Autel Robotics EVO Max 4T Instruction Manual


󵥟󴧃󲰈󱨴󱛔󵥌󳥸󳊷
󹥦󴧃󲰈󱨴󳲊󱚝󳥸󱵀
󲰈󱨴󳲊󱚝
󻧌󼻌󻝈󾘥󼋤󼖠󾘥󼔭󻅵󾘥󼝜󼰄
Directives pour une utilisation sécurisée de la pile
Richtlinien zur Akkusicherheit
Linee guida sul funzionamento sicuro della batteria
Directrices de uso seguro de la batería
Zasady bezpiecznej eksploatacji akumulatorów
Правила безопасной эксплуатации батареи
Рекомендації щодо безпечної експлуатації
батареї
Diretrizes de utilização da bateria em segurança
4T

• Only use the battery and charger provided by Autel Robotics. It
is forbidden to modify the battery pack and its charger, or use
third-party equipment to replace it.
• The electrolyte in the battery is extremely corrosive. If the
electrolyte accidentally spills onto your skin or into your eyes,
please wash the affected area with clean water and seek medical
advice as soon as possible.
EVO Max 4T Series is powered by a lithium-ion polymer battery.
Improper use of these batteries can be dangerous. Please ensure
that all the following battery usage, charging and storage guidelines
are strictly followed.
When installing or removing the aircraft battery, be sure to turn off
the aircraft's power. Other considerations are as follows:
EN
Battery Safety
Battery Usage
Warning:
• Only use batteries and charging devices sold or authorized by
Autel Robotics for the EVO Max 4T. Using unapproved batteries
or charging devices may cause fire, explosion, leakage or other
hazards. Autel Robotics is not responsible for any consequences
caused by the use of third-party batteries or charging devices.
• Do not disassemble, scratch, squeeze, bend, puncture, cut or
otherwise intentionally damage the battery, otherwise it may
cause fire, explosion, leakage or other hazards.
• If the battery begins to bulge, smoke, leak or show any other
signs of damage, stop using it immediately and immerse it in a
container filled with salt water.
• Do not expose the battery to temperatures below -10°C (14°F)

• Do not use a damaged battery charger.
• When the charger is not in use, it should be disconnected from
the aircraft battery and power supply.
• Wait for the battery to cool to room temperature before charging.
If the battery is connected to the charger immediately after a
flight, the over-temperature protection feature may be activated
automatically, preventing the battery from charging until it has
cooled completely.
Battery Charging
Battery Storage
It takes up to 90 minutes to fully charge the aircraft battery, but the
charging time is related to the remaining power.
Other notes are as follows:
Avoid placing the battery near water or heat sources while in storage.
Batteries should be stored at room temperature (ideally 22°C to 28°C
(72°F to 82°F)) in a dry, well-ventilated area.
Additional information:
or above 40°C (104°F). If the battery is exposed to extreme
temperatures, its service life will be shortened. Extreme
temperatures may also cause fire, explosion or other permanent
damage.
• Exposure to temperatures below 5°C (41°F) will speed up battery
discharge.
• Do not use the battery in an environment with strong static
electricity or electromagnetic exposure.
• Do not expose the battery to open flame, explosives, or other
hazards.
• If the aircraft falls into water, remove the battery immediately
after recovering it. Put the battery in an open place and keep a
safe distance from it until it is completely dry. After that, please
stop using the battery. Contact the customer service center to
replace it.

Battery disposal
Aircraft Batteries
• Batteries should be stored out of the reach of children and pets.
• Do not store the battery in direct sunlight, near sharp objects,
water, metals, or reactive chemicals.
• Storing the battery in extreme temperatures will shorten its life.
If the battery is not used for more than 1 day, it should be stored
at temperatures between -10°C (14°F) and 30°C (86°F). Failure to
do so may result in battery damage or failure.
• If left idle for an extended period of time, the life of the battery
will be shortened.
• Be sure to completely discharge the battery before throwing it
away.
• Send the battery to the designated recycling point for proper
disposal.
The aircraft's lithium polymer battery needs to be charged with the
special charger provided.
Turn on the battery
Before installing the battery, make sure it is powered off. After
installation, press and hold the power button for 3 seconds. The
battery level indicator will show the current level.
Turn off the battery
Press and hold the power button for 3 seconds to turn off the
battery. If batteries are installed in the craft, LED 1 and LED 4 will
flash 5 times to indicate that the power is being turned off. Once all
battery level indicators are off, remove the batteries from the craft.

Disassembly button
Battery level indicator
Power button

Battery level indicator status (non-charging state)
0%~12%
51%~62%
13%~25%
63%~75%
26%~37%
76%~87%
38%~50%
88%~100%
- Green light is always on - Green light flashing - Close
Self Heating
The battery has self-heating function for low temperature
environments:
Check the battery level
With the battery off, press the power button for 1 second, then
quickly release it to check the battery level. The LED will show the
current battery level as follows:
• When the temperature is below 10°C (50  , the battery will
start self-heating automatically after the aircraft is powered on.
The self-heating function will automatically turn off after the
aircraft takes off. When the battery temperature is below -10°C
(14 ), the aircraft will not take off. Please try to take off after
self-heating.
• If the battery is not inserted into the aircraft, click the battery
power button and then press and hold for 3 seconds to activate
the self-heating function. The battery temperature will remain
between 15°C and 20°C (59 to 68 ) and the battery will keep
in this temperature for 30 minutes. During the heating process,
you can press and hold the power button for 3 seconds to exit
the self-heating function.
• When the battery is in the self-heating state, the power indicator
will flash as shown in the picture.

