Aven Mighty Vue Inspector User manual

Setup Instructions
Step 1: Attach the clamp onto the edge of a table
and adjust it until the clamp is secure, then insert the
magnifying lamp into the hole located at the top of the
clamp
CAUTION: Carefully secure the lamp prior to removing the
twist tie to prevent the spring balanced arm from swinging
open
Step 2: Connect the power cable to the magnifying lamp
(located near the base of the magnifying lamp) and plug
it into an outlet
( If monitor inspection is not required, skip to step 4)
Step 3:
•Insert the Micro SD card into the magnifying lamp
•Connect the HDMI cable from the magnifying lamp to
your monitor or use the USB cable for PC connectivity
•Remove the lens cap
•Remove the protective battery film from the remote
HDMI
Port Micro
SD Card
Port
USB
Port
Power
Step 4: Power on the magnifying lamp to turn on the
magnifying lamp and monitor
(Unplug the USB cable before powering the device on or off)
www.aventools.com | [email protected] | 734-973-0099 | 4330 Varsity Dr, Ann Arbor, MI 48108

Remote Guide
Power on/off monitor functionality
(while the magnifying lamp is on)
Enter the menu screen to adjust setup
(press again to leave the menu screen)
Capture an image on screen
View images/videos (press again to
return to live mode)
Navigate through the menus with the
arrow keys
Zoom in & out (on screen)
Make a selection
Play/Pause videos
(For PC mode) Toggle between live
view, image library, and HDMI mode
Display cross hair (adjust cross hair
color and cross line in menu setup)
Freeze the frame on screen while in live
mode
Delete image/video
Press once to record (indicator light will
blink) press again to stop recording
Getting Started
Tilt the camera to adjust the image on
screen to your desired angle
Adjust the color temperature and intensity of the
LEDs on the magnifying lamp
Adjust and lock the positioning of the lamp
head with the adjustment knob
View objects through the magnifying lens or
the monitor
•This device is not a toy, to prevent injury or damage to the magnifying lamp, keep out of reach of young children
•To prevent the risk of a fire or shock, do not operate in wet or humid environments
•Conserve energy by powering off the magnifying lamp when not in use
