Automation Dr. Nix QNix 9500 Series User manual

QNix® 9500
QUALITY „MADE IN GERMANY“
OPERATION
MANUAL
Guía rápida
Mode d‘emploi
Istruzioni
Instrukcja obsługiHandleiding

2 3
9500
3 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Contents
English .........................................................................................................................................
4
Guía rápida Español ....................................................................................................................
39
Mode d'emploi abrégé Français .................................................................................................
41
Brevi istruzioni Italiano ...............................................................................................................
43
Korte handleiding Nederlands ....................................................................................................
45
Skrócona instrukcja obsługi Polski .............................................................................................
47
49

4 5
Table of Contents
9500
4 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Table of Contents
1
General Information ................................................................................................................ 7
1.1
Intended Use ........................................................................................................................ 7
1.2
Scope of Delivery .................................................................................................................. 7
1.3
Safety Notes .......................................................................................................................... 7
1.4
Transport and Storage .......................................................................................................... 8
1.5
Cleaning and Care ................................................................................................................. 8
1.6
Disposal ................................................................................................................................. 8
2
Device Overview ...................................................................................................................... 9
2.1
Menu Overview .................................................................................................................. 10
2.1.1
"Jobs" Menu .................................................................................................................... 11
2.1.2
"Limits" Menu ................................................................................................................. 12
2.1.3
"Calibration" Menu ......................................................................................................... 13
2.1.4
"Settings" Menu .............................................................................................................. 14
3
Initial Operation .................................................................................................................... 15
3.1
Insert Battery ...................................................................................................................... 15
3.2
Insert Probe (Optional) ....................................................................................................... 15
3.3
Check Basic Settings ............................................................................................................ 16
3.4
Software Backup ................................................................................................................. 17
4
Operation and Controls ......................................................................................................... 17
4.1
About Operation ................................................................................................................. 17
4.2
Calibration .......................................................................................................................... 17
4.3
Measurement Display ......................................................................................................... 20
4.3.1
Focus Frame .................................................................................................................... 22
4.4
Measure and Save .............................................................................................................. 23
4.5
Analysing Measurements ................................................................................................... 23
4.6
Adding Jobs ......................................................................................................................... 24
Table of Contents
9500
5 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
4.7
Editing Areas ...................................................................................................................... 25
4.7.1
Configuring areas ............................................................................................................ 25
4.7.2 Add area during measurement ....................................................................................... 25
4.7.3
Enable / Disable Area ..................................................................................................... 26
4.7.4
Delete Area or Measurements ....................................................................................... 26
4.8
Configure Limits ................................................................................................................. 27
4.8.1
Edit Limits ....................................................................................................................... 28
5
System Settings ...................................................................................................................... 28
5.1
Select Language .................................................................................................................. 28
5.2
Configure Display Options .................................................................................................. 28
5.3
Set Buzzer ........................................................................................................................... 29
5.4
Configure Power Save Option ............................................................................................ 29
5.5
Change Unit ........................................................................................................................ 29
5.6
Set PIN ................................................................................................................................ 29
5.7
Set Date/Time .................................................................................................................... 30
5.8
Configure Softkey ............................................................................................................... 30
5.9
Format Memory ................................................................................................................. 30
6
Device Management via PC in QN9 ........................................................................................ 31
6.1
Install App .......................................................................................................................... 32
6.2 Manage Jobs....................................................................................................................... 33
6.2.1
Create Template ............................................................................................................. 33
6.2.2
3-Click Report ................................................................................................................. 34
7
Troubleshooting ..................................................................................................................... 35
8
Service and Repair ................................................................................................................. 35
9
Appendix ............................................................................................................................... 36
9.1
Gauge Technical Data ......................................................................................................... 36
9.1.1
Gauge Mechanical Data .................................................................................................. 36
9.1.2
Gauge Electrical Data...................................................................................................... 36

