USER’SGUIDE
Installation,Operation,andMaintenanceforyourproduct.
BUILT‐INWINECOOLER
Model‐AWC151DZ
www.avallon.com 1‐866‐471‐7427
2
ImportantSafetyInformation
ImproperhandlingcancauseseriousdamagetotheAvallonwinerefrigeratorand/orinjurytotheuser.Thiswine
refrigeratorisdesignedfordomesticindooruseonly.Donotusetheunitforindustrialorcommercialuse.Anyother
usemayinvalidatethewarranty.Pleasereviewtheratinglabellocatedontherearpaneloftheunitforelectricaland
othertechnicaldatarelatedtothisunit.Theunitmustbeusedinaproperlygroundedwalloutlet.Pleasereadand
followthesafetyinformationlistedbelowtoreducetheriskoffire,electricshock,orinjury.
ELECTRICALSAFETY
•Donotexceedthepoweroutletratings.
•Itisrecommendedthewinerefrigeratorbeconnectedonitsowncircuit.
•Theunitmustbeinstalledinaccordancewithstateandlocalelectricalcodes.
•Astandardelectricalsupply(115V,60Hz),thatisproperlygroundedinaccordancewiththeNationalElectricalCodeandlocal
codesandordinancesisrequired.
•Useoutletsthatcannotbeturnedoffbyaswitchorpullchain.
•Alwaysturntheunitoffandunplugitfromtheoutletwhencleaning.
•Unplugtheunitifitisnotgoingtobeusedforanextendedperiodoftime.
•Donotoperatetheunitwithapowerplugmissingthegroundplug,adamagedcordoraloosesocket.
•Besurethewinerefrigeratorisproperlygrounded.
•Neverplugorunplugtheunitwithwethands.
•Donotbypass,cutorremovethegroundingplug.
•Donotuseextensioncordsorpowerstripswiththisunit.Youmayneedtocontactyourelectricianifitisnecessarytousea
longercordorifyoudonothaveagroundedoutlet.Donotmodifythepowercord’slengthorsharetheoutletwithother
appliances.
•Donotstartorstoptheunitbyswitchingthecircuit’spoweronandoff.
•Ifthepowercordisdamaged,itmustbereplacedbythemanufactureroraqualifiedtechnician.
•Neverrepairtheunitwhileitispluggedin.
•Immediatelyunplugtheunitifitmakesstrangesounds,emitssmellsorsmokecomesoutofit,andcontactcustomerservice.
•Donotremoveanypartofthecasingunlessinstructedbyanauthorizedtechnician.
•Youshouldneverattempttorepairtheunityourself.Contactcustomerserviceforserviceoptionsiftheunitneedsservice.
GENERALSAFETY
•Topreventbackandothertypesofinjuries,useatleasttwopeopletomoveandinstallthewinecooler.
•Thisapplianceisnotintendedforusebypersons,includingchildren,withreducedphysical,sensoryormentalcapabilities,
unlesstheyhavebeengivensupervisionorinstructionconcerningtheuseoftheappliancebytheperson(s)responsiblefortheir
safety.
•Installthewinerefrigeratorinawellventilatedareawheretheambienttemperatureisabove50°Fandbelow90°F.
•Thetemperaturerangeforthiscoolerisoptimizedforwineandbeveragestorage.Perishablefooditemsmayrequireadifferent
storageenvironment.
•Donotplacehotorwarmitemsintothecoolerbeforetheycooldowntoroomtemperature.
•Thisunitisdesignedtobeinstalledindoors,andprotectedfromrain,sleet,snow,and/ormoisture.
•Neverallowchildrentocrawlinsidethewinerefrigerator.Ifdisposingtheunit,removethedoor.
•Donotusethisappliancenearflammablegasorcombustibles,suchasgasoline,benzene,thinner,etc.
•Donotplacetheunitnearheatsourcessuchasovens,grills,ordirectsunlight.
•Onlyuseinanuprightpositiononaflat,levelsurfaceandprovideproperventilation.
•Donotpinchorkinkthepowersupplylinebetweentheunitandcabinet.
•Donotplaceanyotherappliancesontopoftheunit.
•Donotturntheunitupsidedown,onitsside,oratanangleofflevel.
