AVARRO 0E-HDMIEX4KL User manual

For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
MANUAL
HDMI EXTENDER OVER SINGLE UTP
0E-HDMIEX4KL

1
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Table of Contents
Introduction ....................................................................................... 3
Overview .................................................................................... 3
Features ..................................................................................... 3
Package Contents ..................................................................... 4
Panel .......................................................................................... 4
Transmitter.......................................................................... 4
Receiver.............................................................................. 5
Specification .............................................................................. 6
Installation and Wiring....................................................................... 8
Brackets Installation .................................................................. 8
Wiring ......................................................................................... 9
RS232 Operation............................................................................. 10
Troubleshooting............................................................................... 11
Limited Warranty ............................................................................. 12
Introduction ..................................................................................... 16
Aperçu...................................................................................... 16
Caractéristiques....................................................................... 16
Contenu.................................................................................... 17
Panneau ................................................................................... 17
Transmetteur..................................................................... 17
Récepteur ......................................................................... 19
Spécifications .......................................................................... 20
Installation et câblage ..................................................................... 22
Installation des supports ......................................................... 22
Cableado.................................................................................. 23
Commande RS232.......................................................................... 24
Dépannage...................................................................................... 25
Garantie limitée ............................................................................... 26
Introducción .................................................................................... 30
Descripción .............................................................................. 30
Características ......................................................................... 30
Contenido del paquete ............................................................ 30
Panel ........................................................................................ 31
Transmisor ........................................................................ 31
Receptor ........................................................................... 32
Especificaciones ...................................................................... 33
Instalación y cableado .................................................................... 35
Instalación de los soportes...................................................... 35

2
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Cableado.................................................................................. 36
Control RS232................................................................................. 37
Solución de problemas ................................................................... 38
Garantía limitada ............................................................................. 39

3
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Introduction
Overview
0E-HDMIEX4KL is a slim transmitter and receiver pair, which can extend HDMI
1080P@60Hz signals up to 70m/230ft and 4K@60Hz (chroma sub-sampling
4:2:0 8-bit only) signals up to 40m/130ft via a single Cat 6a/7 cable. The
extender also features bi-directional PoC. It also supports bi-directional IR and
RS232 pass-through.
Features
HDMI 1.4 with 4K and HDCP 2.2 compliant.
Supports resolutions up to 4K@60Hz 4:2:0 8bit and HDCP 2.2.
Via a Cat 6a/7 cable, extends 4K@60Hz 4:2:0 8bit up to 40m/130ft and
1080P up to 70m/230ft.
Via a Cat 5e/6 cable, extends 4K@60Hz 4:2:0 8bit up to 35m/115ft and
1080P up to 60m/197ft.
Use a lockable power port for a stronger connection.
Bi-directional PoC, one power adapter at either transmitter or receiver side
can power both units.
Supports bi-directional IR and RS232 pass-through.
All connectors in one side for easy cabling.

4
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Package Contents
Before you start the installation of the product, please check the package
contents:
1 x 0E-HDMIEX4KL
1 x Power Adapter (DC 18V 1A)
1 x IR Emitter
1 x IR Receiver (30-50KHz)
2 x Phoenix Male Connectors (3.5mm, 3 Pins)
4 x Mounting Brackets (with Screws)
1 x User Manual
Panel
Transmitter
Front Panel
No.
Name
Description
1 POWER LED
ON:
The transmitter is powered on.
OFF: The transmitter is powered off.
2 STATUS LED
ON:
The transmitter is working properly.
OFF:
The transmitter is not working properly.
3 HDCP LED
ON:
HDCP protected content is being
transmitted.
BLINKING:
Non-
HDCP protected content is
being transmitted.
OFF:No content is being transmitted.
4 LINK LED
ON:
HDBT link is normal.
1 432

