double Mode
Trasmettitore & Ricevitore Bluetooth
2-in-1 Bluetooth Transmitter und Receiver
Transmisor & Receptor Bluetooth 2 en 1
Dual Mode Bluetooth Transmitter & Receiver
MR260
EN
FR
DE
IT
ES

1. Safety Instructions
1 Do not use this device near water.
2) Clean only with a dry cloth. Switch this
product off before cleaning.
3) Do not install near any heat sources such as
stoves or other apparatus that produce heat.
4) Only use the accessories supplied by the
manufacturer.
5) Do not open the device, as this will invalidate
the warranty.
2. Main Features
Dual Mode Bluetooth Transmitter / Receiver
AptX Low Latency Technology for lag free music
and movie
Standard 3.5mm Audio Socket
Built-in Rechargeable Battery
Distance: up to 10m (Class II)
Bluetooth Profiles: A2DP, AVRCP, PBAP
3. Box Contents
)
-1-
English
User Manual
Thank you for purchasing the August MR260
Bluetooth Transmitter. This user manual is
designed to familiarize you with all the features of
this device. Please take the time to read this user
manual carefully, even if you are already familiar
with a similar product.
Safety
To ensure the safety of you and others, please
read the Safety Instructions before using this
device. Please do not disassemble the product, it
can be unsafe and will invalidate the
manufacturer's warranty.
Disposal
Please ensure the product and accessories are
disposed of in compliance with the WEEE (Waste
Electrical and Electronic Equipment) Directive
and any other regulations applicable to your
country. Always check with the environment
agency and any other relevant authorities for
current disposal regulations.
Customer Service
You can contact us by phone on: [phone]
0586 or by email at: [e-mail]
should you require further technical support or
customer service.
1) Dual Mode Bluetooth Transmitter / Receiver
2) USB Power Cable
3) 3.5mm Audio Cable
4) 3.5mm to 2xRCA Audio Cable
5) User Manual
Transmetteur & Récepteur Bluetooth Double Mode
Trasmettitore & Ricevitore Bluetooth
2-in-1 Bluetooth Transmitter und Receiver
Transmisor & Receptor Bluetooth
Dual Mode Bluetooth Transmitter & Receiver
MR260
EN
FR
DE
IT
ES
1 2 3
4 5

-2- -3-
English
4. Part Names & Functions
1 Multi-Function Button
2) Sta tus LED
3) Receiver (RX) and Transmitter (TX) Mode Switch
4) Aux In / Out
5) Power Socket
)
5. Operations
5.1 Transmit Audio (TX Mode)
1) Select TX mode. The MR260 will enter
reconnection mode automatically and will
connect automatically to any previous known
device. To pair to a new device, press and hold
the multi-function button for 4 seconds to enter
pairing mode. In pairing mode the status LED will
flash red and blue alternately.
2) Enable Bluetooth on the receiving device
and enter pairing mode (see the device's user
manual for more information).
The MR260 will pair automatically to the receiving
device.
Once successfully paired, the status LED will light
blue constantly.
3) To pair to a new device, press and hold the multi-
function button for 4 seconds to switch the
MR260 into pairing mode again. This can be done
either when a device is already connected to the
MR260 or when the MR260 is in reconnection
mode. In pairing mode, the status LED will flash
red and blue alternately.
Note: When the receiving device is switched off,
the MR260 will enter reconnection mode. The LED
will flash blue twice per second and the MR260 will
reconnect to any previously paired device that is in
range and has Bluetooth switched on.
5.2 Receive Audio (RX Mode)
1) Select RX mode. The MR260 will enter
reconnection mode and will connect
automatically to any previous known device. If no
known device is available, the MR260 will
automatically enter pairing mode after 4 seconds
and the status LED will flash red and blue
alternately.
2) Enable Bluetooth on the source device
1
2
34 5

