Avalue Technology EMX-H110TC User manual

Part No. E2047EMTC01R
EMX-H110TC
Intel® 6th Generation Core™ LGA1151 Socket Processors
with Intel® H110 Mini ITX Motherboard
User’s Manual
2nd Ed –08 December 2017

EMX-H110TC User’s Manual
2 EMX-H110TC User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2017 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

User’s Manual
EMX-H110TC User’s Manual
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

EMX-H110TC User’s Manual
4 EMX-H110TC User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU type and speed, Avalue’s products model name, hardware & BIOS
revision number, other hardware and software used, etc.) Note anything
abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material
authorization) number from your dealer. This allows us to process your good
return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the
purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.
Warning: Battery Notice
Important! To prolong battery life, please avoid adhering the battery to possible source of
heat.
重要! 為了延長電池壽命，請避免電池附著在有可能出現高溫的地方
バッテリ寿命を延長するために、高温の付近にバッテリーを付着することを避けてくださ
い。

User’s Manual
EMX-H110TC User’s Manual
5
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions....................................................................................................8
1.2 Packing List...............................................................................................................8
1.3 Document Amendment History .................................................................................9
1.4 Manual Objectives...................................................................................................10
1.5 System Specifications.............................................................................................11
1.6 Architecture Overview—Block Diagram..................................................................15
2. Hardware Configuration...........................................................................................16
2.1 Product Overview....................................................................................................17
2.2 Jumper and Connector List.....................................................................................18
2.3 Setting Jumpers & Connectors ...............................................................................20
2.3.1 Serial port 1/2 pin9 signal select (JC11/21) ................................................................................... 20
2.3.2 Serial port 2 RS-232/422/485 mode selector (JC22)..................................................................... 20
2.3.3 Panel Type control selector (J1/2/3/4) ........................................................................................... 21
2.3.4 AT/ATX Input power select (AT) .................................................................................................... 22
2.3.5 Clear CMOS (CLR_CMOS1).......................................................................................................... 22
2.3.6 Flash BIOS ME connector (JME)................................................................................................... 23
2.3.7 LVDS power selection (JPWR_LVDS1)......................................................................................... 23
2.3.8 Speaker connector (JSPK1)........................................................................................................... 24
2.3.9 Serial port 1/2 connector (JCOM1/2) ............................................................................................. 24
2.3.10 Front Panel connector (F_PANEL1).......................................................................................... 25
2.3.11 USB 3.0 connector (F_USB1).................................................................................................... 25
2.3.12 USB 2.0 connector (F_USB2).................................................................................................... 26
2.3.13 Front Audio connector (F_AUDIO1) .......................................................................................... 26
2.3.14 System fan connector (SFAN1)................................................................................................. 27
2.3.15 CPU fan connector (CFAN1) ..................................................................................................... 27
2.3.16 SATA power connector 1(JSATA_PWR1)................................................................................. 28
2.3.17 SATA power connector 2 (JSATA_PWR2)................................................................................ 28
2.3.18 Power connector (DC12V1)....................................................................................................... 29
2.3.19 Inverter control connector (IVCN1)............................................................................................ 29
2.3.20 LVDS connector (LVDS1).......................................................................................................... 30
2.3.21 LVDS backlight brightness adjustment (BKCL1)....................................................................... 30
2.3.22 VGA connector (JVGA1)............................................................................................................ 31
2.3.23 Battery connector (BAT1) .......................................................................................................... 31
3.BIOS Setup....................................................................................................................32
3.1 Introduction .............................................................................................................33

