Avalue Technology OFT-1202 User manual

Part No. E2017OT12A0R
OFT-1202/1502
12.1"/15" Open Frame Tablet
Quick Reference Guide
1st Ed –05 July 2017
Copyright Notice
Copyright 2017 Avalue Technology Inc., ALL RIGHTS RESERVED.

OFT-1202/1502
2 OFT-1202/1502 Quick Reference Guide
Federal Communication Commission Interference Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice:
(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied
power cord by used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
3
FCC RF Radiation Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant
to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far
below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a
manner that the potential for human contact during normal operation is minimized. When nearby
persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits
established in the ANSI C95.1 standards, the distance between the antennas and the user should not
be less than 20 cm.

OFT-1202/1502
4 OFT-1202/1502 Quick Reference Guide
WARNING
“CAUTION – Use suitable mounting apparatus to avoid risk of injury.”
“CAUTION – This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures”
“CAUTION –Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.”
“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been approved
and complies with the safety standard of your particular country.”
“WARNING – To avoid risk of electric shock, this equipment must only be connected to a supply
mains with protective earth.”

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
5
WiFi information :
Product Description
IEEE 802.11 b/g/n Wireless LAN and Bluetooth
Combo LGA Module
WLAN Standard
IEEE 802.11b/g/n, Wi-Fi compliant
Bluetooth Standard
Bluetooth 2.1+Enhanced Data Rate (EDR) / BT4.0
Major Chipset
Realtek RTL8723BS
WiFi PID/VID
B723 / 024C
Antenna Type
PIFA
Operating Conditions
Temperature
Operating: 0~70 oC ; Storage: -20~85 oC
Electrical Specifications
Frequency Range
WLAN: 2.4 GHz Band 2.412-2.472 GHz Bluetooth:
2400~2483.5MHz
Number of Channels
802.11b: USA, Canada and Taiwan : 1 ~ 11 Most
European Countries : 1 ~ 13 Japan : 1 ~ 13
802.11g: USA and Canada : 1 ~ 11 Most European
Countries : 1 ~ 13
802.11n: USA and Canada : 1 ~ 11 Most European
Countries : 1 ~ 13
Modulation
WLAN: DSSS, OFDM, BPSK(9/6Mbps),
QPSK(18/12Mbps), DBPSK(1Mbps), DQPSK(2Mbps),
CCK(11/5.5Mbps), 16-QAM(36/24Mbps), 64-QAM
(72.2/54/48Mbps)
Bluetooth: GFSK (1Mbps), Π/4DQPSK (2Mbps) and
8DPSK (3Mbps)
Avalue Technology
Address：7F, 228, Lian-cheng Road, Zhonghe Dist., New Taipei City 235, Taiwan
Tel：[phone]
service：[e-mail]

OFT-1202/1502
6 OFT-1202/1502 Quick Reference Guide
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions ................................................................................................8
1.2 Packing List...........................................................................................................8
1.3 System Specifications ...........................................................................................9
1.4 System Overview.................................................................................................12
1.4.1 Top View.................................................................................................................................... 12
1.4.2 Bottom View............................................................................................................................... 12
1.5 System Dimensions.............................................................................................14
1.5.1 OFT-1202................................................................................................................................... 14
1.5.2 OFT-1502................................................................................................................................... 15
1.6 Wall Mounting Concept............................................................................................16
2. Hardware Configuration...........................................................................................17
2.1 ACP-Z8300 Overviews.............................................................................................18
2.2 ACP-Z8300 Jumper and Connector list....................................................................19
2.3 Ethernet LED behavior.............................................................................................20
2.4 ACP-Z8300 Jumper and Connector settings............................................................21
2.4.1 Clear CMOS (JBAT1).................................................................................................................. 21
2.4.2 AT/ATX Input power select (JAT1).............................................................................................. 21
2.4.3 Serial port 1/2 pin9 signal select (JRI1/2) ................................................................................... 22
2.4.4 Serial port 2 RS-232/485 mode selector (JP1) ........................................................................... 22
2.4.5 Serial port 2 RS-232/485 mode selector (JP2) ........................................................................... 23
2.4.6 U37 mode selector (JP3)............................................................................................................. 23
2.4.7 Power button connector (PWRBTN1)......................................................................................... 24
2.4.8 Volume Up/Down connector (JVOLUD1).................................................................................... 24
2.4.9 Touch button board connector (JTB1) ........................................................................................ 25
2.4.10 SPI connector (JSPI1)............................................................................................................... 25
2.4.11 USB connector (JUSB1)............................................................................................................ 26
2.4.12 LCD Inverter connector (JBKL1)............................................................................................... 26
2.4.13 LVDS connector (JLVDS1)........................................................................................................ 27
2.4.14 AMPLIFIER_L (JSPKL1)........................................................................................................... 28
2.4.15 AMPLIFIER_R (JAMP_R)......................................................................................................... 28
2.4.16 Audio connector (JAUDIO1)...................................................................................................... 29
2.4.17 MCU connector (JMCU1).......................................................................................................... 29
2.4.18 RTC battery connector (JRTC1) ............................................................................................... 30
2.4.19 Serial port1 connector (COM1) ................................................................................................. 30
2.4.20 IET connector (JB2B1).............................................................................................................. 31