•Ifyourmodelwinecoolerisequippedwithalock,takecaretokeepthekeysawayfromchildren.
•Donotmovetheunitwithoutemptyingthecontentsandsecuringthedoorinaclosedposition.
NOTE: Flammable Refrigerant Used! When handling, moving and using the refrigerator: make sure to avoid either
damaging the refrigerant tubing, or increasing the risk of a leak.
3
TableofContents
ImportantSafetyInformation................................................................................................................2
Introduction............................................................................................................................................4
PartsIdentification.................................................................................................................................5
InstallingYourWineRefrigerator...........................................................................................................6
InstallingYourWineRefrigeratorContinued...............................................................................7
InstallingYourDoorHandleandShelves...............................................................................................8
Operation...............................................................................................................................................9
InternalLight........................................................................................................................................10
Defrosting.............................................................................................................................................10
NormalSounds.....................................................................................................................................11
CleaningandMaintenance...................................................................................................................11
PreparingYourWineRefrigeratorforStorage.....................................................................................11
Troubleshooting...................................................................................................................................12
Specifications........................................................................................................................................13
FirstTimeOperatingInstructions:
Beforeuse,makesureallpackaginglabelsandmaterialsareremovedfromtheunit.Besuretokeeptrackofall
includedpartsandpiecesbeforediscardingpackagingmaterials.Itisadvisedthatyoukeeptheoriginalboxand
packagingmaterialsincaseyouareevertomoveorshiptheapplianceinthefuture.
Allowtheunittostandforatleast24hoursbeforeyouuseit;thisallowsthecoolingcomponentstimetosettlefrom
transit.Theinstructionmanualshouldbereadbeforeuse.
Thisowner’smanualisprovidedforreferenceuseonly.Specificationsmaychangewithoutpriornotice.Refertothe
productlabelonthebackofyourwinerefrigeratorforthelatesttechnicalinformation.
4
Introduction
ThankyouforpurchasingyourAvallonwinerefrigerator.Avallonisdedicatedtodevelopingproductsthatwillenhance
yourlifestylewithsuperiorqualityanddistinctivefeatures.Pleasevisitwww.avallon.comformoreinformationonyour
productandotherAvallonproducts.
Thismanualcontainsimportantinformationregardingtheproperinstallation,use,andmaintenanceofyourwine
refrigerator.Followingthismanualwillensurethatyourproductwillworkatitspeakperformanceandefficiency.
Pleasesavetheoriginalproductpackagingincaseyouneedtosafelytransportyourwinerefrigerator.
ForYourRecords:
Pleasewritedownthemodelnumberandserialnumberbelowforfuturereference.Bothnumbersarelocatedonthe
ratinglabelonthebackofyourunitandareneededtoobtainwarrantyservice.Youmayalsowanttostapleyour
receipttothismanualasitistheproofofyourpurchase,andisalsoneededforserviceunderyourwarranty.
ModelNumber:
SerialNumber:
DateofPurchase:
Tobetterserveyou,pleasedothefollowingbeforecontactingcustomerservice:
•Ifyoureceivedadamagedproduct,immediatelycontacttheretailerordealerthatsoldyoutheproduct.
•Readandfollowthisinstructionmanualcarefullytohelpyouinstall,use,andmaintainyourwinerefrigerator.
•Readthetroubleshootingsectionofthismanualasitwillhelpyoudiagnoseandsolvecommonissues.
•Visitusonthewebathttp://www.avallon.comtodownloadproductguides,additionaltroubleshootingresources,and
up‐to‐dateinformation.
•Ifyouneedwarrantyservice,ourfriendlycustomerservicerepresentativesareavailableviaemailat
5
SeamlessStainlessDoor
Roll‐OutShelf
ControlPanel
DoorHandle
DoorLock
FrontVent
InternalFan
CarbonFilter
LevelingLegs
DoorLock
PartsIdentification
NOTE:Thecarbonfiltershouldbereplacedevery3‐6monthsdependingontheunit’sexposureleveltoodor.Iftheunitis
placedinakitchen,regularreplacementeverythree(3)monthsisideal.
TIP:Gatherthemodelandserialnumberfromtheproductlabelandwritedownbeforeinstallingthewinecooler
.