5
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
No.
Name
Description
BLINKING/OFF: No HDBT link or link error.
Rear Panel
No.
Name
Description
1
DC 18V
Connect to the power adapter.
2 HDBT OUT Connect to the receiver via a Cat 5e/6/6a/7 cable.
3
IR IN
Connect to the IR receiver provided.
4 IR OUT Connect to the IR emitter provided.
5
RS232
For RS232 pass-through.
6 HDMI IN Connect to an HDMI source device.
Receiver
Front Panel
No.
Name
Description
1 POWER LED
ON:
The receiver is powered on.
OFF: The receiver is powered off.
2 STATUS LED
ON:
The receiver is working properly.
OFF:
The receiver is not working properly.
3 HDCP LED
ON:
HDCP protected content is being transmitted.
BLINKING:
Non-HDCP protected content is being
transmitted.
1 2 3 4 5 6
1 432

6
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
No.
Name
Description
OFF:
No content is being transmitted.
4 LINK LED
ON:
HDBT link is normal.
BLINKING/OFF: No HDBT link or link error.
Rear Panel
No.
Name
Description
1
DC 18V
Connect to the power adapter.
2
HDBT IN
Connect to the transmitter via a Cat 5e/6/6a/7 cable.
3
IR IN
Connect to the IR receiver provided.
4
IR OUT
Connect to the IR emitter provided.
5
RS232
For RS232 pass-through.
6
HDMI OUT
Connect to an HDMI display device.
Specification
Technical
Input/Output Signal Type HDMI with 4K@60Hz 4:2:0, HDCP 2.2
Input/Output Resolution
Supported
Up to 4096x2160@60Hz, including
4K@60Hz/4K@30Hz/1080P/1080i/720P
Note: 4096x2160/3840x2160@50/60Hz is
based on chroma sub-sampling 4:2:0 8-bit only.
Maximum Data Rate 10.2Gbps
Maximum Pixel Clock
340MHz
Audio Format Supported
Supports
multichannel audio up to PCM 7.1,
Dolby True HD, DTS HD Master Audio, Dolby
Atmos and DTS:X
1 2 3 4 5 6

7
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
General
Operating Temperature
0°C to + 45°C (32 to + 113 °F)
Storage Temperature
-20 to +70°C (-4 to + 158 °F)
Humidity
20% to 90%, non-condensing
ESD Protection ±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Surge Protection
Voltage: ±1 kV
Power Supply
DC 18V 1A
Power Consumption
(Maximum)
8.88W (Pair, PoC)
Device Dimension
(W x H x D)
Transmitter/Receiver:
10.88 cm x 1.5 cm x 6.42 cm/4.3" x 0.6’’ x 2.5’’
Product Weight
Transmitter/Receiver: 0.18kg/0.40lb
Transmission Distance
Note: We recommend the use of T568B straight-through category cables.
Cable Type
Range
Supported Video
Cat 5e/6
60m/197ft
1080P@60Hz 36bpp
35m/115ft
1080p 60 Hz 48 bpp
1080p 60 Hz 3D
3840 x 2160@60Hz 4:2:0 8bit
Cat 6a/7 40m/131ft
70m/230ft
1080P@60Hz 36bpp
HDMI
Input/Output:15m/50ft
1080P@60Hz
Input: 10m/33ft
Output: 15m/50ft
4K@60Hz

8
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Installation and Wiring
Brackets Installation
Note: Before installation, please ensure the device is disconnected from the
power source.
Steps to install the device in a suitable location:
1. Attach the installation bracket to the enclosure using the screws that
were provided in the package separately.
2. The bracket is attached to the enclosure as shown.
3. Repeat steps from 1 to 2 for the other side of the transmitter.
4. Attach the brackets to the surface you want to hold the transmitter
against using the screws (provided by others).
5. Repeat steps from 1 to 4 to install the receiver.

