Avalue Technology OFT-10W02 User manual

Part No. E2017OPCPA1R
OFT-10W02
10.1" Open Frame Tablet
Quick Reference Guide
2nd Ed –19 September, 2018
Copyright Notice
Copyright 2018 Avalue Technology Inc., ALL RIGHTS RESERVED.

OFT-10W02
2 OFT-10W02 Quick Reference Guide
Federal Communication Commission Interference Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice:
(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied
power cord by used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

Quick Reference Guide
OFT-10W02 Quick Reference Guide
3
FCC RF Radiation Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant
to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far
below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a
manner that the potential for human contact during normal operation is minimized. When nearby
persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits
established in the ANSI C95.1 standards, the distance between the antennas and the user should not
be less than 20 cm.

OFT-10W02
4 OFT-10W02 Quick Reference Guide
WARNING
“CAUTION – Use suitable mounting apparatus to avoid risk of injury.”
“CAUTION – This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures”
“CAUTION –Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.”
“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been approved
and complies with the safety standard of your particular country.”
“WARNING – To avoid risk of electric shock, this equipment must only be connected to a supply
mains with protective earth.”

Quick Reference Guide
OFT-10W02 Quick Reference Guide
5
WiFi information :
Product Description
IEEE 802.11 b/g/n Wireless LAN and Bluetooth
Combo LGA Module
WLAN Standard
IEEE 802.11b/g/n, Wi-Fi compliant
Bluetooth Standard
Bluetooth 2.1+Enhanced Data Rate (EDR) / BT4.0
Major Chipset
Realtek RTL8723BS
WiFi PID/VID
B723 / 024C
Antenna Type
PIFA
Operating Conditions
Temperature
Operating: 0~70 oC ; Storage: -20~85 oC
Electrical Specifications
Frequency Range
WLAN: 2.4 GHz Band 2.412-2.472 GHz Bluetooth:
2400~2483.5MHz
Number of Channels
802.11b: USA, Canada and Taiwan : 1 ~ 11 Most
European Countries : 1 ~ 13 Japan : 1 ~ 13
802.11g: USA and Canada : 1 ~ 11 Most European
Countries : 1 ~ 13
802.11n: USA and Canada : 1 ~ 11 Most European
Countries : 1 ~ 13
Modulation
WLAN: DSSS, OFDM, BPSK(9/6Mbps),
QPSK(18/12Mbps), DBPSK(1Mbps), DQPSK(2Mbps),
CCK(11/5.5Mbps), 16-QAM(36/24Mbps), 64-QAM
(72.2/54/48Mbps)
Bluetooth: GFSK (1Mbps), Π/4DQPSK (2Mbps) and
8DPSK (3Mbps)
Avalue Technology
Address：7F, 228, Lian-cheng Road, Zhonghe Dist., New Taipei City 235, Taiwan
Tel：[phone]
service：[e-mail]

OFT-10W02
6 OFT-10W02 Quick Reference Guide
Content
1. Getting Started............................................................................................................7
1.1 Safety Precautions ................................................................................................7
1.2 Packing List...........................................................................................................7
1.3 System Specifications ...........................................................................................8
1.4 System Overview.................................................................................................11
1.4.1 Right View.................................................................................................................................. 11
1.4.2 Left View .................................................................................................................................... 11
1.5 System Dimensions.............................................................................................12
1.5.1 Front and Rear side ................................................................................................................... 12
1.5.2 Installing Extend Brackets.......................................................................................................... 13
1.5.3 Front and Rear side (With Extend Bracket)............................................................................... 14
1.6 Flush Mounting Concept......................................................................................15
1.7 Panel Mounting....................................................................................................16
1.8 Wall Mounting Concept........................................................................................24
1.9 Wall Mounting......................................................................................................25
2. Hardware Configuration...........................................................................................33
2.1 Architecture Overview—Block Diagram...............................................................34
2.2 Motherboard Overviews.......................................................................................35
2.3 Motherboard Connector list..................................................................................37
2.4 Motherboard Connectors settings........................................................................39
2.4.1 Touch button board connector (JTB1)........................................................................................... 39
2.4.2 General purpose I/O connector (JDIO1)........................................................................................ 39
2.4.3 RS-232 connector (J232-1)............................................................................................................ 40
2.4.4 RS-485 connector (J485-1)............................................................................................................ 40
2.4.5 USB connector (JCAM1)................................................................................................................ 41
2.4.6 AMPLIFIER_L (JAMP_L)............................................................................................................... 41
2.4.7 AMPLIFIER_R (JAMP_R).............................................................................................................. 42
2.4.8 A-MIC connector (JAMIC1)............................................................................................................ 42
2.4.9 I2C connector (JSEN1).................................................................................................................. 43
2.4.10 DC Power-in connector (JDCIN3)................................................................................................ 43
2.5 FCC .....................................................................................................................44
2.6 Android Rotate Setting.........................................................................................46

Quick Reference Guide
OFT-10W02 Quick Reference Guide
7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x OFT-10W02 Open Frame Tablet

