Avanti WD361 User manual

INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Model Number/Número de Modelo
WD361
CAUTION:
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
Avanti has a policy of continuous improvement on itsproducts and reserves the right to change materials and
specifications without notice.
La sección en español empieza en la página 15
Avanti Products
P.O. Box 520604 -Miami, Florida 33152
www.avantiproducts.com

2

3
Registration Information
Thank you for purchasing this fine Avanti product. Please fill out this card and return it within 100 days
of purchase and receive these
important benefits:
?Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to help
you refer to this information in the event of an insurance claim such as fire or theft.
?Promote better products:
We value your input. Your responses will help us develop products designed to best meet your
future needs.
----------------------------------------------------------(detach here)----------------------------------------------------------
Avanti Registration Card
__________________________________ _____________________________________
Name Model # Serial #
__________________________________ _____________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your PrimaryResidence, Do You:
Area Code Phone Number ?Own ?Rent
Did You Purchase An Additional Warranty: Your Age:
?Extended ?Food Loss ?None ?under 18 ?18-25 ?26-30
Reason For Choosing This Avanti Product: ?31-35 ?36-50 ?over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase ?Married ?Single
this product. Is This Product Used In The:
?Price ?Home ?Business
?Product Features How Did You Learn About This Product:
?Avanti Reputation ?Advertising ?Product Features
?Product Quality ?In Store Demo ?Personal Demo
?Salesperson Recommendation ?Other______________________________
?Friend/Relative Recommendation Comments____________________________
?Warranty _____________________________________
?Other_______________________ _____________________________________

4

5
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new water dispenser properly.
Keep it handy to answer your questions.
If you don't understand something or you need
more help, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a label located on the back
side of the unit.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your water dispenser.
If you received a damaged water dispenser,
immediately contact the dealer (or builder) that
sold you the water dispenser.
Save time and money. Before you call for
service, check the Problem Solver Guide. It lists
causes of minor operating problems that you
can correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In
most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172

6
PARTSANDFEATURES
1. WATER INTAKE
2. HOT WATER LIGHT (RED)
3. POWER INDICATOR (YELLOW)
4. COLD INDICATOR LIGHT (GREEN)
5. HOT WATER FAUCET (PINK)
6. COLD WATER FAUCET (BLUE)
7. REMOVABLE DRIPTRAY
8. ADJUSTABLE FOOT
9. COOLING SWITCH
10. HEATING SWITCH
11. CONDENSER COIL
12. POWER SUPPLY CORD
13. WATER DRAIN

7
Table of Contents
Registration Information Card __________________________________________ 3
Help Us Help You ____________________________________________________ 5
Parts and Features ___________________________________________________ 6
Important Safety Instructions___________________________________________ 8
Installation Guidelines ________________________________________________ 8
Height Adjustment____________________________________________________ 8
Before Using Your Water dispenser ____________________________________ 9
Operating Your Water dispenser ______________________________________ 10
Steps To Replace Water Bottles_______________________________________ 10
Electrical Connection ________________________________________________ 10
Cold Water Control __________________________________________________ 10
Hot Water Control ___________________________________________________ 10
Cup Dispenser (Optional) ____________________________________________ 11
Care and Maintenance_______________________________________________ 11
Taking Dispenser Out Of Service______________________________________ 11
Troubleshooting Guide ______________________________________________ 12
Service For Your Water dispenser_____________________________________ 12
Your Avanti Products Warranty________________________________________ 13
Wiring Diagram______________________________________________________ 14
Instrucciones En Español _________________________________________15-17

8
Important Safety Instructions
?WARNING?To reduce the risk of burns,fire, electrical
shock, or injury when using your appliance,
follow these basic precautions:
?Read all instructions before using the water dispenser.
?Never clean parts with flammable fluids. The fumes can create a fire hazard or
explosion.
?Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other water dispenser. The fumes can create a fire hazard or explosion
?Do not plug unit into receptacle until you ensure the water tank switches are off.
-Save these instructions-
INSTALLATION GUIDELINES:
?Remove the exterior and interior packing.
?Place your appliance on a floor that is strong enough to support the dispenser when it is fully
loaded. If it does not sit level on the floor, adjust the front right foot to level the unit well to the
floor. Note: Only the front right foot is adjustable.
?Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the appliance not to perform
properly.
?Allow 2 inches of space between the water dispenser and the wall, which allows for proper air
circulation to cool the compressor.
?Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not cut or
remove the third (ground) prong from the power cord under any circumstances. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
?This water dispenser is not recommended for outdoor use.
?Do not locate the dispenser in area where the temperature may fall below freezing (32º F).
?Keep area around dispenser free of dust and dirt.
?Keep the reserve supply of water bottles away from excessive heat and light.
?Never unplug the water cooler, except for maintenance.
Height Adjustment
?Unit is provided with four feet extensions, if you wish to make the unit taller, just attach all four
parts to the bottom feet by placing them on existing feet and pushing firmly to ensure a tight fit.
Unit will be slightly taller. The adjustable foot can still be used for leveling after the extension
part is inserted.