6 7
1 General Information
9500
7 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
1 General Information
These operating instructions describe the gauges QNix® 9500B (Basic) QNix® 9500P (Premium) and
QNix® 9500P+ (Premium+).
Carefully read the information before use.
Keep the instructions with the device.
1.1 Intended Use
This device, depending on the connected probe, is used to measure the thickness of coatings over
metallic surfaces. For surfaces made from steel or iron (FE probe) the coating thickness can be de-
termined for both non-conductive coatings (e.g. paint, enamel) as well as conductive, non-magnetic
coatings (e.g. chrome, copper, zinc). On non-magnetic, metallic surfaces (e.g. aluminium, copper,
brass), an NFe probe or a duplex probe can be used to determine the thickness of each non-
conductive coating.
Any other use is considered improper use. The user is liable for any damages resulting from improp-
er use.
1.2 Scope of Delivery
> QNix® 9500
> 2 reference plates Fe / NFe with test films
> Software QN9 (loaded on the device)
> 2 batteries (type mignon/AA)
> 1 battery (type CR-1220)
> Operation manual
> Case
> Certificate
For QNix® 9500 with cable:
> Probe and cable (optional)
> Probe holder (optional)
1.3 Safety Notes
Observe the safety notes, as failure to do so may result in dangers to persons or the environment or
device damage.
CAUTION Device modification
Do not open or modify the device.
Repairs must be performed by the manufacturer or authorised speciality retailer.
1 General Information
9500
7 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
1 General Information
These operating instructions describe the gauges QNix® 9500B (Basic) QNix® 9500P (Premium) and
QNix® 9500P+ (Premium+).
Carefully read the information before use.
Keep the instructions with the device.
1.1 Intended Use
This device, depending on the connected probe, is used to measure the thickness of coatings over
metallic surfaces. For surfaces made from steel or iron (FE probe) the coating thickness can be de-
termined for both non-conductive coatings (e.g. paint, enamel) as well as conductive, non-magnetic
coatings (e.g. chrome, copper, zinc). On non-magnetic, metallic surfaces (e.g. aluminium, copper,
brass), an NFe probe or a duplex probe can be used to determine the thickness of each non-
conductive coating.
Any other use is considered improper use. The user is liable for any damages resulting from improp-
er use.
1.2 Scope of Delivery
> QNix® 9500
> 2 reference plates Fe / NFe with test films
> Software QN9 (loaded on the device)
> 2 batteries (type mignon/AA)
> 1 battery (type CR-1220)
> Operation manual
> Case
> Certificate
For QNix® 9500 with cable:
> Probe and cable (optional)
> Probe holder (optional)
1.3 Safety Notes
Observe the safety notes, as failure to do so may result in dangers to persons or the environment or
device damage.
CAUTION
Device modification
Do not open or modify the device.
Repairs must be performed by the manufacturer or authorised speciality retailer.
A detailed instrucon manual can be downloaded from our homepage:
hps://www.q-nix.com/en/download/bda/
Table of Contents
9500
6 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
9.2
Probe Technical Data .......................................................................................................... 36
9.2.1
Probe mechanical data.................................................................................................... 36
9.2.2 Probe Electrical Data ....................................................................................................... 37
9.3
Measuring Data .................................................................................................................. 37

8 9
1 General Information
9500
8 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
CAUTION Electromagnetic compatibility
Electromagnetic influences in the surrounding area may interfere with the device resulting in false
readings. Only use probe cables and USB cables under 3 m in length to connect the device.
Do not operate the device with an external USB power supply.
NOTICE Handling batteries
Remove the battery if the device will not be used for extended periods to prevent battery leakage.
Dispose of the used batteries in compliance with local regulations.
NOTICE
Operating the Gauge
Protect the device from dust and dirt.
Protect the device from moisture, chemicals and aggressive gases.
Avoid direct sunlight or extreme temperature fluctuations.
1.4 Transport and Storage
Always transport the gauge inside the case to ensure it is properly protected. If the device will not
be used for extended periods, remove the batteries and store the device inside the case.
1.5 Cleaning and Care
Clean the device with a damp, lint-free cloth. If very dirty, you may clean with acetone (Attention!
Do not use on soft rubber parts), cellulose thinner or ethanol.
1.6 Disposal
Dispose of used batteries and the device in compliance with local regulations. Do not dispose of
batteries or the device in the household waste.
2 Device Overview
9500
9 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2 Device Overview
Key functions
Status LED Indicates USB connection
Power button / Menu/
Homebutton
Switch device on or off, or switch between menu and
measurement display
Q button Context-based or programmable function
programmable functions
QNix® 9500B:
Start calibration
QNix® 9500P, 9500P+: Start calibration or advance
area
Navigation
buttons
Navigation within the screen / menu
OK button Confirm entry

10 11
2 Device Overview
9500
10 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2.1 Menu Overview
Use the buttons to navigate within the four main menus (Jobs, Limits, Calibration and Set-
tings).
Navigating within the menus:
Symbol / button Explanation
Previous / next menu;
when entering values: previous / next decimal place
Previous / next menu item;
when entering values: Value up / down (hold button for fast scan)
Confirm value / go to submenu / confirm selection
Previous;
context-based Q button
On / Off
Home; return to measurement display
context-based button Power / Menu / Home
Context and model-based symbols in the menus:
Symbol
Explanation
Job (only if several jobs exist)
Job contains the enabled area
Defined area
Enabled area
Menu item has a submenu
Menu item contains an entry or selection list
Checkbox, multiple items can be selected
Radio button, only one item can be selected
The background colours of the symbols correspond with the colours in the main menu.
2 Device Overview
9500
11 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2.1.1 "Jobs" Menu
Illustration 1: Jobs Menu Structure

12 13
2 Device Overview
9500
12 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2.1.2 "Limits" Menu
Illustration 2: Limits menu structure
2 Device Overview
9500
13 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2.1.3 "Calibration" Menu
Illustration 3: Calibration menu structure
Model 9500P+ has calibration methods based on relevant standards preallocated. Use menu item
"Custom" or the software QN9 to customise the calibration.

