AUTEC DYNAMIC+P Series Instruction manual

LIUPJMV03_eng-00
In󰄋ruction Manual for the use and the maintenance
of the Radio Remote Control
Original in󰘵ructions
Part C: PJM Transmitting Unit with video option
DYNAMIC+P SERIES

LIUPJMV03_eng-00AUTEC
THIS PART OF THE MANUAL CONSISTS OF: Part C - Information, in󰄋ructions and
warnings for the PJM (Model J9P) Transmitting Unit. The Manual consi󰄋s of Part A –
General, Part B – Conformity and Frequencies, Part C – Transmitting Unit, Part D –
Receiving Unit, Part E – Battery and Battery Charger, plus the Technical Data Sheet.
THIS MANUAL, INCLUDING ALL PARTS THEREOF, AND ALL INSTRUCTIONS CONTAINED
HEREIN, MUST BE READ CAREFULLY AND UNDERSTOOD BEFORE INSTALLING, USING,
MAINTAINING OR REPAIRING THE AUTEC RADIO REMOTE CONTROL.
FAILURE TO READ AND COMPLY WITH ALL APPLICABLE WARNINGS AND INSTRUCTIONS
OR ANY ONE OF THE LIMITATIONS NOTED IN THIS MANUAL CAN RESULT IN SERIOUS
BODILY INJURY OR DEATH, AND/OR PROPERTY DAMAGE.
THE AUTEC RADIO REMOTE CONTROL IS NOT A STANDALONE PRODUCT AND IS
INTENDED ONLY AS A COMPONENT ON A MACHINE:
- ON WHICH AND WHERE THE USE OF A RADIO REMOTE CONTROL IS APPROPRIATE,
- THAT CAN BE OPERATED SAFELY AND IN ACCORDANCE WITH ALL APPLICABLE
LAWS, REGULATIONS AND STANDARDS BY SUCH REMOTE CONTROL.
ACCORDINGLY, IT IS THE RESPONSIBILITY OF THE MACHINE MANUFACTURER ON
WHICH THE AUTEC RADIO REMOTE CONTROL IS INTENDED TO BE INSTALLED, to
perform an in-depth and accurate risk assessment to determine if the Autec Radio Remote
Control is suitable for operating a Machine in conditions of safety and operational
effectiveness, taking into account the conditions of use, the intended uses and the
reasonably foreseeable incorrect ones, so that the in󰄋allation, maintenance and use of
the Autec Radio Remote Control, and all its components, are performed only and entirely
in compliance with this Manual and in accordance with all local regulations, safety
󰄋andards and regulations (referred to herein as "Laws, Regulations and Standards").
With reference to the USA market the Laws, Regulations and Standards include all safety
rules and regulations of the Occupational Safety & Health Admini󰄋ration (OSHA) (http://
www.osha.gov), all federal, 󰄋ate and local laws, regulations and building and electrical
codes, and all applicable 󰄋andards, including but not limited to ANSI Standards.