9
OPERATION INSTRUCTIONS:
Before Using Your Water Dispenser
?Check to be sure the following parts are included:
?Instruction manual
?4extra cup dispenser cabinet plugs
?Accessories order form.
?4height adjustment foot extensions
?Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
?The water dispenser is pre-cleaned at the factory but the reservoir and water lines must
be flushed with fresh water before use as follows:
?Keep the unit unplugged.
?Fill water tank with tap water full to capacity (more than 3/4 of a gallon).Wait for 5
minutes until water settles.
?Press the hot water faucet until water comes out, then stop.
?Plug the dispenser into the electrical outlet. Both heating and cooling indicator lights on
front will light up at first. We are ready to complete the first cycle. In order to do that,
wait for the hot water indicator light to go off first (approximately 10 minutes), then wait
for the cold water indicator light to go off (another 40 minutes, approximately).
?Unplug the dispenser from the electrical outlet. Proceed to drain the water from the
faucets one at a time until no more water remains.
(Note: To facilitate this operation, use a large container).
?Then, drain any water left in the tanks by opening the drain plug located on the back,
until it drains completely.
?Proceed to close the drain cap.
?Place the 5-gallon bottle of water on the water intake, allow water to stand for
approximately one minute.
?Open water faucets to insure water flows from both faucets.
?Plug dispenser into the electrical outlet.
?Now you are ready to use your water dispenser.
NOTE: Your water dispenser has been cleaned and sanitized before leaving the
factory, but in case a taste problem develops, place two tablespoons of
baking soda and add tap water. Fill water tank again and repeat basic
operations previously outlined, except turn the switch marked HOT “OFF” to
avoid leaving residues in hot water tank.
ATTENTION:
If you do not plan to use the water heating function for more than three days, we
recommend that you turn the HOT switch to the “OFF” position.
ATTENTION:
If you do not plan to use the water heating function for more than three days, we recommend
that you turn the HOTswitch to the “OFF” position.
?WARNING?
IMPROPER USE OF THE GROUNDED PLUG CAN RESULT IN THE RISK OF ELECTRICAL SHOCK. IF
THE POWER CORD IS DAMAGED, HAVE IT REPLACED BY AN AUTHORIZED AVANTI PRODUCTS
SERVICE CENTER.

10
OPERATING YOUR WATER DISPENSER
?Steps to replace water bottles
?Use a clean cloth to wipe off neck of bottle.
?Remove cap.
?Carefully lift bottle (approx. 40 lbs.) using your legs and not your back. Do not place hands on
opening of bottle while placing in reservoir.
?Insert the water bottle on the water intake over reservoir opening so it settles properly on it.
?Wipe off any water which may have splashed on dispenser top.
?When a new bottle is installed you must open the hot water faucet and remove no less than 4 full
cups of water to insure the water flows properly and the water reservoir is at the proper level.
?Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance is equipped
with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of
electrical shock.
Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning
power and or grounding should be directed toward a certified electrician or an authorized Avanti Products
service center.
This appliance requires a standard 115/120-volt. 60Hz electrical outlet with three-prong ground.
The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental
injury.
Do not use an adapter plug with this appliance.
Do not use an extension cord with this appliance. If the power cord is too short, have a qualified
electrician or service technician install an outlet near the appliance.
?Cold Water Control
Turn the cooling switch on. The green indicator will be lit on and the process begins. When the water
reaches the right temperature the green light goes off automatically.
?Hot Water Control
Turn the heating switch on, the red indicator will be lit on and the heating process starts. When the
water reaches the right temperature the red light goes off automatically. When the temperature goes
down to approx. 80º C (176º F), the red indicator will glow again and another heating process starts.
To dispensehot water:
?Slide red safety button to the left and hold while pressing downward on hot water faucet to dispense
hot water.
?Safety button will return to its original position when faucet is released.
NOTE:
THE HOT WATER FAUCET HAS A CHILD-SAFETY GUARD ATTACHMENT.

