1 PRODUCT DESCRIPTION
The Orion 2 electromagnetic owmeter is a device that enables measurement of the quantity of liquid passing through it.
Using a principle of electromagnetic measurement (there are no moving mechanical parts inside it), the owmeter outputs a signal to the computer
proportional to the liquid ow that goes through it; Orion 2displays the owrate calculated according to the data received from the owmeter and the
value of the owmeter constant previously set.
1.1 Intended use
This device is designed to work on agricultural machinery for crop spraying applications.
The machine is designed and built in compliance with EN ISO 14982 standard (Electromagnetic compatibility - Forestry and
farming machines), harmonized with 2004/108/EC Directive.
The owmeter must not be used to measure the passage of hydrocarbons, ammable, explosive or toxic liquids. The owmeter is
not suitable for contact with liquids for human consumption. Use for sales transactions is not allowed.
2 INSTALLATION
Install the owmeter at least 20 cm from the elements that could cause turbulence inside the tubes (valves, bends, constrictions, etc.).
The owmeter can be installed in a horizontal or vertical position.
CAUTION:
For proper sealing of the owmeter, use ARAG assembly kit ONLY (Ref. ARAG General catalogue - Accessories for series 463/473
modular valves).
ARAG is not liable for damage to the system, persons, animals or things caused by the use of material other than specied.
CONTINUES
Fig. 1

4
2.1 Dimensions (mm)
H
DN
X
X
A
CODE DN A H L X ange
46211AG0000 4 96 90 114 41
463
863
46211A00000 5 96 90 114 41
46211A10000 7 96 90 114 41
46211A20000 10 96 90 114 41
46211A30000 14 96 90 114 41
46211A40000 18,5 96 90 114 41
46221A40000 18,5 96 90 114 45
473
873
46221A50000 28 96 90 114 45
46221A60000 28 96 90 114 45
46221A70000 28 96 90 114 45
Fi g . 2
Tab. 1

5
Dimensions (mm)
DN
A
L
F
H
CODE DN F A H L
46211AG1313 4 G 3/4 96 90 185
46211AG3333 4 G 3/4 96 90 184
46211A01313 5 G 3/4 96 90 185
46211A03333 5 G 3/4 96 90 184
46211A11313 7 G 3/4 96 90 185
46211A13333 7 G 3/4 96 90 184
46211A21313 10 G 3/4 96 90 185
46211A23333 10 G 3/4 96 90 184
46211A31414 14 G 1 96 90 185
46211A33434 14 G 1 96 90 184
46211A41414 18,5 G 1 96 90 185
46211A43434 18,5 G 1 96 90 184
46211A41515 18,5 G 1 1/4 96 90 189
46221A51515 28 G 1 1/4 96 90 191
46221A51616 28 G 1 1/2 96 90 199
46221A61616 28 G 1 1/2 96 90 199
46221A61717 28 G 2 96 90 234
46221A71717 28 G 2 96 90 234
Fi g . 3
Tab. 2

6
Dimensions (mm)
DN
H
L
T
A
T
CODE DN T A H L
46211A3A5B5 14 T5 96 90 192
46211A4A5B5 18,5 T5 96 90 192
Fig. 4
Tab. 3

7
2.2 Assembly
To ensure trouble-free operation, comply with the indicated installation layout (Fig. 5a and Fig. 5b).
The connector must NEVER be positioned upwards.
OK
OK
- Comply with the correct uid inlet-outlet direction, as indicated by the arrow printed on the owmeter body (Fig. 6).
INOUT IN OUT
Use inlet and outlet pipes of the same diameter as the internal passages of the owmeter; for any reference, see tables 7a-7b-7c
(Chap. 5 - Technical data).
HORIZONTAL ASSEMBLY
VERTICAL ASSEMBLY
Fig. 5a
Fig. 5b
Fig. 6