InternalFan
Thisisanair‐cooledunit
equippedwithan
internalfanthat
maintainsaconsistent
internaltemperature.
CarbonFilter
Abuilt‐incarbonfilter
protectsyourwineby
actingasanaturalbarrier
againstharmfulodors.
6
InstallingYourWineRefrigerator
Thewinerefrigeratorshouldbeinstalledinaccordancewithlocalelectricalcoderequirements.Itshouldalsobeplaced
inalocationthatisstrongenoughtosupportitstotalweight,keepinginmindthatitwillweighsubstantiallymorewhen
fullyloadedthanwhenempty.
Beforeyouplugthewinerefrigeratorintoapowersupply,besuretoletitstanduprightforatleast24hourstoallow
thecompressor’soilstosettle.
WARNING:Usetwoormorepeopletomoveandinstallthewinerefrigerator.Failuretodosocanresultinbackorother
injury.Carefullyremovethepackagingmaterials.Removeanyshippingtapeandgluefromyourwinerefrigerator
beforeusing.Donotusesharpinstruments,rubbingalcohol,flammablefluids,orabrasivecleanerstoremovetapeor
glue.Theseproductscandamagethesurfaceofyourwinerefrigerator.
IMPORTANT:Donotremoveanysafety,warning,orproductinformationlabelsfromyourwinerefrigerator.
TYPESOFINSTALLATION:
Thiswinerefrigeratorhasbeendesignedforfree‐standingorbuilt‐ininstallation.Ineverycase,theremustbeadequate
ventilationandaccessforservice.
Free‐standinginstallation:Afree‐standinginstallationwillallowyoutoinstallthewinerefrigeratorinalmostanyplace
youdesire.Youmustfollowthestatedinstructionsforelectricalrequirementsandlevelingthewinerefrigerator.
Built‐ininstallation:Arecessedinstallationwillallowyoutoinstallthewinecoolerunderacounterorinakitchen
cabinetprovidedtheclearancespacerequirementsaroundthewinecoolerarefollowed.Itisnecessarytoallow
adequateventilationspacearoundtheunit(makesurethereisatleastsomeventilationroomforthebackoftheunit).
Thefollowingadditionalitemsmustbeobserved:
1. Placethewinerefrigeratorinfrontoftheinstallationlocation.
2. Adjustthefeetandplacetheunitflatonthefloororonaplatformdependingonyourinstallationrequirements.
3. Iftheelectricaloutletforthewinerefrigeratorisbehindthecabinet,pluginthewinerefrigerator.
4. Pushthewinerefrigeratorintoposition.
WARNING:DoNOTinstallthewinerefrigeratorbehindaclosedcabinetdoor.
7
InstallingYourWineRefrigeratorContinued
INSTALLING:
Wheninstallingthewinerefrigeratorunderacounter,followtherecommendedspacingdimensionsshown.
•Toensureproperserviceaccessandventilation,allow
between2‐3inchesofclearanceatthebackasshown
inthediagram.
•Theinstallationshouldallowtheunittobepulled
forwardforservicing,ifnecessary.
•Astandardelectricalsupply(115VAConly,60Hz),
properlygroundedinaccordancewithNational
ElectricalCodeandlocalcodesandordinancesis
required.
IMPORTANT: Onceyouarereadytoinstallitina
cabinetordirectlyonthefloor,youmustadjustthe
feettolevelthewinerefrigerator.
LEVELING:
Thewinerefrigeratorshouldbeinstalledonafirmandlevelsurfacethatwillbeabletosupporttheentireweightofa
fullyloadedunit.Itisimportantforthewinerefrigeratortobeleveledinordertoworkproperly.Itcanberaisedor
loweredbyrotatingtheplasticsheathsaroundeachofthefeetonthebottomofthemachine.Ifyoufindthatthe
surfaceisnotlevel,rotatethefeetuntilthewinerefrigeratorbecomeslevel.Youmayneedtomakeseveral
adjustmentstolevelit.Werecommendusingacarpenter’sleveltocheckthemachine.Turnthelevelingfeettothe
righttolowerthatsideoftherefrigerator.Turnthelevelingfeettothelefttoraisethatsideoftherefrigerator.