OFT-10W02
8 OFT-10W02 Quick Reference Guide
1.3 System Specifications
Component
CPU
Intel Atom Z8300/Z8350
CPU Cooler (Type)
Heatsink
Memory
2GB DDR3L
Power Supply
DC Input 12 ~ 24V
Microphone
1 x A-MIC interface
Speaker
2 x speaker(L & R) interface
Camera
1 x USB pin header
Wireless LAN
WIFI 802.11 b/g/n
Bluetooth
BT4.0
Operating System
Windows10 IoT 2016 64bit
Other Component
1 x RS232 or RS485
1 x 16 bit DIO
1 x Touch Button interface
1 x eDP & Dual channel 24bit LVDS
1 x backlight control & power
1 x I2C interface for PCAP
1 x USB interface for PCAP
1 x DC input 4pin header
1 x Optional I2C interface
Storage
Other Storage
Device
32GB eMMC
Internal I/O
LCD Panel
10.1": 1280x800 pixel
Touch Screen
PCAP
External I/O
USB Port
1 x USB 2.0 Type A
1 x Micro USB2.0 client (reserved)
Video Port
1 x HDMI
Audio Port
1 x Headphone Jack
LAN Port
1 x 10/100/1000 Ethernet
Wireless LAN
Antenna
1 x 400mm PIFA Antenna
Expansion Slots
1 x Micro SD slot
Mechanical

Quick Reference Guide
OFT-10W02 Quick Reference Guide
9
Power Type
DC Input 12 ~ 24V
Power Connector
Type
DC jack
DC input 4pin header
optional Powered LAN 802.3AT (10.1” only)
Dimension
252 x 166 x 38mm
Weight
1.18kg
OS Support
Windows10 IoT 2016 64bit
Reliability
EMI Test
CE
FCC Class A
VCCI
Vibration Test
Sine Vibration test (Non-operation)
Reference IEC60068-2-6 Testing procedures
Test Fc : Vibration sinusoidal
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
Package Vibration Test
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration boardband random Test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
Random Vibration Operation
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration boardband random Test
1. PSD: 0.00454G²/Hz , 1.5 Grms
2. Operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
Mechanical Shock
Bump Test

OFT-10W02
10 OFT-10W02 Quick Reference Guide
Test
Reference IEC 60068-2-29 Testing procedures
Test Eb : Bump Test
1. Wave form：Half Sine wave
2. Acceleration Rate：10g for operation mode
3. Duration Time：11ms
4. No. of Shock：Z axis 300 times
5. Test Axis: Z axis
6. Operation mode
Operating
Temperature
0°C ~ 40°C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Storage
Temperature
-20°C ~ 60°C
Note: Specifications are subject to change without notice.

Quick Reference Guide
OFT-10W02 Quick Reference Guide
11
1.4 System Overview
1.4.1 Right View
1.4.2 Left View
Connectors
Label
Function
Note
HP
Audio line-out connector
HDMI
HDMI connector
USB
2 x USB 2.0 connector
DCIN
DC power-in connector
SD
Micro SD card slot
Micro USB
Micro USB connector
LAN
RJ-45 Ethernet

OFT-10W02
12 OFT-10W02 Quick Reference Guide
1.5 System Dimensions
1.5.1 Front and Rear side
(Unit: mm)

Quick Reference Guide
OFT-10W02 Quick Reference Guide
13
1.5.2 Installing Extend Brackets
Step1. Locate brackets on both sides, matching the holes on the monitor.
Step2. Insert and fasten 16 screws on each side of the monitor to secure Mounting brackets.
Note: Brackets sold separately.

OFT-10W02
14 OFT-10W02 Quick Reference Guide
1.5.3 Front and Rear side (With Extend Bracket)
(Unit: mm)

Quick Reference Guide
OFT-10W02 Quick Reference Guide
15
1.6 Flush Mounting Concept

OFT-10W02
16 OFT-10W02 Quick Reference Guide
1.7 Panel Mounting
(Installation
surface)
(Opening dimension)
(Opening dimension) (Opening dimension)
A
A
(Panel thickness)
(Unit: mm)

Quick Reference Guide
OFT-10W02 Quick Reference Guide
17
Step1-1. Locate brackets on both sides, matching the holes on the monitor.
Step1-2. Insert and fasten 12 screws on each side of the monitor to secure Mounting brackets.
2
Hexagon Stud
12
1
Motherboard_10W1_ASSY
1
Item
Part Name
Quantity

OFT-10W02
18 OFT-10W02 Quick Reference Guide
Step2. Insert and fasten 4 screws on each side of the monitor to secure Front bracket.
2
Hexagon Stud
12
1
Motherboard_10W1_ASSY
1
Item
Part Name
Quantity

Quick Reference Guide
OFT-10W02 Quick Reference Guide
19
Step3. Insert and fasten 8 screws to secure Bracket T/B.
5
Bracket T/B
2
4
Screw
8
3
Front Bracket
1
Item
Part Name
Quantity

OFT-10W02
20 OFT-10W02 Quick Reference Guide
(Outside of the wall)
Step4. Insert Motherboard 10”Open frame into the wall.
6
Wall
1
Item
Part Name
Quantity
