AV Access 4KEX100-DP-KVM User manual

4K HDBT DP KVM Extender with USB 2.0
User Manual
4KEX100-DP-KVM

www.avaccess.com
1
[e-mail]
Table of Contents
Introduction............................................................................................................ 2
Overview...................................................................................................................................... 2
Features........................................................................................................................................ 2
Package Contents ..................................................................................................................... 2
Panel.............................................................................................................................................. 3
Front Panel......................................................................................................................... 3
Rear Panel........................................................................................................................... 3
Installation and Application................................................................................... 4
Brackets Installation ................................................................................................................. 4
Application.................................................................................................................................. 5
Specification ...........................................................................................................6
Warranty .................................................................................................................7

Introduction
www.avaccess.com
2
[e-mail]
Introduction
Overview
This product is a 100m 4K DisplayPort over HDBT extender with USB 2.0 and
audio pass-through. It offers the distribution of uncompressed 4K@30Hz
UHD video, audio, power, RS232 and USB 2.0 together up to 100m/330ft
over a single Cat X cable.
With USB 2.0 pass-through, it allows users to control or monitor a remote
server from a harsh environment, or operate a physically inaccessible PC,
server or workstation remotely. Bi-directional audio pass-through allows for
audio distribution in both directions.
With 48V PoE integrated inside, a single power adapter connected to the
transmitter powers both units. Its 12V power adapter is secured with a
screw-on connector to prevent the power being accidentally disconnected.
LED indicators for power supply to units and signal status show established
connection between connected devices.
Features
Slim appearance and space saving.
One-way PoE, transmitter supplies the power for receiver.
Via Cat 6a/7 cable, 4Kx2K@30Hz or 1080P@60Hz output up to 100m.
Via Cat 5e/6 cable, 4Kx2K@30Hz output up to 90m, 1080P@60Hz up to
100m.
DP 1.2 supported, up to 4k@30Hz and HDCP 1.4 compliance.
Supports Bi-directional stereo audio, RS232 and EDID pass through
over HDBaseT.
USB 2.0 pass through over HDBaseT, with USB-HOST built in transmitter
and USB-DEVICE built in receiver.
All connectors in one side for easy installation.
Package Contents
Before you start the installation of the product, please check the package
contents:
Transmitter x 1
Receiver x 1
Power Adapter (DC 12V 2A) x 1
Phoenix Male Connector (3.5mm 3 Pin) x 2
USB 2.0 Type-B to Type-A Cable (L=1.5m) x 1
Mounting Bracket (with Mounting Screws) x 4
User Manual x 1

Introduction
www.avaccess.com
3
[e-mail]
Panel
Front Panel
Transmitter/Receiver
No.
Name
Description
1 Power LED
On: The device is powered on.
Off: The device is powered off.
2 Status LED
Blinking: The device is working properly.
Off: The device is not working properly.
3 HDCP LED
On: HDCP protected content is being transmitted.
Blinking: Non-HDCP protected content is being
transmitted.
Off: No content is being transmitted.
4 Link LED
On: HDBT link is normal.
Off/Blinking: No HDBT link or link error.
Rear Panel
Transmitter
No.
Name
Description
1 DC 12V
Connect to the DC 12V power adapter provided.
Note: Only one power adapter is needed at transmitter
side.
2
HDBT Out
Connect to the receiver via a Cat X cable.
3
RS232
RS232 pass-through.
4
DP In
Connect to a DisplayPort source.
5
Audio In
Connect to an audio source device such as PC.
6
Audio
Out
Connect to an audio device such as earphone, amplifier.
7 USB Host
Connect to device to be controlled such as server,
computer etc.