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
7
2.4.21 Debug connector (JDBG1)........................................................................................................ 32
2.5 FCC..........................................................................................................................33
3. Software Configuration............................................................................................34
3.1 HDMI Monitor/Touch Calibration on Windows..........................................................35

OFT-1202/1502
8 OFT-1202/1502 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x OFT-1202/1502 Open Frame Tablet
1 x ACC-ADP-060N-04R AC/DC adapter 12V/5A

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
9
1.3 System Specifications
Component
Model
OFT-1202
OFT-1502
Mother Board
ACP-Z8300
CPU
Intel Atom Z8350
CPU Cooler(Type)
Heatsink
Memory
2GB DDR3L
Power Supply
DC Input, 12 ~ 24V
Microphone
1 x A-MIC & Audio pin header
Speaker
2 x speaker(L & R) interface
Camera
1 x USB pin header
Wireless LAN
WIFI 802.11 b/g/n
Bluetooth
BT4.0
Operating System
Windows 10
Expansion Card
Micro SD Socket
(UHS-I type (SD 3.0) Micro SD card is recommended.)
Other Component
1 x RS232 or RS485
1 x RS232
1 x Touch Button interface
1 x eDP & Dual channel 24bit LVDS
1 x backlight control & power
1 x I2C interface for PCAP
Storage
Other Storage
Device
8GB or 32GB eMMC
Panel
LCD Panel
12.1”: 1024 x 768 pixel
15.1": 1024 x 768 pixel
Touch Screen
PCAP: By USB or I2C
RES: onboard touch controller
Touch Controller
EETI Res. Touch controller
External I/O
Serial Port
DSUB-9 x1
USB Port
1 x USB 2.0 Type A
1 x Micro USB2.0 client (reserved)
Video Port
1 x HDMI
LAN Port
1 x 10/100/1000 Ethernet
Others
Avalue IET module:

OFT-1202/1502
10 OFT-1202/1502 Quick Reference Guide
ARC-BYT DB-A (4 x USB3.0 module) or
ARC-BYT DB-B (3xAudio Jack+HDMI) or
ARC-BYT DB-C (HDMI+Mini PCIe+3G SIM)
Mechanical
Power Type
DC 12 ~ 24V
Power Connector
Type
DC jack
Dimension
TBD
Weight
TBD
OS Support
Windows 10
Reliability
EMI Test
CE
FCC Class B
VCCI
Vibration Test
Sine Vibration test (Non-operation)
Reference IEC60068-2-6 Testing procedures
Test Fc : Vibration sinusoidal
1 Test Acceleration : 2G
2 Test frequency : 5 ~ 500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
Package Vibration Test
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration boardband random Test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
Random Vibration Operation
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration boardband random Test
1. PSD: 0.00454G²/Hz , 1.5 Grms
2. Operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
11
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
Mechanical
Shock Test
Bump Test
Reference IEC 60068-2-29 Testing procedures
Test Eb : Bump Test
1. Wave form：Half Sine wave
2. Acceleration Rate：10g for operation mode
3. Duration Time：11ms
4. No. of Shock：Z axis 300 times
5. Test Axis: Z axis
6. Operation mode
Operating
Temperature
0°C ~ 40°C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Storage
Temperature
-20°C ~ 60°C
Note: Specifications are subject to change without notice.

