IMPORTANT INFORMATION
AIR SERIES

LIIA0100E0-02.fm 1 AUTEC - Air Series
A8 - Configuration Menu
General instructions
General instructions
This manual aims at providing information to enable, disable and modify the features of Autec Air series' radio remote controls.
This manual and the “user manual” need to be fully read and understood by those who decide upon and/or modify the radio
remote control's features.
Contact Autec if any of the instructions and/or warnings provided in this manual are not clear.
No part of this manual may be reproduced, in any form or by any means, without written permission of Autec (including re-
cording and photocopying).
All operations described in this manual must be carried out by qualified technicians who are suitably trained with respect to
the relevant norms and laws.
As for instructions and warnings regarding the machine where the radio remote control is to be installed, follow the instructions
given in the machine's manual.
Symbol conventions
This manual contains two symbols that highlight special indications.
This symbol marks all extremely important indications and information: if they are not respected, this may result in
critical danger for people or property.
This symbol identifies all texts in the manual that shall be read carefully.
Caption
General Section
Signals
LED is off
LED blinks once in a second
LED blinks twice in a second
LED blinks three times in a second
LED is steady on
LED repeats 1 blink and an off phase
LED repeats 2 blinks and an off phase
LED repeats 3 blinks and an off phase
LED repeats 4 blinks and an off phase
LED repeats 5 blinks and an off phase
Pushbuttons
pushbutton is released
pushbutton pressed to first step
pushbutton is pressed
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
S3
LED 1
LED 2
LED 3
Red LED
green LED
LED 4
1
2
3
4
5

AUTEC - Air Series 2 LIIBKU00E1-02.fm
A8 - Configuration Menu
PAIR 2.0
In radio remote controls consisting of one transmitting unit and one receiving unit, when the transmitting unit cannot be used
any more it is possible to replace it with a back-up unit by performing the PAIR 2.0. procedure
The back-up transmitting unit is identical to the radio remote control's transmitting unit.
The back-up unit is marked with a label on the battery cover reading “BACK-UP UNIT”.
The PAIR 2.0 procedure is used to match a transmitting unit with a receiving unit.
The PAIR 2.0 procedure can only be performed if the radio remote control's transmitting unit cannot be used any
more (being broken, lost, damaged), that is to say, only in case of maintenance or replacement.
The PAIR 2.0 procedure can only be used for radio remote controls consisting of a transmitting unit and a receiving
unit.
This procedure cannot be used to share the control of a receiving unit among different transmitting units: if it is used
for that purpose, the machine where the radio remote control is used will result non-compliant (ref. IEC 60204-1 and
IEC 60204-32).
Depending on the application and on the working environment where the radio remote control works, a transmitting unit can
be paired with a receiving unit by performing one of these two procedures:
- PAIR 2.0 DIP: procedure that requires the opening of the receiving unit
- PAIR 2.0 SERIAL: procedure that implies entering the “SERIAL N.” and does not require the opening of the receiving unit.
BACK-UP UNIT
(with PAIR 2.0)