8
2.3 Electric connections
The Orion 2owmeter has been designed to be connected to ARAG devices (computers, screens, displays) but can also be connected to equipment
made by other manufacturers as long as they are designed for owmeters of this typology.
ARAG is not liable for damage to the system, persons, animals or things caused by incorrect or inadequate installation of the
owmeter. In the event of damage to the owmeter, caused by incorrect or unsuitable assembly, any form of guarantee is auto-
matically rendered null and void.
Color Position Connection
Black 1GND
Red 2+12 VDC
Green 3Signal
(square wave)
2.4 Hydraulic connections
For connection to the system, use appropriate ttings (Ref. ARAG General catalogue).
Avoid bends and constrictions before connections and on tubes.
Regarding connections, use tubes and ttings properly sized for the operating pressure of the system.
The tightening of hose tails should be made with special metal clamps ensuring perfect sealing even at high pressures.
The connection by means of threaded ttings should be done taking operating pressure into account.
CAUTION: For the implementation on already operating systems it is necessary to follow all safety rules described herein.
System assembly and start-up must be carried out by expert personnel according to the safety rules so as to ensure the same
safety level of the system the owmeter is going to be installed in.
Tab. 4

9
2.5 Hydraulic connections for control units
The Orion 2 owmeters to be integrated in the control units are available with both anged 863/873 (in previous 463/473 series) and T5 fork coupling
connectors.
If you need to integrate the owmeter in an existing tie rod control unit previously congured without a owmeter, remember to order new tie-rods
in order to reconstruct the unit correctly after the owmeter has been incorporated (Ref. ARAG general catalog, control unit section, assembly kit).
ONLY use ARAG tie-rods. If other tie-rods are used, the warranty is automatically void.
Flowmeters with fork coupling do not need other accessories and can be directly inserted in the existing control unit provided it already comes with
T5 fork coupling.
CAUTION: BEFORE INCORPORATING THE FLOWMETER TO AN EXISTING CONTROL UNIT, MAKE SURE THAT THE OPERATING
PRESSURE IS SUITED FOR THAT SPECIFIC CONTROL UNIT.
FLOWMETERS WITH T5 FORK COUPLING CAN WITHSTAND A MAXIMUM PRESSURE OF 20 BAR.
ARAG is not liable for damages to the equipment, persons, animals or objects caused by failure to observe the above instructions.
Remember to correctly position seals and O-Rings in the coupling seats.
Note: usually, in standard control units, the owmeter is inserted between the control valve and the section valves unit (Fig. 8a-8b).
This does not prevent the assembly of the owmeter in any other part of the control unit, however, keep in mind that if the owmeter is positioned in
different points the values may differ depending on the connected components.
Filtering the liquid is recommended.
In order to obtain a correct reading, contact a dealer or installer that can give you advice on how to correctly position the
owmeter inside the control unit.
FLANGED CONNECTOR FORK COUPLING
Incorporating anged connector
Incorporating fork coupling
Fig. 8a
Fig. 8b

10
3 PRELIMINARY SETUP FOR USE
Set owmeter constant (B, Fig. 9): on the computer connected to Orion 2owmeter: refer to the label on the body (A, Fig. 9) and tables 7a-7b-7c -
Chap. 5 "Technical data".
Rubiera (RE)
MADE
IN
ITALY
H195099
s/n :
10 ÷ 200 lit/min 300 pls/lit
2.6 ÷ 53 GPM l 1135 pls/GAL
20 bar 290 psi 40 bar 580 psi
QC PASSED 12VDC 300mA
}
A
40 bar 580
B
1135 pls/GAL
For further information regarding how to set the constant, consult the use and maintenance manual of the computer being used.
4 USE
When using the system, the owmeter sends impulses to the computer, which, according to the constant value previously set, indicates the instant ow.
A LED in the connector slot indicates the status of the device (Fig. 10):
Orion 2 owmeter can only detect conductive uids with a conductivity equal to 50 μS/cm (Rif. Tab. 5.2 - Chap. 5).
- Do not aim pressurised water onto the equipment.
- Respect the device’s rated power requirement (12 Vdc).
- If arc welding is required, ensure that owmeter power is off and disconnect the power cables, if necessary.
- Use the owmeter only within the ow limits given in the “Technical data” table. Outside these limits, the owmeter could give incorrect
data and therefore lead the operator or the automatic system to make errors.
ARAG cannot be held responsible for damage caused to persons, animals or things by incorrect or unsuitable use of the owmeter or its parts.
Fig. 9
Fig. 10
LED OFF:
the device is not powered.
LED ON NOT FLASHING with low light intensity:
the device is powered but it does not detect liquid passage.
LED ON FLASHING with high light intensity:
the device is powered and it detects liquid passage.
La frequenza dell'intermittenza è proporzionale alla portata.

