AUSTRALIAN MONITOR Digipage JR User manual

The DigiPage Jr is a matrix switching system allowing any one of up to 8
remote paging microphones (DPJ88M) to page into any combination of
up to 8 output zones over industry standard CAT-5 cable. The system
also allows any one of up to 4 program inputs to be directed to any or all
of the 8 output zones. An emergency input is also provided.
The DigiPage Jr matrix is an attractive, slim-line, 2RU steel cabinet, desk
or 19" rack mounted. It includes inputs for each of the 8 remote DPJ88M
microphone stations (line level signal and control) and a line level output
to each of the 8 output zones. Also included are inputs for the 4 program
sources (CD, tape, tuner etc) with associated level trim pots and an input
for an emergency signal such as from an EWIS control panel or priority
message system. Alert and evacuate signal tone generators are
connected internally and may be activated remotely by simple contact
closure.
The DigiPage Jr allows for total control over the operation of each of the 8
output zones. Each of the 8 output zones is equipped with controls for
program selection, by means of 4 interlocking push buttons, with controls
for microphone level, program level, bass, treble and master output level.
Each zone also has an associated push button to allow any zone the
option to be isolated from receiving paging announcements.
The DigiPage Jr may be powered via AC mains 240 volts or DC, 12 - 24
volts. (alternate voltages on special order)
SPECIFICATIONS
Data/Digital Audio Mic
RJ45 CAT5 Connector
Program Sources (Trim Max.)
Unbalanced (RCA): Input
Impedance:100KΩ;
Sensitivity:150mV
Balanced (XLR): Input
Impedance:1k3Ω;
Sensitivity:1mV -57dbu
Min.Trim: -46dB
Local Source
Unbalanced (RCA): Input
Impedance:100KΩ;
Sensitivity: 1.5V
Balanced (XLR) MIC: Input
Impedance:1k3Ω;
Sensitivity:11mV
Balanced (XLR) LINE: Input
Impedance:45KΩ;
Sensitivity:350mV
Sum Input
Input Sensitivity:330mV;
Threshold: -46dBu
(at output, ind.of input)
Frequency Response (3dB)
15Hz - 17kHz
THD
0.005%
Noise
Page Mic: -84dB;
Other Inputs: -89dB
Power Supply 2
4VDC 30VAPlug-pack
Dimensions (H x W x D)
5.2” x 19.01” x 6.7”
Weight
9.9 lbs.
Shipping weight
12.2 lbs
DIGIPAGE JRDIGIPAGE JR
DIGIPAGE JRDIGIPAGE JR
DIGIPAGE JR
Zone Paging System

DPJ88M Paging Station & Microphone
Each DPJ88M microphone station includes 8 zone select
buttons with associated zone status LEDs, a ‘Zone Page’
button, an ‘All Page’ button, a ‘Clear’ button and a ‘System
Busy’ LED. Also included is a gooseneck microphone and
microphone sensitivity control. A bass cut switch is located on
each DPJ88M to reduce ‘booming’ in high noise areas if
required. The DPJ88M is housed in an attractive and heavy-
duty case and may be desk or wall mounted.
Operation
When a page is made, a pre-announce tone will sound in each
of the output zones selected. Any program material playing in
to the zone(s) selected will be ducked for the duration of the
page. Microphone #1 has priority over Microphones #’s 2-8.
Connection
DigiPage Jr connects simply by Cat-5 cable. The Cat 5 carries
the audio and control from the mics to the main DigiPage Jr
unit. The DPJ88M microphones can be daisy chained for up to
200 meters.s.
