Autel Robotics EVO 2 User manual

Trademark Information
EVO 2™, Autel Explorer™, Starpoint™ and the Autel Robotics® logo are
trademarks of Autel Robotics Co., Ltd., registered in China, the United States and
other countries. All other products and company names mentioned in this User
Manual are registered trademarks of their respective holders.
Copyright Warning
Reproduction or retransmission of any part of this manual in any form or by any
means, whether electronic, mechanical, photocopying, recording, or otherwise, is
forbidden without the express written permission of Autel Robotics.
Disclaimer
Please closely follow the steps in these instructions in order to ensure safe and
successful operation of your EVO 2 aircraft.
Children must remain under adult supervision when using the aircraft. Keep the
aircraft out of the reach of children when it is not in use.
If the customer fails to follow safety instructions, Autel Robotics is not liable for
and provides no warranty coverage for any product damages that occur during
use, be they direct or indirect, legal, special, incidental, or economic (including
but not limited to loss of profits). Do not use unapproved components or attempt
to modify the aircraft in any way inconsistent with the instructions in the official
aircraft documentation.
These safety instructions will show you how to get started safely with your EVO 2.
Only you can ensure that you fly your EVO 2 securely and never jeopardize the
safety of yourself, other people, or their property.
These safety instructions will be updated from time to time. To check whether
you have the latest version, visit www.autelrobotics.com/support/downloads/.
Data Storage and Usage
When the Flight Log Backup option is disabled, as it is by default, no flight or
user data will be uploaded or transmitted via the Autel ExplorerTM app. When
Flight Log Backup is enabled and the app is paired with the aircraft, flight log
data (including flight telemetry) will be uploaded and maintained on Autel
Robotics data servers. All telemetry and flight logs are stored on data servers
located within the boundaries of the continental United States, and the data
upload occurs automatically only if the Flight Log Backup option is enabled.

The Autel Robotics customer support team doesn’t have access to flight log data
except when explicitly granted permission by the user via the Autel ExplorerTM
app. When that permission is granted, only flight logs within the selected date
range can be accessed.
Information, including still and motion imagery and data from the aircraft’s
sensors, will be stored on the aircraft's internal drive. If your aircraft ever needs
to be sent to us for service, the information on the internal storage unit may be
used to diagnose problems with the aircraft. The information will not be retained
except as required to perform the service or repair. Do not remove or alter the
data on the internal storage device in any way. Doing so will invalidate all
warranty coverage.
Autel Robotics’ purpose in gathering data is to provide support and service for
our customers, and to improve the performance of our products. We take your
privacy as seriously as we do our own. We will consent to the disclosure of
uploaded data only when required by law to do so.
Safety Instructions
Battery Safety
The EVO 2 is powered by a lithium-polymer battery. The misuse of Li-Po/Li-Ion
batteries can be hazardous. As such, make sure to strictly follow all the battery
usage, charging and storage instructions below.
WARNING!
• Only use batteries and charging devices that came with the aircraft or
are sold by Autel Robotics for use with the EVO 2. Do not tamper with
the battery pack or its charger.
• Battery electrolytes are highly corrosive. If any electrolyte comes in
contact with your skin or your eyes, immediately flush the affected area
with clean running water and seek medical attention.
Battery Usage
Always turn off the aircraft before installing or removing the battery. Additional
information:
• Only use batteries and charging devices that came with the aircraft or are sold
or authorized by Autel Robotics for use with the EVO 2. Using unapproved
batteries or charging devices may result in fire, explosion, leakage, or other
hazards. Autel Robotics will not be liable for any consequences resulting from
the use of third-party batteries or charging devices.
• Do not disassemble, open, crush, bend, deform, puncture, shred, or otherwise
intentionally cause damage to the battery. Doing so may result in fire,