LIUPJMV03_eng-00 AUTEC
It is also the responsibility of the Manufacturer and of the design professionals of the
Machine on which the Autec Radio Remote Control is to be in󰄋alled and used to be certain
that the 󰄋ructure, condition, organization and markings of the Machine as in󰄋alled at
the facility is appropriate for and will allow for the safe and reliable use and control of
the Machine through the Autec Radio Remote Control interface.
IT IS THE RESPONSIBILITY OF THE OWNER AND FACILITY OPERATOR, AND THEIR
DESIGN PROFESSIONALS, that the in󰄋allation, maintenance and operation of the Autec
Radio Remote Control and all of its components are done solely and completely in
accordance with this Manual, and with all applicable Laws, Regulations and Standards,
even local. It is also the responsibility of the Manufacturer of the Machine on which the
Autec Radio Remote Control is to be in󰄋alled and used, and their design professionals,
to be certain that the 󰄋ructure, condition, organization and markings of the Machine as
in󰄋alled at the facility is appropriate for and will allow for the safe and reliable use and
control of the Machine through the Autec Radio Remote Control interface.
ONLY QUALIFIED AND PROPERLY TRAINED PERSONNEL SHOULD BE PERMITTED TO
OPERATE OR USE THE AUTEC RADIO REMOTE CONTROL AND THE MACHINE OPERATED
BY OR THROUGH THE AUTEC RADIO REMOTE CONTROL. ONLY QUALIFIED AND
PROPERLY TRAINED PERSONNEL SHOULD BE PERMITTED TO BE IN THE VICINITY OF
MACHINE OPERATED BY OR THROUGH THE AUTEC RADIO REMOTE CONTROL.
FAILURE TO PROPERLY INSTALL, OPERATE, MAINTAIN AND SERVICE THE AUTEC
RADIO REMOTE CONTROL CAN RESULT IN SERIOUS BODILY INJURY OR DEATH AND/
OR PROPERTY DAMAGE. Refer to this Manual and each of its Parts for further assi󰄋ance
or contact Autec. Autec is not responsible for and shall not be held liable for any in󰄋allation
of the Autec Radio Remote Control not performed by Autec or for any use of the Autec
Radio Remote Control not in complete compliance with, and/or not maintained in complete
compliance with, all Autec in󰄋ructions and warnings and all applicable Laws, Regulations
and Standards, even local.
Autec is not responsible for and shall not be held liable for any alteration or modification
of the Autec Radio Remote Control, or the use of non-Autec components or products
used with or incorporated into the Autec Radio Remote Control.
IT IS THE RESPONSIBILITY OF THE OWNER AND FACILITY OPERATOR, AND THEIR
DESIGN PROFESSIONALS, to be certain that the Autec Radio Remote Control is properly
maintained and serviced at all times in compliance with all Autec in󰄋ructions and
warnings, and with all applicable Laws, Regulations and Standards, even local.

LIUPJMV03_eng-00AUTEC
IT IS THE RESPONSIBILITY OF THE OWNER AND FACILITY OPERATOR, AND THEIR
OFFICERS, MANAGERS AND SUPERVISORS, to be certain that all Users of the Autec
Radio Remote Control and that all Persons who are or will be working with or near the
Machine operated by or through the Autec Radio Remote Control are fully and properly
educated and trained by qualified Personnel in the proper and safe use of the Autec Radio
Remote Control and of the Machine, including without limitation complete familiarity
with and under󰄋anding of Autec warnings and in󰄋ructions, and all applicable Laws,
Regulations and Standards, even local, and that such Users and other Persons do in fact
at all times operate or work with the Autec Radio Remote Control safely and ONLY in
compliance with Autec in󰄋ructions and warnings and with all applicable Laws, Regulations
and Standards, even local. FAILURE TO DO SO CAN RESULT IN SERIOUS BODILY INJURY
OR DEATH AND/OR PROPERTY DAMAGE.
IT IS THE RESPONSIBILITY OF THE OWNER AND FACILITY OPERATOR, AND THEIR
OFFICERS, MANAGERS AND SUPERVISORS, to be certain that the areas in which the
Machine operated by or through the Autec Radio Remote Control is located and operates
are clearly delineated and marked in accordance with all Autec warnings and in󰄋ructions,
and all applicable Laws, Regulations and Standards, even local, and otherwise sufficient
to alert and warn ALL PERSONS that the Machine is operated by or through a Radio
Remote Control, and prohibiting any unauthorized access thereto. FAILURE TO DO SO
CAN RESULT IN SERIOUS BODILY INJURY OR DEATH AND/OR PROPERTY DAMAGE.
FAILURE TO OPERATE THE AUTEC RADIO REMOTE CONTROL SAFELY AND IN
COMPLIANCE WITH AUTEC INSTRUCTIONS AND WARNINGS AND WITH APPLICABLE
LAWS, REGULATIONS AND STANDARDS, EVEN LOCAL, AND/OR PERMITTING USERS
OR OTHER PERSONS NOT PROPERLY TRAINED IN THE SAFE AND PROPER USE OF
THE SYSTEM, OR THE MACHINE ON WHICH IT IS INSTALLED, CAN RESULT IN SERIOUS
BODILY INJURY OR DEATH AND/OR PROPERTY DAMAGE.

