Aukey EP-B60 User manual

UserManua
WirelessHeadphone：EP‐B60(FCCID：2AFHP‐EP‐B60)
ThankyouforpurchasingtheAUKEYEP‐B60MagneticWirelessEarbuds.Pleasereadthisusermanual
carefullyandkeepitforfuturereference.Ifyouneedanyassistance,pleasecontactoursupportteamwith
yourproductmodelnumberandAmazonordernumber.
PackageContents
MagneticWirelessEarbuds
Micro‐USBCable
ThreeSetsofEar‐Tips(S/M/L)
ThreePairsofIn‐EarEar‐hooks(S/M/L)
CarryingPouch
UserManual
WarrantyCard

ProductDiagram



Volume+/NextTrack
Multi‐FunctionButton
Volume‐/PreviousTrack
LEDIndicator
Micro‐USBChargingPort
Microphone

Specifications
ModelEP‐B60
Techn o l ogyBT4.1,A2DP,AVRCP,HSP,HFP
Driver8mm(D)x5mm(H)/0.31”(D)x0.2”(H)
Impedance16ohm
Sensitivity95±3dB
FrequencyRange20Hz–20kHz
MicrophoneNoiseReduction6thgenerationcVcaudiotechnology
InputDC5V
ChargingTime1.5hours
PlayTime8hours
StandbyTime120hours
BatteryTypeLi‐Polymer(2×60mAh)
OperatingRangeUpto10m/33ft
Weight15g/0.53oz

GettingStarted
Fullychargeyourearbudsbeforefirstuse.Beforecharging,makesuretheearbudsareturnedoff.Tocharge,
simplyconnectoneendofthemicro‐USBcabletoaUSBchargingportandtheotherendtotheinputport
ontheearbuds.WhentheredLEDindicatorlightturnsblue,yourearbudsarefullychargedandreadyfor
use.Chargingtakesaround1.5hours.


TurningOn/Off
●Topoweron,pressandholdthemulti‐functionbuttonfor2seconds,andtheLEDindicatorwillflash
blue
●Topoweroff,pressandholdthemulti‐functionbuttonfor5seconds,andtheLEDindicatorwillflashred
andthenoff



Pairing
Startingwithyourearbudspoweredoff:
1. Pressandholdthemulti‐functionbuttonfor5secondsuntiltheLEDindicatorflashesblueandred
alternately
2. Turnonthepairingfunctionofthedeviceyouwanttopairwiththeearbuds
3. Inthelistofavailabledevices,findandselect“AUKEYEP‐B60”.Whenconnected,theLEDindicatorwill
flashbluetwiceevery5seconds
4. Ifacodeorpinisrequiredforpairing,enter“0000”

SimultaneousPairingwithTwoDevices
1.Followtheinstructionsinthe“Pairing”sectiontopairtheearbudswithDeviceA
2.Oncepaired,disablewirelessfunctiononDeviceAandturnofftheearbuds
3.Followtheinstructionsinthe“Pairing”sectiontopairwithDeviceB
4.OncepairedwithDeviceB,reactivatewirelessfunctiononDeviceAandselect“AUKEYEP‐B60”inthelist
ofpaireddevices
5.Youcannowmakeandreceivecallsfromeitherofthetwopaireddevices

Notes
•Toclearpairinglist,powerontheearbudsanddonotmaketheearbudsconnectedwithanydevices,
thenholdvolume+andmulti‐functionbuttonsimultaneouslyfor5secondsuntiltheLED
indicatorflashesred5times.Whenyouturnontheearbudsnexttime,theearbudswillautomaticallyenter
intopairingmode
•Theearbudswillautomaticallyshutdownafter5minutesinpairingmodeifnodevicesarepaired
•Ifyourpaireddeviceisturnedofformanuallydisconnected,theearbudsLEDindicatorwillflashblue
onceevery8secondsandtheearbudswillautomaticallyshutdownafter5minutes
•Themaximumwirelessoperatingrangeis33ft(10m).Ifyouexceedthisrange,theearbudswill
disconnectfromyourpaireddevices.TheLEDindicatorwillflashbluetwiceevery5secondsin10minutes
andthenitwillflashonceevery8secondsin5minutes.Theconnectionwillbere‐establishedonceyou
re‐enterthewirelessrangewithin15minutes.Theearbudswillautomaticallyreconnecttothelast‐paired
device.Toconnectwithotherdevices,repeattheprevious“Pairing”steps

MusicandCallsControl
MakingCalls
Oncepairedwithyoursmartphone,makingandansweringphonecallscanbemanagedviathein‐line
remote.
Answer/EndacallPressthemulti‐functionbuttononce
RediallastcallednumberDoublepressthemulti‐functionbuttonwhenconnected
RejectanincomingcallHoldthemulti‐functionbuttonfor2seconds
Mute/ResumeacallPressandholdthevolume‐for2secondsduringacall
VoiceswitchPressandholdthevolume+for2secondsduringacalltoswitchbetween
theearbudsandyourphonefortalking
DeviceswitchPressandholdthemulti‐functionbuttonfor2secondsduringacallto
switchbetweentwomobilephones