RECOMMENDEDGROUNDINGMETHOD:
Foryourpersonalsafety,thisappliancemustbegrounded.Itisequippedwithapowersupplycordhavinga3‐prong
groundingplug.Tominimizepossibleshockhazard,thecordmustbepluggedintoamating3‐prongedwallsocket,and
groundedinaccordancewiththeNationalElectricalCodeandlocalcodesandordinances.Ifamatingwallsocketisnot
available,itisthepersonalresponsibilityofthecustomertohaveaproperlygrounded,3‐prongwallreceptacleinstalled
byaqualifiedelectrician.
ELECTRICALSHOCKHAZARD!
•Plugintoagrounded3‐prongoutlet
•Neverremovethegroundingprongfromtheplug
•Neveruseanadaptertobypassthegroundingprong
•DONOTuseanextensioncord
•Failuretofollowtheseinstructionscanresultinfire,electricalshock,orpersonalinjury
Beforeyoumoveyourwinerefrigeratorintoitsfinallocation,itisimportanttomakesureyouhavetheproperelectrical
connection.Astandardelectricalsupply(115V,60Hz),properlygroundedinaccordancewiththeNationalElectrical
Codeandlocalcodesandordinances,isrequired.Itisrecommendedthataseparatecircuit,servingonlyyourwine
refrigerator,beprovided.Usereceptaclesthatcannotbeturnedoffbyaswitchorpullchain.
Thefuse(orcircuitbreaker)sizeshouldbe15Amps.
8
InstallingYourDoorHandleandShelves
INSTALLINGTHEDOORHANDLE:
1. Openthedoorandcarefullypullthedoorgasketaroundtheareawherethehandleistobeinstalled.
2. InserteachPhillipsheadscrewthroughthegasketsideofthedooruntilthescrewpassthroughthedoor.
3. AlignthehandlewiththescrewsandtightenusingaPhillipsheadscrewdriveruntilthehandleisflushagainstthe
doorframe.CAUTION:Donotover‐tightenthescrewsasthismaycausedamagetothehandleortothestainless
steeldoor.
4. Carefullypressthedoorgasketintoitsoriginalposition.
INSTALLINGTHESHELVES:
1. Openthedoorcompletely.
2. Pushtheshelftracksaffixedtothewallsoftheinnercabinettotherearoftheunitsothatthetracksarefullyseated
insidethecoolercompartment.
3. Lineuptherailsaffixedtotheshelfwiththecorrespondingwinecoolertracksattachedtotheinnercabinetwalls.
4. Pushthefrontoftheshelfinwardsevenlyuntiltheshelfrestsfullyinsideoftheunitandyouareabletoclosethe
door.
5. Theshelfshouldglidesmoothlybackandforth.Ifitdoesnot,youmayneedtoremoveitandstartover.
REMOVINGTHESHELVES:
1. Openthedoorcompletely.
2. Removeallofthecontentsloadedontheshelf,ifapplicable.
3. Pulltheshelftowardsyourselfuntilitisfullyextendedoutward.
4. Theshelfhasplasticpostsonbothsidesasindicatedinthediagrambelow.Whilefacingtheunit,presstheplastic
postontherightsidedownwhilepullingupontheleftplasticpost.Youmaychoosetodothisbyhandorbyusinga
flatheadscrewdriver.
5. Evenlypullouttheshelffromthetrackuntilitiscompletelyremovedfromtheinnercompartment.
TIP:Topreventdamagingthedoorgasket,makesuretoopenthedoorfullybeforepullingtheshelvesoutoftheirtrack.
9
Operation
INSTALLATIONCHECKLISTBEFOREOPERATION:
1. Haveallpackingmaterialsandtapebeenremovedfromtheinteriorandexteriorofthewinerefrigerator?
2. Havetheinstallationinstructionsbeenfollowed,includingconnectingthemachinetoelectricity?
3. Haspropergroundingbeeninstalledforthewinerefrigerator?
4. Hasthemachinebeenleveled?
5. Isthewinerefrigeratorinasitewheretheambienttemperatureisbetween50ºFand90ºFallyearround?
6. Isthereaclearanceofatleast2to3”attherearforproperaircirculation?
USINGYOURCONTROLPANEL:
Thiswinecoolerhasatemperaturerangefrom40°Fto65°F.