-4- -5-
English
3) Scan for Bluetooth devices on your source
device and select MR260 to connect to it.
Once successfully paired, the status LED will
flash blue every 4 seconds.
4) To pair to a new device, press and hold the multi-
function button for 4 seconds to switch the
MR260 into pairing mode again. This can be done
either when a device is already connected to the
MR260 or when the MR260 is in reconnection
mode. In pairing mode, the status LED will flash
red and blue alternately.
Note: When the source device is switched off, the
MR260 will enter reconnection mode. The status
LED will flash blue twice per second and you will be
able to reconnect to any previous paired device. For
Android source devices, the MR260 will reconnect
automatically, for all other devices select the
MR260 from their Bluetooth device list.
For PC connections, Windows XP and Windows
Vista require third party software to connect to
Bluetooth speakers. If you are using a later version
of Windows and the MR260 is not outputting audio,
please check that the drivers for your PCs
Bluetooth module are up to date and that the Audio
Output source is set to the MR260.
5.3 Multi-Function Button
Whilst connected in either TX or RX Mode, press
the multi-function button to mute or unmute the
MR260.
When connected to a device or in reconnection
mode, press and hold the multi-function button for 4
seconds to reset the connection and enter pairing
mode again. The status LED will flash red and blue
alternately and you will be able to connect the
MR260 to a new device.
7. Specifications
Bluetooth Version v2.1 aptX Low Latency
Bluetooth Profile
Operating Range
Power Input
Internal Battery
Working Time
Charging Time
A2DP, AVRCP, PBAP
Up to 10m
DC 5V/180mA
3.7V/ 200mAh Li-polymer battery
Up to 8 hours
About 1.5 hours
Dimensions
Net Weight
50x35x13.7mm
20g
6. Charging
Connect the MR260 to a powered USB port using
the provided USB charging cable.
While charging, the status LED will light red and go
off once the battery is fully charged.
A full charge takes approximatively 1.5 hours
depending on power input.

-6-
English
8. Troubleshooting
Unable to switch on Fully charge the MR260
Turn switch on TX or RX
Unable to pair
Bluetooth source
device or Bluetooth
audio device
Confirm that the MR260 is in
pairing mode.
Confirm that the MR260 is
within 10m of the source
device or audio device.
Delete existing connection to
MR260 from source device
and repair.
Can't install the
driver for MR260
on a computer
For Windows 7 and 8, update
the Bluetooth driver from the
Bluetooth module manufacturer's
website. For further information
on you PCs Bluetooth module,
please consult your PC supplier.
Bluetooth headsets are not
supported by Windows XP and
Vista, a third party Bluetooth d
river can be used to solve this issue.
There is no sound
from my Bluetooth
audio device
Make sure the Bluetooth audio
device is connecting to MR260
via Bluetooth.
Make sure the cable is connection
between your source device and
MR260.
Check the volume on both source
device and your Bluetooth audio
device.
9. Warranty
This product is guaranteed for twelve months
from the date of the original purchase. In the
unlikely event of any defect arising due to faulty
materials or workmanship, the unit will be either
replaced or repaired free of charge (where
possible) during this period. An alternative
product will be offered in case the product is no
longer available or repairable.
This warranty is subject to the following
conditions:
The warranty is only valid within the country
where the product is purchased.
The product must be correctly installed and
operated in accordance to the instructions
given in this user manual.
The product must be used solely for domestic
purposes.
The warranty only covers the main unit, and
does not cover the accessories.
The warranty does not cover the damage
caused by misuse, negligence, accident and
natural disaster.
The warranty will be rendered invalid if the
product is resold or has been damaged by
inexpert repairs. The manufactures disclaim
any liability for incidental or consequential
damages.
Please consult our customer adviser before
returning any product; we are not responsible
for any unexpected product returns.
-7-
Problems Possible Causes and Solutions

Any faulty product must be kept and returned
in the original packaging with all the
accessories and the original copy of the
purchase receipt.
The warranty is in addition to, and does not
diminish, your statutory or legal rights.
Customer Service:
Telephone: [phone]
Email: [e-mail]
-8-
English
This product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC. The declaration of conformity
may be consulted at August International Ltd,
Rawmec Business Park, Plumpton Road, Hoddesdon,
EN11 0EE, United Kingdom.
