Autonics krn100 series User manual

Universal input card
[KRN-UI2]
Digital input card
[KRN-DI6]
Alarm output card
[KRN-AR4 (relay output)]
※Each channel is isolated and dielectric
strength is 500V.
Alarm output card
[KRN-AT6 (transistor output)]
Transmitter power output card
[KRN-24V3]
Communication output card
[KRN-COM]
※AL1,2,3 and AL4,5,6 are isolated. ※Each 24V output is isolated individually.
+
-
+
-
100mm Hybrid Recorder
KRN100 SERIES
I N S T R U C T I O N M A N U A L
Screen Layout And Status Display
l/O Card
Connections
Dimensions
Specications
Screen layout is divided as two; upper screen for status display, lower screen for measuring value display, virtual keyboard display,
parameter setting display.
Upper screen displays recorder status and information of recorder as icon.
Input Type Setting
Jumper
pin
Input
specication Input break alarm
①0 to 20mA, 4 to 20mA Enables only 4 to 20mA
②TC, RTD, ±60mV, ±200mV Enables
③±2V, 1 to 5V, ±5V, -1 to 10V Disables
※This rear side dimension is with
installed I/O cards to every slot.
168
18.6
137
137
● Panel cut-out
※Use a steel plate which is 2 to 8mm thickness.
138+1.0
0
138+1.0
0
Min.175
Min.175
(unit: mm)
Slot Description
1 to 6 Connects universal input card (KRN-UI2).
7 to 10
Connects digital input card (KRN-DI6), alarm output
card (KRN-AR4, KRN-AT6), transmitter power output
card (KRN-24V3).
C Connects communication output card (KRN-COM).
SOURCE
100-240VAC
50/60Hz, 55VA
F.G.
※The above specications are subject to change and some models may be discontinued without notice.
Thank you for choosing our Autonics product.
Please read the following safety considerations before use.
1. Fail-safe device must be installed when using the unit with machinery that may cause serious injury or substantial
economic loss. (e.g. nuclear power control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, re, or economic loss.
2. The unit must be installed on a device panel before use.
Failure to follow this instruction may result in electric shock.
3. Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in electric shock .
4. Do not disassemble or modify the unit. Please contact us if necessary.
Failure to follow this instruction may result in electric shock or re.
5.Check the terminal numbers before connecting the power source.
Failure to follow this instruction may result in re.
Safety Considerations
1. Do not use the unit outdoors.
Failure to follow this instruction may result in shortening the life cycle of the unit, or electric shock.
2. Use the unit within the rated specications.
Failure to follow this instruction may result in shortening the life cycle of the unit, or re.
3. Do not use water or oil-based detergent when cleaning the unit. Use dry cloth to clean the unit.
Failure to follow this instruction may result in electric shock or re.
4. Do not use the unit where ammable or explosive gas, humidity, direct sunlight, radiant heat, vibration, or impact may
be present.
Failure to follow this instruction may result in re or explosion.
5. Keep dust and wire residue from owing into the unit.
Failure to follow this instruction may result in re or product damage.
6. Check the polarity of the power contact before wiring the unit.
Failure to follow this instruction may result in re or explosion.
Warning
Caution
※Please observe all safety considerations for safe and proper product operation to avoid hazards.
※Safety considerations are categorized as follows.
Warning Failure to follow these instructions may result in serious injury or death.
Caution
Failure to follow these instructions may result in personal injury or product damage.
※The symbols used on the product and instruction manual represent the following
symbol represents caution due to special circumstances in which hazards may occur.
※Please read “Safety Considerations” in KRN100 user manual before using.
Before setting the parameters, set the jumper pin channel 1/2 of
universal input card (KRN-UI2) depending on input specification
as below figure.
This gure is the rear side of KRN100-04000-00-0S.
Section Icon Name Description
1
Record start icon Marks if for starting recording measuring value of recordable channels.
Record stop icon Stops recording measuring value.
List record icon Flashes during list recording.
Reservation record icon Flashes during reservation recording.
FEED icon Flashes during feeding recording paper.
Backup data print icon Flashes during backup data printing.
2
Digital mode icon Marks it for digital record mode.
Graph mode icon Marks it for graph record mode.
Record memory status
icon Marks it storage capacity of record memory in digital mode or graph mode.
No recording paper icon Marks it for no recording paper. Please replace new recording paper.
3
USB
communication icon
Marks icon during Modbus RTU communication using USB.
Ethernet communication
icon Marks
icon during Modbus TCP communication using Ethernet.
RS485 communication
icon
Marks icon during Modbus RTU communication using RS485.