Theupperzonehasatemperaturerangeof54°Fto65°F.
Thelowerzonehasatemperaturerangeof40°Fto54°F.
POWERBUTTON:Pressandholddownforthreesecondstopoweryouruniton.Oncepressed
the“Run”indicatorlightwillilluminatetoindicatetheunitisonandrunning.Pressandholdfor
threesecondsagainandtheunitwillpoweroffandthe“Run”Indicatorlightwillturnoff.
UPPERZONETEMPERATURE:Tochangethetemperatureofyourlowerzone,pressthisbuttonto
lowerthetemperaturebyone(1)degreeincrements.Oncethetemperaturesettingissetat54°
pressingagainwillbringitbackto65°.
LOWERZONETEMPERATURE:Tochangethetemperatureofyourupperzone,pressthisbutton
tolowerthetemperaturebyone(1)degreeincrements.Oncethetemperaturesettingissetat
40°pressingagainwillbringitbackto54°.
INTERIORLIGHT:Pressthisbuttontocyclethroughthedifferentinternallightsettings.There
arefourlightsettings‐ConstantBlue,ConstantWhite,AutomaticBlue,andAutomaticWhite.
Pressthisbuttontocyclethroughthedifferentlightsettings.Thelightswillfadeastheunit
transitionsbetweenlightsettings.Pressandholdthisbuttonforthreesecondstoturnthelight
on/off.Openandclosethedoortocheckthecolorandthecurrentsetting.Pleaserefertothe
“InternalLight”sectiononthenextpageforfurtherdetail.
NOTE:PressingandholdingtheUpperZoneandLowerZoneTemperaturebuttonsatthesametimewillswitchthe
temperaturedisplayfrom°Fto°C
TIP:Ifyoupoweredofftheunit,pleasewaitatleastfive(5)minutesbeforepoweringitbackon.
WARNING:Allowatleast24hoursforyourwinecoolertorunbeforestoringyourwinesandtoallowthetemperatureto
acclimate.Whetheryourwinecoolercanreachtheactualsettemperaturedependsontheambientenvironmental
conditions.
10
InternalLight
Thisrefrigeratorisequippedwithtopandsideinternallightsthatcanbeeitherblueorwhiteincolor–whicheveryou
choose.Additionally,becauseitcomeswithaglassdoor,thelightshavetheoptiontodisplayintwodifferentmodes:
ConstantModeandAutomaticMode.
CONSTANTMODE:Theinternallightswillstayilluminatedwhetherthedoorisopenorclosed.
AUTOMATICMODE:Theinternallightswillilluminatewhenthedoorisopenandturnoffwhenthedoorisclosed.
Witheachpressofthelightbutton,theunitwillprogressthroughthelightsettingcycleseenbelow.
NOTE:Weruntesteveryunitthatweproduceinourfactory.Becauseofthis,yourmodelmaydefaulttoanyofthe
abovesettingsoutofthebox.Simplycyclethroughtheprogressionuntilyoureachyourdesiredlightsetting
.
Thelights
willreturntotheConstantBlueSettingaftertheAutomaticWhitesetting,thusstartingbackatthebeginningofthe
progression.
TIP:ClosethedoortodetermineifthelightiscurrentlyinConstantModeorAutomaticMode.
Holdingthelightbuttonforthreesecondswillturnthelightsonandoff.Ifyoupowerthelightsofftheywillremainoff,
evenwhenthedoorisopen.Holdthelightbuttonforthreesecondsagaintoturnthelightsbackon.
Theautomaticlightfeatureistriggeredbyasensorlocatedonthefrontvent.Thissensorallowstherefrigeratorto
recognizewhenthedoorisopenorclosed.
Defrosting
Notethatundermostrefrigeratingsettings,theunitwillautomaticallydefrostundermostambientconditions.
However,oncoldersettings,somefrostmaybuildup.Additionally,themorehumidtheambientconditions,themore
frostmaybuildup.Keepthedoorclosedasmuchaspossibleandavoidopeningthedoorunnecessarilytominimize
frostbuild‐up.
Iffrostispreventingthedoorfromclosingproperly,youmayneedtopowertheunitoffuntilthefrostmelts.Useasoft
absorbenttoweltodrytheunit.
