AUX L Series User manual

Technical Manual
(DC Inverter Free Match R32)
ΑΓΗΝΩΡ A.E.
ΟΜΙΛΟΣ ΕΤΑΙΡΙΩΝ ΤΟΥΡΝΙΚΙΩΤΗ
ΓΕΝΙΚΟΙ ΑΝΤΙΠΡΟΣΩΠΟΙ
ΑΓΗΝΩΡ A.E.
ΟΜΙΛΟΣ ΕΤΑΙΡΙΩΝ ΤΟΥΡΝΙΚΙΩΤΗ
ΓΕΝΙΚΟΙ ΑΝΤΙΠΡΟΣΩΠΟΙ

AUX DC Inverter Free Match 50HZ R32
KΕΝΤΡΙΚΑ ΓΡΑΦΕΙΑ: Λ. ΑΘΗΝΩΝ 50 & ΣΠ. ΠΑΤΣΗ 8, 10441 ΑΘΗΝΑ
ΤΗΛ. ΚΕΝΤΡΟ: 210 5288888, FAX: [phone]
SERVICE: 210 5288832-4

AUX DC Inverter Free Match 50HZ R32
3
CONTENTS
CONTENTS ...................................................................................................................3
Part1 General Information..................................................................................7
1. Nomenclature ....................................................................................................................7
2. Unit appearance.................................................................................................................8
3. Combination Table ...........................................................................................................13
4. Accessories Included........................................................................................................17
Part2 Features ...................................................................................................... 18
1. Outdoor Units ..................................................................................................................18
2. Wall Mounted ..................................................................................................................21
3. Four-way Cassette ............................................................................................................22
4. Ceiling Floor .....................................................................................................................23
5. Duct ..................................................................................................................................24
6.WIFI Control ......................................................................................................................25
Part3 Piping System............................................................................................ 26
1. 14K, 18K ...........................................................................................................................26
2. 21K, 27K ...........................................................................................................................26
3. 36K ...................................................................................................................................28
4. 42K ...................................................................................................................................29
Part4 Specification.............................................................................................. 30

AUX DC Inverter Free Match 50HZ R32
1. Wall Mounted ..................................................................................................................30
2. Cassette............................................................................................................................38
3. Ceiling Floor .....................................................................................................................41
4. Duct ..................................................................................................................................43
5. Outdoor Unit....................................................................................................................45
Part5 Dimension.................................................................................................. 52
1. Wall Mounted ..................................................................................................................52
2. Cassette............................................................................................................................53
3. Ceiling Floor .................................................................................................................54
4. Duct ..................................................................................................................................55
5. Outdoor Unit....................................................................................................................57
Part6 Electrical Principle Diagram................................................................ 60
1. Wall Mounted ..................................................................................................................60
2. Cassette............................................................................................................................63
3. Ceiling Floor .....................................................................................................................64
4. Duct ..................................................................................................................................65
5. Outdoor Unit....................................................................................................................66
Part7 Capacity Amendment ............................................................................. 68
1. Operation range ...............................................................................................................68
2. Capacity amendment of different ambient temperature................................................68
3. Long piping length............................................................................................................70
4. Capacity amendment of different piping length..............................................................71

AUX DC Inverter Free Match 50HZ R32
5
5. Equivalent Pipe length conversion...................................................................................72
Part8 Static pressure curve.............................................................................. 73
1. 07K、09K Duct..............................................................................................................73
2. 12K Duct........................................................................................................................74
3. 18K Duct........................................................................................................................75
Part9 Controller ................................................................................................... 76
1. Controller .........................................................................................................................76
2. Parameters Setting.........................................................................................................106
3. Room Card Function.......................................................................................................111
4. Wifi Module ...................................................................................................................113
Part10 Explosive View .....................................................................................116
1. Wall Mounted ................................................................................................................116
2. Cassette..........................................................................................................................135
3. Ceiling Floor ...................................................................................................................137
4. Duct ................................................................................................................................139
5. Outdoor Unit..................................................................................................................143
Part11 Installation............................................................................................151
1. Preparation.....................................................................................................................151
2. Precaution ......................................................................................................................152
3. Wall Mounted ................................................................................................................153
4. Cassette..........................................................................................................................155

AUX DC Inverter Free Match 50HZ R32
5. Ceiling Floor ...................................................................................................................161
6. Duct ................................................................................................................................164
7. Outdoor Unit..................................................................................................................167
8. Connection piping installation .......................................................................................168
9. Emptying or vacuum ......................................................................................................171
10. Insulation......................................................................................................................173
11. Additional refrigerant charge.......................................................................................175
12. Electrical connection....................................................................................................176
Part12 PCB Instruction....................................................................................180
1. Outdoor Unit PCB...........................................................................................................180
2. Indoor Unit PCB..............................................................................................................184
Part13 Trouble Shooting.................................................................................187
1. Failure code display........................................................................................................187
2. Failure analysis ...............................................................................................................189