14 15
2 Device Overview
9500
14 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
2.1.4 "Settings" Menu
Illustration 4: Settings menu structure
3 Initial Operation
9500
15 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
3 Initial Operation
3.1 Insert Battery
This device includes:
> Type mignon/AA (LR6 / FR 6 / AM3); quantity 2
> Type button cell CR-1220 (backup battery for system clock); quantity 1
The battery compartment is located at the back of the device.
> To unlock the cover, turn the ring anti-clockwise
> Lift off cover
> Insert or replace battery
> Attach the battery cover at the bottom and lock
NOTICE
Replacing batteries
Please note the correct polarity when inserting the battery.
When replacing the backup battery (CR-1220), leave the regular battery in the device or connect
the device via USB port or the date and clock will be reset.
Dispose of batteries in compliance with local regulations!
3.2 Insert Probe (Optional)
On devices with replaceable or separate probe (grey probe latch), insert the probe as follows:

16 17
3 Initial Operation
9500
16 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Remove the probe holder or probe cable from the probe input
> To unlock, turn the probe input anti-clockwise. The arrow on the probe holder shows the open
padlock on the probe input.
> Pull the probe holder from the input.
Insert the probe in the probe holder
> Push the probe into the probe holder using a slight turn/push movement. The arrow on the
probe and on the probe holder must align.
- When aligned correctly, all 6 lugs will lock into the respective groove on the probe.
> Reinsert the probe holder or plug the probe into the cable and screw in place.
> To lock the probe input in place, turn clockwise until it locks. The arrow on the probe holder
points at the locked padlock on the probe input
Connect the probe to the probe cable
> Screw the probes together with the cable.
> For better probe guidance, insert the probe into the probe holder of the gauge.
The gauge is now ready for use.
To remove a probe, follow the above steps in reverse order.
3.3 Check Basic Settings
Check and, if necessary, change the factory settings of your device. At a minimum, check the settings
for
> the language
> the unit
> the date and time
> the configuration of the button and
> the power save options
These settings can be found in the "System" menu.
The settings pertaining to the measurement job can be found in the menu "Jobs", "Limits" and "Cali-
bration".
4 Operation and Controls
9500
17 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
3.4 Software Backup
The "QN9" is loaded on the device. This software is used to later manage the device and the record-
ed measurements on the PC. Back this software up to your PC.
NOTICE
Formatting will erase all data
Formatting the memory will also erase the software from the device.
You can download the software from www.q-nix.com/download.
4 Operation and Controls
4.1 About Operation
Please note the following instructions to ensure conclusive results:
> Hold the device by the probe holder
> Carefully place the device or the probe perpendicular on the surface
> Ensure the probe makes good contact with the surface and avoid the probe shaking
> Do not drag the probe across the coated surface
If the device does not register a measurement or no button is pushed within the amount of time set
under menu "System" > "Power save options", the display will first dim, then the device will switch
off.
To reduce unstable measurements, you can set a delay from when the probe is applied and meas-
urement starts. For the settings, go to menu "Settings" > "Probe" > "Measure"
4.2 Calibration
The gauge will need to be calibrated before first using it, after replacing the battery, for different
measurement jobs, or as necessary. Either use our reference plates or, ideally, a piece of uncoated
material being tested.
NOTICE
Push softkey to start calibration
On delivery, the button is programmed to the function "Start calibration". You can start the
calibration directly from the measurement display. The calibration will then be executed with the
preset parameters.
NOTICE Incorrect calibration
Calibrating with the incorrect reference plate can reduce accuracy.
NOTICE
Using reference plates
The included test films are not certified. Certified films are available from the address in chapter
Service and Repair [page. 35].

18 19
4 Operation and Controls
9500
18 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
NOTICE Measurement results
During calibration use the uncoated original substrate for the most accurate measurements.
NOTICE
Error of measurement
Rough surfaces or dirt can cause errors of measurement.
Calibration methods
Zeroing For zero point calibration, simply place the probe on the uncoated original
substrate. This calibration is ideal for smooth surfaces.
1-point For 1-point calibration, select a suitable reference film close to the expectancy
range and a smooth, uncoated original substrate.
2-point For 2-point calibration, select two reference films of different thicknesses
which also include the expectancy range and a smooth, uncoated original
substrate.
Custom
Here you can customise your calibration method.
Setting calibration parameters
In the "Calibration" menu you can set the following parameters prior to calibration:
> Open the "Calibration" menu
> Under "Settings", select the calibration based on the job or the limit set
> If necessary, adjust the parameters
4 Operation and Controls
9500
19 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Available options Unit
QNix
®
9500B
QNix
®
9500P
QNix
®
9500P+
Settings Zeroing X X X
1-point
X
X
X
2-point X X X
Custom
-
X
X
ISO 19840 zero/offset - - X
ISO 19840 2-point - - X
SSPC PA2 zero/offset - - X
SSPC PA2 2-point - - X
Averaging on/off (Flexible, 3,
5, 10)
X X X
Roughness on/off
(roughness adjustable)
X X X
Calibration
memory
Save and retrieve calibration
results
- X X
Show Fe Shows the calibration
results.
- X X
Show NFe - X X
Factory calibration Resets calibration to the
factory settings
X X X
> Use the button to start the calibration. If the button is reconfigured on the 9500P or
9500P+,
> Select "Start" and press the button to start the calibration.
> Place the gauge on a suitable substrate or reference plates and perform the necessary number of
measurements.
> If necessary, save the results to the calibration memory.
CAUTION
Factory calibration
After confirming the selection, the current calibration settings will be erased and the factory set-
tings restored.
If necessary, recalibrate the device.