Installation and Application
www.avaccess.com
4
[e-mail]
Receiver
No.
Name
Description
1 DC 12V
Connect to the DC 12V power adapter provided.
Note: Only one power adapter is
needed at
transmitter side.
2
HDBT In
Connect to the transmitter via a Cat X cable.
3
RS232
RS232 pass-through.
4
DP Out
Connect to a DisplayPort display.
5
Audio In
Connect to an audio source such as PC.
6
Audio Out
Connect to an audio device such as earphone,
amplifier.
7 USB Device
Connect to USB devices such as mouse, keyboard,
USB disk etc.
Installation and Application
Brackets Installation
Note: Before installation, please ensure the device is disconnected from the
power source.
In order to keep elegant appearance, we design to share screws with the
product chassis, please refer to the below steps to install.
1. Remove the screws on the side panel of the transmitter/receiver (See
Figure 1).
2. Position and install the mounting bracket using the screws provided
(see Figure 2).
3. Mounting to a surface or any right place by using the mounting screws
to affix the units.
Figure 1 Figure 2

Installation and Application
www.avaccess.com
5
[e-mail]
Application
Use Cat5e/6/6a/7 to connect the transmitter and receive r.
4
Connect to the
power adapter
provided.
8
PC Serve r
Connect to a
DP source.
1
Connect to an
audio source.
2
Connect to the
USB Host PC.
3
Earphone
Connect to
an audio
device, such as
earphone.
6
5
Connect to a
DP display Connect to
the USB
devices.
7
Powe rAdapte r
Transmitte r
Receive r
Note:
With one-way PoE, one power adapter is needed to be connected to
the transmitter to power both units.
Make sure the connected Cat x cable is no less than the maximum
transmission distance (refer to “Specification” section).

Specification
www.avaccess.com
6
[e-mail]
Specification
Technical
Video Signal Type
DP1.2 with HDCP1.4
Audio Format
L/R channel PCM 2.0
Input/Output Resolution
Support
640x480
8
, 800x600
8
, 1024x768
8
, 1280x720
8
,
1280x7688, 1280x8008, 1280x9608,
1280x10248, 1360x7688, 1366x7688,
1440x9008, 1600x9008, 1600x12008,
1680x10508, 1920x12008, 1920x12008,
2560x14408, 2560x16008, 3840x2160P5,
1920x10809
5 = at 30 Hz, 8 = at 60 Hz, 9 = 120Hz
General
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
10% to 90%, non-condensing
ESD Protection
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Surge Protection
Voltage: ±1 kV
Power Consumption
(Maximum)
≤14.2W (Pair)
DP Cable length
5m (Max)
Device Dimensions
(W x H x D)
200 mm × 25 mm ×100 mm
7.91'' x 0.99'' x 3.95''
Product Weight
Transmitter: 0.5kg/1.10lb
Receiver: 0.5kg/1.10lb
Transmission Distance
Note: AV Access recommends the use of T568B straight-through Category
cables.
Cable Type
Range
Supported Video
CAT5e/CAT6
100m/328ft
1080p@60Hz 36bpp
90m/295ft
1080p@60Hz 48bpp
1080p@60Hz 3D
3840 x 2160@30Hz 4:4:4
CAT6a/CAT7 100m/328ft
1080p@60Hz 48bit
1080p@60Hz 3D
3840 x 2160@30Hz 4:4:4

Warranty
www.avaccess.com
7
[e-mail]
Warranty
Products are backed by a limited 1-year parts and labor warranty. For the
following cases AV Access Technology Limited shall charge for the service(s)
claimed for the product if the product is still remediable and the warranty
card becomes unenforceable or inapplicable.
1. The original serial number (specified by AV Access Technology Limited)
labeled on the product has been removed, erased, replaced, defaced or
is illegible.
2. The warranty has expired.
3. The defects are caused by the fact that the product is repaired,
dismantled or altered by anyone that is not from an AV Access
Technology Limited authorized service partner. The defects are caused
by the fact that the product is used or handled improperly, roughly or
not as instructed in the applicable User Guide.
4. The defects are caused by any force majeure including but not limited
to accidents, fire, earthquake, lightning, tsunami and war.
5. The service, configuration and gifts promised by salesman only but not
covered by normal contract.
6. AV Access Technology Limited preserves the right for interpretation of
these cases above and to make changes to them at any time without
notice.
Thank you for choosing products from AV Access.
If you have any question, please contact us via the following emails:
General Enquiry: [e-mail]
Customer/Technical Support: [e-mail]

www.avaccess.com
8
[e-mail]