AUX DC Inverter Free Match 50HZ R32
7
Part1 General Information
1. Nomenclature
Indoor Unit
Outdoor Unit

AUX DC Inverter Free Match 50HZ R32
2. Unit appearance
2.1 Wall - Mounted
/
Capacity Range / Mode
L
Series
07 K Btu/h
AMWM-H07/4R3(L*)
09 K Btu/h
AMWM-H09/4R3(L*)
12 K Btu/h
AMWM-H12/4R3(L*)
18 K Btu/h
AMWM-H18/4R3(L*)
F
Series
07 K Btu/h
AMWM-H07/4R3(F*)
09 K Btu/h
AMWM-H09/4R3(F*)
12 K Btu/h
AMWM-H12/4R3(F*)
18 K Btu/h
AMWM-H18/4R3(F*)
24K Btu/h
AMWM-H24/4R3(F*)
J
Series
07 K Btu/h
AMWM-H07/4R3(J*)
09 K Btu/h
AMWM-H09/4R3(J*)
12 K Btu/h
AMWM-H12/4R3(J*)
18 K Btu/h
AMWM-H18/4R3(J*)
24K Btu/h
AMWM-H24/4R3(J*)

AUX DC Inverter Free Match 50HZ R32
9
2.2 Cassette
/
Capacity Range / Mode
Four-way cassette
09 K Btu/h
AMCA-H09/4R3A
12 K Btu/h
AMCA-H12/4R3A
18 K Btu/h
AMCA-H18/4R3A
Standard Panel
MB13A-I
MB13B-I
Optional Panel
MB09A
MB09B

AUX DC Inverter Free Match 50HZ R32
2.3 Ceiling Floor
/
Capacity Range / Mode
Ceiling Floor
09 K Btu/h
AMCF-H09/4R3A
12 K Btu/h
AMCF-H12/4R3A
18 K Btu/h
AMCF-H18/4R3A

AUX DC Inverter Free Match 50HZ R32
11
2.4 Duct
/
Capacity Range / Mode
DUCT
07 K Btu/h
AMSD-H07/4R3A
09 K Btu/h
AMSD-H09/4R3A
12 K Btu/h
AMSD-H12/4R3A
18 K Btu/h
AMSD-H18/4R3A

AUX DC Inverter Free Match 50HZ R32
2.5 Outdoor Unit
Capacity(Btu)
1 drive 2 14k/18k
1 drive 3 21k/27k
（AM2-H14/4DR3）
（AM3-H21/4DR3）
（AM2-H18/4DR3）
（ AM3-H27/4DR3）
Capacity(Btu)
1 drive 4 36k
1 drive 5 42k
（AM4-H36/4DR3）
（AM5-H42/4DR3）

AUX DC Inverter Free Match 50HZ R32
13
3. Combination Table
14K
AM2-H14/4DR3
Suggested Combination
1 drive 2
One Unit
Two Units
7
7+7
—
9
7+9
—
12
9+9
—
18
—
—
18K
21K
AM3-H21/4DR3
Suggested Combination
1 drive 3
One Unit
Two Units
Three Units
—
7+7
9+12
7+7+7
—
7+9
9+18
7+7+9
—
—
7+12
12+12
7+7+12
—
18
7+18
—
7+9+9
—
24
9+9
—
9+9+9
—
27K
AM3-H27/4DR3
Suggested Combination
1 drive 3
One Unit
Two Units
Three Units
18
7+12
9+24
7+7+7
7+9+18
24
7+18
12+12
7+7+9
7+12+12
—
7+24
12+24
7+7+12
9+9+9
—
9+9
18+18
7+7+18
9+9+12
—
9+12
18+24
7+9+9
9+12+12
—
9+18
—
7+9+12
AM2-H18/4DR3
Suggested Combination
1 drive 2
One Unit
Two Units
9
7+7
9+9
12
7+9
9+12
18
7+12
—
—
—

AUX DC Inverter Free Match 50HZ R32
36K
AM4-H36/4DR3
Suggested Combination
1 drive4
One
Unit
Two Units
Three Units
18
7+12
12+12
7+7+7
7+9+18
9+9+12
12+12+12
24
7+18
12+18
7+7+9
7+9+24
9+9+18
12+12+18
—
7+24
12+24
7+7+12
7+12+12
9+9+24
—
9+9
18+18
7+7+18
7+12+18
9+12+12
9+12
18+24
7+7+24
7+12+24
9+12+18
—
9+18
—
7+9+9
7+18+18
9+12+24
—
9+24
—
7+9+12
9+9+9
9+18+18
AM4-H36/4DR3
Suggested Combination
1 drive4
Four Units
7+7+7+7
7+7+9+18
7+9+12+18
7+7+7+9
7+7+12+12
7+12+12+12
7+7+7+12
7+7+12+18
9+9+9+9
7+7+7+18
7+9+9+9
9+9+9+12
7+7+7+24
7+9+9+12
9+9+9+18
7+7+9+9
7+9+9+18
9+9+12+12
7+7+9+12
7+9+12+12
9+12+12+12
42K
AM5-H42/4DR3
Suggested Combination
1 drive5
One Unit
Two Units
18
7+18
18+18
24
7+24
18+24
—
9+12
24+24
—
9+18
—
—
9+24
—
—
12+12
—
—
12+18
—
—
12+24
—