explosion, leakage, or other hazards.
• If the battery starts to swell, smoke, leak, or show any signs of damage, stop
using or charging it immediately and submerge it in a container of salt water.
• Do not expose the battery to temperatures below -10°C (14°F) or above 40°C
(104°F). Exposing the battery to extreme temperatures will reduce its lifespan
and may result in fire, explosion, or other permanent damage.
• Temperatures below 5°C (41°F) will cause the battery to discharge faster.
• Do not use the battery in strong electrostatic or electromagnetic environments.
• Do not expose the battery to fire, explosions, or other hazards.
• If the aircraft becomes submerged, remove the battery immediately after you
retrieve it. Leave the battery in an open area, away from flammable objects,
and maintain a safe distance until it is completely dry. Don’t use the battery
again. Contact our customer support team for a replacement.
Battery Charging
It should take a maximum of 90 minutes to fully charge the aircraft battery,
though charging times will vary according to the remaining power level.
Additional information:
• Do not use a damaged battery charger.
• When the charger is not in use, disconnect it from the aircraft battery and the
power source.
• Wait until the battery has cooled down to room temperature before charging it.
If you connect the battery to the charger immediately after flight, overheat
protection will prevent charging.
Battery Storage
In storage as in flight, it’s important not to allow the battery to come in close
contact with moisture or heat sources. Store the battery in a dry and well
ventilated area at room temperature —ideally 22°C to 28°C (72°F to 82°F).
Additional information:
• Keep the battery out of reach of children and pets.
• Do not store the battery in direct sunlight or near sharp items, moisture, metal,
or reactive chemicals.
• Storing the battery at extreme temperatures will reduce its lifespan. If the
battery is left unused for over 7 days, store it at a temperature below 30°C
(86°F). Otherwise, battery damage or failure may result.
• Over time, some reduction in battery life is expected.

Battery Disposal
• Completely discharge the battery before disposal.
• Dispose of the battery properly at an approved battery recycling location.
Flying the Aircraft Safely & Securely
Flight Environment
• Comply with all local regulations on flying drones. Only fly within designated
drone flying areas, and set compliant distance and height limits using the
Autel ExplorerTM app.
• Do not fly in hazardous situations or severe weather conditions, such as
tornadoes, rain, hail, or snow.
• Do not fly the aircraft near facilities that could produce electromagnetic
interference, such as power plants, transmission lines, substations, and
broadcasting towers.
• Fly in an open and safe area. Avoid obstacles that can interfere with the GPS
signal, such as buildings and trees.
• Exercise caution when flying in environments over 6000 meters (18,000 feet)
above sea level, as the aircraft's battery and power system performance may
be affected.
Before Flying
Before flying the aircraft, always ensure that:
• The remote control, the battery, and the mobile device used with the Autel
ExplorerTM app are fully charged.
• The propellers are correctly installed and not damaged.
• The aircraft's front and back arms are fully unfolded.
• The aircraft's motor, gimbal, and camera work properly when the aircraft is
powered on.
• All warnings and error messages displayed on the app have been addressed.
Only use accessories that came with the aircraft or are sold or authorized by
Autel Robotics for use with the aircraft. Using unapproved accessories presents
serious risks to safety and will void the product’s warranty.
While Flying
• During takeoff and landing, keep the aircraft away from people, vehicles, and
other moving objects.
• Keep the aircraft in your visual line of sight at all times.

• Do not fly the aircraft close to water surfaces.
• When the low battery warning appears, do not cancel the automatic go-home
process. Otherwise, the aircraft may not have enough battery power to return
to the home point.
• In high or low temperatures or windy environments, the aircraft will consume
power faster.
• If a warning appears on the Autel ExplorerTM app, follow the corresponding
instructions immediately.
• Do not fly the aircraft if you are dizzy, fatigued, under the influence of alcohol
or drugs, or experiencing any other condition that may impair your ability to
safely operate the aircraft.
WARNING
If any part of the aircraft or the remote control fails to function correctly or
has visible damage, do not fly the aircraft. Contact our support team at
www.autelrobotics.com/contact-us/.
Storage & Maintenance
Carefully check every part of the aircraft after any crash or collision. Keep the
aircraft and its accessories stored out of the reach of children and pets.
• Store the aircraft and its accessories in a cool, dry place.
• Keep the aircraft away from moisture and heat sources.
• The recommended storage temperature for the aircraft is 22°C to 28°C (72°F to
82°F).
The Autel Robotics support team stands ready to help via chat, phone or email at
www.autelrobotics.com/contact-us/.