9
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Wiring
HDMI IN
HDMI OUT
TV Remote/
Télécommande TV/
Control remoto de televisión
DVD Player/
Lecteur DVD/
Reproductor de DVD
IR Receiver 2/
récepteur IR 2/
receptor IR 2
IR Receiver 1/
récepteur IR 1/
receptor IR 1
IR Emitter 1/
émetteur IR 1/
emisor IR 1
IR Emitter 2/
émetteur IR 2/
emisor IR 2
Transmitter/
Transmetteur/Transmisor
Receiver/
Récepteur/
Receptor
Source Remote/Télécommande
infrarouge source/Fuente remota
HDBT

10
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
RS232 Operation
RS232 ports can be used for bi-directional RS232 signal pass-through between
the transmitter and receiver.
RS232 Device/
appareil RS232/
dispositivo RS232
RS232 Device/
appareil RS232/
dispositivo RS232
RX
TX
GND
TX
RX
G
Transmitter/
Transmetteur/
Transmisor
Receiver/
Récepteur/
Receptor
HDBT
RS232
RS232

11
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Troubleshooting
1. No Power
Ensure the power is on.
Ensure you use the power adapter provided in the package.
2. No Picture or Video Flash
Ensure all devices are on, and all cables are qualified and connected
properly. Ensure all the cables’ length are within the maximum distance
(refer to “Specification” table).
Ensure all the LED indicators are normal.
When connecting source to display directly, ensure them can work
properly.
Ensure the input resolution is supported by the device.
Ensure the input resolution is within 4K@30Hz when Dolby vision signal
is input.
3. Weak or Not Working IR Signal
Ensure the devices support IR control (not Bluetooth/WIFI).
Ensure you use the IR cables provided in the package, and install them
correctly according to the Application Diagram.
Pay attention to the control angle and distance.
IR Cable IR Emitter IR Receiver
Suggested Angle 0° 0°
Distance (Max) 30cm 8m
When work with the third-party device, ensure it follows the pin
definition below.
Gnd
5V
5V
IR Receiver
IR Signal
IR Emitter
IR Signal

12
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Limited Warranty
1. Limited Warranty
a. General
Subject to the terms and conditions of this Limited Warranty, from the date of
sale through the period of time for product categories specified in Section 1(b),
ADI warrants AVARRO branded products to be free from defects in materials
and workmanship under normal use and service, normal wear and tear excepted.
Except as required by law, this Limited Warranty is only made to Buyer and may
not be transferred to any third party.
ADI shall have no obligation under this Limited Warranty or otherwise if:
(i) The product is improperly installed, applied or maintained;
(ii) The product is installed outside of stated operating parameters, altered, or
improperly services or repaired;
(iii) Damage is caused by outside natural occurrences, such as lightning, power
surges, fire, floods, acts of nature, or the like.
(iv) Defects resulting from unauthorized modification, misuse, vandalism, or
other causes unrelated to defective materials or workmanship, or failures
related to batteries of any type used in connection with the products sold
hereunder.
ADI only warrants those products branded AVARRO and sold by ADI. Any
other products branded by third parties are warranted by the third-party
manufacturer for a period as defined by the third-party manufacturer, and ADI
assigns to Buyer those warranties and only those warranties extended by such
third-party manufacturers or vendors for non-ADI branded products. ADI does
not itself warrant any non-ADI branded product and sells only on an as is basis
in accordance with ADI’s terms and conditions of sale.
b. Specific Warranties for product categories are as follows:
Product Categories
Warranty Period
HDMI Distribution 2 years

13
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
2. EXCLUSION OF WARRANTIES, LIMITATION OF LIABILITY
THERE ARE NO WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, OF
MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE OR
OTHERWISE, WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE
HEREOF. TO THE FULLEST EXTENT PERMITTED BY LAW, IN NO CASE
SHALL ADI BE LIABLE TO ANYONE FOR ANY (I) CONSEQUENTIAL,
INCIDENTAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES ARISING OUT OF
OR RELATING IN ANY WAY TO THE PRODUCT AND.OR FOR BREACH OF
THIS OR ANY OTHER WARRANTY OR CONDITION, EXPRESS OR IMPLIED,
OR UPON ANY OTHER BASIS OF LIABILITY WHATSOEVER, EVEN IF THE
LOSS OR DAMAGE IS CAUSED BY ADI’S OWN NEGLIGENCE OR FAULT AND
EVEN IF ADI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSSES OR
DAMAGES. Any product description (whether in writing or made orally by ADI
or ADI’s agents), specifications, samples, models, bulletin, drawings, diagrams,
engineering sheets, or similar materials used in connection with the Buyer’s
order are for the sole purpose of identifying ADI’s products and shall not be
construed as an express warranty or condition. Any suggestions by ADI or
ADI’s agents regarding use, applications or suitability of the products shall not
be construed as an express warranty or condition unless confirmed to be such
in writing by ADI. ADI does not represent that the products it sells may not be
compromised or circumvented; that the products will prevent any personal injury
or property loss by burglary, robbery, fire or otherwise, or that the products will
in all cases provide adequate warning or protection. Buyer understands and
will cause its customer to understand that a properly installed and maintained
product is not insurance or guarantee that such will not cause or lead to personal
injury or property loss. CONSEQUENTLY, ADI SHALL HAVE NO LIABILITY FOR
ANY PERSONAL INJURY, PROPERTY DAMAGE OR OTHER LOSS BASED ON
ANY CLAIM AT ALL INCLUDING A CLAIM THAT THE PRODUCT FAILED TO
GIVE WARNING. However, if ADI is held liable whether directly or indirectly for
any loss or damage with respect to the products it sells, regardless of cause or
origin, its maximum liability shall not in any case exceed the purchase price of
the product, which shall be fixed as liquidated damages and not as a penalty