20 21
4 Operation and Controls
9500
20 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
4.3 Measurement Display
The measurement display contains the areas
Illustration 5: Measurement Display
Depending on the context, the measurement display will contain the following information:
Section Symbols Description
Device status bar Areas are enabled
Measurements are saved to the enabled area.
Conformance display indicating conformance / non-
conformance with the selected limits; always pertains to
the measurements in an area
Calibration done
Battery level 100 % / 50 % / 25 % / empty
Note! When the batteries are below 50 %, a warning
screen will appear. Press "OK" to confirm the screen and
replace the batteries promptly.
12:40
Clock
Job / Area nnnnn/nnnnn Selected job and enabled area
Measurement range
n
Number of spots used in the enabled area
Number of measurements used for averaging, if over 5
values the display will show a number.
filled boxes correspond to the number of measurements
recorded
µm / mil
Unit for the coating thickness
4 Operation and Controls
9500
21 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Section Symbols Description
Current measurement (within the limits)
Not all measurements for averaging have been recorded
Measurement outside the limits
n-1:
n-2:
Last and next to last measurement
NFe / Fe Probe type
Analysis area Note: The analysis area is split into three areas: Graphics,
statistics and conformance. This describes the area statis-
tics value. For more information, please see chapter
"Analysing Measurements [S. 23]".
Average
x-max Highest measurement
x-min
Lowest measurement
σ Standard deviation
Probe status bar Probe connected
Menu button assign-
ment
Switch to menu (On/Off button)
Switch directly to measurement
Q button assignment Manually advance area
(with Q button assigned accordingly; QNix®9500P and
QNix®9500P+ only)
All areas disabled
Start calibration
(with Q button assigned accordingly)
In menu: one level up
When selecting a limit set: Open settings

22 23
4 Operation and Controls
9500
22 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
4.3.1 Focus Frame
You can already navigate through measurements whilst the test is running to analyse these or erase
individual values. To do so, open the focus frame with the and buttons and navigate to the
desired area.
Use the and buttons to navigate between "Job/Area", "Measurement area" and "Analysis
area".
The focus frame will highlight the selected area.
Navigation job/area bar
Use the and buttons to swap the active area.
Navigating the measurement area
With the measurement area selected, use the and buttons to browse recorded measurements
and if necessary press the button (paper bin) to erase these.
Navigating the analysis area
Use the and buttons in the analysis area to view three types of statistics.
NOTICE View limits
This display varies based on the selected limit sets. The example shows a view with "simple limits"
and averaging selected.
Default Overview of minimum / maximum measurement, average and standard deviation
Navigate left Shows the measurements in a bar diagram;
Displays the selected limits, minimum / maximum measurement and current
measurement
Navigate right Number of spots saved in the area;
limit condition met or exceeded
4 Operation and Controls
9500
23 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
To exit the focus frame, press the button.
4.4 Measure and Save
NOTICE
Check device
Check the device with the zero plates before every job and calibrate if necessary.
Zero with the uncoated original substrate for optimal measurements.
> Select job (9500P+ only)
> Enable start area (9500P and 9500P+); typically area 0001
NOTICE! Measurements are always saved to the enabled area.
> If necessary, calibrate or select a saved calibration
> Apply the probe and take a measurement
NOTICE! If measurements are already stored under the job / area, a warning will appear.
Overwrite the measurements or select a different job.
> Analyse the data on the PC in QN9.
4.5 Analysing Measurements
You can already navigate through measurements whilst the test is running to analyse these and if
necessary erase individual values, or erase the measurements in an area or an entire series of meas-
urements If limits are set, an icon indicating if the measurements are within / above the limits will
appear in the status bar and the measurement area:
Erase individual measurement:
> Use the and buttons to set the focus frame to the measurement area
> Use the and buttons to select the measurement
>
Use the button (paper bin) to erase the measurement