LIIBKU00E1-02.fm 3 AUTEC - Air Series
A8 - Configuration Menu
Warnings PAIR 2.0
Warnings
Specific competence and caution are required to carry out the PAIR 2.0 procedure: only those who are aware of risks
deriving from the use of the system “machine + radio remote control” can perform this procedure.
As required by standards IEC 60204-1 (§9.2.7.4) and IEC 60204-32 (§9.2.7.5), the PAIR 2.0 procedure ensures that one
single transmitting unit is enabled to control the machine at a specific moment.
Hence, a receiving unit can only be controlled by the last transmitting unit that performed the PAIR procedure. After
performing the PAIR procedure, the transmitting unit that was previously paired cannot control the machine any
more.
Before pairing the back-up unit with a receiving unit, those who perform the PAIR 2.0 procedure must do the follow-
ing:
- store the transmitting unit to be replaced in an inaccessible place
- inform all persons involved that this unit cannot control the machine any more.
This way, operators won't have doubts on which unit is to be used.
If the output dedicated to the machine's horn, siren or blinker is used for another command, due to application's and/
or functional reasons, it is not possible to perform the PAIR 2.0 SERIAL procedure, because it would not be possible
to verify the correct pairing.
To perform the PAIR 2.0 DIP procedure, do the following:
As required by standard IEC 60204-32, each radio remote control is uniquely identified through a serial number (“SE-
RIAL N.”). The "SERIAL N." is provided in the identification plate in the two units that compose the radio remote con-
trol. For this reason, in case of replacement move the battery cover from the replaced transmitting unit to the back-
up unit, so that the transmitting unit shows the same “SERIAL N.” as the paired receiving unit.
Autec cannot be held liable if the battery cover, where the “SERIAL N.” is reported, is not moved to the back-up unit.
If it were not possible to use the battery cover of the replaced transmitting unit or if the identification plate were damaged and/
or not readable, write the “SERIAL N.” indelibly.
If it were not possible to use the battery cover of the replaced transmitting unit or if the identification and technical data plates
were damaged and/or not readable, contact Autec.
After performing the PAIR procedure, test the system “machine+radio remote control” and make sure that the back-
up unit is paired with the right receiving unit. Also make sure that the commands sent correctly match with the ac-
tions performed by the machine (in particular the STOP command).
Introduction to the PAIR 2.0 procedure
The PAIR procedure is used to match a transmitting unit with a receiving unit.
Before performing the PAIR 2.0 procedure, do the following:
- In the data sheet related to the receiving unit you want to pair, look up the “PAIR” section under “FACTORY SETTINGS”
and check that it reads “2.0”.
- Make sure that the transmitting unit has not already been paired with any receiving unit; in case it is, perform the UNPAIR
procedure (see the document "Menu of Transmitting Unit (MTU)"), which is also available in Autec's website).
- Make sure that the transmitting unit is set on the same frequency band as the receiving unit. The frequency band is selected
by DIP 1 on the transmitting unit's battery housing and DIP 1 on the receiving unit. These DIPs shall be set in the same way.
With the PAIR procedure, PIN START UP, PIN CODE and SWITCH OFF are restored to factory settings. If those settings
have been modified (as recorded in the technical data sheet), restore them as shown in the document “Menu of Transmitting
Unit (MTU)”, which is also available in Autec's website.
A single transmitting unit can be paired endless times with the same receiving unit, whereas each receiving unit can be paired
with up to 15 different transmitting units.

AUTEC - Air Series 4 LIIBKU00E1-02.fm
A8 - Configuration Menu
PAIR 2.0 DIP
PAIR 2.0
PAIR 2.0 DIP
The PAIR 2.0 DIP procedure uses DIP setting in the receiving unit; this aims at defining the beginning and end of the proce-
dure. This way the possibility of pairing the unit with an undesired receiving unit is avoided.
To perform the PAIR 2.0 DIP procedure, do the following:
1. Remove power from the receiving unit and wait until the POWER LED switches off.
2. Open the receiving unit and set DIP switch 2 on the mother board to ON.
3. Close the receiving unit and power it (POWER LED on).
4. Within 2 minutes after powering the receiving unit, perform the following actions with the transmitting unit unpaired and
switched off, and the STOP pushbutton not activated.
5. Remove power from the receiving unit and wait until the POWER LED switches off.
6. Open the receiving unit and set DIP switch 2 on the mother board to OFF.
7. Close the receiving unit.
8. Make sure that the transmitting unit is paired with the desired receiving unit (see page9).
ON
21
Receiving unit
DIP
ON
21
1
2
34
R
G
STOP
S1 S2
1
2
34
R
G
STOP
S1 S2
1
2
34
R
G
STOP
S1 S2
PAIR
1R1R1R
STARTFUNCT.STARTFUNCT.STARTFUNCT.
2
34
G 2
34
G 2
34
G
Keep pushbutton START
pressed until the red LED is
steady on and the green
LED blinks.
Perform the UNPAIR proce-
dure if this signal does not
appear.
Keep pushbuttons FUNCTION,
START and S1 pressed until the
ENABLE LED (receiving unit)
and the green LED (transmitting
unit) illuminate
Keep pushbuttons
FUNCTION, START and
S2 pressed until the green
LED is steady on to save
this setting
Receiving unit powered on. Transmitting unit off STOP pushbutton releasedTransmitting unit unpaired
ON
21

