AUTOTECH 10.611.199K-207K User manual

AUTOTECH
Installation Instructions
Phone [phone] Fax [phone]-E Paseo Adelanto, San Juan Capistrano, CA 92675
PART NUMBER(S):10.611.199K; .202K; .203K; .204K; .205K; .206K; 207K
DESCRIPTION: SportTuned STAINLESS STEEL BRAIDED BRAKE LINES
PROCEDURE:
1.Jack up the car and support it on jack stands.
2. Using an open ring spanner wrench, remove the standard brake lines. Note: it may be
necessary to use a little penetrating oil on some of the hard line fittings.
3. Starting with the front brake lines, screw the male end of the line into the brake caliper
first and tighten to the factory torque spec of 11 ft. lbs. Make sure that the brake line does
not rub against any other metal objects as the braid will gradually grind through whatever
it is touching.
4. When installing the female end of the brake line, do not try to turn the end fitting of the
new line with a wrench. The braided brake line ends do not swivel. The hard metal lines
on your vehicle have ends that are designed to rotate. Thread the hard line into the braided
lines at a torque of 11 to 14 ft. lbs.
5. For the rear of the vehicle, loosen the bolts mounting the rear axle beam and lower it away
from the car with a rolling floor jack. This allows access to the rotating ends of the hard
lines. It may be necessary to use a special brake wrench for accessing these fittings.
6. Once installed, re-attach the rear axle beam to the vehicle using the factory torque specs
of 32 ft. lbs.
7.Flush your braking system thoroughly to get rid of any possible sediment. Install a new,
high quality brake fluid into the system and bleed all corners of the car until the spongy
feeling in the pedal is completely gone.
8. Remove the vehicle from the jack stands and test the vehicle initially at a low speed to
make sure the system is safe and functioning properly
Installation Tip: To avoid rounding the flats on the VW brake line fittings, Autotech recom-
mends using an open ring spanner wrench (Autotech part no. 99.012.009) instead of a
normal open end wrench. The shape of the tool should resemble this.