LIUPJMV03_eng-00 AUTEC
INDEX
1 Information on the use of in󰄋ructions ..................................................................... 8
1.1 Structure of the In󰘵ruction Manual ...................................................................... 8
1.2 Caption and terminology ................................................................................... 10
1.3 Symbols ........................................................................................................... 11
1.4 To whom the in󰘵ructions are addressed ............................................................ 11
1.5 In󰘵ruction 󰘵orage ............................................................................................ 11
1.6 Intellectual property .......................................................................................... 11
2 Brief product presentation ..................................................................................... 12
2.1 Series, Radio Remote Control and Unit ............................................................. 12
2.2 Conformity with 󰘵andards ................................................................................. 12
2.3 Contacts and useful addresses ......................................................................... 12
2.4 Warranty .......................................................................................................... 12
2.5 Technical assi󰘵ance and spare parts ................................................................ 12
3 Description .............................................................................................................. 13
3.1 Transmitting Unit .............................................................................................. 13
3.2 Data Feedback Function ................................................................................... 14
4 Technical data ......................................................................................................... 16
5 Technical Data Sheet .............................................................................................. 17
6 Plates ....................................................................................................................... 17
7 Light and acou󰄋ic warning signals ........................................................................ 18
7.1 Light signals ..................................................................................................... 18
7.2 Acou󰘵ic signals ................................................................................................ 19
8 General operating in󰄋ructions ............................................................................... 20
8.1 Power keyswitch ............................................................................................... 20
8.2 START pushbutton ........................................................................................... 21
8.3 GSS pushbutton ............................................................................................... 21
8.4 EMS pushbutton ............................................................................................... 22
8.5 Pushbuttons for display/LED ............................................................................. 22
8.6 Command meaning .......................................................................................... 23
8.7 Battery ............................................................................................................. 25
8.8 Starting up the Radio Remote Control ............................................................... 26
8.9 How to take control of the Receiving Unit in a Take & Release Radio Remote
Control ............................................................................................................. 27
8.10 How to release the Receiving Unit in a Take & Release Radio Remote Control ... 27
8.11 Command activation ......................................................................................... 28
8.12 Interruption of the radio link ............................................................................... 28
8.13 Transmitting Unit automatic switch off ............................................................... 28
8.14 Switching off the Transmitting Unit .................................................................... 30
8.15 Cable control .................................................................................................... 30
8.16 BACK-UP UNIT ................................................................................................ 32
9 In󰄋ructions for the User ......................................................................................... 32
9.1 Usage re󰘵rictions ............................................................................................. 33
9.2 User behaviour ................................................................................................. 33
9.3 Belt or harness ................................................................................................. 35
10 Maintenance ............................................................................................................ 39

LIUPJMV03_eng-00AUTEC
11 Malfunction signalled by the Transmitting Unit ..................................................... 40
11.1 Red LED and green LED ................................................................................... 40
11.2 Identifying the activated command .................................................................... 42
12 Decommissioning and disposal ............................................................................. 43

LIUPJMV03_eng-00 AUTEC
8
1 Information on the use of in󰄋ructions
Before reading this part of the Manual, you mu󰘵 read and under󰘵and the general
part (Part A) of the Manual provided with the Radio Remote Control.
1.1 Structure of the In󰄋ruction Manual
The Manual for the use and maintenance of Autec Radio Remote Controls consists of di󰘯erent
parts, that altogether form the Manual; the Manual must be read carefully, understood and
applied by the Radio Remote Control's Owner, User and by all those Persons that, for any
reasons, may operate with the Radio Remote Control or with the Machine where it is installed.
The following table describes the structure of the Instruction Manual for the use and the
maintenance of the Radio Remote Control.
Part Title Contents
AGeneral part
- General information regarding the series,
- directions for risk assessment of the "Machine+Radio Remote
Control" sy󰘵em,
- warnings for in󰘵allation of the Radio Remote Control,
- warnings for use and maintenance of the Radio Remote
Control,
- in󰘵ructions for correct transportation and 󰘵orage of Radio
Remote Control.
BConformity and
frequencies
- Operating frequency bands of the Radio Remote Control,
- conformity and law references of the Radio Remote Control.
CTransmitting Unit
Description and in󰘵ructions concerning the Transmitting Unit,
including:
- description of operation,
- commands,
- light signals,
- malfunctions,
- additional in󰘵ructions to the general part.
DReceiving Unit
Description and in󰘵ructions concerning the Receiving Unit,
including:
- description of operation,
- light signals,
- malfunctions,
- additional in󰘵ructions to the general part.
EBattery and battery
charger
Description, warnings and in󰘵ructions concerning batteries and
battery chargers, including:
- description of operation,
- light signals,
- malfunctions,
- in󰘵ructions for the User.

