Avid CNC Rotary Axis
Recessed Installation & Calibration Instructions
Version 2019Q4.2
1.1 Machine Preparation
The recessed (undermount) rotary mounting kit allows the rotary assembly to be installed between any two crossmembers
that are within the work area of your Avid PRO CNC Machine. The images used throughout the mounting process that
show the rotary assembly installed at the front of the machine are for illustrative purposes only.
The following steps to prepare your machine will ease in the installation and calibration of your rotary assembly.
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.1.1.2
Ensure the two crossmembers where the rotary assembly will be installed are spaced 360mm (14-3/16") apart, inside edge
to inside edge. Adjust the crossmembers as needed.
360mm (14-3/16")
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
Parts and Tools Required
The following parts and tools will be used in Section 1.2
QTY Part/Description Packaged In
2 CRP190-17, Mounting Plate Recessed Mounting Kit
2 CRP190-19, Mid-Support Recessed Mounting Kit
1 M12 Proximity Sensor Cable, 20' CRP190-00-BASE
1 NEMA 34 Motor Cable, 20' Rotary Electronics
1 CRP194-00-FAST: Recessed Mounting Kit
- (24) M8 x 16mm Socket Head Cap Screw
- (24) M8 Roll-in T-Nut
- (6) M8 x 35mm Socket Head Cap Screw
- (6) M8 Hex Jam Nut
Required Tools:
- 6mm Ball-End Allen Wrench
- 13mm Combination Wrench
- Tape Measure
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.2.1.6
Attach the mounting plates to the underside of your crossmembers as indicated, partially tightening the fasteners.
Jack Screws
M8 Roll-in T-Nut
M8 x 16mm Socket Head Cap Screw
Assembly Note
Ensure the mounting plates are oriented with the jack screws biased towards the outside of the machine.
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.2.1.7
On the side where you are going to locate the tail stock, position the mounting plate flush with the end of the
crossmember.
Fully tighten the fasteners attaching this mounting plate to the crossmembers.
Flush with end of
table crossmember
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.2.1.8
On the side where you are going to locate the chuck, position the mounting plate 124mm (4-7/8") from the end of the
crossmember.
Fully tighten the fasteners attaching this mounting plate to the crossmembers.
124mm (4-7/8")
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.2.2 Rotary Assembly
1.2.2.1
Place the rotary assembly on to the mounting plates as indicated.
Assembly Note
The jack screws in the mounting plates will locate in the t-slots of the 4040 and 4080 rotary crossmembers.
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
1.2.2.4
Center the rotary assembly between the table crossmembers as indicated.
Assembly Note
Keep the rotary assembly parallel with the table crossmembers. This will provide the best starting point for the calibration
procedure.
Avid CNC Rotary Axis
Recessed Installation &
Calibration Instructions
Version 2019Q4.2
© 2019
All Rights Reserved