LIIBKU00E1-02.fm 5 AUTEC - Air Series
A8 - Configuration Menu
PAIR 2.0 SERIAL PAIR 2.0
PAIR 2.0 SERIAL
The PAIR 2.0 SERIAL procedure saves in the transmitting unit the “SERIAL N.” of the receiving unit you want to pair. This way
the possibility of pairing the unit with an undesired receiving unit is avoided, without the need to open the receiving unit.
The pairing may occur even when the transmitting unit is placed in enclosed spaces or is out of sight (e.g. the trans-
mitting unit and receiving unit are not in the same working environment or are separated by walls). Therefore, do not
perform this procedure if the receiving unit is out of sight, as it is important to follow the correctness of the paring
step by step.
Pay particular attention when entering the “SERIAL N.”.
If a wrong “SERIAL N.” is entered, the transmitting unit may get paired with an undesired receiving unit if this is in
its working range (even though the pairing in this case has very low probabilities to happen).
To perform the PAIR 2.0 SERIAL procedure, do the following:
1. Note down the “SERIAL N.” corresponding to the receiving unit you want to use for the PAIR procedure (see page 6).
2. Save the number (excluding the first two letters) that forms the "SERIAL N." in the transmitting unit (see page 6).
3. Make sure that the number is correct (see page 7).
4. Pair the transmitting unit with the desired receiving unit (see page 8).
5. Make sure that the transmitting unit is paired with the desired receiving unit (see page9).

AUTEC - Air Series 6 LIIBKU00E1-02.fm
A8 - Configuration Menu
PAIR 2.0 SERIAL
PAIR 2.0
Finding the “SERIAL N.”
The “SERIAL N.” is present on the identification plate (or in the address key) of the receiving unit you want to pair.
Saving the "SERIAL N."
To save the number that forms the “SERIAL N.” in the transmitting unit, perform the following procedure with the transmitting
unit unpaired, switched off and with the STOP pushbutton released.
SERIAL N. XX_ _ _ _ _
Letters Number
C1
C2
C3
C4
C5
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
34
R
G
1
2
34
R
G
STOP
S1 S2
1R
STARTFUNCT.
2
34
G1
2
34
R
G1 2
34
R
G
123
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1,2,3,4
5,6,7,8 9,0
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1,2,3,4
5,6,7,8 9,0
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
34
R
G
1
2
34
R
G
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
34
R
G
45
1,2,3,4
5,6,7,8 9,0
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1,2,3,4
5,6,7,8 9,0
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1,2,3,4
5,6,7,8 9,0
Keep pushbutton START
pressed until the red LED
is steady on and the green
LED blinks.
Perform the UNPAIR pro-
cedure if this signal does
not appear.
Keep pushbuttons
FUNCTION and START
pressed until the green
LED blinks once and then
pauses
Transmitting unit unpaired Transmitting unit off STOP pushbutton released
Keep pushbuttons
FUNCTION, START and
S2 pressed until the green
LEDilluminatestosavethis
setting
Green LED
1 blink
ConfirmC1
by press-
ing push-
button S2
Green LED
2 blinks Green LED 3 blinks
Green LED
4 blinks Green LED
5 blinks
Enter C1
(see note) ConfirmC2
by press-
ing push-
button S2
Enter C2
(see note)
ConfirmC5
by press-
ing push-
button S2
Enter C5
(see note)
With the repeated
pressure of pushbut-
ton S1, you can select
numbers 1, 2, 3 and 4;
this is signalled by the
corresponding LED.
Enter C3
(see note) ConfirmC4
by press-
ing push-
button S2
Enter C4
(see note)
NOTE
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
34
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
5
6
78
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
9
0
With the repeated
pressure of pushbut-
ton FUNCTION you
can select numbers 5,
6, 7 and 8; this is sig-
nalled by the corre-
sponding LED.
With the repeated
pressure of pushbut-
ton START, you can
select numbers 9 and
0; this is signalled by
the corresponding
LED.
ConfirmC3
by press-
ing push-
button S2