OFT-1202/1502
12 OFT-1202/1502 Quick Reference Guide
1.4 System Overview
1.4.1 Top View OFT-1202
OFT-1502
1.4.2 Bottom View
OFT-1202
OFT-1502

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
13
Connectors
Label
Function
Note
USB
USB 2.0 connector
COM
Serial port connector
LAN
RJ-45 Ethernet
HDMI
HDMI connector
SD
Micro SD card slot
Micro USB
Micro USB connector
DCIN
DC power-in connector

OFT-1202/1502
14 OFT-1202/1502 Quick Reference Guide
1.5 System Dimensions
1.5.1 OFT-1202
(Unit: mm)

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
15
1.5.2 OFT-1502
(Unit: mm)

OFT-1202/1502
16 OFT-1202/1502 Quick Reference Guide
1.6 Wall Mounting Concept

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
17
2.Hardware
Configuration
For advanced information, please refer to:
1- ACP-Z8300 included in this manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

OFT-1202/1502
18 OFT-1202/1502 Quick Reference Guide
2.1 ACP-Z8300 Overviews

Quick Reference Guide
OFT-1202/1502 Quick Reference Guide
19
2.2 ACP-Z8300 Jumper and Connector list
Jumpers
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.00mm
JAT1
AT/ATX Input power select
3 x 1 header, pitch 2.00mm
JP1
Serial port 2 RS-232/485 mode selector
3 x 1 header, pitch 2.00mm
JP2
Serial port 2 RS-232/485 mode selector
3 x 1 header, pitch 2.00mm
JP3
U37 mode selector
3 x 2 header, pitch 2.00mm
JRI1/2
Serial port 1/2 pin9 signal select
3 x 2 header, pitch 2.00mm
Connectors
Label
Function
Note
PWRBTN1
Power button connector
2 x 1 wafer, pitch 2.00mm
PWR1
Power connector
JVOLUD1
Volume Up/Down connector
3 x 1 header, pitch 2.00mm
JTB1
Touch button board connector
6 x 2 header, pitch 2.00mm
JSPI1
SPI connector
4 x 2 header, pitch 2.00mm
JUSB1
Internal USB2.0 connector
5 x 1 wafer, pitch 2.00mm
USB1
USB2.0 connector
MUSB1
Micro USB2.0 connector
JLVDS1
LVDS connector
20 x 2 wafer, pitch 1.25mm
JBKL1
LCD Inverter connector
5 x 1 wafer, pitch 2.00mm
JRTC1
RTC battery connector
2 x 1 wafer, pitch 1.25mm
SIM1
SIM card slot
MPCIE1
Mini-PCIe connector 1
JSPKL1
AMPLIFIER_L
2 x 1 wafer, pitch 2.00mm
JSPKR1
AMPLIFIER_R
2 x 1 wafer, pitch 2.00mm
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00 mm
JB2B1
IET connector
40 x 2 wafer, pitch 0.80mm
COM1
Serial port 1 connector
5 x 2 wafer, pitch 2.00mm
COM2
Serial port 2 connector
JMCU1
MCU Firmware upgrade connector
5 x 1 header, pitch 2.00 mm

OFT-1202/1502
20 OFT-1202/1502 Quick Reference Guide
LAN1
RJ-45 Ethernet connector
HDMI1
HDMI connector
JSD1
Micro SD card slot
LED1
LED indicator connector 1
JDBG1
Debug connector
4 x 1 wafer, pitch 2.00mm
2.3 Ethernet LED behavior
Label
LED color
Indication
Meaning
Data Rate
Yellow
LED off
10 Mbits/sec data rate is selected
LED on
100 Mbits/sec data rate is selected
Link/ACT
Green
off
LAN link is not established
LED on
LAN link is established
LED Blinking
LAN active is occurring