EMX-H110TC User’s Manual
6 EMX-H110TC User’s Manual
3.2 Starting Setup .........................................................................................................33
3.3 Using Setup ............................................................................................................34
3.4 Getting Help............................................................................................................35
3.5 In Case of Problems................................................................................................35
3.6 BIOS setup..............................................................................................................36
3.6.1 Main Menu...................................................................................................................................... 36
3.6.1.1 System Language.................................................................................................................. 37
3.6.1.2 System Date.......................................................................................................................... 37
3.6.1.3 System Time.......................................................................................................................... 37
3.6.2 Advanced Menu ............................................................................................................................. 37
3.6.2.1 APCI Settings ........................................................................................................................ 38
3.6.2.2 IT8784 Super IO Configuration.............................................................................................. 39
3.6.2.2.1 Serial Port 1 Configuration .................................................................................................... 39
3.6.2.2.2 Serial Port 2 Configuration .................................................................................................... 40
3.6.2.3 Hardware Monitor.................................................................................................................. 40
3.6.2.4 CPU Configuration................................................................................................................. 41
3.6.2.5 SATA Configuration............................................................................................................... 42
3.6.2.6 Network Stack Configuration................................................................................................. 43
3.6.2.7 CSM Configuration ................................................................................................................ 43
3.6.2.8 USB Configuration................................................................................................................. 44
3.6.3 Chipset.......................................................................................................................................... 45
3.6.3.1 System Agent (SA) Configuration.......................................................................................... 45
3.6.3.1.1 Memory Configuration ........................................................................................................... 46
3.6.3.2 PCH-IO Configuration............................................................................................................ 47
3.6.3.2.1 PCI Express Configuration .................................................................................................... 47
3.6.3.2.2 HD Audio Configuration......................................................................................................... 51
3.6.4 Security......................................................................................................................................... 51
3.6.5 Boot .............................................................................................................................................. 52
3.6.6 Save and exit................................................................................................................................ 53
3.6.6.1 Restore Defaults.................................................................................................................... 53
3.6.6.2 Save Changes and Reset...................................................................................................... 54
3.6.6.3 Discard Changes and Reset.................................................................................................. 54
3.6.6.4 Launch EFI Shell from filesystem device .............................................................................. 54
4. Drivers Installation.......................................................................................................55
4.1 Install Chipset Driver...............................................................................................56
4.2 Install VGA Driver....................................................................................................57
4.3 Install ME Driver......................................................................................................59
4.4 Install Audio Driver (For Realtek ALC662 HD Audio)..............................................60
4.5 Install LAN Driver....................................................................................................61
4.6 Install RST Driver....................................................................................................62

User’s Manual
EMX-H110TC User’s Manual
7
5. Mechanical Drawing ....................................................................................................64

EMX-H110TC User’s Manual
8 EMX-H110TC User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x EMX-H110TC motherboard
1 x SATA Cable
1 x SATA Power Cable
1 x I/O Shield

User’s Manual
EMX-H110TC User’s Manual
9
1.3 Document Amendment History
Revision
Date
By
Comment
1st
October 2017
Avalue
Initial Release
2nd
December 2017
Avalue
Increase Battery Notice

EMX-H110TC User’s Manual
10 EMX-H110TC User’s Manual
1.4 Manual Objectives
This manual describes in details Avalue Technology EMX-H110TC Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to set up
EMX-H110TC or change the standard configurations. Whilst all the necessary information
is available in this manual we would recommend that unless you are confident, you contact
your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors regarding this manual and want to inform us
of these, please contact our Customer Service department with the relevant details.

User’s Manual
EMX-H110TC User’s Manual
11
1.5 System Specifications
System
CPU
Intel® LGA1151 Socket Supports 6th Generation Core™ i7/ i5/ i3 Processors (Max.
TDP at 65W)
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
System Chipset
Intel® H110 Chipset
I/O Chip
iTE 8784E-I
System Memory
2 x 260-pin DDR4 2133MHz SO-DIMM supports up to 32GB
Watchdog Timer
H/W Reset, 1sec. –65535sec./min.1sec. or 1min. step
H/W Status
Monitor
CPU temperature monitoring
Voltages monitoring
CPU fan speed control
Expansion
1 x M.2 Type B 3042/2242/2260 (with 1 x PCI-e x 1, USB 2.0, SATA Signal) with
support WWAN+GNSS or SSD with AUX SIM board
1 x M.2 Type A 2230 support WiFi module, 1 x PCI-e x 1, USB 2.0 Signal)
I/O
USB
2 x USB 3.0 at I/O, 2 x USB 2.0, 2 x USDB 3.0 by internal connector
Display
Resolution
VGA: 1920 x 1200 @60Hz (DP to VGA Realtek RTD2168 )
HDMI: 3840 x 2160 @ 30Hz, 2560 x 1600 @ 30Hz
LVDS:1920 x 1080 Dual channel 18/24-bits LVDS (Chrontel CH7511B eDP to
LVDS)
Multiple Display
VGA + HDMI, HDMI+ LVDS ,VGA+LVDS
Dual Display
HDMI
HDMI
LCD Interface
2CH 18/24bits LVDS 1920 x 1080
Chrontel. CH7511B eDP to LVDS Converter
Audio
HD/AC97 Codec
Realtek ALC662 HD Audio Decoding Controller
Audio Amp
Realtek ALC105 Stereo Class-D 3W x 2 Audio Amplifier
Ethernet
LAN Chip
2 x Realtek 8111E PCI-Express Gigabit Ethernet
Ethernet
Interface
10/100/1000 Gigabit Ethernet
Internal I/O
Connectors
Fan
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
1 x 1 x 4 pin, pitch 2.54mm System fan connector with smart fan function supported