LIUPJMV03_eng-00AUTEC
9
Usage and maintenance in󰘵ructions are supplemented by the Radio Remote Control's Technical
Data Sheet, that:
- Describes the Transmitting Unit's con󰘰guration
- Indicates the relation between commands sent by the Transmitting Unit and those available on
the Receiving Unit.
Usage and maintenance instruction as a whole are to be considered as an integral part both
of the Autec Radio Remote Control and of the Machine, system, device or Machinery system
where the Radio Remote Control is installed.
The Manufacturer of the Machine on which the Autec Radio Remote Control is in󰘵alled, and
the Owner and User of the Machine, mu󰘵 make sure that the In󰘵ruction Manual and all of its
parts are included in the In󰘵ruction Manual of the Machine.
The CD attached to each In󰘵ruction Manual includes the translations of the Manual.
Act as follows to identify the single Manual parts in the relevant language in the CD:
- Choose the desired language
- Select the single parts of the Manual: refer to the code name provided on the cover of each
part.
XXXXXXXXX_language-XX
XXXXXXXXX_language-XX
Instruction Manual for the use and the
maintenance of the Radio Remote Control
Original instructions
Part X: XXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XX SERIES

LIUPJMV03_eng-00 AUTEC
10
1.2 Caption and terminology
Contact Autec if any of the in󰘵ructions, symbols, warnings or images are not clear
and under󰘵andable, or if you have doubts or que󰘵ions.
In this part of the Manual, the terms li󰘵ed below have the same meaning explained in the
corresponding paragraph of the general part (Part A):
-Unit
-Radio Remote Control
-Transmitting Unit
-Receiving Unit
-Radio link
-Active 󰄋op
-Automatic 󰄋op
-Manual 󰄋op
-Passive 󰄋op
-Machine
-Manufacturer
-In󰄋aller
-User
-Maintenance Technician
-Manual or In󰄋ruction Manual
-In󰄋allation manual
-Person
-Owner
Functions indicated for the Manufacturer, the In󰘵aller, the User and the Maintenance Technician
may be performed by a single Person, if he/she has the needed competence and undertakes
the resulting responsibilities. Each Person mu󰘵 be aware of the in󰘵ructions contained in the
Manual, depending on the activity they carry out.
For example, if a Manufacturer is also the In󰘵aller, and/or Maintenance Technician, he/she
mu󰘵 also know and follow the in󰘵ructions specifically addressed to those Persons. The same
applies, for example, if a User is also the Manufacturer and/or the In󰘵aller.

LIUPJMV03_eng-00AUTEC
11
1.3 Symbols
This symbol identifies the parts of text in the Manual that mu󰘵 be read with special
attention.
This symbol identifies the parts of text in the Manual containing warnings,
information and/or in󰄋ructions that are particularly relevant with regards to
safety; failure in under󰄋anding them may cause hazards for People and/or
property.
1.4 To whom the in󰄋ructions are addressed
Addressees of instructions are listed in the paragraph with the same title in the general part:
please refer to that part.
1.5 In󰄋ruction 󰄋orage
Regulation for the storage of instructions are described in the paragraph with the same title
in the general part: please refer to that part.
1.6 Intellectual property
Restrictions connected to intellectual property are described in the paragraph with the same
title in the general part: please refer to that part.

