Avalue Technology OFT-10WR1 User manual

Part No. E2017ACP8A0R
OFT-10WR1
10.1" Open Frame Tablet
Quick Reference Guide
1st Ed –15 June, 2020
Copyright Notice
Copyright 2020 Avalue Technology Inc., ALL RIGHTS RESERVED.

OFT-10WR1
2 OFT-10WR1 Quick Reference Guide
Federal Communication Commission Interference Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice:
(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied
power cord by used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
3
FCC RF Radiation Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant
to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far
below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a
manner that the potential for human contact during normal operation is minimized. When nearby
persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits
established in the ANSI C95.1 standards, the distance between the antennas and the user should not
be less than 20 cm.

OFT-10WR1
4 OFT-10WR1 Quick Reference Guide
WARNING
“CAUTION – Use suitable mounting apparatus to avoid risk of injury.”
“CAUTION – This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures”
“CAUTION –Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.”
“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been approved
and complies with the safety standard of your particular country.”
“WARNING – To avoid risk of electric shock, this equipment must only be connected to a supply
mains with protective earth.”

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
5
Content
1. Getting Started............................................................................................................7
1.1 Safety Precautions ................................................................................................7
1.2 Packing List...........................................................................................................7
1.3 System Specifications ...........................................................................................8
1.4 System Overview.................................................................................................11
1.4.1 Top View.................................................................................................................................... 11
1.4.2 Bottom View............................................................................................................................... 11
1.5 System Dimensions.............................................................................................12
1.5.1 Front and Rear side ................................................................................................................... 12
1.5.2 Installing Extend Brackets.......................................................................................................... 13
1.6 Flush Mounting Concept......................................................................................14
1.7 Panel Mounting....................................................................................................15
1.8 Wall Mounting Concept........................................................................................23
1.9 Wall Mounting......................................................................................................24
2. Hardware Configuration...........................................................................................32
2.1 Architecture Overview—Block Diagram...............................................................33
2.2 ACP-RK3288 Overviews......................................................................................34
2.3 ACP-RK3288 Connector list.................................................................................36
2.4 Ethernet LED behavior.........................................................................................37
2.5 Evaluation Cable Kit (Optional)............................................................................37
2.6 ACP-RK3288 Jumpers & Connectors settings.....................................................38
2.6.1 AT/ATX Input power select (JSATX1)......................................................................................... 38
2.6.2 Touch button board connector (JTB1) ........................................................................................ 38
2.6.3 General purpose I/O connector (JGPIO1)................................................................................... 39
2.6.4 RS-485 connector (J485_COM2)................................................................................................ 39
2.6.5 USB Camera connector (JCAM_DMIC1).................................................................................... 40
2.6.6 A-MIC connector (JAMIC1)......................................................................................................... 40
2.6.7 DC Power-in connector (DCIN2)................................................................................................. 41
2.6.8 Speaker connector (JSPK1)........................................................................................................ 41
2.6.9 USB Touch connector (JUTP1)................................................................................................... 42
2.6.10 I2C connector (JSEN1) ............................................................................................................. 42
2.6.11 I2C Touch Panel connector (JITP1).......................................................................................... 43
2.6.12 Debug connector (JDBG1)........................................................................................................ 43
2.6.13 Serial port 1 connector (JCOM1) .............................................................................................. 44
2.6.14 MCU Firmware upgrade connector (JMCU1)............................................................................ 44

OFT-10WR1
6 OFT-10WR1 Quick Reference Guide
2.6.15 RTC Battery connector (JBAT1) ............................................................................................... 45
2.6.16 Battery connector (JBAT2)........................................................................................................ 45
2.6.17 LVDS connector (JLVDS1)........................................................................................................ 46
2.6.18 Power Button (PWRBTN1)........................................................................................................ 47
2.6.19 MIPI Port (JMIPI1)..................................................................................................................... 48

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x OFT-10WR1 Open Frame Tablet
Power cord / Power adapter (Optional)
Screw M3-4mm x1pc, ziplock bag No.00 40x60mm x1pc

OFT-10WR1
8 OFT-10WR1 Quick Reference Guide
1.3 System Specifications
Board Specification
Mother Board
ACP-RK3288
CPU
RockChip RK3288W Cortex-A17 Quad Core 1.6GHz
CPU Cooler (Type)
NA
Memory
2GB DDR3L
Storage
16GB eMMC
Power Supply
DC in 12V~24V
Or Powered LAN 802.3AT
Speaker
1 x Speaker header, pitch 2.0mm
Microphone
1 x A-MIC header, pitch 2.0mm
1 x D-MIC interface
Sensor
1 x I2C header, 5pinx2, pitch 2.0mm
1 x G sensor
Operating System
Android 8.1
Wifi
1 x 802.11 b/g/n Wireless LAN
Storage
eMMC
16 GB
Panel & Touch
LCD Panel
10”1280 x 800
Luminance
350nits or 1000nits
Touch Screen
PCAP, 10 points touch
Internal I/O Connectors
USB OTG
Micro USB x 1
USB
JCAM1 5P x 2, pitch 2.0mm
USB Touch
JUTP1 5P x 1, pitch 2.0mm
Micro SD
Micro SD x 1
M.2 Socket
M.2 B-Key (3042) x 1
Touch Button
JTB1 6P x 2, pitch 2.0mm
DC in 2
4P x 1 (12 ~ 24V), pitch 2.0mm
Battery 2
7P x 1, pitch 2.0mm
Note : You need a 19v or a 24v power adapter to fully charge the
battery. You cannot fully charge the battery with a 12v power
adapter.
LVDS 1
40P x1, pitch 0.5mm
Analog MIC
JAMIC1 3P x 1, pitch 2.0mm
Speaker
JSPK1 4P x 1, pitch 2.0mm