11
5 MAINTENANCE
- After every spraying operation, ush the pipe with clean water.
- In case of malfunction, and at any rate at the end of every season, clean the owmeter pipe with a special detergent.
- Do not use metal or abrasive objects for cleaning the duct.
- Do not use solvents or petrol for cleaning the external parts of the device.
5.1 Troubleshooting
FAULT CAUSE REMEDY
The owmeter does not read any value No power supply • Check the owmeter wiring.
The value read by the owmeter is not
linear or stable
Presence of turbulence or air in the
circuit • Check the circuit.
5.2 Technical data
Description Orion 2
Power supply 10 ÷ 16 Vdc
Max. absorption 300 mA
Min. liquid conductivity 50 μS/cm
Working temperature 0 °C ÷ 60 °C
32 °F ÷ 140 °F
Storage temperature -30 °C ÷ 80 °C
-22 °F ÷ 176 °F
Material Nylon / Brass / Polypropylene /
Stainless Steel Inox
Dimensions (mm) 184 ÷ 234 (depending on the model) x 103 x 132
Weight 906 ÷ 1670 g (depending on the model)
Tab. 5
Tab. 6
CONTINUES

12
Technical data
Flowrate Operating
pressure
Pressure drop at
maximum owrate
Internal
passages
(Ø mm)
Pulses
For valves
CODE l/min. US GPM P max
(BAR)
P max
(PSI)
P max
(BAR)
P max
(PSI) pls/l pls/ US GAL
46211AG0000 0,3 ÷ 6 0,08 ÷ 1,6 40 580 0,3 4 4 6000 22710
863
463
series
46211A00000 0,5 ÷ 10 0,13 ÷ 2,6 40 580 0,3 4 5 6000 22710
46211A10000 1 ÷ 20 0,3 ÷ 5 40 580 0,3 4 7 3000 11355
46211A20000 2,5 ÷ 50 0,6 ÷ 13 40 580 0,5 7 10 1200 4542
46211A30000 5 ÷ 100 1,3 ÷ 26 40 580 0,5 7 14 600 2271
46211A40000 10 ÷ 200 2,6 ÷ 53 40 580 0,5 7 18,5 300 113 5
46221A40000 10 ÷ 200 2,6 ÷ 53 20 290 0,5 7 18,5 300 113 5
873
473
series
46221A50000 20 ÷ 400 5 ÷ 106 20 290 0,2 3 28 150 568
46221A60000 30 ÷ 600 8 ÷ 158 20 290 0,5 7 28 100 378
46221A70000 40 ÷ 800 11 ÷ 211 20 290 0,5 7 28 75 284
Flowrate Operating
pressure
Pressure drop at
maximum owrate
Thread
(BSP)
Internal
passages
(Ø mm)
Pulses
CODE l/min. US GPM P max
(BAR)
P max
(PSI)
P max
(BAR)
P max
(PSI) pls/l pls/ US GAL
46211AG1313 0,3 ÷ 6 0,08 ÷ 1,6 20 290 0,3 4 G 3/4 4 6000 22710
46211AG3333 0,3 ÷ 6 0,08 ÷ 1,6 40 580 0,3 4 G 3/4 4 6000 22710
46211A01313 0,5 ÷ 10 0,13 ÷ 2,6 20 290 0,3 4 G 3/4 5 6000 22710
46211A03333 0,5 ÷ 10 0,13 ÷ 2,6 40 580 0,3 4 G 3/4 5 6000 22710
46211A11313 1 ÷ 20 0,3 ÷ 5 20 290 0,3 4 G 3/4 7 3000 11355
46211A13333 1 ÷ 20 0,3 ÷ 5 40 580 0,3 4 G 3/4 7 3000 11355
46211A21313 2,5 ÷ 50 0,6 ÷ 13 20 290 0,5 7 G 3/4 10 1200 4542
46211A23333 2,5 ÷ 50 0,6 ÷ 13 40 580 0,5 7 G 3/4 10 1200 4542
46211A31414 5 ÷ 100 1,3 ÷ 26 20 290 0,5 7G 1 14 600 2271
46211A33434 5 ÷ 100 1,3 ÷ 26 40 580 0,5 7G 1 14 600 2271
46211A41414 10 ÷ 200 2,6 ÷ 53 20 290 0,5 7G 1 18,5 300 113 5
46211A43434 10 ÷ 200 2,6 ÷ 53 40 580 0,5 7G 1 18,5 300 113 5
46211A41515 10 ÷ 200 2,6 ÷ 53 20 290 0,5 7G 1 1/4 18,5 300 113 5
46221A51616 20 ÷ 400 5 ÷ 106 20 290 0,2 3G 1 1/2 28 150 568
46221A61616 30 ÷ 600 8 ÷ 158 20 290 0,5 7G 1 1/2 28 100 378
46221A61717 30 ÷ 600 8 ÷ 158 20 290 0,5 7 G 2 28 100 378
46221A71717 40 ÷ 800 11 ÷ 211 20 290 0,5 7 G 2 28 75 284
Flowrate Operating
pressure Connector
Internal
passages
(Ø mm)
Pulses
CODE l/min. US GPM P max
(BAR)
P max
(PSI) pls/l pls/ US GAL
46211A3A5B5 5 ÷ 100 1,3 ÷ 26 20 290 T5 F/M 14 600 2271
46211A4A5B5 100 ÷ 200 2,6 ÷ 53 40 290 T5 F/M 18,5 300 113 5
Tab. 7a
Tab. 7b
Tab. 7c