14
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
and shall be the complete and exclusive remedy against ADI.
3. Limitation on Liability to Buyer’s Customers.
Buyer agrees to limit liability to its customers to the fullest extent permitted by
law. Buyer acknowledges that ADI shall only be deemed to give consumers of
its products such statutory warranties as may be required by law and at no time
shall Buyer represent to its customers and/or users of ADI products that ADI
provides any additional warranties. By accepting the products, to the fullest
extent permitted by law, Buyer assumes all liability for, and agrees to indemnity
and hold ADI harmless against and defend ADI from, any and all suits, claims,
demands, causes of action and judgments relating to damages, whether for
personal injury or to personal property, suffered by any person, firm, corporation
or business association, including but not limited to, Buyer’s customers and/or
users of the products because of any failure of the products to detect and/or
warn of the danger for which the goods were designed or any other failure of
the products whether or not such damages are caused or contributed to by the
sold or joint concurring negligence or fault of ADI.
4. Returns
Subject to the terms and conditions listed below, during the applicable warranty
period, ADI will replace Product or provide a credit at purchase at its sole option
free of charge any defective products returned prepaid. Any obligations of ADI
to replace Limited Lifetime warranty products pursuant to this warranty which
result from defect are limited to the availability of replacement product. ADI
reserves the right to replace any such products with the then currently available
products, or provide a credit in its sole discretion. In the event Buyer has a
problem with any ADI product, please call your local ADI branch for return
instructions:
For US call 1-800-233-6261
For Canada call 877-234-7378
For Puerto Rico call 787-793-8830

15
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Be sure to have the model number and the nature of the problem available. In
the event of replacement, the return product will be credited to Buyer’s account
and a new invoice issued for the replacement item. ADI reserves the right to
issue a credit only in lieu of replacement.
If any AVARRO branded products are found to be in good working order or such
product’s inability to function properly is a result of user damage or abuse, the
product will be returned to Buyer in the same condition as received and Buyer
shall be responsible for any return freight changes.
5. Governing Law
The laws of State of New York apply to this Limited Warranty.
6. Miscellaneous
Where any term of this Limited Warranty is prohibited by such laws, it shall be
null and void, but the remainder of the Limited Warranty shall remain in full force
an effect.