WARNING:Neverattempttoremovefrostwithasharpobject.
11
NormalSounds
Yournewwinerefrigeratormaymakesoundsthatarenotfamiliartoyou.Mostofthenewsoundsarenormal.Hard
surfaceslikethefloororwallscanmakethesoundsseemlouderthantheyactuallyare.Thefollowingdescribesthe
kindsofsoundsthatmightbenewtoyouandwhatmaybemakingthem.
•Rattlingnoisesmaycomefromtheflowoftherefrigerantorthewaterline.
•Itemsstoredontopofthewinerefrigeratorcanalsomakenoises.
•Thehighefficiencycompressormaymakeapulsatingorhigh‐pitchedsound.
•Theinternalfanwillrunfrequentlytocreateaconsistentinternaltemperatureenvironment.
•Waterrunningfromtheevaporatortothewaterbinmaymakeasplashingsound.
•Aseachcycleends,youmayhearagurglingsoundduetotherefrigerantflowinginyourwinerefrigerator.
•Youmayhearairbeingforcedoverthecondenserbythecondenserfan.
CleaningandMaintenance
Periodiccleaningandpropermaintenancewillensureefficiency,topperformance,andlonglife.
INTERIORCLEANING:
1. Disconnectpowertotheunit.
2. Openthedoorandremovethecontentsandshelves.
3. Waituntiltheunitdefrosts.
4. Withacleancloth,wipedowntheinterioroftheunit.
5. Reinserttheshelvesandbeverages.
6. Reconnectpowertotheunit.
EXTERIORCLEANING:
Thedoorandcabinetmaybecleanedwithamilddetergentandlukewarmwatersolutionsuchastwo(2)tablespoonsof
bakingsodatoone(1)quartofwater.Donotusesolventbasedorabrasivecleaners.Useasoftspongeandrinsewith
cleanwater.Wipewithasoftcleantoweltopreventwaterspotting.Ifthedoorpanelisstainlesssteel,itcandiscolor
whenexposedtochlorinegasandmoisture.Cleanstainlesssteelwithaclothdampenedwithamilddetergentand
warmwatersolution.Neveruseanabrasiveorcausticcleaningagent.
PreparingYourWineRefrigeratorforStorage
Ifthewinerefrigeratorwillnotbeusedforalongtime,oristobemovedtoanotherplace,itwillbenecessarytodefrost
theunitanddrytheinterior.
1. Disconnectthecoolerfromthepowersupplybyremovingthepowerplugfromthewallsocket.
2. Leavethedooropentoallowforaircirculationandtopreventmold,mildewandunpleasantsmells.
3. Oncetheinteriorisdryandcleantheunitwillbereadyforstorage.
CAUTION:Storetheunitoutofthereachofchildren.Ifyouhavechildren,youmaywanttotakeadditionalprecautions
suchasremovingthedoortopreventachildfrombeingtrappedinsidethecooler.
IMPORTANT:DoNOTtouchthepowerplugwhenyourhandsarewet.NEVERunplugtheunitbypullingtheplug.
12
Troubleshooting
ISSUEPOSSIBLECAUSESOLUTION
Thewinecoolerturnson
andofffrequently.
•Theroomtemperatureishigherthanthe
recommendedambientenvironment.
•Thedoorisbeingopenedoften.
•Thedoorisnotcompletelyclosed.
•Thedoorgasketisnotsealingproperly.
•Thecoolerdoesnothavethesuggested
ventilation.
•Runthecoolerattheappropriateambient
temperature.
•Minimizethenumberoftimesthedooris
opened.
•Makesurethedooriscompletelyclosed.
•Makesurethedoorgasketisproperly
sealed.
•Readandfollowthe“InstallationClearance
Requirements”section.
Thewinecoolerdoes
notturnon.
•Thereisapowerfailure.
•Thecoolerisnotpluggedin.
•Ahousefusehasblownorthecircuit
breakeristripped.
•Ensurethecoolerispluggedinandthe
poweroutlethaspower.
•Plugtheunitintoapoweroutletthathas
sufficientamperage.
•Replacethebrokenfuseinyourfuseboxor
resetthebreaker.