EMX-H110TC User’s Manual
12 EMX-H110TC User’s Manual
Buzzer
Yes
CMOS Battery
1 x horizontal type battery connector (Battery cable 80mm length)
Power ON
1 x 2 x 5 pin, pitch 2.54mm connector for front panel
Audio
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
others
Storage:
- 2 x SATA III connectors
- 2 x SATA power connectors
Pin1: +12V，Pin2/3:GND，Pin4: +5V
1 x M.2 Type B 2242/2260 (with 1 x PCI-e x 1, USB 2.0, SATA Signal) with support
WWAN+GNSS or SSD with AUX SIM board
1 x M.2 Type A 2230 support WiFi module, 1 x PCI-e x 1, USB 2.0 Signal)
COM:
COM1
- 1 x 2 x 5 pin, pitch 2.54mm connector for COM1 support RS- RS232 connector, Pin
9 with / +5V/+12V & RI Supported
-1 x 2 x 3 pin, pitch 2.00mm connector for COM1 Pin 9 with / +5V/+12V or RI
selection
COM2
-1 x 2 x 5 pin, pitch 2.54mm connector for COM2 support RS-232/422/485 connector,
Pin 9 with / +5V /+12V & RI Supported
-1 x 2 x 3 pin, pitch 2.00mm connector for COM2 Pin 9 with / +5V/+12V or RI
selection
-1 x 2 x 3 pin, pitch 2.00mm connector for COM2 t RS-232/422/485 selection
1 x 2 x 5 pin, pitch 2.54mm connector for 2 x USB 2.0
1 x 2 x 10 pin, pitch 2.0mm connector for 2 xUSB 3.0
1 x horizontal type battery connector (Battery cable 80mm length)
1 x 2 x 5 pin, pitch 2.54mm connector for front panel
1 x 2 x 15 pin, pitch 2.00mm connector for 2CH 18/24bit LVDS
1 x 2 x 3 pin, pitch 2.54mm connector for LVDS power connector (3.3V/5V/12V)\
1 x 1 x 6 pin, pitch 2.00mm connector for Inverter\
1 x 1 x 4 pin, pitch 2.00mm connector for backlight control
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
1 x 1 x 4 pin, pitch wafer 2.00mm connector for 3W x 2 Speaker
1 x 1 x 3 pin, pitch 2.00mm connector for CMOS clear
1 x 1 x 3 pin, pitch 2.00mm connector for BIOS ME flash
1 x 1 x 3 pin, pitch 2.00mm connector with AT/ATX model function supported
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
1 x 1 x 4 pin, pitch 2.54mm System fan connector with smart fan function supported
1 x 1 x 12 pin, pitch 2.00mm connector for VGA

User’s Manual
EMX-H110TC User’s Manual
13
The VGA port can be alternatively output via I/O or internal pin header
1 x 2 x 2 pin, pitch 4.20mm connector for power input connector (DC input +12~24V)
Rear I/O
Connectors
USB
2 x USB 3.0
LAN
2 x RJ45
HDMI
HDMI
others
1 x VGA
1 x Mic-In and 1 x Line-out
1 x DC Jack
Mechanical &
Environmental
Power
Requirement
DC in +12 ~ 24V
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 3.0 Compliant
Power Type
AT/ATX mode
Operating Temp.
0 ~ 60°C (32 ~ 140°F)
Storage Temp.
-40 ~ +75°C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Size (L x W)
6.7" x 6.7" (170mm x 170mm)
Weight
0.40 kg
OS Support
(listed in accordance
with Intel document)
Windows 7 / Windows 10/ Linux
Note:
1. Specifications are subject to change without notice.
2. LAN LED
Behavior
LAN LED
1000M/1G
Green
100 M
Green
Data transmit
Orange (Flashes)
AT/ATX mode
AT/ATX
LCD Interface
LVDSl

EMX-H110TC User’s Manual
14 EMX-H110TC User’s Manual
USB with Standby 5V
S3/S4 Wake up
USB1~6 supported
Watchdog
V
3. Use the Hardware Method (Button) to set the brightness of motherboard
Due to the different firmware version of chip CH7511, the brightness function of motherboards will have
different behaviors. Motherboard: EMX-H110TC couldn’t use the hardware method (button) to keep the
brightness value. After the motherboard wakes up from S3/S4/S5 modes, the brightness value of
motherboard will change back to the default value (brightest). If you want to keep the brightness value that
you set, you should use the software way to adjust in OS mode. Otherwise, you could contact the sales
representative to request the OEM BIOS (OEM Chip CH7511 Firmware) for customizing to use the hardware
method to set.

User’s Manual
EMX-H110TC User’s Manual
15
1.6 Architecture Overview—Block Diagram
The following block diagram shows the architecture and main components of EMX-H110TC.

EMX-H110TC User’s Manual
16 EMX-H110TC User’s Manual
2. Hardware
Configuration

User’s Manual
EMX-H110TC User’s Manual
17
2.1 Product Overview

EMX-H110TC User’s Manual
18 EMX-H110TC User’s Manual
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