4 Alarm ON icon Marks channel icon which alarm occurs.
5
Digital input(DI) icon Marks the below icon according to input function setting during digital input (DI).
Digital input(DI)-
memo icon
Marks it when digital memo of digital input or front is input in recording
status.
Digital input(DI)-
alarm reset icon Marks it when alarm reset signal of digital input (DI) is input.
Digital input(DI)-
start record icon Marks it when start record signal of digital input (DI) is input.
Digital input(DI)-
stop record icon Marks it when stop record signal of digital input (DI) is input.
Digital input(DI)-
LIST output icon Marks it when LIST output signal of digital input (DI) is input.
Digital input(DI)-
record speed icon Marks it when changing record speed signal of digital input (DI) is input.
6
Unlock icon Marks it for unlock status.
User(general user)
lock icon Marks it for user (general user) lock status.
Administrator lock icon Marks it for administrator and general user lock status.
7
Inner and external (USB)
memory capacity icon
Displays data capacity of internal memory as bar graph.
8
Date/Time display Displays current date and time. In summer time season, (S) mark is also
displayed at front of year.
Inner
Inner
Series KRN100
Power voltage 100-240VAC 50/60Hz
Allowable voltage range 85 to 110% of rated voltage
Power consumption Max. 55VA
Screen
LCD type STN Graphic LCD
Resolution 320×120 Pixel
Adjusting brightness 4-level (OFF/Min/Standard/Max)
Backlight White LED, 2-level (Temp/Always)
Input channels 2 / 4 / 6 / 8 / 10 / 12-channel (2-channel/card)
Universal input Temperature sensor (RTD, thermocouple), analog (voltage, current)
Sampling period
1 to 4-channel: 25ms/125ms/250ms, 5 to 12-channel: 125ms/250ms
(inner sampling period is operation unit time for average movement lter and alarm output function.)
※Min. sampling period for TC-R, U, S, T sensor is 50ms.
Recording speed in graph mode 10, 20, 40, 60, 120, 240mm/H
Recording speed accuracy F.S. ±0.5%
Storage cycle 1 to 3600 sec (storage interval time to inner log le is 1 sec)
Inner memory 512MB
USB memory User purchased, recognizes max. 32GB, enables to use cable up to 1.5m
Dielectric voltage 2500VAC 50/60Hz for 1 min (power terminal and case) ※Excepts USB Device and Ethernet
Vibration strength
(for convey and storage) and
operating vibration
Vibration strength: 10 to 60Hz 4.9m/s2 (each X, Y, Z axis for 1 hour)
Operating vibration: 10 to 60Hz 1m/s2 (each X, Y, Z axis for 10 min)
Insulated resistance Min. 20MΩ (at 500VDC megger)
Noise ±2kV the square wave noise (pulse width 1㎲) by the noise simulator
Time accuracy Within ±2 min/year (enables to use up to 2100 year)
Mech-
anism
Ink cartridge Enables to normal print with going and returning printing max. 5 times within 7 days after
opening the unit
Ink dry time Max. 15 minutes
Protection IP40 (for front panel)
Recording paper 113mm×9m
Environ-
ment
Ambient temperature 0 to 50℃, storage: -20 to 60℃ (without ink cartridge)
Ambient humidity 35 to 85%RH, storage: 35 to 85%RH
Approval ,
Weight※1Approx. 2.4 to 2.7kg (approx. 1.7 to 2.0kg)
※1: The weight includes packaging. The weight in parentheses is for unit only.
※Environment resistance is rated at no freezing or condensation.
Alarm Output
USB 2.0
(Mini B type)
RS485 A(+)
RS485 B(-)
RS485 S.G
10/100 Base-T
RJ45(Ethernet)
NPN Open
Collector
12-24VDC/
30mA Max.
RESISTIVE
LOAD
Relay Contact
250VAC 3A 1a
RESISTIVE LOAD
Alarm Output
User Manual
For the detail information and instructions, please refer to user
manual and user manual for communication.
Download manuals from the enclosed CD-ROM or our web site
(www.autonics.com).
Ch1 Jumper
Ch2 Jumper
Terminal
direction
③
② ①
144

QUICK MENU consists of usually used parameters for quickly parameter setting.
QUICK MENU
1) Parameters of QUICK MENU
※Refer to “KRN100 user manual”.
Page Parameter Description Linked parameters
QUICK
MENU [1]
CH Select channel for the QUICK MENU[1] setting.
TYPE Input type [INPUT SETUP]-[Input Type]
DOT Decimal point [INPUT SETUP]-[Range/Scale Point]
UNIT Display/Temperature unit [INPUT SETUP]-[Display/Temp Unit]
PEN COLOR Pen color [INPUT SETUP]-[Pen Color]
QUICK
MENU [2]
CH Select channel for the QUICK MENU[2] setting.