LIUPJMV03_eng-00 AUTEC
12
2 Brief product presentation
2.1 Series, Radio Remote Control and Unit
The object of this part of the Manual is the PJM (Model J9P) Transmitting Unit of an Autec
Dynamic+P series' Radio Remote Control.
Autec Dynamic+P series' Radio Remote Controls are designed to be used on Machines and
provide a command interface to their command and control sy󰘵em, to be used from an appropriate
di󰘵ance and position.
2.2 Conformity with 󰄋andards
The conformity of Radio Remote Controls with standards and with working requirements and
conditions in the single Countries is provided in the related speci󰘰c part “Conformity and
frequencies” (Part B) of the Manual.
2.3 Contacts and useful addresses
The Radio Remote Controls are produced by Autec Srl – Via Pomaroli, 65 - 36030 Caldogno
(VI) - Italy.
You can find contacts for Autec, its di󰘵ributors, dealers and authorized service centres on the
website www.autecsafety.com.
2.4 Warranty
General warranty conditions are indicated both in the relevant sheet provided together with this
documentation, and in the specific page on the website www.autecsafety.com.
2.5 Technical assi󰄋ance and spare parts
If you need technical services and/or spare parts, please refer to contacts provided in the website
www.autecsafety.com.
When applying for technical service to Autec, its di󰘵ributors, dealers and authorized service
centres, the Radio Remote Control's serial number is required; you can find it on the identification
plate on the Transmitting Unit and/or on the Receiving Unit.

LIUPJMV03_eng-00AUTEC
13
3 Description 3.1 Transmitting Unit
TA1441-01
AUTECSrl
ViaPomaroli, 65 - 36030 Caldogno (VI) - Italy
BATTERY ................................... MBM06MH (7.2V )
............................................................ LPM02 (7.4V )
............................................................ LPM04 (7.4V )
RADIO MODULE ......................................... FSAACI03A
FREQUENCY RANGE ................................ 863-870MHz
RF POWER ............................................... <25mW ERP
FREQUENCY RANGE ................................ 915-928MHz
RF POWER ............................................... <50mW ERP
IC: 9061 A-J8PNJ55 5
FCC ID: OQ A-J8PNJ555
This radio device complies with Part 15 of the FCC
Rules. Operat ion is subject to the followi ng two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may
causeundesiredoperation.
KK
GG
EE
DD
AA
AA
AA
FF
CC
MM
AA
SS
HH
TT
B
AActuators (joy󰘵icks, selectors,
pushbuttons)
BBattery CBattery housing DDisplay and LEDs
EPushbuttons for display/LED
FConnector for cable control (if present)
GRadio Remote Control identification plate
HTransmitting Unit identification plate KPower keyswitch
MGSS or EMS pushbutton
SSTART pushbutton
TTechnical data plate

LIUPJMV03_eng-00 AUTEC
14
3.2 Data Feedback Function
Thanks to the Data Feedback function, the following is available to the User:
- Images 󰘰lmed by cameras, related to the working area or to speci󰘰c Machine movements.
- Information and/or signals concerning some speci󰘰c situations and the movements of the
controlled Machine.
The Data Feedback function operates through the display and the LED array on the Transmitting
Unit.
During normal operation, pay particular attention to the images shown and
to the indications given on the display and/or on the LEDs on the Transmitting
Unit: they can be helpful to evaluate the Machine working 󰄋atus, but they do
not replace nor exhau󰄋 the necessary visual inspections the User needs to
carry out so that the Machine operation and movements are performed in
safety conditions.
Any image shown and any indication signalled on the display and/or through
the LEDs can never be considered or used as a safety signal or for legal
metrology.
When operating the Machine, remember that the Radio Remote Control does
not cut in autonomously when potential hazardous situations are shown and
signalled.
The display does not signal the presence of people, animals or belongings,
even if they appear in the cameras' frame, and does not signal the risk of hitting
people, animals or belongings.
3.2.1 Operation with display
The display on the Transmitting Unit shows the images filmed by the camera/s.
Signal icons, measurements collected from the Machine and their description may be shown
too.
The Machine Manufacturer chooses which information is displayed and the way they are
displayed (images and/or icons and/or measurements and/or descriptions).
In addition, the battery level and the quality of the radio link may also appear.
Images filmed by the cameras are transmitted to the PAU (Power & Acquisition Unit), that in
turn sends them to the Transmitting Unit through the access point.
The instructions and warnings for the cameras, the PAU and the access point are to be found
in the corresponding manuals that come with the single devices.