LED1 LED2 LED3 LED4 Warning Notes
When LED 1 and LED 3 flash
alternately with LED 2 and LED 4, it
indicates the battery is self-heating.
The four LED indicators flash
simultaneously, that indicates the battery
is keeping the temperature between 15
to 20(59to 68).
-Indicator light blinking -Close
Additional Features
The following features protect and extend battery life.
• Storage self-discharge protection：If the battery is stored in a
hot environment or not used for 6 days and the charge level is
high, the self-discharge protection will be activated. The battery
will automatically discharge to a safe level. This is the default
setting, and the discharge process takes 2-3 days. Although the
battery does not indicate during the self-discharge cycle, you
may notice a slight warming of the battery, which is normal.
• Low power protection：If the battery is low, it will automatically
enter sleep mode to prevent over-discharge. In this mode, the
battery will not respond when the power button is pressed. To
wake up the battery, connect it to the charger.
• Charging temperature detection：If the temperature is below
5(41 ) or above 45 (113 ) when charging, the battery
will stop charging.
• Overcurrent protection：When the charging current is too high,
the battery will stop charging.
• Overcharge protection：Charging will stop automatically when
the battery is fully charged.
• Balance protection：The voltage of each battery cell is balanced

LED indicator warning description
LED1 LED2 LED3 LED4 Warning Notes
Charging temperature is too high
or too low.
The charging current is too high and
has caused a short circuit.
Overcurrent, overload or short circuit
problems occurred during discharge.
-Indicator light blinking -Close
to prevent overcharging or over-discharging.
• Over-discharge protection：When the battery is not in use, it
will automatically disconnect the power output function after the
self-discharge cycle is completed. This function is disabled during
flight.
• Short circuit protection：If a short circuit is detected, the power
will be cut off.
• Power saving mode：If there is no operation for 30 minutes, the
battery will turn off.
• Communication：When in use, the aircraft is continuously
synchronized with the battery to provide real-time information,
including voltage, capacity, current, temperature, etc.
• Ultra-low energy mode：To conserve power, this mode will
be activated if the battery is idle for 6 days with a voltage lower
than 11.6V. The battery will resume normal function after being
connected to the charger.

Specification
Capacity 8070mAh
Nominal voltage 14.88V
Charging limit voltage 17.0V
Battery Type Li-Po 4S
Energy 120Wh
Charging ambient temperature 5~45℃
Maximum charging power 247W

• 󳏳󹰛󱛔󵥌󸶛󸴁󳽾󶾨󲰨󳹂󳫁󱜁󵯔󵥟󴧃󱼑󱧹󵥟󽗉󶂵󴟼󳵫󸴓󵥟󴧃󶮐󱷷󱩎󱧹
󵥟󽗉󽙓󳟾󱛔󵥌󶐎󱒵󳹂󸗜󲙘󲳳󱩎󸱞󷼇󴁡󳨇󽙓󲳳󱕨󱛔󵥌󹨾󸶛󸴁󳽾󶾨󲰨󳹂󳫁
󱜁󵯔󱧹󵥟󸗜󲙘󸱞󷼇󱧹󵥟󳡇󸴓󳟸󵯔󱒪󱬫󱹖󴅞  󸶛󸴁󳽾󶾨󲴉󱒹󱕡󸟧󸟫
•
󵥟󴧃󱓩󵯔󵥟󸈐󴮵󾈸󴁸󴄴󳌁󵯔󷁊󷯷󳒋󷏕󵥟󸈐󴮵󱒹󳚆󴴟󱨮󵳮󵴟󳟾󵰘󶻮󽙓
󸘕󶍐󱵫󵥌󴱔󴦃󱪠󴫓󳕓󲙓󳅽󱷷󳺲󲵊󱴕
  󹂞󵥌󹙹󶹛󱹎󵒜󵥟󴧃󱜁󵥟󹙹󶹛󱹎󵒜󵥟󴧃󵯔󱛔󵥌󱒹󳌯󱸯󶾨󸴓󳟸
󱵨󹡄󸘕󱓞󴉓󸷸󲰆󱗵󱒷󳡇󴁸󵥟󴧃󱛔󵥌󱧹󵥟󱷷󲮨󱣕󳥸󳊷
󲰈󷿙󳟾󳤘󱵳󹲯󷼇󽗉󵥟󴧃󳺲󽙓󸘕󱰘󳏳󱩊󹞫󹲯󷼇󽗉󵥟󴴰󱩎󱗞󴪒󳘍󱕥󹰙󲜾󱒷󾙏
