AUREL AC-RX2/CS User manual

AC-RX2/CS
User Manual
Le caratteristiche tecniche possono subire variazioni senza preavviso. La AUR°EL S.p.A non si assume la responsabilità di danni causati dall’uso improprio del dispositivo.
AUR°EL S.p.A. Via Foro dei igli, 4 - 47015 Modigliana (FC) – I ALY Rev. A, 2-02-2010
el.: [phone] – Fax: [phone] Pag 1 di 4
http://www.aurel.it - email: [e-mail]
AC-RX2/CS Receiver
RF data receiver super-reactive ASK modulation, low cost and low consumption ideal for Microchip HCS
KEELOQ decoder/encoder family.
Pin-out
Component Side
21 3 7 11 13 14 15
38.1
12.3
2.54
0.5 0.25
7
3
15
Connections
Pin 2-7-11 round GND Connections: Internally connected to a single ground plate
Pin 3 Antenna 50Ω impedence antenna connection
Pin 1-15 +V Connection to the +5V ±0.5V supply positive pole
Pin 13 Test Point Analog output of the demodulated signal. By connecting an oscillograph
the entity and quality of the received RF signal can be seen.
Pin 14 Data Out Receiver digital output. Apply loads over 10 KΩ
Technical features
Min Tipico Max Unità Annotazioni
Working centre frequency 433.92 MHz
Voltage supply 4.5 5 5.5 V
Absorbed current 3 mA
RF sensitivity -106 dBm Vedi nota 1
-3 dB RF bandwidth ±2 MHz
Square wave output 3 KHz
Output low voltage Gnd+0.4
V Vedi nota 4
Output high voltage V
S
– 0.4
V Vedi nota 4
RF spurious emissions in antenna -65 dBm Vedi nota 2
Switch-on time 2 s Vedi nota 3
Operating temperature range -20 +80 °C
Dimension 38.1 x 12.3 x 3 mm
Nota1: Values have been obtained by applying the test system as per Fig. 1.
Nota2: he RF emission measure has been obtained by connecting the spectrum analyser directly to RX Pin 3.
Nota3: By switch-on time is meant the time required by the receiver to acquire the declared characteristics from the very moment the
power supply is applied.
Nota4: Values obtained with 10KΩ maximum load applied.
1

AC-RX2/CS
User Manual
Le caratteristiche tecniche possono subire variazioni senza preavviso. La AUR°EL S.p.A non si assume la responsabilità di danni causati dall’uso improprio del dispositivo.
AUR°EL S.p.A. Via Foro dei igli, 4 - 47015 Modigliana (FC) – I ALY Rev. A, 2-02-2010
el.: [phone] – Fax: [phone] Pag 2 di 4
http://www.aurel.it - email: [e-mail]
he declared technical features have been verified by applying the following test system:
Device usage
In order to take advantage of the performances described in the technical specifications and to comply with
the operating conditions which characterize the Certification, the receiver has to be fitted on a printed
circuit, considering what follows:
5V Supply voltage
1. he receiver must be supplied by a very low voltage source, safety protected against short circuits.
2. Maximum voltage variations allowed: ± 0.5 V.
3. De-coupling, next to the receiver, by means of a minimum 100.000 pF. ceramic capacitor.
round
1. It must surround at the best the welded area of the receiver. he circuit must be double layer, with
throughout vias to the ground planes, approximately each 15 mm.
2. It must be properly dimensioned, specially in the antenna connection area, in case a radiating whip
antenna is fitted in it (an area of approximately 50 mm radius is suggested.)
Fig. 1
Fig.2 Suggested lay-out for the device
correct usage