LIUPJMV03_eng-00AUTEC
15
AB
C
D
METAL G-52SHPacn METAL G-52SHPacn
E
F
GH
ACameras
BPAU
CAccess point
DAntenna
EWi-Fi connection
FTransmitting Unit
GRadio link
HReceiving Unit
Images of the cameras and of the access point provided above are for illu󰘵rative
purposes only.
The Transmitting Unit communicates with the Receiving Unit through a radio link described
in “Part A” of the Instruction Manual.
The Transmitting Unit communicates with the access point through Wi-Fi connection.
The Wi-Fi connection between the access point and the Transmitting Unit,
and the radio link between the Transmitting Unit and the Receiving Unit are
two independent connections. Therefore, only one of the two connections
may be present.
The visualization of images filmed by cameras on the display may interrupt
in any moment without prior notice due to the interruption of the Wi-Fi
connection between the access point and the Transmitting Unit.
The Machine Manufacturer, the In󰄋aller, the Owner, the User and/or the
Maintenance Technician, mu󰄋 make sure that the interruption of the Wi-Fi
connection between the access point and the Transmitting Unit can never
lead to a hazardous situation in the specific working application.

LIUPJMV03_eng-00 AUTEC
16
A delay occurs between the camera filming and the visualization of the filmed
images on the display on the Transmitting Unit. This delay cannot be removed
or reduced.
Depending on the display configuration set by the Machine Manufacturer or
by the In󰄋aller, if the Wi-Fi connection between the access point and the
Transmitting Unit is interrupted, the la󰄋 filmed image before the interruption
may remain displayed.
The Machine Manufacturer, the In󰄋aller, the Owner, the User and/or the
Maintenance Technician, mu󰄋 make sure that the delay between the camera
image filming and the display of the image on the Transmitting Unit display
cannot generate or contribute to generate a hazardous situation in the specific
working application.
3.2.2 Operation with LED
If the Transmitting Unit has an LED array for the Data Feedback function, specific Machine
conditions are signalled if they are illuminated (by way of example: load limits, limit switch).
The signalled conditions depend on the settings chosen by the Machine Manufacturer.
4 Technical data
Power supply batteryLPM04
Antenna integrated
Housing material PA 6 (20%fg)
Protection degree IP65 (NEMA 4)
Dimensions 310x220x220mm (12.2x8.7x8.7in)
Weight 2.5kg (5.5lb)
Run time at 20°C (68°F) 5.5h
Power frequency magnetic field immunity
according to CEI EN 61000-4-8 up to 300A/m

LIUPJMV03_eng-00AUTEC
17
5 Technical Data Sheet
The Radio Remote Control 's Technical Data Sheet:
- Describes the Transmitting Unit's con󰘰guration
- Indicates the relation between commands sent by the Transmitting Unit and those available on
the Receiving Unit.
The Technical Data Sheet mu󰘵 be filled in, checked and signed by the In󰘵aller, who is responsible
for correct wiring.
A Technical Data Sheet mu󰘵 always be kept together with this Manual: if you need to use the
Technical Data Sheet for admini󰘵rative purposes (te󰘵s, check, etc.), make a copy of it.
The wiring of the Receiving Unit's outputs mu󰄋 always reflect the wiring
indicated in the Technical Data Sheet.
6 Plates
Plate Position Content
Radio Remote Control
identification plate Battery housing
Radio Remote Control serial
number (S/N), QR code and
manufacturing year.
Transmitting Unit identification
plate Battery housing
Manufacturing year, a QR code
and the Transmitting Unit
identification number (TU ID)
Technical data plate Battery housing
Model, Type and main
Transmitting Unit technical data,
marking and possible Radio
Remote Control marks