LIIBKU00E1-02.fm 7 AUTEC - Air Series
A8 - Configuration Menu
PAIR 2.0 SERIAL PAIR 2.0
Checking the “SERIAL N.” saved in the transmitting unit
Perform the following procedure with the STOP pushbutton not activated to check the number saved in the transmitting unit.
1
2
34
R
G
?
C1
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
S3 S4
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
3
R
G
4
?
C5
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
3
R
G
4
?
C2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
3
R
G
4
?
C3
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
1
2
3
R
G
4
?
C4
Keep pushbuttons START
and S4 pressed until LED 1
illuminates
The green LED indicates
digits related to C1 (see
note).
If the red LED illuminates,
no “SERIAL N.” is saved.
Press S1, and LED 2
illuminates. The green
LED indicates digits
related to C2 (see note).
Transmitting unit off STOP pushbutton released
PressS1,and LED 1and
LED 2 illuminate. The
green LED indicates
digits related to C3 (see
note).
Press S1, and LED 3
illuminates. The green
LED indicates digits
related to C4 (see note).
PressS1,and LED 1and
LED 3 illuminate. The
green LED indicates dig-
its related to C5 (see
note).
If you press S1 once
more, it indicates again
digits related to C1
(LED 1 illuminated).
Transmitting unit with saved “SERIAL N.”
Switch off the transmitting unit
to escape this view.
ESCAPING
Digit “1” : the green LED repeats 1 blink and an off phase.
Digit “2” : the green LED repeats 2 blinks and an off phase.
Digit “3” : the green LED repeats 3 blinks and an off phase.
Digit “4” : the green LED repeats 4 blinks and an off phase.
Digit “5” : the green LED repeats 5 blinks and an off phase.
Digit “6” : the green LED repeats 6 blinks and an off phase.
Digit “7” : the green LED repeats 7 blinks and an off phase.
Digit “8” : the green LED repeats 8 blinks and an off phase.
Digit “9” : the green LED repeats 9 blinks and an off phase.
Digit “0” : the green LED repeats 10 blinks and an off phase.
NOTE

AUTEC - Air Series 8 LIIBKU00E1-02.fm
A8 - Configuration Menu
PAIR 2.0 SERIAL
PAIR 2.0
Pairing the units
Once the “SERIAL N.” has been saved and checked in the transmitting unit, it is possible to complete the pairing procedure
as described hereafter.
1. Remove power from the receiving unit and wait until the POWER LED switches off.
2. Power on the receiving unit (LED POWER on).
3. Within 2 minutes after powering the receiving unit, perform the following actions with the transmitting unit unpaired,
switched off, with “SERIAL N.” saved and the STOP pushbutton not activated.
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
PAIR
1
2
34
R
G1 2
34
R
G1 2
34
R
G
STARTFUNCT.
1
2
34
R
G
STOP
S1 S2
Keep pushbutton START
pressed until the red LED is
steady on and the green LED
blinks.
Perform the UNPAIR proce-
dure and save the “SERIAL
N.”againifthissignaldoes not
appear.
Keeppushbuttons START
and S2 pressed until the
ENABLE LED (receiving
unit) and the green LED
(transmitting unit) illumi-
nate
The POWER LED then
switches on
Keep pushbuttons FUNC-
TION, START and S2
pressed until the green
LEDilluminatestosavethis
setting.
Receiving unit powered on. Transmitting unit with saved “SERIAL N.”Transmitting unit unpaired
Transmitting unit off STOP pushbutton released
Keep the
START push-
button
pressed (see
machine's
confirmation)
When the START pushbutton is pressed, the related output on the receiving unit commutes. The signal
(e.g. visual or acoustic) enabled by this output allows to verify that the transmitting unit is paired with
the desired receiving unit.
if the transmitting unit does not result paired with the desired receiving unit, switch off the transmitting unit without
saving the settings and without saving the correct “SERIAL N.”.
Machine maintenance

LIIBKU00E1-02.fm 9 AUTEC - Air Series
A8 - Configuration Menu
Checking pairing PAIR 2.0
Checking pairing
To make sure that the transmitting unit is paired with the desired receiving unit, start up the radio remote control and check
LED signals in the transmitting unit and the ENABLE LED signal in the receiving unit.
Transmitting unit Receiving unit PAIRING
The green LED blinksslowly. The ENABLE LED is off. WRONG The transmitting unit has been paired with an
undesired receiving unit because a wrong “SERI-
AL N.” has been saved.
This situation is highly dangerous, so immedi-
ately press the STOP pushbuttona.
a. If the transmitting unit is paired with a receiving unit that is not the desired one, do the following:
1 restore the receiving unit that has been paired by mistake: perform the UNPAIR (this procedure deletes the “SERIAL N.” that
has previously been saved); then perform the PAIR procedure with the transmitting unit that was originally paired with this
receiving unit;
2 finally perform the UNPAIR procedure and repeat the PAIR 2.0 procedure with the desired transmitting unit.
The green LED blinks.
The red LED is on. The ENABLE LED is off. FAILED The transmitting unit has not been paired with any
receiving unit. You need to repeat the PAIR 2.0
procedure.
The green LED blinks slowly. The ENABLE LED blinks. SUCCEEDED The transmitting unit has been paired with the
desired receiving unit.

AUTEC SRL - via pomaroli, 65 - 36030 Caldogno - Italy - phone [phone] - fax [phone] - [e-mail] - www.autecsafety.com
