Avalue Technology EBM-LX800 User manual

Part No. E2017551201R
EBM-LX800
5.25" AMD Geode™ LX800 Mini Module
Quick Installation Guide
2nd Ed – 7 December 2009
To receive the latest version of the user’s manual; please visit our Web site
at:
http://www.avalue.com.tw
Copyright Notice
Copyright ©2009-2010 Avalue Technology Inc., ALL RIGHTS RESERVED.

EBM-LX800 Quick Installation Guide
2 EBM-LX800 Quick Installation Guide
Contents
1. Getting Started............................................................................................................3
1.1 Safety Precautions ....................................................................................................3
1.2 Packing List...............................................................................................................3
2. Hardware Configuration.............................................................................................4
2.1 Product Overview......................................................................................................5
2.2 Jumper and Connector List .......................................................................................6
2.3 Setting Jumpers & Connectors .................................................................................8
2.3.1 AT/ATX Power Select (JAT/ATX)..................................................................................................... 8
2.3.2 Clear CMOS (JBAT)......................................................................................................................... 8
2.3.3 JCOM1-4 Pin 8 Signal Select (JRI1)................................................................................................ 9
2.3.4 Serial Port 2 Connector in RS-422/485 Mode (JRS422) ................................................................. 9
2.3.5 Auxiliary Power Connector (PWR2) ............................................................................................... 10
2.3.6 Audio Input Connector (JAUDIO)................................................................................................... 10
2.3.7 LCD Inverter Connector (JBKL) ..................................................................................................... 11
2.3.8 CD-ROM Audio Input Connector (JCDIN)...................................................................................... 12
2.3.9 CF Master/Slave Selecting Connector (JCFSET).......................................................................... 12
2.3.10 Serial Port 1, 2, 3, 4 Connector (JCOM1-4)............................................................................... 13
2.3.11 Serial Port 2 Connector in RS-232 Mode (JCOM1-4, Pin 11-20) .............................................. 14
2.3.12 Serial Port 5, 6 Connector (JCOM5, JCOM6)............................................................................ 14
2.3.13 Digital Input/Output Connector (JDIO)....................................................................................... 15
2.3.14 Front Panel Connector (JFP) .....................................................................................................16
2.3.15 IrDA Connector (JIR) ................................................................................................................. 16
2.3.16 Keyboard & Mouse Connector (JKBMS) ................................................................................... 17
2.3.17 LVDS Connector (JLVDS) ......................................................................................................... 18
2.3.18 Serial Port 2 Connector in RS-422/485 Mode (JRS422) ........................................................... 19
2.3.19 TFT Panel Connector (JTFT)..................................................................................................... 20
2.3.20 USB Connector 0 & 1, 2 & 3 (JUSB1, JUSB2) .......................................................................... 22
2.3.21 VGA Connector (JVGA) ............................................................................................................. 22
2.3.22 LCD Backlight Brightness Adjustment Connector (JVR) ........................................................... 23
2.3.23 Parallel Port Connector (LPT).................................................................................................... 23
2.3.24 Power Input Connector (PWR1) ................................................................................................ 24
2.3.25 Power Input Connector (PWR3) ................................................................................................ 24

Quick Installation Guide
EBM-LX800 Quick Installation Guide
3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z1 x EBM-LX800 AMD Geode™ LX800 Mini Module
z1 x Quick Installation Guide for EBM-LX800
z1 x DVD-ROM or CD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities

EBM-LX800 Quick Installation Guide
4 EBM-LX800 Quick Installation Guide
2. Hardware
Configuration

Quick Installation Guide
EBM-LX800 Quick Installation Guide
5
2.1 Product Overview

EBM-LX800 Quick Installation Guide
6 EBM-LX800 Quick Installation Guide
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board's jumpers and connectors.
Jumpers
Label Function Note
JAT/ATX AT/ATX power select 3 x 1 header, pitch 2.54mm
JBAT Clear CMOS 3 x 1 header, pitch 2.54mm
JRI1 JCOM1-4 pin 8 signal select 3 x 2 header, pitch 2.54mm
JPWR1 (Reserved) 3 x 1 header, pitch 2.54mm
PWR2 Auxiliary power select 3 x 1 wafer, pitch 2.54mm