16
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Introduction
Aperçu
0E-HDMIEX4KL est un ensemble transmetteur / récepteur conçu pour étendre
les signaux HDMI 1080P à 60 Hz jusqu’à 70 m et les signaux 4K à 60 Hz (4:2:0)
jusqu’à 40 m, par l’intermédiaire d’un câble de catégorie 6a/7. Le transmetteur
et le récepteur n’ont besoin que d’une source d’alimentation pour alimenter les
deux appareils grâce à la fonction PoC bidirectionnelle. Il prend également en
charge la transmission IR bidirectionnelle et la transmission RS232.
Caractéristiques
HDMI 1.4 conforme HDCP 2.2 et 4K.
Prend en charge les résolutions vidéo jusqu’à 4K à 60 Hz, 4:2:0, 8 bits et
HDCP 2.2.
Via câbles de cat. 6a/7, sortie 4K à 60 Hz (4:2:0) jusqu’à 130 pi. (40 m),
1080P à 60 Hz jusqu’à 230 pi. (70 m).
Via câble de cat. 5a/6, sortie 4K à 60 Hz (4:2:0) jusqu’à 115 pi. (35 m),
1080P à 60 Hz jusqu’à 197 pi. (60 m).
Utilisez un port d'alimentation verrouillable pour une connexion plus solide.
Prend en charge la technologie PoC bidirectionnelle; un seul adaptateur
d’alimentation est nécessaire pour l'émetteur ou le récepteur..
Il prend également en charge la transmission l’IR bidirectionnel et la
transmission RS232 bidirectionnel.
Tous les connecteurs sont installés du même côté pour faciliter le câblage.

17
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Contenu
Avant de commencer l’installation du produit, veuillez vérifier le contenu de la
boîte :
1 x appareil 0E-HDMIEX4KL
1 x adaptateur de puissance (18 VCC, 1 A)
1 x émetteurs IR
1 x récepteurs IR (30 à 50 kHz)
2 x connecteurs mâles Phoenix (3 broches 3,5 mm)
4 x supports de montage
1 x manuel d’utilisation
Panneau
Transmetteur
Panneau avant
Réf.
Nom
Description
1 VOYANT « POWER
» (ALIMENTATION)
Allumé : Le transmetteur est en marche.
Éteint : Le transmetteur est hors tension.
2 VOYANT D’ÉTAT
Allumé : Le transmetteur fonctionne
correctement.
É
teint : Le transmetteur ne fonctionne pas
correctement..
3 VOYANT HDCP
Allumé : Du contenu à protection HDCP est
en cours de transmission.
Clignotement rapide : Du contenu qui n’est
pas à protection HDCP est en cours de
1 432

18
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Réf.
Nom
Description
transmission.
Éteint : Aucun contenu n’est en cours de
transmission.
4 VOYANT « LINK »
(LIAISON)
Allumé : La liaison HDTB est normale.
CLIGNOTEMENT/Éteint : Aucune liaison HDTB
ou erreur de liaison.
Panneau arrière
Réf.
Nom
Description
1 Alimentation
Connexion à l’adaptateur d’alimentation CC de 18 V.
Avec le PoC bidirectionnel pris en charge, un
adaptateur électrique doit être connecté au
transmetteur ou au récepteur pour alimenter les deux
unités.
2
HDBT OUT
(SORTIE
HDBT)
Connexion au récepteur via un câble de cat.
5e/6/6a/7.
3 IR IN
(ENTRÉE IR) Connecter au récepteur IR.
4 IR OUT
(SORTIE IR)
Connecter à l’émetteur IR.
5 RS232 Connecter à un appareil compatible RS232 pour le
RS232 traversant.
6
HDMI IN
Connecter à une source HDMI.
1 2 3 4 5 6

19
For more information please call 1-833-574-9124 or email [e-mail] ··· To learn more about AVARRO products visit avarro.adiglobaldistribution.us
Récepteur
Panneau avant
N°
Nom
La description
1 VOYANT « POWER
» (ALIMENTATION)
Allumé : Le récepteur est en marche.
Éteint : Le récepteur est hors tension.
2 VOYANT D’ÉTAT
Allumé : Le récepteur fonctionne correctement.
Éteint : Le récepteur ne fonctionne pas
correctement.
3 VOYANT HDCP
Allumé : La liaison HDTB est normale.
Éteint : Aucune liaison HDTB ou erreur de
liaison.
4 VOYANT « LINK »
(LIAISON)
Allumé : La liaison HDTB est normale.
CLIGNOTEMENT/Éteint : Aucune liaison HDTB
ou erreur de liaison.
Panneau arrière
Réf.
Nom
Description
1 Alimentation
Connexion à l’adaptateur d’alimentation CC
de 18 V.
Avec le PoC bidirectionnel pris en charge, un
adaptateur électrique doit être connecté au
1 432
1 2 3 4 5 6