24 25
4 Operation and Controls
9500
24 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Erase all measurements in an area:
> Open the "Jobs" menu.
- The current job is highlighted.
> Press to confirm
- The current job will open, with the current area selected.
> Select the desired area and press to confirm.
> Select "Erase measurements" and press to confirm.
- A confirmation message will appear.
> Use the and buttons to confirm (☑) or cancel (☒) and press to confirm.
NOTICE! A confirmation will not appear, the measurements in the selected area have been
erased.
> If necessary, enable the selected area and repeat the measurement.
4.6 Adding Jobs
Depending on the mode, measurements are stored in jobs and areas:
Memory
9500B
9500P
9500P+
Number of jobs 1 1 100
Number of areas per job
1
100
100
Number of spots per area, max. 10 000 10 000 10 000
Max. memory number of spots
10 000
1 000 000
2 000 000
Both the QNix® 9500B and 9500P only offer one job.
The following description only applies to model QNix® 9500P+:
> Open the "Jobs" menu
If there is more than one job, the job the enabled area is under will be highlighted.
You can now
> press "Add job" to add a new job
- This adds a new job with an area. The settings of the currently enabled area will be applied.
> or select a job and "Save as new job"
- The selected job will be copied. The settings for the areas will be applied.
NOTICE
Job templates
If you have created templates for jobs in the QN9 software and uploaded these to the hand-held
unit, you will be able to use the function "Create job from template". You can select the respective
template. The defined names for job and areas will remain stored.
4 Operation and Controls
9500
25 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
4.7 Editing Areas
4.7.1 Configuring areas
With models QNix® 9500P and 9500P+ you can configure several areas for one job (see chart in
previous chapter). You can assign a different limit set for each area.
> Select the "Jobs" menu
> Select job and press open to confirm
The existing areas will be displayed
> Select "New area" and press to confirm
The new area has been added. The limits for the enabled area will be applied
To configure a different limit set for the new area:
> Select "Enable area" and press to confirm
This will enable the area
> Use the navigation buttons and to got to the "Limits" menu
> Select the limits set and if necessary adjust
(also see chapter "Configure Limits [S. 27]")
> Return to the "Jobs" menu
4.7.2 Add area during measurement
There are two options for adding an area during a measurement:
> Via autorange
> With the button
Adding via autorange:
If the "Autorange" field is enabled in a limit set, a new area will automatically be added when the set
number of spots has been reached.
The icon in the Status bar indicates whether autorange is enabled:
Also see chapter "Configure Limits [S. 27]".
Adding via the button
If the has been programmed to "Advance area", you can add or advance to areas during a
measurement.
The menu bar will show the icon:
Also see chapter "Configure Softkey [S. 30]".

26 27
4 Operation and Controls
9500
26 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Enabled area
The number of the enabled area will appear in the "Jobs / Area" bar in the measurement display.
When adding an area, the number will automatically increase.
4.7.3 Enable / Disable Area
You can enable or disable an area:
> Open the "Jobs" menu
> Select the desired job and press to confirm
> Select the desired area and press to confirm
> Enable or disable area
CAUTION Enable / Disable Area
You can disable all areas, however when doing so the measurements will not be saved!
You can only enable one area at a time.
The job containing the enabled area will be selected.
NOTICE! If all areas are disabled, the "Job / Area" bar in the measurement display will be blank.
4.7.4 Delete Area or Measurements
> Open the "Jobs" menu
The current job will be selected
> Press to confirm
The current job will open with the current area selected
> Select the desired area and press to confirm
Erase all measurements in an area:
> Select "Erase measurements" and press to confirm
A confirmation message will appear
> Use the and buttons to confirm (☑) or cancel (☒), then press "OK" to confirm
NOTICE! A confirmation will not appear, the measurements in the selected area have been
erased.
> If necessary, enable the selected area and repeat the measurement
Erase entire area:
> Select "Delete area" and press to confirm
A confirmation message will appear
> Use the and buttons to confirm (☑) or cancel (☒), then press to confirm
NOTICE! A confirmation will not appear, if the selected area has been deleted. The numbering
will not change.
4 Operation and Controls
9500
27 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
4.8 Configure Limits
You can change the limit parameters in the "Limits" menu. You can configure a different limit set for
each area.
NOTICE
Edit limits
You can only change the limit set and the limits if there currently are no measurements. The func-
tion is disabled if any measurement has been carried out.
You can configure the limit set and the parameters if no area is active, presumed there are no
measurements.
> Open the "Limits" menu
> Select the desired limit set and press to enable
> Press the button to open the limit set
> Adjust all limits and press to apply
> Close the limit set with or press the button to go directly to the measurement display
Available options
Unit
Limits QNix® 9500B QNix® 9500P QNix® 9500P+
No limits X X X
Simple limits
X
X
X
Custom - X X
ISO 19840 - - X
IMO PSPC - - X
SSPC PA (Level 1-5)
-
-
X