11
Cup Dispenser (Optional)
A cup dispenser may be installed by using the mounting holes (covered with plastic caps) located near
the top of the right side panel of the cooler. The cup dispenser comes equipped with a mounting bracket
and screws and may be ordered by completing the enclosed order form provided with your instruction
manual.
CAREANDMAINTENANCE
?Wash the inside of the reservoir with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
?The drip tray and water faucets should be cleaned with mild detergent and warm water.
?At regular intervals or once a month inspect the coils located across the back of the dispenser.
Vacuum accumulation of dust or clean it with a hard brush.
TAKING DISPENSER OUT OF SERVICE
?If the water dispenser will not be used for a long period of time, unplug the power cord from the wall
outlet.
?Drain the water through the faucets.
?Turn the switch market hot to the “OFF” position.
?Drain the water from the tank by removing the plug from the back of the dispenser.
?Unit should not be transported on the sides. Place it upright if possible and cover it with a blanket.
WARNING—THE WATER COMING OUT OF THE BACK SIDE MARKED “HOT” MAY BE SCOLDING.

12
PROBLEMS WITH YOUR WATER DISPENSER
You can solve many common water dispenser problems easily, saving you the cost of a
possible service call. Try the suggestions outlined below to see if you can solve the
problem before calling the service.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Water dispenser does not operate. Not plugged in.
The circuit breaker tripped or a blown fuse.
Water cooler is not cold enough. Check to be sure the cold switch on the back is ON.
The water dispenser does not have the correct
clearances.
Water dispenser hot water is not hot enough. Check to be sure the hot switch on the back is ON.
Compressor turns on and off frequently. The room temperature is hotter than normal.
The temperature control is not set correctly.
The water dispenser does not have the correct
clearances.
Vibrations. Check to assure that the water dispenser is level.
The water dispenser seems to make too much
noise. The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your water dispenser.
Contraction and expansion of the inside walls may cause
popping and crackling noises.
The water dispenser is not level.
Bottle feels warm. The water system is overfilled. Dispense Cold water until
air is released into the bottle.
Water bottle is hot. Water is boiling in the hot tank and bubbling up into the
bottle. Press the hot dispenser button until water flows to
remove air from the hot tank.
SERVICE FOR YOUR WATER DISPENSER
We are proud of our customer service organization and the network of professional service technicians
that provide service on your Avanti appliances. With the purchase of your Avanti appliance, you can have
the confidence that if you ever need additional information or assistance, the Avanti Products Customer
Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029 Whatever your questions are about our products, help is available.
Part Orders
800-220-5570You may order parts and accessories that will be
delivered directly to your home.
You may order these items by personal check,
money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570 An Avanti Products authorized service center will provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.

13
YOUR Avanti Products WARRANTY Staple your sales receipt here. Proof of
original purchase date is needed to obtain
service under warranty.
WHAT IS COVERED
LIMITED ONE-YEAR
WARRANTY
For one year from the date of purchase
by the original owner, Avanti Products
will, at its option, repair or replace any
part of the appliance which proves to be
defective in material or workmanship
under normal use. During this period
Avanti Products will provide all parts
and labor necessary to correct such
defects free of charge, so long as the
appliance has been installed and
operated in accordance with the written
instructions in this manual. In rental or
commercial use, the warranty period is
90 days.
?Incidental or consequential damages.
?Parts and labor costs for the following will
not be considered as warranty:
?Inner door panels, door shelves, door rails,
and/or door supports.
?Light bulbs and/or plastic housing.
?Plastic cabinet liners.
?Punctured evaporator that voids the
warranty on the complete sealed system.
?Replacement of house fuses or resetting
circuit breakers.
LIMITED SECOND THROUGH
FIFTH YEAR WARRANTY
For the second through the fifth year from date
of original purchase, Avanti Products will
provide a replacement compressor free of
charge due to a failure. You are responsible for
the service labor and freight charges. In rental or
commercial use, the limited compressor
warranty is one year and nine months. Cost to
move the appliance to the servicers’ shop and
back to the user's home, as may be required,
are the user's responsibility.
?Repairs performed by unauthorized
servicers.
?Service calls that do not involve defects in
material or workmanship such as customer
education, door reversal, or proper
installation.
?Service calls that are related to external
problems, such as abuse, misuse,
inadequate electrical power, accidents, fire,
floods, or acts of God.
?Failure of the product if it is used for other
than its intended purpose.
?This warranty does not apply outside the
continental U.S.A.
WHAT IS NOT COVERED