AUX DC Inverter Free Match 50HZ R32
15
AM5-H42/4DR3
Suggested Combination
1 drive5
Three Units
7+7+7
7+9+24
9+9+18
12+12+18
7+7+9
7+12+12
9+9+24
12+12+24
7+7+12
7+12+18
9+12+12
12+18+18
7+7+18
7+12+24
9+12+18
12+18+24
7+7+24
7+18+18
9+12+24
18+18+18
7+9+9
7+18+24
9+18+18
—
7+9+12
9+9+9
9+18+24
—
7+9+18
9+9+12
12+12+12
—
AM5-H42/4DR3
Suggested Combination
1 drive5
Four Units
7+7+7+7
7+7+12+12
7+9+12+24
12+12+12+12
7+7+7+9
7+7+12+18
7+12+12+12
12+12+12+18
7+7+7+12
7+7+12+24
9+9+9+9
—
7+7+7+18
7+9+9+9
9+9+9+12
—
7+7+7+24
7+9+9+12
9+9+9+18
—
7+7+9+9
7+9+9+18
9+9+12+12
—
7+7+9+12
7+9+12+12
9+12+12+12
—
7+7+9+18
7+9+12+18
9+12+12+18
—
AM5-H42/4DR3
Suggested Combination
1 drive5
Five Units
7+7+7+7+7
7+7+7+9+24
7+7+12+12+12
9+9+9+9+18
7+7+7+7+9
7+7+7+12+12
7+9+9+9+9
9+9+9+12+12
7+7+7+7+12
7+7+7+12+18
7+9+9+9+12
9+9+12+12+12
7+7+7+7+18
7+7+9+9+9
7+9+9+9+18
—
7+7+7+7+24
7+7+9+9+12
7+9+9+12+12
—
7+7+7+9+9
7+7+9+9+18
7+9+12+12+12
—
7+7+7+9+12
7+7+9+12+12
9+9+9+9+9
—
7+7+7+9+18
7+7+9+12+18
9+9+9+9+12
—

AUX DC Inverter Free Match 50HZ R32
Note：
All of the above indoor unit can be freely matched and combined, but must be
installed strictly according to the above table or the cooling capacity and stability would
be decreased.

AUX DC Inverter Free Match 50HZ R32
17
4. Accessories Included
4.1 Outdoor Units
N°
Name
QUANTITY
AM2-H14/
4DR3
AM2-H18/
4DR3
AM2-H21/
4DR3
AM3-H27/
4DR3
AM4-H36/
4DR3
AM5-H42/
4DR3
1
Installer
manual
1
1
1
1
1
1
2
Drainage
connector
1
1
1
1
1
1
3
Pipe
adaptor
0
0
0
0
0
0
4
copper
nuts
8
8
12
12
16
20
4.2 Indoor Units
N°
Name
QUANTITY
Wall
Mounted
Duct
Cassette
Ceiling & Floor
1
User manual
1
1
1
1
2
Remote control
1
0
1
1
3
Batteries for Remote Control
2
0
2
2
4
Touch screen wired Control
0
1
0
0
5
Panel screw
0
0
4
0
6
Drainage tube
0
1
1
1
7
Pipe adaptor
0
1
1
1
8
Thermal insulation pipe
0
2
2
2

AUX DC Inverter Free Match 50HZ R32
Part2 Features
1. Outdoor Units
Environmental-friendly Refrigerant R32
The GWP value of R32 is smaller, so the effect on the greenhouse effect is smaller. The ODP
value of R32 is 0,so it’s no harm to our planet’s ozone layer.
High Efficiency
Equipped with high efficiency DC Inverter compressor, adjustable fan motor and advanced
180° sine wave vector driver, the system can be higher than 6.1 in SEER and 4.0 in SCOP so as
to meet the European and Australian new energy efficiency standards.
Reliability
Stable cooling under -10°C and heating under -15°C outdoor environment temperature.
180°Sine Wave Control
DC inverter compressor uses 180°sine wave vector control technique, make compressor
motor operate smoothly and efficiency increases significantly.

AUX DC Inverter Free Match 50HZ R32
19
Energy Saving
Cutting-edge DC inverter of sine wave control and active PFC technology realize low noise
and economical operation.
Space-Saving Installation
Up to 5 indoor units can be connected to a single outdoor unit, which reduces the number of
outdoor units required so as to save installation space. Besides, each indoor unit can controlled
individually and they even needn’t to be installed at the same time.

AUX DC Inverter Free Match 50HZ R32
EXV Regulation
Each Indoor Unit adjusted by a EXV,whole unit could achieve quick cooling/heating,and
decrease throttling noise in indoor units.