28 29
5 System Settings
9500
28 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
The probe has a colour indicator to show when the set limits have been exceeded.
> Green: measurement within the limits
> Red: below minimum coating thickness limits
> Yellow: over maximum coating thickness limit
> Blue: measurement outside the measuring range; also see chapter "Troubleshooting [S. 35]"
4.8.1 Edit Limits
Press the button to open the menu to edit limit sets. Some limits are protected with a padlock
icon and cannot be changed. Limit sets which can be edited can be enabled or disabled with and
then edited.
Depending on the limit set selected you can select and deselect different limits as well as set param-
eters.
5 System Settings
You can configure the device in the "Settings" menu.
5.1 Select Language
Use menu item "Language" to configure the language for the entire device.
> Open the "Settings" menu and press to confirm "System"
> Press to confirm "Language"
> Select the language and press to confirm
NOTICE Language options
If the language options only show German and English, first save your measurements with the QN9
software, then reset the device and memory to the factory settings.
5.2 Configure Display Options
You can choose from the following display options.
Rotation Brightness
Resolution
Day/night mode
> Open the "Settings" menu and press to confirm "System"
> Press to confirm "Display"
> Select the desired display option
> Configure the settings and press to confirm
5 System Settings
9500
29 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
NOTICE
The preset rotation does not change the function of the buttons (0°, 90°, 180° and 270°). Rotation
only pertains to the measurement display, the menu and status bar do not rotate.
5.3 Set Buzzer
You can change the volume and the touch sound.
> Open the "Settings" menu, select "System" and press to confirm
> Press to confirm "Buzzer"
> Select "Volume" and press to confirm
- Adjust the volume in the submenu and press to confirm
> Press to enable or disable the "Touch sound"
5.4 Configure Power Save Option
To extend the life of the batteries you can configure when the backlight will dim and the device
shuts off. If no button is pressed or measurement taken during the set time, first the backlight will
dim. Then the device will shut off completely.
> Open the "Settings" menu, select "System" and press to confirm
> Press to confirm "Power save options"
> Select "Display" or "Off" and press to confirm
> Set the desired time in seconds with the or buttons
> Press to confirm your entry
5.5 Change Unit
You can select the unit measurements are displayed in.
> Open the "Settings" menu, select "System" and press to confirm
> Press to confirm "Unit"
> Select "µm" or "mil" and press to confirm
NOTICE
Changing units
When changing the unit, all values (including previous measurements) will be converted and dis-
played accordingly.

30 31
5 System Settings
9500
30 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
5.6 Set PIN
You can add a 4-digit PIN to lock certain device functions.
> Open the "Settings" menu, select "System" and press to confirm
> Press to confirm "PIN"
> Enter the 4-digit PIN with the and buttons
> Press to apply the PIN
NOTICE Impacts of using a PIN
Entering and confirming the PIN will lock ALL configured measurements options. You can still con-
figure the system settings. You will also still be able to add or edit jobs.
The PIN can be reset in the QN9 software or by entering it again.
5.7 Set Date/Time
The format for the date and time is YYYY-MM-DD-hh-mm.
> Open the "Settings" menu, select "System" and press to confirm
> Press to confirm "Date/Time"
> Set the date/time with the and buttons and press to confirm
5.8 Configure Softkey
The softkey can be programmed to two functions, "Calibrate" and "Advance area".
> Open the "Settings" menu, select "System" and press to confirm
> Select "Configure softkey" and press to confirm
> Select the desired setting and press to confirm
5.9 Format Memory
CAUTION
Format Memory
The "Format memory" function will erase all jobs, areas, measurements, all user settings, all lan-
guages except German/English, and the QN9 software on the device.
> Open the "Settings" menu, select "System" and press to confirm
> Select "Format memory"
A confirmation message will appear. If you actually want to reformat the memory, confirm the
message.
If an error occurs, repeat the formatting process. If you are still unable to format the memory,
please contact your retailer.
6 Device Management via PC in QN9
9500
31 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
6 Device Management via PC in QN9
You can use the QN9 software to manage your devices on a PC. Among other things, you will be able
to,
> rename jobs
> generate test reports
> perform live measurements
> configure device settings on the PC and copy to one or multiple hand-held units
> request help and support via remote maintenance
and much more. For more information, please see the help section in the QN9 software.
Index Software menu Function
1, 11 Jobs Create job template
Manage jobs
Edit job
Create job
Specifications
Manage measurement memory
2, 14 Life measurement View
Settings
3 Create 3-click report

32 33
6 Device Management via PC in QN9
9500
32 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Index Software menu Function
4, 5 Help/support Instructions
Information
Help/support
Teamviewer session / remote maintenance
6
Connect to gauge
Shows connection status
7 File sync Synchronises the current files on the gauge
8 USB Indicates if connected via USB
9 Program settings File paths
Connection status
Language
Reports
Unit
Help/support
Exit
10 Reports Create
Templates
12 Device settings Probe
System
Limit settings
Status
Calibration certificate
13 Calibration Settings
15
Home
Return to start screen
6.1 Install App
You can download the app from our website at www.q-nix.com/downloads or directly from the
hand-held unit when using the device for the first time. Proceed as follows:
> Connect the gauge to the computer via USB cable
> Select and execute the file "Start_QN9"
> Start software
NOTICE
Detect device
The software automatically detects your device.
6 Device Management via PC in QN9
9500
33 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
6.2 Manage Jobs
You can easily prepare jobs on the PC and then transfer them to the hand-held unit. The software
allows you to replace the number with any alphanumeric name. You can further configure multiple
devices the same for more efficient measurements. The jobs, areas, limit sets, etc., work the same in
the QN9 software as on the actual device.
You can use the software to import measurement series from the device, save these, and generate
test reports. In addition to the standard templates, you can also customise these or create new
templates.
6.2.1 Create Template
You can use the software to create job templates with actual names and transfer these to the de-
vice. If you then create a new job from a template on the device, the actual names will also be ap-
plied.
You can name both jobs and areas.
> From the home screen, click on the quick menu "Jobs"
> Select an existing template to edit or click the "NEW TEMPLATE" button to create a new template
Illustration 6: Use the "NEW AREA" button to add areas.
> Under "SETTINGS", configure the limits for the area
Here you can also decide whether to apply the settings for all areas under the job or only the se-
lected area.
> Click "APPLY" to save the settings
> Click the "FILE SYNC" button to transfer the templates to one or more devices

