AutomationDirect C-more EA7-T10C Guide

WARNING: This proced re sho ld only be performed by q alified personnel who are experienced in working with electronic eq ipment. Take the necessary steps to
prevent damage from static electricity discharge. Disconnect inp t power to the to ch panel before proceeding. Be caref l not to pinch the ribbon cable between
the ho sing and bezel when re-assembling the panel.
Preparation: Disconnect input power and all other connections, then remove the touch panel from the control cabinet. In a clean environment, place the panel face
down on a lint-free soft surface to prevent scratching the front of the panel.
w w w . a u t o m a t i o n d i r e c t . c o m / c - m o r e
With power disconnected, use a #2 Phillips screwdriver to remove the four
outer screws holding the touch panel’s main electronics housing to the
front bezel.
Lift the touch panel’s main electronics housing from the front bezel. Set
the front bezel and four screws to the side. Observe the ribbon cable
recess on the front bezel (see detail) for use in re-assembling the panel.
1 - 8 0 0 - 6 3 3 - 0 4 0 5
Carefully lift the bulb’s wires out of the wire guides so they are free from
obstructions. Do this for both the upper and lower backlight bulbs.
Place the touch panel’s main electronics housing facing up on a lint-free
soft surface. Position the housing so that the backlight bulb connectors
are in plain view.
BACKLIGHT BULB REPLACEMENT INSTRUCTIONS
P/NEA-10-BULB* OR EA-10-BULB2**
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
22
22
11
11
33
3344
44
Ribbon cable
recess
pper & lower back-
light bulb connectors
YYMF
YY: Year (05–99 --- e.g. 05 = 2005)
M: Month (1–9,X, Y,Z--- e.g. X= Oct.)
DD:Day(1–31)
F: Manufacturing Site (0–9,A–Z)
NNN:Sequence number for the date listed(000–999)
Serial Number =
[PartNumber]+[YYMDDFNNN]
DateCode=
C-more Replacement Bulbs
C-more Model Bulb Model C-more Serial Number
EA7-T10C
EA-10-BULB* EA7-T10C+10Z11B080 and older
EA-10-BULB2** EA7-T10C+10Z11B081 thru EA7-T10C+12Y29B120
Non-Replaceable LED EA7-T10C+12Y29B121 and newer

This photo shows the backlight bulb completely removed from its guide in
the panel’s main electronics housing. (Only one bulb shown.)
Remove the replacement bulb from its shipping tube and the protective
bubble wrap. Note: The replacement bulbs come in pairs and should be
replaced in pairs for longevity and maintenance convenience.
Plug each backlight bulb’s power cable connector back into its respective
circuit board connector.
Position the replacement bulb so that the opening in its three-sided gold
colored reflector faces toward the LCD touch screen. sing gentle
pressure, slide the bulb into the guide until the retaining clip locks.
Gently position each backlight bulb’s wires back into the wire guides.
Position any excess wire length in between the printed circuit board and
the LCD to prevent it from becoming pinched between the housing and
bezel.
Position the touch panel’s main electronics housing into the front bezel so
that the flat ribbon cable on the housing aligns with the recess in the front
bezel. Insert the four screws and tighten to a maximum of
70 oz-in [0.5 Nm].
Data Sheet: EA-10-B LB-DS, Rev. D
Copyright 2014, Automationdirect.com Incorporated/All Rights Reserved Worldwide
88
88
77
77
99
9911 1100 00
11
1111 1111 1122 22
w w w . a u t o m a t i o n d i r e c t . c o m / c - m o r e
1 - 8 0 0 - 6 3 3 - 0 4 0 5
nplug the backlight bulb’s power cable connector from the circuit board
connector. Again, do this for both the upper and lower backlight bulbs.
Push up on the bulb retaining clip (see detail) while grasping the metal tab
on the end of the bulb assembly and gently slide the bulb from its guide.
Do this for both bulbs. The bulb is glass and fragile, so handle with care.
66
66
55
55Bulb
retaining clip
Metal
tab