Thewinecoolerwillnot
reachthedesired
temperature.
•Thecoolerisplacedtooclosetoaheat
source.
•Thecoolerdoesnothavesufficient
ventilation.
•Thedoorisopenedtoofrequentlyorfor
longperiodsoftime.
•Keepthecoolerawayfromdirectsunlightor
otherheatsources.
•Readandfollowthe“InstallationClearance
Requirements”section.
•Closethedoortightlyanddonotopenthe
doortoofrequentlyorforlongperiodsof
time.
Thewinecooleris
makingstrangenoises.
•Certainsoundsarenormal
•Theunitisnotleveloristouching
anotherappliance.
•Readthe“NormalSounds”section.
•Checktomakesurethatthecoolerislevel
andthatitisnotincontactwithanother
applianceorfurniture.
Thebodyofthewine
refrigeratoris
electrified.
•Theunitisnotproperlygrounded.•Contactyourlocalelectriciantotestyour
electricalgroundingsystem.
Frostisforminginthe
winecooler.
•Theenvironmentishumid.
•Theambienttemperatureistoolow.
•Thedoorisbeingopenedtoofrequently.
•Thoughtheunitusesan“auto‐defrost”
system,undercertainconditions,manual
defrostingmayberequired.Iffrostbuildsup,
youcantryrunningthecooleronawarmer
temperaturesetting,minimizingthenumber
oftimesyouopenthedoor,orunpluggingthe
unittoallowthefrosttomelt.
Thedoorwillnotshut
properly.
•Thecoolerisnotlevel.
•Thedoorgasketisdirty.
•Thedoorgasketisnotinstalledcorrectly.
•Theshelvesareincorrectlyinstalled.
•Makesurethecoolerisonalevelsurface.
•Cleanthedoorgasket.
•Makesurethedoorgasketisproperly
installed.
•Makesuretocorrectlyinstalltheshelves.
13
Specifications
DESCRIPTIONOFPRODUCTDualZoneBuilt‐InWineRefrigerator
MODELAWC151DZ
VOLTAGE/FREQUENCYAC115/60Hz
AMPERAGE0.93A
INPUTPOWER100W
COLORBlackCabinetwithStainlessSteelDoor
STORAGECAPACITY23Bottles
REFRIGERANTR600a,1.06oz.
TEMPERATURERANGE40to65F°
DIMENSIONS
(HEIGHTXWIDTHXDEPTH)
34.2”X15”X23.7”
WEIGHT99Pounds
NOTE:Technicaldataandperformanceinformationisprovidedforreferenceonly.
Specificationsaresubjecttochange.Checktheratinglabelonthewinerefrigeratorforthemostaccurateinformation.
*Storagecapacitybasedstandard750ml.winebottles.
WHAT IS COVERED:
One Year Parts and Labor: For one year from the date of original
retail purchase, Avallon will repair or replace any part free of charge
including labor that fails due to a defect in materials or workmanship.
Avallon will be responsible for all transportation costs for the first 90
days from original purchase date, after 90 days the consumer will be
responsible. Labor will be performed free of charge at an authorized
Avallon repair facility and will supply new, rebuilt, or refurbished parts
free of charge. Avallon may request a defective part be returned in
exchange for the replacement part. After the 12 month period,
Avallon will no longer be responsible for labor charges incurred or
replacement parts. All defective products and parts covered by this
warranty will be repaired or replaced on a mail-in basis to an Avallon
authorized repair facility.
Five Year Limited Warranty (Compressor– Labor Not Included): In the
second through fifth year from the date of original retail purchase,
Avallon will replace the compressor free of charge. The consumer will
be responsible for all transportation and labor costs. Avallon will sup-
ply a new, rebuilt, or refurbished compressor and may request for the
defective compressor to be returned in exchange. This limited 5-Year
warranty is for the compressor only and does not include labor.
All warranties apply to the original purchaser only, and only covers
defects in workmanship experienced during operation of the product
under normal service, maintenance, and usage conditions. This war-
ranty applies to the purchase and use of this product in residential
settings within the United States of America. All products and parts
replaced by Avallon under warranty service become the property of
Avallon. All defective products and parts covered by this warranty
will be repaired or replaced on a mail-in basis to an Avallon author-
ized repair facility.