34 35
6 Device Management via PC in QN9
9500
34 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
6.2.2 3-Click Report
After exporting the measurement data from the hand-held unit, you can generate a report with just
3 clicks.
> On the home screen, click the quick menu "Create"
Illustration 7: Select the job you want to export.
> Select the desired template from "REPORT TEMPLATES"
> Select "CREATE AND SAVE"
The report will be saved to the defined directory.
To add or edit project-specific data, e.g. job number, select "CREATE AND EDIT".
7 Troubleshooting
9500
35 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
7 Troubleshooting
If the device is not responding as expected, please check the following items:
Error
Possible Cause
Action
Device doesn’t switch on Batteries drained Replace the batteries or connect
the device to a USB connection.
Calibration with reference plates
produces implausible
results
Incorrect reference plate
selected
Select the reference plate
Fe/NFe based on your probe.
Device or probe defective Please contact your authorised
service location.
Sensor ring lights up blue Measuring range exceeded
Sensor ring briefly lights up blue
during probe change
(no error)
No error Probe is connected correctly.
8 Service and Repair
The equipment must be repaired by a manufacturer authorised technician.
If you have any questions, please contact your local retailer or our Support:
www.q-nix.com/support
Automation Dr. Nix GmbH & Co KG
Robert-Perthel-Strasse 2
50739 Cologne
Germany
Tel.: [phone]
Fax.: [phone]
[email protected]

36 37
9 Appendix
9500
36 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
9 Appendix
9.1 Gauge Technical Data
9.1.1 Gauge Mechanical Data
Mechanical Data
Display IPS-LCD, 2.4", colour, 600 lm,
viewing angle 70° in all directions
Dimensions (L x W x H) Approx. 160 mm x 68 mm x 38 mm
Weight (without batteries) Approx. 270 g
Robustness / ambient conditions
IP rating IP65
Operating temperature -20 °C to +70 °C
Storage temperature -20 °C to +70 °C
9.1.2 Gauge Electrical Data
Electrical data
Protection rating III
Device power supply
2 x batteries 1.5 V (type AA) or via USB
Battery life without operation at min. 50% battery capacity > 1 year
Battery life at one measurement per second Approx. 60 000
System clock power supply
1 x CR1220
System clock battery life
> 2 years
9.2 Probe Technical Data
9.2.1 Probe mechanical data
Mechanical Data
Upper housing material Stainless steel (1.4305)
Bottom housing material Trogamid® (CX7323)
Test prod material
polished ruby (Al203)
Dimensions (length / diameter) 35.5 mm / 14.5 mm
Weight 11.9 g
9 Appendix
9500
37 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Robustness / ambient conditions
IP rating IP65 (closed)
Operating temperature -20 °C to +70 °C
Storage temperature
-20 °C to +70 °C
Max. surface temperature in continuous measurement mode 80 °C
Max. surface temperature at 1s test time ever 20s 100° C
9.2.2 Probe Electrical Data
The probes may only be used with the gauges QNix® 9500 and QNix®5500.
9.3 Measuring Data
Measuring Data
Fe
NFe
Principle of Measurement Magnetic field principal,
Magnetic field change,
Hall effect
Magnetic field principal,
Eddy current
As per standard (varies by model) DIN EN ISO 2808,
DIN EN ISO 2178
DIN EN ISO 2808,
DIN EN ISO 2360
DIN 50981, DIN 50984, BS 5411 (3 & 11), BS 3900-C5,
ASTM B 499, ASTM D 1400, ASTM D 1186, ASTM D 7091
Status indication
By RGB-LED at the probe
Limits indication By RGB-LED at the probe
Probe type See probe data sheet
Measuring range
Varies by probe type
Measuring interval >= 100 measurements /min
Units µm / mil
Display resolution
0.01 µm
Measurement uncertainty*
(based on factory standards)
± (1 µm + 2 %) up to 2 mm
± 3 % from 2 mm
± (2 µm + 2 %) up to 2 mm
± 3 % from 2 mm
Minimum measuring area (Ø) 14.5 mm 14.5 mm
* Accuracy may deviate outside a range of -5 °C to 65 °C, but not more than the factor 2 of the
measurement uncertainty.