LOW RANGE Low-limit input value or
graph scale value
[INPUT SETUP]-[Low Range] or
[INPUT SETUP]-[Low Graph Scale]
HIGH RANGE High-limit input value or
graph scale value
[INPUT SETUP]-[High Range] or
[INPUT SETUP]-[High Graph Scale]
LOW SCALE Low-limit scale value [INPUT SETUP]-[Low Scale]
HIGH SCALE High-limit scale value [INPUT SETUP]-[High Scale]
QUICK
MENU [3]
PRINT MODE Record mode [RECORD SETUP]-[Record Mode]
PRINT SPEED Standard record speed [RECORD SETUP]-[Standard Speed]
PRINT MEMO Digital memo period [RECORD SETUP]-[Memo Period]
BACK LIGHT LCD backlight [SYSTEM SETUP]-[Backlight]
LCD ON/OFF
LCD backlight On/Off [SYSTEM SETUP]-[Backlight On/Off]
QUICK
MENU [4]
USB REC Memory save [FILE/MEMORY SETUP]-
[USB LogData Save]
USB COPY Call USB COPY window [FILE/MEMORY SETUP]-
[USB Memory Copy/Move]
UPGRADE Call upgrade window [USER/INFORMATION SETUP]-
[Firmware Upgrade]
CANCEL Cancel the settings
SAVE Save the setting of QUICK MENU[1] to [4].
Operation
Special
function for
record
Trend graph
→ Bar graph
→ Digital number
Usually used
parameters of
parameter setting group
are reorganize as
QUICK MENU.
Each parameter setting
is linked.
Start/Stop
recording
Parameter
setting
information
output
Manual feed
(when stop
recording)
Digital memo
Screen
display
QUICK
MENU
Parameter
setting
group
3 sec
3 sec
3 sec
3 sec
RUN mode
Major Products
Photoelectric Sensors Temperature Controllers
Fiber Optic Sensors Temperature/Humidity Transducers
Door Sensors SSRs/Power Controllers
Door Side Sensors Counters
Area Sensors Timers
Proximity Sensors Panel Meters
Pressure Sensors Tachometer/Pulse(Rate) Meters
Rotary Encoders Display Units
Connectors/Sockets Sensor Controllers
Switching Mode Power Supplies
Control Switches/Lamps/Buzzers
I/O Terminal Blocks & Cables
Stepper Motors/Drivers/Motion Controllers
Graphic/Logic Panels
Field Network Devices
Laser Marking System(Fiber, CO₂, Nd:YAG)
Laser Welding/Cutting System
Recorders Thyristor Units
Indicators Pressure Transmitters
Converters Temperature Transmitters
Controllers
http://www.autonics.com
Trusted Partner In Industrial Automation
HEADQUARTERS:
18, Bansong-ro 513beon-gil, Haeundae-gu, Busan,
South Korea, 48002
OVERSEAS SALES:
#402-303, Bucheon Techno Park, 655, Pyeongcheon-ro,
Wonmi-gu, Bucheon, Gyeonggi-do, South Korea, 14502
TEL: [phone] / FAX: [phone]
E-mail: [email protected]
AEP-E-0121B
2) QUICK MENU Setting
Parameters
DIGITAL INPUT
SETUP
(digital input setting)
ALARM SETUP
(alarm setting)
COMMUNICATION
SETUP
(com. setting)
3 sec
INPUT SETUP
(input setting)
OK,
Cancel
SYSTEM SETUP
(system setting)
FILE/MEMORY
SETUP
(le/memory setting)
USER/INFORMATION
SETUP
(user/info. setting)
RECORD BACKUP
DATA
(backup data record setting)
RECORD SETUP
(record setting)
RUN mode
※Dot parameters may or may not appear, depending on the other parameter setting.