14
WIRING DIAGRAM

15
PARA OBTENER AGUA CALIENTE:
?MUEVA HACIA LA IZQUIERDA Y NO SUELTE EL BOTON DE SEGURIDAD.
?MANTENGA AGARRADO ESE BOTON DE SEGURIDAD MIENTRAS QUE EMPUJE EL GRIFO
HACIA ABAJO PARA DISPENSAR EL AGUA CALIENTE.
?CUANDO SUELTE EL GRIFO ASEGURESE DE RETORNARLO A LA POSICION ORIGINAL.
PASOS RECOMENDADOS PARA CAMBIAR EL BOTELLON
?QUITE EL BOTELLON VACIO.
?LIMPIE EL CUELLO DEL BOTELLON NUEVO CON UN TRAPO LIMPIO.
?LEVANTE EL BOTELLON HACIENDO FUERZA CON LAS PIERNAS Y NO LA ESPALDA.
?TOME EL BOTELLON POR LOS LADOS Y DIRIJA EL CUELLO DEL MISMO HACIA LA
APERTURA DEL TANQUE.
?VOLTEE EL BOTELLON COMO SI FUERA A SOLTAR AGUA E INSERTE EL CUELLO DEL
BOTELLON EN LA APERTURA DEL TANQUE HASTA QUE SE COLOQUE EN LA POSICION
CORRECTA.
DIRECCIONES BASICAS DE OPERACION:
?COLOQUE EL ENFRIADOR DE PIE POR UN PERIODO DE 2 HORAS ANTES DE ENCHUFAR LA
UNIDAD A LA PARED.
?COLOQUE EL ENFRIADOR EN UN AREA BIEN VENTILADA Y DEJE UN ESPACIO DE UN
POCO MAS DE 2 PULGADAS ENTRE LA UNIDAD Y LA PARED.
?ESCOJA UN LUGAR CON PISO NIVELADO.
?NO COLOQUE EL ENFRIADOR DONDE LA TEMPERATURA AMBIENTAL PUEDA BAJAR DE
32°F (0°C).
ANTES DE ENCHUFARLO
AUNQUE ENFRIADOR SALE LIMPIO DE LA FABRICA, DEBE LIMPIAR Y ESTERILIZAR LOS
CONDUCTOS DEL TANQUE Y LOS GRIFOS DE ACUERDO A LOS SIGUIENTES PASOS:
?LLENE EL TANQUE DE AGUA (HASTA EL TOPE) CON AGUA DE LA PILA.
?DEJE NIVELAR EL AGUA POR 5 MINUTOS.
?ABRA LA LLAVE DE AGUA CALIENTE HASTA QUE SALGA AGUA Y CIERRELA
INMEDIATAMENTE.
?ENCHUFE LA UNIDAD A LA PARED.ENCRENDA LOS DOS INTERRUPTORES SITUADOS EN
LA PARTE TRASERA. LOS DOS INDICADORES DE LUZ SE ALUMBRARAN. ESPERE HASTA
QUE EL INDICADOR DE AGUA CALIENTE SE APAGUE (APROX. 10 MINUTOS).
?ENTONCES ESPERE HASTA QUE EL INDICADOR DE AGUA FRIA SE APAGUE (APROX. 5
MINUTOS).
?DESCONECTE LA UNIDAD DE LA PARED.
?EMPIEZE A DRENAR LAS LLAVES UNA A LA VEZ HASTA QUE SALGA EL ULTIMO CHORRO
DE AGUA.
?EN LA PARTE TRASERA DE LA UNIDAD ENCONTRARA UNA TAPA PLASTICA. GIRE HACIA LA
IZQUIERDA LA TAPA HASTA QUE SALGA EL ULTIMO CHORRO.
?CUANDO NO SALGA MAS AGUA DE LA APERTURA, CIERRE LA TAPA PLASTICA.
?TOME EL BOTELLON DE AGUA Y SIGA LAS INSTRUCCIONES PARA CAMBIAR EL
AVISO:
ESTE GRIFO DE AGUA CALIENTE TIENE UN ADAPTADOR DE SEGURIDAD PARA NIÑOS.