38 39
9 Appendix
9500
38 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
Measuring Data Fe NFe
Minimum curvature radius, convex
(accuracy tested up to 250 µm)
Zeroing and
Calibration at 250 µm
(on original substrate)
4 mm 30 mm
Zeroing
(on original substrate)
6 mm 50 mm
Minimum thickness of the
base material
(accuracy tested up to 250 µm)
Zeroing and
Calibration at 250 µm
(on original substrate)
25 µm 20 µm
Zeroing
(on original substrate)
100 µm 50 µm
Guía rápida / 1 Avisos generales
9500
39 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
1 Avisos generales
1.1 Uso adecuado
Según su variante, este dispositivo se emplea para medir el espesor del recubrimiento de una super-
ficie metálica. En el caso de superficies de acero o hierro (sondas FE) el espesor puede determinarse
a partir de revestimientos no conductores (por ejemplo, laca o esmalte), así como de revestimientos
conductores pero no magnéticos (por ejemplo, cromo, cobre, zinc). En el caso de superficies me-
tálicas no magnéticas (por ejemplo, aluminio, cobre o latón) puede determinarse el grosor de los
recubrimientos no conductores utilizando una sonda NFe o una dual.
Cualquier uso distinto al indicado se considera inadecuado. El usuario será el responsable de los
daños resultantes.
1.2 Indicaciones de seguridad
Tenga en cuenta las indicaciones de seguridad, ya que su incumplimiento supondría un riesgo para
las personas y el medio ambiente, así como posibles daños en el dispositivo.
PRECAUCIÓN Intervención en el dispositivo
No abra el dispositivo ni realice modificaciones en el mismo.
Las reparaciones únicamente podrán ser realizadas por el fabricante o por un distribuidor autoriza-
do.
PRECAUCIÓN Compatibilidad electromagnética
Las influencias electromagnéticas en el entorno pueden estropear el dispositivo y ofrecer resulta-
dos de medición erróneos. Para conectar el dispositivo, tanto para el cable de sonda como para la
conexión USB, utilice únicamente un cable de menos de 3 m de longitud.
No utilice el dispositivo con una fuente de alimentación USB externa.
AVISO Tratamiento de las pilas
Retire las pilas si no va a utilizar el dispositivo durante mucho tiempo, de esta forma evitará su
sulfatación.
Deseche las pilas gastadas de acuerdo con la normativa aplicable.
AVISO Manejo
Proteja el dispositivo frente a la suciedad y el polvo.
Proteja el dispositivo frente a la humedad, los productos químicos y los gases agresivos.
Evite la acción directa del sol y los cambios bruscos de temperatura.
Guía rápida / 1 Avisos generales
9500
39 / 48
QNix 9500 EN_ES_FR_IT_NL_PL
1 Avisos generales
1.1 Uso adecuado
Según su variante, este dispositivo se emplea para medir el espesor del recubrimiento de una super-
ficie metálica. En el caso de superficies de acero o hierro (sondas FE) el espesor puede determinarse
a partir de revestimientos no conductores (por ejemplo, laca o esmalte), así como de revestimientos
conductores pero no magnéticos (por ejemplo, cromo, cobre, zinc). En el caso de superficies me-
tálicas no magnéticas (por ejemplo, aluminio, cobre o latón) puede determinarse el grosor de los
recubrimientos no conductores utilizando una sonda NFe o una dual.
Cualquier uso distinto al indicado se considera inadecuado. El usuario será el responsable de los
daños resultantes.
1.2 Indicaciones de seguridad
Tenga en cuenta las indicaciones de seguridad, ya que su incumplimiento supondría un riesgo para
las personas y el medio ambiente, así como posibles daños en el dispositivo.
PRECAUCIÓN
Intervención en el dispositivo
No abra el dispositivo ni realice modificaciones en el mismo.
Las reparaciones únicamente podrán ser realizadas por el fabricante o por un distribuidor autoriza-
do.
PRECAUCIÓN
Compatibilidad electromagnética
Las influencias electromagnéticas en el entorno pueden estropear el dispositivo y ofrecer resulta-
dos de medición erróneos. Para conectar el dispositivo, tanto para el cable de sonda como para la
conexión USB, utilice únicamente un cable de menos de 3 m de longitud.
No utilice el dispositivo con una fuente de alimentación USB externa.
AVISO
Tratamiento de las pilas
Retire las pilas si no va a utilizar el dispositivo durante mucho tiempo, de esta forma evitará su
sulfatación.
Deseche las pilas gastadas de acuerdo con la normativa aplicable.
AVISO
Manejo
Proteja el dispositivo frente a la suciedad y el polvo.
Proteja el dispositivo frente a la humedad, los productos químicos y los gases agresivos.
Evite la acción directa del sol y los cambios bruscos de temperatura.
Un detallado manual de instrucciones puede ser descargado de nuestra página web:
hps://www.q-nix.com/en/download/bda/