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
9
sensor
JSEN1 I2C x 2, 5P x 2, pitch 2.0mm
Touch Panel
JITP1 6P x 1, pitch 0.5mm
Console Debug
JDBG1 3P x 1, pitch 2.0mm
RS232
JCOM1 5P x 1, pitch 2.0mm
RS485
JCOM2 5P x 2, pitch 2.0mm
GPIO
JGPIO1 10P x 2, 16bit, pitch 1.0mm
RTC Battery
JBAT1 2P, pitch 1.25mm
External I/O
DC in Power jack
1 x Power Jack
USB Port
2 x USB Type A Host
Video Port
1 x HDMI
Audio Port
1 x Headphone Jack for Line out
Expansion Slots
1 x Micro SD slot
Reset
1 x Reset
LAN
1 x 10/100/1000 Ethernet
Mechanical
Power Type
12V ~ 24V wide voltage DC input
Power Connector
Type
DC jack
Or Powered LAN
Dimension
252x165.87x32.65 (mm)
Weight
700g
Color
Metallic
Fanless
Yes
OS Support
Android 8.1
Reliability
EMI Test
CE
FCC class A
Safety
EN62368-1 (LVD)
Dust and Rain Test
NA
Random Vibration
Operation
1. PSD: 0.00454G²/Hz, 1.5 Grms
2. Operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
7. Storage : CF or SSD
Sine Vibration test
(Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)

OFT-10WR1
10 OFT-10WR1 Quick Reference Guide
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package vibration
test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
6. IEC 60068-2-64 Test:Fh
Shock Test
1. Wave form：Half Sine wave
2. Acceleration Rate：10g for operation mode
3. Duration Time：11ms
4. No. of Shock：Z axis 300 times
5. Test Axis: Z axis
6. Operation mode
7. Reference IEC 60068-2-29 Testing procedures
Test Eb : Bump Test
Package drop test
1 One corner , three edges, six faces
2 ISTA 2A, IEC-60068-2-32 Test:Ed
Mechanical Shock
Test
10Grms, IEC 60068-2-27, Half Sine, 11ms
Operating
Temperature
0°C ~ 40°C
Operating
Humidity
40°C @ 95% Relative Humidity, Non-condensing
Storage
Temperature
-20°C ~ 60°C
Note: Specifications are subject to change without notice.

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
11
1.4 System Overview
1.4.1 Top View
1.4.2 Bottom View
Connectors
Label
Function
Note
SD
Micro SD card slot
Micro USB
Micro USB connector
HP
Audio line-out connector
HDMI
HDMI connector
USB
2 x USB 2.0 connector
LAN
RJ-45 Ethernet
Reset
Reset button
DCIN
DC power-in connector

OFT-10WR1
12 OFT-10WR1 Quick Reference Guide
1.5 System Dimensions
1.5.1 Front and Rear side
(Unit: mm)

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
13
1.5.2 Installing Extend Brackets
Step1. Locate brackets on both sides, matching the holes on the monitor.
Step2. Insert and fasten 4 screws on each side of the monitor to secure Mounting brackets.
Note: Brackets sold separately.

OFT-10WR1
14 OFT-10WR1 Quick Reference Guide
1.6 Flush Mounting Concept

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
15
1.7 Panel Mounting
(Installation
surface)
(Opening dimension)
(Opening dimension) (Opening dimension)
A
A
(Panel thickness)
(Unit: mm)

OFT-10WR1
16 OFT-10WR1 Quick Reference Guide
Step1-1. Locate brackets on both sides, matching the holes on the monitor.
Step1-2. Insert and fasten 12 screws on each side of the monitor to secure Mounting brackets.
2
Hexagon Stud
12
1
BCX11_10W1_ASSY
1
Item
Part Name
Quantity

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
17
Step2. Insert and fasten 4 screws on each side of the monitor to secure Front bracket.
2
Hexagon Stud
12
1
BCX11_10W1_ASSY
1
Item
Part Name
Quantity

OFT-10WR1
18 OFT-10WR1 Quick Reference Guide
Step3. Insert and fasten 8 screws to secure Bracket T/B.
5
Bracket T/B
2
4
Screw
8
3
Front Bracket
1
Item
Part Name
Quantity

Quick Reference Guide
OFT-10WR1 Quick Reference Guide
19
(Outside of the wall)
Step4. Insert BCX11 10”Open frame into the wall.
6
Wall
1
Item
Part Name
Quantity

OFT-10WR1
20 OFT-10WR1 Quick Reference Guide
(Inside of the wall)
Step5. Fasten 4 screws to secure Panel mount brackets and insert it into Bracket/TB.
5-1
8
Panel mount Screw
4
7
Panel mount Bracket
4
5
Bracket T/B
2
Item
Part Name
Quantity