16
BOTELLON.
?ENCHUFE LA UNIDAD. AHORA SU ENFRIADOR ESTA LISTO PARA SU USO.
COMO AUMENTAR LA ALTURA
CON SU UNIDAD ESTAN INCLUIDAS 4 EXTENSIONES PARA AUMENTAR LA ALTURA DE SU
ENFRIADOR.
COLOQUE LAS EXTENSIONES SOBRE LAS PATA NORMALES QUE VIENEN CON LA UNIDAD.
ASEGURESE QUE ESTAN FIJAS.
LA UNICA PATA NIVELADORA TRABAJARA CON LA EXTENSION PROVEIDA
CONTROLES DE OPERACION
?CONTROL DE AGUA FRIA:
ABRA LA LLAVE DE AGUA FRIA (10). EL INDICADOR DE LUZ VERDE SE ENCENDERA Y
EL PROCESO DE ENFRIAMIENTO COMENZARA. CUANDO LA TEMPERATURA ALCANCE
APROXIMADAMENTE 5-7°C LA LUZ VERDE SE APAGARA AUTOMATICAMENTE.
?CONTROL DE AGUA CALIENTE:
ABRA LA LLAVE DE AGUA CALIENTE (11). EL INDICADOR DE LUZ ROJA SE ENCENDERA
Y EL PROCESO DE CALENTAMIENTO DEL AGUA COMENZARA.
CUANDO LA TEMPERATURA ALCANCE APROXIMADAMENTE 80°C LA LUZ ROJA SE
APAGARA AUTOMATICAMENTE Y OTRO CICLO DE CALENTAMIENTO EMPEZARA.
MANTENIMIENTO
?A INTERVALOS REGULARES (UNA VEZ AL MES), INSPECCIONE EL CONDENSADOR O
REJILLA DE ALAMBRE LOCALIZADA EN LA PARTE TRASERA DE LA UNIDAD.
?ANTES DE EFECTUAR LA LIMPIEZA, DESENCHUFE EL ENFRIADOR. USE UNA ASPIRADORA
O UN CEPILLO DURO PARA QUITAR EL POLVO.
?PARA LIMPIAR LAS PARTES DE PLASTICO SE REQUIERE JABON LIQUIDO Y AGUA TIBIA. NO
USE LIMPIADORES ABRASIVOS EN LA SUPERFICIE SUPERIOR NI EN LA BANDEJA DE
ESCURRIMIENTO.
SI NO VA A USAR EL ENFRIADOR POR UN TIEMPO PROLONGADO
?DESENCHUFE LA UNIDAD.
?QUITE EL BOTELLON DE AGUA.
?COLOQUE LOS INTERRUPTORES MARCADOS CALIENTE Y FRIO (EN LA PARTE TRASERA)
EN LA POSICION “OFF”.
?DRENE EL AGUA ABRIENDO LAS LLAVES.
?DRENE LA APERTURA EN LA PARTE TRASERA QUITANDO EL TAPON.
?EL ENFRIADOR DEBE TRANSPORTARSE PARADO Y CUBIERTO CON UNA FRAZADA PARA
EVITAR QUE SE RAYE.
CENTRO DE SERVICIOS
LA MAYORIA DE LOS PROBLEMAS SE RESUELVEN CON UNA SIMPLE LLAMADA
TELEFONICA A NUESTRO NUMERO SIN CARGO.
1-800-220-5570
ANTES DE DEVOLVER EL PRODUCTO O PARA OBTENER LA DIRECCION Y NUMERO DE
TELEFONO DEL CENTRO DE SERVICIO MAS CERCANO LLAME AL SIGUIENTE NUMERO.
1-800-220-5570

17
POSIBLES PROBLEMAS CAUSA
DERRAME DE AGUA POR FUERA DEL
ENFRIADOR LA BOTELLA ESTA PERFORADA – REEMPLACELA
EL AGUA NO ESTA SUFICIENTEMENTE FRIA. SU TEMPERATURA DEBERIA SER DE 5?A 7?
C CON UNA TEMPERATURA AMBIENTE DE
20?C. SI NO ES ASI, LLAME AL CENTRO DE
SERVICIO, EL TERMOSTATO PODRIA ESTAR
DEFECTUOSO.
EL AGUA NO ESTA SUFICIENTE CALIENTE SU TEMPERATURA DEBERIA SER DE 80?A
90?C CON UNA TEMPERATURA AMBIENTE
DE 20?C. SI NO ES ASI, LLAME AL CENTRO
DE SERVICIO, EL TERMOSTATO PODRIA
ESTAR DEFECTUOSO.
EL ENFRIADOR NO ENFRIA O CALIENTA EL
AGUA VERIFIQUE LOS CIRCUITOS, FUSIBLES O DISYUNTORES.
PRINTED IN CHINA