Siri/GoogleassistantPressmulti‐functionbuttonforonly1secondandthenmustreleaseyour
finger,youwillhearatone

StreamingAudio
Oncepaired,youcanwirelesslystreamaudiofromyourdevicetoyourearbuds.Musicwillautomatically
pausewhenyoureceiveanincomingphonecall,andresumeoncethecallhasended.
Play/PausePressthemulti‐functionbuttononce
VolumeControlPressthevolume+/‐
Next/PreviousTrackPressandholdthevolume+/‐for2seconds
EQSwitchDoublepressmulti‐functionbuttontoswitchvocals/treble/
basswhenplayingmusicandyouwillhearatone

LEDIndicatorStatus
Blue&redflashingalternatelyPairingmode
Blueflashingtwiceevery5secondsConnected
Blueflashingtwiceevery8secondsPlayingmusic
Blueflashingonceevery8secondsDisconnected/Incall
BlueflashingonceeverysecondIncomingcall
Redflashingtwiceevery8secondsLowbattery
RedCharging
Blue(aftercharging)Fullycharged

FAQ
Theearbudsareonbutnotconnectingtomydevice
Fortheearbudsandyourdevicetoestablishaconnection,youneedtoputthembothinpairing
mode.Pleasefollowtheinstructionsinthe“Pairing”sectionofthismanual.

Mydevicecan’tfind“AUKEYEP‐B60”onthepairinglistwhentryingtopair
MakesuretheearbudSareinpairingmode(flashingblueandredalternately;seethe“Pairing”sectionof
thismanual).Otherwise,restartyourdeviceandtheearbuds;thentrypairingagain.

Ihaveestablishedaconnectionwithmysmartphonebutcan’thearanysound
Double‐checkthevolumelevelonyoursmartphoneandtheearbuds.Somesmartphonesrequireyoutoset
uptheearbudsasanaudiooutputdevicebeforetheaudiocanbetransmitted.Ifyouareusingamusic
playerorotherdevice,pleasemakesureitsupportstheA2DPstereomusicprofile.

Thesoundisnotveryclearorthecallercannothearmyvoiceclearly
Adjustthevolumeonyoursmartphoneandtheearbuds.Trygettingclosertoyoursmartphonetoruleout
thepossibilityofinterferenceorwirelessrange‐relatedissues.

CanIusetheearbudswhiletheyarecharging?
No.




Whatisthewirelessrangeoftheearbuds?
Themaximumrangeis33ft(10m).However,theactualrangewilldependonenvironmentalfactors.For
optimalperformance,keepyourdevicesconnectedwiththeearbudswithina15ft‐25ftrangeandmake
surethattherearenomajorobstacles(likereinforcedsteelwalls)betweentheearbudsandyourdevices.

Myearbudswon’tturnonevenwhenIhavefullychargedthem
ConnecttheearbudstoaUSBchargerportwiththeincludedmicro‐USBcable.Pressandholdthe
multi‐functionbuttonuntiltheearbudsturnon.Iftheearbudsstillwon’tpoweron,pleasecontactour
supportteamattheaddressbelow.

ProductCare&Use
•Pleasekeepawayfromliquidsandextremeheat
•Donotusetheearbudsathighvolumeforextendedperiods,asthismaycausepermanenthearing
damageorloss

Warranty&CustomerSupport
Forquestions,support,orwarrantyclaims,contactusattheaddressbelowthatcorrespondswithyour
region.PleaseincludeyourAmazonordernumberandproductmodelnumber.

AmazonUSorders:[email protected]
AmazonEUorders:[email protected]
AmazonCAorders:[email protected]
AmazonJPorders:[e-mail]
*Pleasenote,AUKEYcanonlyprovideaftersalesserviceforproductspurchaseddirectlyfromAUKEY.Ifyouhavepurchasedfroma
differentseller,pleasecontactthemdirectlyforserviceorwarrantyissues.

NoticeforUS
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe
user'sauthoritytooperatetheequipment.ThisdevicecomplieswithPart15oftheFCCRules.Operation
issubjecttothefollowingtwoconditions:

1.Thisdevicemaynotcauseharmfulinterference,and
2.Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation






FCCRules
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept
anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance
couldvoidtheuser'sauthoritytooperatetheequipment.
NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,
usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewith
theinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno
guaranteethatinterferencewillnotoccurinaparticularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.Thedevicecanbeuse
dinportableexposureconditionwithoutrestriction.
FCCID:2AFHP‐EP‐B60
Caution
ChangesormodificationsmadetothisdevicethatarenotexpresslyapprovedbyAUKEYmayvoidthe
user'sauthoritytooperatethisequipment.