LIUPJMV03_eng-00 AUTEC
18
7 Light and acou󰄋ic warning signals
7.1 Light signals
A
C
B
ARed LED
BGreen LED
CLEDs for Data Feedback function
The Transmitting Unit always has a green LED [B] and a red LED [A] that provide information
regarding the Radio Remote Control.
Symbol Meaning
This symbol identifies the red LED [A]
This symbol identifies the green LED [B]
The meaning of signals provided by the LEDs identified with “C” are explained in
the Data Feedback function part (see paragraph 3.2). The meaning of LEDs related
to the Data Feedback function are decided and e󰘵ablished by the Machine
Manufacturer depending on the Machine's functions for which he wants to receive
information.
Signals provided by the red LED [A] indicate a Radio Remote Control malfunction. The meaning
of such signals and possible actions to perform are described in chapter 11.

LIUPJMV03_eng-00AUTEC
19
The meaning of signals provided by the green LED [B], when the red LED [A] is off, are described
in the following table.
Signals Meaning
The green LED is off. The red LED is off. The Transmitting Unit is off.
The green LED blinks fa󰘵.
The red LED is off.
The Transmitting and Receiving Unit do not
communicate.
The green LED repeats the sequence: a blink and a
pause. The red LED is off.
The Radio Remote Control is 󰘵arted and the Units
communicate via radio link in the 863-870MHz
frequency band.
The green LED repeats the sequence: two blinks
and a pause. The red LED is off.
The Radio Remote Control is 󰘵arted and the Units
communicate via radio link in the 915-928MHz
frequency band.
The green LED repeats the sequence: three blinks
and a pause.
The red LED is off.
The Radio Remote Control is 󰘵arted and the Units
communicate via cable control.
The meaning of the green [B] and red [A] LED signals cannot be modified.
7.2 Acou󰄋ic signals
The Transmitting Unit has an acou󰘵ic signal device that activates when:
- The battery is nearly 󰘱at.
- The Transmitting Unit has been on for twenty-four hours.
- The Transmitting Unit does not work correctly.
- During the Radio Remote Control 󰘵art up, the GSS or the EMS pushbutton is pressed or
damaged.
- During the Radio Remote Control 󰘵art-up, the SAFETY command is activated (see Technical
Data Sheet).
- During the Radio Remote Control 󰘵art-up, one of the commands D2-D20 is activated (see
Technical Data Sheet).
- During the Radio Remote Control 󰘵art-up, one of the commands A1-A8 is activated (see
Technical Data Sheet).
- During the Radio Remote Control 󰘵art-up, one of the commands H1-H8 is activated (see
Technical Data Sheet).
- During the Radio Remote Control 󰘵art-up, one of the commands L1-L8 is activated (see
Technical Data Sheet).
- During the Radio Remote Control 󰘵art-up, the battery is 󰘱at.
The acou󰘵ic signal device activates whenever the red LED [A] illuminates. The meaning of the
red LED [A] lighting up and of the activation of the acou󰘵ic signal and possible actions to perform
are described in chapter 11.
The meaning of the acou󰘵ic signals cannot be modified.

LIUPJMV03_eng-00 AUTEC
20
8 General operating in󰄋ructions
8.1 Power keyswitch
The Transmitting Unit have a power keyswitch. It can either one of the following:
- Mechanical key (see paragraph 8.1.1).
- M-Key (see paragraph 8.1.2).
The Radio Remote Control cannot work if the power keyswitch is not inserted in the Transmitting
Unit.
8.1.1 Mechanical key
The mechanical key makes it possible to power the Transmitting Unit.
Inserting the mechanical key
Do the following to insert the mechanical key:
1. Insert the mechanical key into its receptacle.
2. Turn the mechanical key clockwise.
Removing the mechanical key
Do the following to remove the mechanical key:
1. Turn the mechanical key anticlockwise.
2. Pull the mechanical key to remove it from its receptacle.
8.1.2 M-Key
The M-Key makes it possible power the Transmitting Unit.
Inserting the M-Key
Push the M-Key to the bottom of its housing.
Removing the M-Key
Remove the M-Key from its housing by pulling the lanyard.