Quick Installation Guide
EBM-LX800 Quick Installation Guide
7
Connectors
Label Function Note
CF Compact Flash card connector
DIMM DDR DIMM 2.5V STD 184-pin DDR DIMM socket
FLP Floppy connector 17x 2boxheader, pitch 2.54 mm
IDE1 Primary IDE connector 20 x 2 box header, pitch 2.0 mm
IDE2 Secondary IDE connector 20 x 2 box header, pitch 2.0 mm
JAUDIO Audio connector 8 x 2 box header, pitch 2.54mm
JBKL LCD inverter connector 5 x 1 wafer, pitch 2.0mm
JCDIN CD-ROM audio input connector 4 x 1 wafer, pitch 2.0mm
JCFSET CF Master/Slave selecting connector 3 x 1 header, pitch 2.54mm
COM1-4 Serial port 1, 2, 3, 4 connector 20x 2boxheader, pitch 2.54mm
JCOM5 Serial port 5 connector 5 x 2 box header, pitch 2.54mm
JCOM6 Serial port 6 connector 5 x 2 box header, pitch 2.54mm
JDIO Digital I/O connector 10 x 2 header, pitch 2.54mm
JFP Front panel connector 8 x 2 header, pitch 2.54mm
JIR IrDA connector 5 x 1 header, pitch 2.54mm
JKBMS Keyboard & mouse connector 4 x 2 header, pitch 2.54mm
JLVDS LVDS connector HIROSE DF13-40DP-1.25V
JRS422 Serial Port 2 Connector in RS-422/485
mode
3 x 2 header, pitch 2.54mm
JTFT TFT panel connector HIROSE DF13-40DP-1.25V
JUSB1 USB connector 0 & 1 5 x 2 header, pitch 2.54mm
JUSB2 USB connector 2 & 3 5 x 2 header, pitch 2.54mm
JVGA VGA connector 8 x 2 box header, pitch 2.54mm
JVR LCD backlight brightness adjustment
connector
3 x 1 header, pitch 2.54mm
LAN RJ-45 Ethernet
LPT Parallel port connector 13x 2boxheader, pitch 2.54 mm
PC/104 PC/104 connector
PCI PCI slot
PWR1 Power input connector
PWR3 Power input connector
SATA1 Serial ATA connector 1
SATA2 Serial ATA connector 2

EBM-LX800 Quick Installation Guide
8 EBM-LX800 Quick Installation Guide
2.3 Setting Jumpers & Connectors
2.3.1 AT/ATX Power Select (JAT/ATX)
AT*
ATX
* Default
2.3.2 Clear CMOS (JBAT)
Protect*
Clear CMOS
* Default

Quick Installation Guide
EBM-LX800 Quick Installation Guide
9
2.3.3 JCOM1-4 Pin 8 Signal Select (JRI1)
* Default
Ring*
+5V
+12V
2.3.4 Serial Port 2 Connector in RS-422/485 Mode (JRS422)
Signal PIN PIN Signal
422/485TXC- 1 2 485RXC-
422/485TXC+ 3 4 485RXC+
+5V 5 6 GND

EBM-LX800 Quick Installation Guide
10 EBM-LX800 Quick Installation Guide
2.3.5 Auxiliary Power Connector (PWR2)
* Default
Signal PIN
PSON 1
+5V 2
5VSB 3
AT*
ATX
2.3.6 Audio Input Connector (JAUDIO)
Signal PIN PIN Signal
Mic-In 1 2 Mic Bais
GND 3 4 GND
Line-Out L 5 6 Line-Out R
NC 7 8 NC
Line-In L 9 10 Line-In R
GND 11 12 NC
GND 13 14 NC
GND 15 16 NC

Quick Installation Guide
EBM-LX800 Quick Installation Guide
11
2.3.7 LCD Inverter Connector (JBKL)
Signal PIN
+12V 1
GND 2
ENBKL 3
VR 4
+5V 5
Note:
For inverters with adjustable Backlight function, it is possible to control the
LCD brightness through the VR signal controlled by JVR. Please see the
JVR section for detailed circuit information.
2.3.7.1 Signal Description – LCD Inverter Connector (JBKL)
Signal Signal Description
VR Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W)
ENBKL LCD backlight ON/OFF control signal

EBM-LX800 Quick Installation Guide
12 EBM-LX800 Quick Installation Guide
2.3.8 CD-ROM Audio Input Connector (JCDIN)
Signal PIN
NC 1
CD_L 2
GND 3
CD_R 4
2.3.9 CF Master/Slave Selecting Connector (JCFSET)
* Default
Master*
Slave
Signal PIN
3.3V 1
Master 2
GND 3

Quick Installation Guide
EBM-LX800 Quick Installation Guide
13
2.3.10 Serial Port 1, 2, 3, 4 Connector (JCOM1-4)
Serial Port 1 (Pin 1-10)
Signal PIN PIN Signal
DCD1 1 2 DSR1
RxD1 3 4 RTS1
TxD1 5 6 CTS1
DTR1 7 8 RI1/+5V/+12V
GND 9 10 NC
Serial Port 3 (Pin 21-30)
Signal PIN PIN Signal
DCD3 21 22 DSR3
SIN3 23 24 RTS3
SOUT3 25 26 CTS3
DTR3 27 28 RI3/+5V/+12V
GND 29 30 NC
Serial Port 4 (Pin 31-40)
Signal PIN PIN Signal
DCD4 31 32 DSR4
RxD4 33 34 RTS4
SOUT4 35 36 CTS4
DTR4 37 38 RI4/+5V/+12V
GND 39 40 NC

