Avery Dennison Eartrace RH7 Operator's manual

Updated: May 2021 AD_SMT_Eartrace Handheld Reader RH7 Classification: Avery Dennison - InternalUpdated: May 2021 AD_SMT_Eartrace Handheld Reader RH7 Classification: Avery Dennison - Public
Eartrace®
Handheld Reader RH7
Avery Dennison
Smartrac
Instructions
Instructions
Overview
Frequency Band
LF 124 kHz - 134.2 kHz
HDX and FDX
Hard Tag Dimensions
660 x 65 mm / 25.98 x 2.56 in
Industry Segments
Animal Identification
rfid.averydennison.com
Eartrace-Handheld-Reader-RH7-05-21-EN-IS
The RH7 can read all ISO 11784 and
11785 compliant animal transponders
(FDX-B and HDX) as well as FDX-A and
EM4102 transponders.
Switch Reader Off
Press the ‘ON/OFF’ button for about
2 seconds. In case of inactivity the reader
switches off automatically after about
2 minutes.
Charging Battery
Connect the reader to a computer or an
USB power supply. When fully charged
the LED changes from red to green.
The battery status is shown in the upper
right corner of the OLED display.
Reader Configuration
From initial scan view press ‘UP’ once and
enter Settings by pressing ‘OK’. The menu
offer configuration of Language, Memory,
Bluetooth®, Hex. For selecting the desired
function please press ‘OK’.
Bluetooth® Setting
Scroll to ‘Bluetooth’ and press ‘OK’ for
disabling or enabling communication
via Bluetooth®. When enabled the LED
is blue. For saving battery power please
disable Bluetooth®.
Reading Transponders
Switch on the reader, wait until ‘Scan’
Is shown and press ‘OK’. Approach the
reader antenna to the transponder.
After detecting a transponder the
identification number is shown on the
OLED display. For another reading press
‘OK’ again.
Continuous Scan
Continuous reading can be activated by
scrolling down from initial scan view to
‘Continuous Scan’ and pressing ‘OK’.

Updated: May 2021 AD_SMT_Eartrace Handheld Reader RH7 Classification: Avery Dennison - InternalUpdated: May 2021 AD_SMT_Eartrace Handheld Reader RH7 Classification: Avery Dennison - Public
Avery Dennison
Smartrac
Instructions
Eartrace-Handheld-Reader-RH7-05-21-EN-IS
Memory Setting
Scroll to ‘Memory’ and push ‘OK’ for
disabling or enabling memory
functionality. If enabled the transponder
numbers are stored in the reader’s internal
memory. When selecting ‘Memory’ a
second time data can be transmitted via
Bluetooth® or USB after pressing ‘OK’.
Language Setting
Scroll to ‘Language’ and push ‘OK’. By
scrolling up and down one of the following
languages can be chosen: English, French,
Spanish, Italian, Portuguese, German,
Polish. Confirm with ‘OK’.
Operating Controls
The reader is controlled by four buttons:
●‘ON/OFF’
●‘UP’ for scrolling up in displayed menu
●‘DOWN’ for scrolling down
●‘OK’ for selecting the displayed option
OLED Display and LED (Blue)
The OLED display shows configuration
menus, device status and transponder
identification numbers in four lines of
16 characters each. The LED indicates
Bluetooth® connectivity status.
Mini-USB Connector and LED
The mini-USB connector is used for:
●charging the battery (red / green LED)
●transferring data to a PC
Scope of Delivery
●Eartrace® Handheld Reader RH7
●Rechargeable battery
●Mini-USB cable
Certificates
●CE
●FCC
Specifications
●OLED 4 x 16
●LED indicator
●4 buttons
●Beeper
●Reads ISO 11784 and 11785 compliant
transponders (FDX-B and HDX)
●Reads FDX-A and EM4102 transponders
●Mini-USB connector
●Bluetooth®
●Rechargeable battery 3.7V, 5000mAh
●Dimensions: approx. 660 x 65 x 48 mm
●Weight: approx. 460g
●Storage temperature: -10°C to 55°C
●Operating temperature: -5°C to 40°C
Reader Description
OLED display
LED
ON/OFF
UP
DOWN
OK
Mini-USB
