modway MOD-5824 User manual

MOD-5824 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 1 of 5
Thank you for purchasing the QUEEN BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
and environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten
the components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Hardware:
Components:
1 .Headboard x1 2. Bed Rail x2 3. Footboard x1 4.Center rail x1 5.Center support leg x3
7. Side Plastic Cover x26 8. Slat x26 9. Left column x1 10. Right column x1 11. Leg x4 12. Slat support x2
x6
x10
x12
x46
x46
x1
x16
A.
I.
B.
C.
F.
G.
H.
x8
Bolt M8x70mm
Bolt M8x50mm
Bolt M8x40mm
Bolt M8x25mm
Bolt M8x20mm
Flat Washer
Lock Washer
Screw25mm
Allen Wrench
x10
D.
E.
J.
Screw Driver x1 (Not included)
6. Center Plastic Cover

MOD-5824 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 2 of 5
STEP 1:
1. Attach the Left Column (9) & Right Column (10) to the side of Headboard(1) by using 6 pieces of
Bolts(A), 6 pieces of Lock Washers(G) and 6 pieces of Flat Washers(F). Tighten Bolt by using Allen
Wrench(I), as shown.
STEP 2:
1. Turn Headboard (1) and Footboard (3) flat on the carpeted or padded area. Please take out 4 pieces of
Legs (11) from the carton.
2. Attach one of the Leg (11) to the bottom of the Footboard (3) by using 2 pieces of Bolts (D), 2 pieces of
Lock Washers(G) and 2 pieces of Flat Washers(F). Tighten Bolts by using Allen Wrench (I) as shown,
then use 4 pieces of Screws (H)to screw in from the Leg(11) to the bottom of the Footboard (3) by
using a Screw Driver (J) (Not included).
3. Repeat the same steps for the other 3 pieces of Legs(11).
DG
HEADBOARD
FOOTBOARD
1
3
A
x 6
x 6
F
x 6
G
I
x 1
D
x 8
x 8
F
x 8
G
I
x 1
x 16
H
Phillips Head Screwdriver
NOT INCLUDED
J
11
11
11
11
11

MOD-5824 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 3 of 5
STEP 3:
Attach one end of Bed rail (2) to the assembled Headboard (1) by using 3 pieces of Bolts (C), 3 pieces of Lock
Washers (G) and 3 pieces of Flat Washers (F). Do not fully tighten Bolts at this step.
Repeat the same steps for the other end of Bed Rail (2) to the Footboard (3) and Headboard (1). Finally tighten
all the Bolts fully.
STEP 4:
1. Attach one of the Slat Support (12) to one of the middle of the Bed rail (2) by using 5 pieces of Bolts (B),
5 pieces of Lock Washers(G) and 5 pieces of Flat Washers(F). Please pay attention that the Slat
Support (12) with holes is on the top. Tighten Bolt by using Allen Wrench (I) as shown.
2. Repeat the same steps for the other Slat Support (12) to the other Bed Rail (2).
B
x 10
x 10
F
x 10
G
I
x 1
C
x 12
x 12
F
x 12
G
I
x 1

MOD-5824 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 4 of 5
STEP 5:
1. Attach each Center Support Leg (5) to Center Rail (4) by using 2 pieces of Bolts(E), 2 pieces of Lock
Washers(G) and 2 pieces of Flat Washers(F). Tighten Bolt by using Allen Wrench (I) fully as shown.
2. Attach the assembled Center Rail (4) & Center Support Leg (5) to the Headboard (1) & Footboard (3)
by using 4 pieces of Bolts (E), 4 pieces of Lock Washers (G) and 4 pieces of Flat Washers (F). Tighten
Bolt by using Allen Wrench (I) fully as shown.
3. Please note the bottom of each Center Support Leg (5) has the adjustable foot glide which you can
adjust the height if necessary.
STEP 6:
Insert 2 pieces of Side Plastic Cover (7) into each end of 2 pieces of Slats (8) as shown.
Insert the other end of the Slats (8) into 1 piece of Center Plastic Cover (6) as shown.
Insert the assembled Side Plastic Covers (7) into the corresponding holes on the Slat Support (12) of the Bed
Rail (2), and the assembled Center Plastic Cover (6) into the corresponding holes on Center Rail (4) as shown.
Repeat the same steps for the remaining 24 pieces of Slats (8).
5
2
5
E
x 10
x 10
F
x 10
G
I
x 1

MOD-5824 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 5 of 5
Assembly is complete. The Queen Bed is ready to enjoy now!