Exceptions: Commercial or Rental Use Warranty: 90 days labor and
parts from date of original purchase. No other warranty applies.
WHAT IS NOT COVERED- The following limitations apply to the
coverage of this warranty. This warranty does not cover:
Labor charges for installation, setup or training to use the
product. Shipping damage, and any damage caused by
improper packaging for shipment to an authorized service
center, and any damaged caused by improper voltage or
any other misuse, including abnormal service, handling, or
usage. Cosmetic damage such as scratches and dents. Nor-
mal wear and tear on parts or replacement of parts designed
to be replaced, e.g. filters, cartridges, batteries. Service trips
to deliver, pick-up, or repair, install the product, or to instruct
in proper usage of the product. Damages or operating prob-
lems resulting from misuse, abuse, operation outside environ-
mental specifications, uses contrary to instructions provided in
the owner’s manual, accidents, acts of God, vermin, fire,
flood, improper installation, unauthorized service, mainte-
nance negligence, unauthorized installation or modification,
or commercial use. Labor, service transportation, and ship-
ping charges for the removal and replacement of defective
parts, beyond the initial 12 month period. Products that have
been modified to perform outside of specifications without
the priorwritten permission of Avallon. Products lost in ship-
ment, or theft. Products sold AS IS or from an unauthorized
reseller. Products that have had their serial numbers removed,
defaced, or with serial numbers that have been invalidated.
Damage from other than normal household use. Replace-
ment or repair of household fuses, circuit breakers, wiring or
plumbing. Damage to personal property from use of product.
Damage from service other than from an authorized Avallon-
repair facility. Hoses, knobs, lint trays and all attachments,
accessories and disposable parts. Any service charges not
specifically identified as normal such as normal service area
or hours. Any special or consequential damages arising out of
the use of the product.
ƻNjŸ_ȖOǼɟNjNjŘǼɴ
OBTAINING WARRANTY SERVICE: If you believe your product is defective, contact Avallon Customer Support for troubleshooting assis-
tance and warranty service at www.avallon.com or call 1-866-471-7427. Before contacting Customer Support you are required to have
your model number, serial number and proof of purchase available upon request. Once an Avallon authorized representative has con-
firmed that your product is defective and eligible for warranty service, the product must be returned to an Avallon authorized repair
facility. Avallon is not responsible for damage resulting from shipper mishandling or improper packaging. Do not return a defective prod-
uct to the place of purchase. Products received without a return authorization number will be refused.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY
PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNI-
TIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT,
TORT, OR OTHERWISE. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
This product is warranted by Avallon and is subject to any conditions set forth as follows:
ɟNjNjŘǼɴƻsNjÞŸ_ ɚĶĶŸŘɠÞĶĶEsNjsǣƼŸŘǣÞEĶs¯ŸNjʲ NŸŘǣȖŎsNjɠÞĶĶEsNjsǣƼŸŘǣÞEĶs¯ŸNjʲ
1st year All costs for repairing or replacing parts and/or unit which proves to
be defective. All transportation costs in the first 90 days. All transportation costs after 90 days.
Limited 2nd-5th year
(compressor only) Repairing or replacing any compressor which proves to be
defective. (Labor not included) Labor and all transportation costs.
AVALLON GLOBAL, LLC
3736 Bee Cave Rd.
STE 1 #188
West Lake Hills, TX 78746
Toll Free: 1-866-471-7427
Web: http://www.avallon.com
E-mail: service@avallon.com
Product contents and specifications may change without notice.
Copyright © 2015 Avallon Gobal, LLC
This manual suits for next models
1
Table of contents
Other Avallon Kitchen Appliance manuals
Avallon
Avallon AWC241DZLH User manual
Avallon
Avallon AWBC242GGFDBLSS User manual
Avallon
Avallon AWC152SZRH User manual
Avallon
Avallon AWC241FD User manual
Avallon
Avallon AWC241DZRH User manual
Avallon
Avallon AWC241SZ User manual
Avallon
Avallon AWC241TDZLH User manual
Avallon
Avallon AWBV54152 User manual
Avallon
Avallon AWC241TSZRH User manual
Avallon
Avallon AWBC241GGFDBLSS User manual