Input Set Copy
(input parameter
copy)
LCD/Paper Record
(display and record
measuring value)
Pen Color
(record color)
Record Zone
(record zone)
Tag Name
(channel name)
Input Type
(input
specications)
Range/Scale Point
(decimal point)
Display/Temp Unit
(display/temp. unit)
High/Low Range
& Graph Scale
(high/low input value
and graph scale)
Low Scale/
High Scale
(high/low scale value)
Special Func
(special function)
Two Unit
(display vacuum,
static pressure)
Ref Channel
(reference channel)
Input Bias
(error correction)
Span
(gradient adjustment)
Record Method
(data storage method)
Filter Type
(input digital lter)
Filter Counter
(number of digital
lters)
Burnout Action
(display setting for
break)
Select UI Card
(universal input card
select )
Select UI Channel
(universal input
select)
Alarm Set Copy
(copy alarm
parameter)
Alarm type
(alarm operation
mode)
Alarm Ref Channel
(alarm reference
channel)
Alarm Option
(alarm option)
Alarm Value
(alarm SV)
Alarm Hysteresis
(alarm hysteresis)
Alarm ON/OFF Delay
(alarm output ON/
OFF delay time)
Alarm Alarm No
(alarm output
alarm number)
Selection Alarm Card
(Alarm output card
select)
Alarm- Status
(relay and transistor
output method
Select DI Card
(digital input card
select )
DI- Type
(digital input
select)
DI- Reset No
(reset alarm number)
DI- Status
(operation status)
Modbus Address
(com. address)
RS485 Port
(RS485 com. use)
Baud Rate
(com. speed)
Parity Bit
(com. parity bit)
Stop Bit
(com. stop bit)
Termination Set
(terminating
resistance)
Response Wait Time
(com. response
waiting time)
Protocol
(com. protocol)
RS485 Com/Write
(RS485 com. write)
Ethernet Port
(Ethernet com. use)
IP Address
(IP address)
Subnet Mask
(subnet mask)
Default Gateway
(default gateway)
Ethernet Com Write
(Ethernet com.
write)
USB Device Port
(USB com. use )
USB Com Write
(USB com. write)
Record Mode
(record mode)
Digital Print type
(1 line record CH during
numeric recording)
Standard Speed
(standard record
speed)
Option Speed
(option record
speed)
Memo Period
(digital memo cycle)
Divide Zone
(record zone
division)
Standard Period
(standard record
cycle)
Option Period
(option record
cycle)
Listing Language
(language for list
printing)
Alarm Speed
(alarm record
speed)
Power On Status
(record status when
power ON)
Run Status
(list printing at start
recording)
List Out Option
(list record option)
Zone Dot Line Distance
(dot line for zone
division)
CH Print Distance
(record interval for
each channel graph
Start Line Print
(start line when
starting record)
Range Print Time
(input range record
period)
Device Name
(device name)
Date/Time
(date/time)
Date Type
(date type)
Summer Time
(summer time)
Summer Time Period
(summer time period)
Reservation Type
(reservation record)
Reservation Period
(reservation record
period)
Reservation Time
(reservation record
time)
Alarm Sound
(alarm sound)
Sampling Rate
(sampling period)
Log Speed
(save cycle)
Backlight
(LCD backlight
brightness)
Baklight On/Off
(LCD backlight ON
method)
Load Set File
(parameter setting
le open)
Save Set File
(parameter setting
le save)
Memory Status
(memory capacity)
Memory Clear
(memory delete)
USB LogData Save
(USB save function)
Memory Save Option
(memory save
option)
USB Memory
Copy/Move
(data move/copy)
Password
(password mode)
Login Admin
(admin. log in)
Change Admin
Password
(password change by admin.)
User Lock
(user authority
change)
Information
(system info. check)
Firmware Upgrade
(rmware upgrade)
Record Backup
(backup data
record)
Backup Data List
(backup data list)
Start Date and Time
(start time for data save)
End Date and Time
(end time for data save)
Backup Print Mode
(backup data print
mode)
Selection Print Mode
(backup data recording
mode setting)
① ② ③
Press the key once in RUN mode and it
enters to QUICK MENU.
QUICK MENU consists of usually used param-
eters for quickly parameter setting.
Set the keys following the each parameter. Press
the NEXT ( ) key and it moves to next page.
E.g.) When changing the temperature unit (℃→℉)
of CH1, press the SET ( ) key.
After completing the setting, press the SAVE
() key at QUICK MENU[4] and save the
settings. It returns to RUN mode.
ᆞE.g.) In case of CH1, recording as input type=TC-U, low-limit input value=300, standrad record speed= 240mm/h
①② ③
Press the key in RUN mode to enter
QUICK MENU.
Press the SET ( ) key at QUICK MENU [1]
and below screen is displayed. Set input type
[TYPE] as TC-U by pressing SET ( ,)
keys and press the key.
Press the NEXT ( ) key once and it moves
to QUICK MENU [2]. Press the SET ( ) key
using
, , , keys to set
low-limit input range [LOW RANGE] as 300 and
press the key.
④ ⑤
Press the NEXT ( ) key once and it moves
to QUICK MENU [3]. Press the SET ( ) key
and set standard record speed [PRINT SPEED]
as 240mm/h.
Press the NEXT ( ) key once and it moves
to QUICK MENU [4]. Press the SAVE ( )
key to save the settings of QUICK MENU [1] to
[4] and it returns to RUN mode.
