Aveo Systems Mira Connect 10 User manual

Aveo Systems, Inc. • 1791 West Oak Parkway, Suite 8 • Mariea, GA 30062 • Phone: [phone] • www.aveosystems.com
Aveo Systems® Mira Connect™
SPECIFICATION SHEET
R
SYSTEMS
Mira Connect™ 10 In-Wall Backbox Installaon Instrucons
Aveo Systems, the Aveo Systems logo, Mira, Mira Connect, and Mira Portal are trademarks for Aveo Systems Inc. Specicaons subject to change without noce.
Mira Connect 10 is an award-winning smart control system for conference rooms, meeng spaces, huddle rooms, and
other spaces that can be wall-mounted or used on a tabletop. Mira Connect 10 makes it easy for users to manage audio
and video sources, dial audio and video conference calls, and control the displays, projectors, video switchers, DSP audio
systems, and other equipment in their rooms.
The in-wall backbox makes it easy to install Mira Connect 10 into a wall, nearly ush with the surface.
Designed for the Mira Connect 10, the in-wall backbox easily mounts into new or exisng installaons. The ultra-low
prole design extends only 2.5mm from the wall. The gloss black color looks professional in any environment. The
backbox Installs easily with one drywall cut, and rotang mounng clips secure the system to drywall with ease.
The removable trim ring allows access to the enclosed touch screen, yet remains rmly in place with snap fasteners. With
the trim ring in place, the touch screen is fully usable while access to the Ethernet cable is hidden. The trim ring may be
painted to match interior paint colors.
Technical Specicaons
Part Number
• 105.2004.001
Package Includes
• Mira Connect™ 10 In-wall backbox,
adapter tray, trim ring, and mounng screws
• Does not include Mira Connect 10 touch screen.
Order separately: SKU 100.2100.001
Physical Characteriscs
• Gloss black metal
• Cut-out dimensions: 300 x 207 mm, 11 3/4 x 8 1/8 in.
• In-wall depth: 76.2 mm, 3 in.
• Outer trim ring: 33 mm, 1.3 in. border width on sides
25 mm, 1 in. on top and boom,
extends 2.5 mm, 0.1 in. depth from front of wall
• Weight: 1.8 kg, 3.9 lbs. (without touch screen)
Shown with touch screen Backbox
Adapter plate
Installaon Overview
Tools Required for Installaon

Aveo Systems, Inc. • 1791 West Oak Parkway, Suite 8 • Mariea, GA 30062 • Phone: [phone] • www.aveosystems.com
DS-10100-001 Version 2020_01_06
Installaon Steps
1
Step To get started, locate the studs near where
you'd like to install the enclosure before cung
the drywall. The in-wall backbox is designed to
t between wall studs.
Once the studs have been located on the le
and right of the desired locaon, leave at least
13 mm (1/2 in.) clearance from the studs to
ensure mounng clips can rotate and secure the
backbox to the drywall.
Use a level to draw straight lines.
Cut an opening in the drywall with dimensions
300 x 207 mm (11 3/4 x 8 1/8 in.).
300 mm
11 3/4”
207mm
8 1/8”
13 mm, 1/2” minimum
2
Step Pull and terminate the network cable into the
box through the boom cut-outs in preparaon
for connecng to Mira Connect 10.
Insert the backbox into the hole with the clips
remaining on the inside of the backbox.
Rotate one of the top drywall clips by ghtening
the clip screw just enough to secure the box to
the wall. Do not nish ghtening.
Repeat this for the opposite top clip, then with
the two boom clips.
Once the box is secure enough to remain in
posion, but not completely ghtened, level the
box and ghten the screws so the enclosure is
secure and level.
3
Step Mount the adapter plate to the back of the Mira
Connect 10 touch panel using four M4 screws
provided.
4
Step Turn the adapter plate over, connect the
network cable to Mira Connect 10, ensure the
power switch is turned on. Use a Power over
Ethernet (PoE) enabled network connecon.
Mount mount the adapter plate to the backbox
using four M4 screws with the Ethernet
connecon on the boom.
5
Step Install the trim ring by aligning over the opening
and then snapping it into place. The trim ring
can be carefully removed by pulling it from the
backbox.
Trim ring Finished