EBM-LX800 Quick Installation Guide
14 EBM-LX800 Quick Installation Guide
2.3.11 Serial Port 2 Connector in RS-232 Mode (JCOM1-4, Pin 11-20)
Signal PIN PIN Signal
DCD2 11 12 DSR2
RxD2 13 14 RTS2
TxD2 15 16 CTS2
DTR2 17 18 RI2/+5V/+12V
GND 19 20 NC
2.3.12 Serial Port 5, 6 Connector (JCOM5, JCOM6)
Signal PIN PIN Signal
DCD# 1 2 SIN
SOUT 3 4 DTR#
GND 5 6 DSR#
RTS# 7 8 CTS#
RIC# 9 10 NC
JCOM5
JCOM6

Quick Installation Guide
EBM-LX800 Quick Installation Guide
15
2.3.13 Digital Input/Output Connector (JDIO)
Signal PIN PIN Signal
DIO20 1 2 DIO10
DIO21 3 4 DIO11
DIO22 5 6 DIO12
DIO23 7 8 DIO13
DIO24 9 10 DIO14
DIO25 11 12 DIO15
DIO26 13 14 DIO16
DIO27 15 16 DIO17
SMB_CLK_S 17 18 SMB_DATA_S
GND 19 20 +5V

EBM-LX800 Quick Installation Guide
16 EBM-LX800 Quick Installation Guide
2.3.14 Front Panel Connector (JFP)
Signal PIN PIN Signal
RESET 1 2 5VSB
GND 3 4 GND
+5VSLED 5 6 +5V
HD_LED 7 8 GND
PWR_BTN 9 10 +5V
GND 11 12 +5V
LAN_RX/TX 13 14 3.3V
LAN_SPD 15 16 3.3V
2.3.15 IrDA Connector (JIR)
Signal PIN
+5V 1
CIRRX 2
IRRX 3
GND 4
IRTX 5

Quick Installation Guide
EBM-LX800 Quick Installation Guide
17
2.3.16 Keyboard & Mouse Connector (JKBMS)
Signal PIN PIN Signal
KDAT 1 2 KCLK
GND 3 4 +5V
MDAT 5 6 MCLK
NC 7 8 NC

EBM-LX800 Quick Installation Guide
18 EBM-LX800 Quick Installation Guide
2.3.17 LVDS Connector (JLVDS)
Signal PIN PIN Signal
+5V 2 1 +3.3V
+5V 4 3 +3.3V
I2C_DAT 6 5 I2C_CLK
GND 8 7 GND
Txout0 10 9 Txout1
Txout0# 12 11 Txout1#
GND 14 13 GND
Txout2 16 15 Txout3
Txout2# 18 17 Txout3#
GND 20 19 GND
NC 22 21 NC
NC 24 23 NC
GND 26 25 GND
NC 28 27 NC
NC 30 29 NC
GND 32 31 GND
Txclk 34 33 NC
Txclk# 36 35 NC
GND 38 37 GND
+12V 40 39 +12V
2.3.17.1 Signal Description – LVDS Connecter (JLVDS)
Signal Description
I2C_DAT, I2C_CLK
I2C interface for panel parameter EEPROM. This EERPOM is mounted on the
LVDS receiver. The data in the EEPROM allows the EXT module to automatically
set the proper timing parameters for a specific LCD panel.

Quick Installation Guide
EBM-LX800 Quick Installation Guide
19
2.3.18 Serial Port 2 Connector in RS-422/485 Mode (JRS422)
Signal PIN PIN Signal
422/485TXC- 1 2 485RXC-
422/485TXC+ 3 4 485RXC+
+5V 5 6 GND

EBM-LX800 Quick Installation Guide
20 EBM-LX800 Quick Installation Guide
2.3.19 TFT Panel Connector (JTFT)
Signal PIN PIN Signal
+5V 2 1 +5V
GND 4 3 GND
+3.3V 6 5 +3.3V
GND 8 7 NC
P1 10 9 P0
P3 12 11 P2
P5 14 13 P4
P7 16 15 P6
P9 18 17 P8
P11 20 19 P10
P13 22 21 P12
P15 24 23 P14
P17 26 25 P16
P19 28 27 P18
P21 30 29 P20
P23 32 31 P22
GND 34 33 GND
FLM 36 35 SHFCLK
LP 38 37 M
NC 40 39 ENBKL
2.3.19.1 Signal Description – TFT Panel Connector (JTFT)
Signal Description
P [0:23] Flat panel data output for 18/24 bit TFT flat panels. Refer to table below for
configurations for various panel types. The flat panel data and control outputs are
all on-board controlled for secure power-on/off sequencing
SHFCLK Shift Clock. Pixel clock for flat panel data
LP Flat panel equivalent of HSYNC (horizontal synchronization)
FLM Flat panel equivalent of VSYNC (vertical synchronization)
M Multipurpose signal, function depends on panel type. May be used as AC drive
control signal or as BLANK# or Display Enable signal
ENBKL Enable backlight signal. This signal is controlled as a part of the panel power
sequencing