AC-RX2/CS
User Manual
Le caratteristiche tecniche possono subire variazioni senza preavviso. La AUR°EL S.p.A non si assume la responsabilità di danni causati dall’uso improprio del dispositivo.
AUR°EL S.p.A. Via Foro dei igli, 4 - 47015 Modigliana (FC) – I ALY Rev. A, 2-02-2010
el.: [phone] – Fax: [phone] Pag 3 di 4
http://www.aurel.it - email: [e-mail]
50 Ohm line
1. It must be the shortest as possible.
2. 1,8 mm wide for 1 mm thick FR4 printed circuits and 2,9 mm wide for 1,6 mm thick FR4 printed circuits.
On the same side, it must be kept 2 mm away from the ground circuit.
3. On the opposite side a ground circuit area must be present.
Antenna connection
1. It may be utilized as the direct connection point for the radiating whip antenna.
2. It can bear the connection of the central wire of a 50 Ω coaxial cable. Be sure that the braid is welded to
the ground in a close point.
Antenna
1. A whip antenna, 16,5 mm long and approximately 1 mm dia, brass or copper wire made, must be
connected to the RF input of the receiver.
2. he antenna body must be keep straight as much as possible and it must be free from other circuits or
metal parts (5 cm minimum suggested distance.)
3. It can be utilized either vertical or horizontal, provided the connection point between antenna and
receiver input, is surrounded by a good ground plane.
N.B: As an alternative to the a.m. antenna it is possible to utilize the whip model manufactured by Aurel
(see related Data Sheet ed Application Notes).
By fitting whip antennas too different from the described ones, the EC Certification is not assured.
Other components
1. Keep the receiver separate from all other components of the circuit (more than 5 mm).
2. Keep particularly far away and shielded all microprocessors and their clock circuits.
3. Do not fit components around the 50 Ohm line. At least keep them at 5 mm distance.
4. If the Antenna Connection is directly used for a radiating whip antenna connection, keep at least a 5 cm
radius free area. In case of coaxial cable connection then 5 mm radius will suffice.
Reference Rules
he AC-RX2/CS receiver is EC certified and in particular it complies with the European Rules E SI EN 300
220-2 V2.3.1 (2009-12) in class 3 and EN 301-489-3 V1.4.1 (2002-08) in class 3, with max voltage
supply. he equipment has been tested according to rule EN 60950 and it can be utilized inside a special
insulated housing that assures the compliance with the above mentioned rule. he receiver must be supplied
by a very low voltage safety source protected against short circuits he use of the receiver module is
foreseen inside housings that assure the overcoming of the rule EN 61000-4-2 not directly applicable to
the module itself. In particular, it is at the user’ s care the insulation of the external antenna connection, and
of the antenna itself since the RF output of the receiver is not built to directly bear the electrostatic charges
foreseen by the a.m. rule.

AC-RX2/CS
User Manual
Le caratteristiche tecniche possono subire variazioni senza preavviso. La AUR°EL S.p.A non si assume la responsabilità di danni causati dall’uso improprio del dispositivo.
AUR°EL S.p.A. Via Foro dei igli, 4 - 47015 Modigliana (FC) – I ALY Rev. A, 2-02-2010
el.: [phone] – Fax: [phone] Pag 4 di 4
http://www.aurel.it - email: [e-mail]
Temperature - sensitivity
-3
-2
-1
0
1
-40 -20 0 20 40 60 80 100
Temperature [°C]
Sensitivity [dB]
PLOT2
he declared technical features have been verified by applying the test system in FIG.1
Fig.3
Frequency - sensitivity plot
-120
-110
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
420 430 440 450
Frequency [MHz]
Sensitivity [dB]
PLOT1
Plot was obtained using the test set up as
in Fig.1 with variation of frequency and
output level of RF generator

AC-RX2/CS
User Manual
Le caratteristiche tecniche possono subire variazioni senza preavviso. La AUR°EL S.p.A non si assume la responsabilità di danni causati dall’uso improprio del dispositivo.
AUR°EL S.p.A. Via Foro dei igli, 4 - 47015 Modigliana (FC) – I ALY Rev. A, 2-02-2010
el.: [phone] – Fax: [phone] Pag 5 di 4
http://www.aurel.it - email: [e-mail]
Temperature - Power Consumption
2
2,2
2,4
2,6
2,8
3
3,2
3,4
3,6
3,8
4
-40 -20 0 20 40 60 80 100
Temperature °C
Power Consumption mA
PLOT3
he declared technical features have been verified by applying the test system in FIG.1
Temperature - Frequency center
431,5
432
432,5
433
433,5
434
434,5
-40 -20 0 20 40 60 80 100
Temperature °C
Frequency center MHz
PLOT4
he declared technical features have been verified by applying the test system in FIG.1 and frequency
center detection at –3dB.