13
6 GUARANTEE TERMS
1. ARAG s.r.l. guarantees this apparatus for a period of 360 day (1 year) from the date of sale to the client user (date of the goods delivery note).
The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or production pro-
cess, will be repaired or replaced free of charge at the nearest Assistance Centre operating at the moment the request for intervention is made. The
following costs are excluded:
- disassembly and reassembly of the apparatus from the original system;
- transport of the apparatus to the Assistance Centre.
2. The following are not covered by the guarantee:
- damage caused by transport (scratches, dints and similar);
- damage due to incorrect installation or to faults originating from insufficient or inadequate characteristics of the electrical system, or to alterations
resulting from environmental, climatic or other conditions;
- damage due to the use of unsuitable chemical products, for spraying, watering, weedkilling or any other crop treatment, that may damage the ap-
paratus;
- malfunctioning caused by negligence, mishandling, lack of know how, repairs or modications carried out by unauthorised personnel;
- incorrect installation and regulation;
- damage or malfunction caused by the lack of ordinary maintenance, such as cleaning of lters, nozzles, etc.;
- anything that can be considered to be normal wear and tear.
3. Repairing the apparatus will be carried out within time limits compatible with the organisational needs of the Assistance Centre.
No guarantee conditions will be recognised for those units or components that have not been previously washed and cleaned to remove residue of
the products used.
4. Repairs carried out under guarantee are guaranteed for one year (360 days) from the replacement or repair date.
5. ARAG will not recognise any further expressed or intended guarantees, apart from those listed here.
No representative or retailer is authorised to take on any other responsibility relative to ARAG products.
The period of the guarantees recognised by law, including the commercial guarantees and allowances for special purposes are limited, in length of
time, to the validities given here. In no case will ARAG recognise loss of prots, either direct, indirect, special or subsequent to any damage.
6. The parts replaced under guarantee remain the property of ARAG.
7. All safety information present in the sales documents regarding limits in use, performance and product characteristics must be transferred to the
end user as a responsibility of the purchaser.
8. Any controversy must be presented to the Reggio Emilia Law Court.
7 DISPOSAL AT THE END OF SERVICE
Dispose of the system in compliance with the established legislation in the country of use.

14

Conformity Declaration
ARAG s.r.l.
Via Palladio, 5/A
42048 Rubiera (RE) - Italy
P.IVA 01801480359
Dichiara
che il prodotto
descrizione: Flussometro elettromagnetico
modello: Orion 2
serie: 46211Axxxxx, 46221Axxxxx
risponde ai requisiti di conformità contemplati nella seguente Direttiva Europea:
2004/108/CE e successive modificazioni (Compatibilità Elettromagnetica)
Riferimenti alle Norme Applicate:
EN ISO 14982 (Macchine agricole e forestali – Compatibilità elettromagnetica
Metodi di prova e criteri di accettazione)
CEI EN 61326-1 (Apparecchi elettrici di misura, controllo e laboratorio. Prescrizioni di
compatibilità elettromagnetica - Parte 1: Prescrizioni generali)
Rubiera, 04 Novembre 2015
Giovanni Montorsi
(Presidente)

D20344_GB-m02 11/2017
Via Palladio, 5/A
42048 RUBIERA (Reggio Emilia) - ITALY
Tel. [phone]
Fax [phone]
www.aragnet.com
[e-mail]
Only use original ARAG accessories and spare parts, to maintain safety conditions foreseen by the constructor.
Always refer to the ARAG spare parts catalogue.
