EN Indoor rotating 720P IP Wi-Fi camera
ref. 123882
www.avidsen.com
V1
V1
•REC
(Not included)
720p
V1
Google Play
Free available on
Available on the
Google Play
Free available on
Available on the
Free available on
2.4 GHz

CONTENTS
A - SAFETY INSTRUCTIONS 05
1 - OPERATING PRECAUTIONS 05
2 - MAINTENANCE AND CLEANING 05
3 - RECYCLING 05
B - PRODUCT DESCRIPTION 06
1 - KIT CONTENTS 06
2 - CAMERA 06
3 - MAINS ADAPTOR 07
C - INSTALLATION 08
1 - INSTALLING THE CAMERA 08
2 - CONNECTING THE CAMERA 08
3 - INSERTING A MICRO SD CARD (NOT INCLUDED) 08
D - CONFIGURATION 10
1 - CONFIGURING THE CAMERA AND ADDING IT TO THE APP 10
2 - ACCESS TO ALL SETTINGS 11
2.1 - CONFIGURATION 11
2.2 - INFORMATION AND CHANGING THE CAMERA NAME 11
2.3 - MOTION DETECTION AND ALERTS 12
2.4 - SETTINGS FOR RECORDING ON THE MICRO SD CARD 13
E - OPERATION 14
1 - LIVE VIDEO 14
2 - PLAYING CAMERA RECORDINGS 14
3 - PLAYING ALERT VIDEOS 15
4 - ACCOUNT AND LOCAL STORAGE OF YOUR PHOTOS/VIDEOS 15
5 - ALBUM MANAGEMENT 16
5.1 - IOS 16
5.2 - ANDROID 16

3ENEN
ROTATING 720P IP WIFI CAMERA
3EN
F - RESETTING 18
G - FAQ 19
H - TECHNICAL AND LEGAL INFORMATION 21
1 - TECHNICAL CHARACTERISTICS 21
2 - WARRANTY 21
3 - HELP AND ADVICE 21
4 - PRODUCT RETURNS/AFTER-SALES SERVICE 22
5 - DECLARATION OF CONFORMITY 22

5EN
ROTATING 720P IP WIFI CAMERA
A - SAFETY INSTRUCTIONS
1 - OPERATING PRECAUTIONS
• The cameras must not be installed where the
lens filter may be vulnerable to scratching and
dirt.
• Do not expose the lens to direct sunlight or any
reflected light source.
• Do not daisy-chain extension cords and/or
multi-socket adapters.
• Do not install near acidic chemicals, ammonia
or sources of toxic gases.
• The installation and use of the camera must
comply with local laws.
2 - MAINTENANCE AND CLEANING
• Always unplug the product from the mains
before carrying out any maintenance.
• Never use abrasive or corrosive substances to
clean the products.
• Use a soft, slightly damp cloth.
• Never use an aerosol to spray the product as
this may damage the internal workings.
3 - RECYCLING
This logo denotes that devices which are
no longer in use must not be disposed of
as household waste. They are likely to
contain hazardous substances that are
dangerous to both health and the
environment. Return the equipment to
your local distributor or use the recycling collection
service provided by your local council.
Pour en savoir plus :
www.quefairedemesdechets.fr

6
ROTATING 720P IP WIFI CAMERA
EN
B - PRODUCT DESCRIPTION
1 - CONTENTS OF THE KIT
2 - CAMERA
1
7
6 8 9
4
5
2
3
6x 3 5x 3 1x 1
1Camera
2Wall mounting
3230 V A/C 50Hz mains adaptor / 5 V D/C 1A
1Twilight sensor
2Lens
3Light for night vision
4Micro SD slot
5Microphone
4USB cable for powering the camera
5Wall plugs for attaching the base
6Screws for attaching the base
7Narrow tool for WiFi reset
6Wall mount attachment
7Loudspeaker
8WiFi reset button
95V DC 1A mains adaptor power supply
included
3x 1 2x 1 4x 1
Front view View from underneath Rear view
7x 1

7EN
ROTATING 720P IP WIFI CAMERA
B - PRODUCT DESCRIPTION
3 - MAINS ADAPTER
A 230 V A/C 50 Hz / 5 V D/C 1A mains adapter for powering the camera is included in the kit. Do not use
other power supplies as they could damage the camera and invalidate the warranty.

8
ROTATING 720P IP WIFI CAMERA
EN
C - INSTALLATION
1 - INSTALLING THE CAMERA
• Mount the camera using suitable screws and wall plugs for the type of surface (the screws and plugs
supplied are suitable for solid walls).
• Make sure the camera is properly secured to prevent it from falling.
• The camera can also be fitted to a flat surface.
2 - CONNECTING THE CAMERA
3 - INSERTING A MICRO SD CARD (NOT INCLUDED)
Your camera has a micro SD card slot, which gives it an internal storage memory. The maximum size is 64 GB.
This use is optional, but it is necessary if you want the camera to record independently.

9EN
ROTATING 720P IP WIFI CAMERA
C - INSTALLATION
• Ensure the camera lens is perfectly horizontal before inserting a micro SD card.
Note: These operations must be carried out with the camera disconnected from the mains power supply.

10
ROTATING 720P IP WIFI CAMERA
EN
D - CONFIGURATION
1 - CONFIGURING THE CAMERA AND
ADDING IT TO THE APP
Download the Avi-cam IP application from
the appstore or Google Play and then launch the
application.
Important: first connect your smartphone or tablet
to the WiFi network that your camera should be
using.
Network compatibility: 2.4 GHz - 20/40 auto - WPA/
WPA2
Not compatible with 5 GHz WiFi, not compatible
with WEP encryption.
Special characters (#!»&@ etc.) in your security key
or network name as well as HT40 (forced 40 MHz
bandwidth) may lead to connection difficulties.
Please check the WiFi settings of your gateway
with your Internet service provider if you experience
connection difficulties.
• Log in to your account by tapping “Se connecter”
[Log in] and enter your username and password,
finish by tapping “Se connecter” [Log in].
• If you don’t already have an account, tap
“s’enregistrer” [Register]
Fill in the “E-mail” [Email] and “Mot de passe”
[Password] fields E-mail: “indiquez une adresse
e-mail valide” [enter a valid email address].
Mot de passe [Password]: choose a personal
password containing letters and numbers between
6 and 30 characters long.
Press “Envoyez le code de vérification” [Send
confirmation code] Check your inbox in order
to obtain the code, which you will then enter into
the “entrer le code de vérification” [Enter the
confirmation code] field.
Once you have entered the confirmation code, finish
by clicking on “Terminer” [Finish] or “s’enregistrer”
[Register].
Note:if, after 5 min, you still have not received the
email with the code, please make sure the message
was not sorted into your “courrier indésirable”
[junk mail] or “SPAM” [Spam] folder.
When you log into your account for the first time,
tap “Ajout appareil” [Add device] in the centre of
the screen.
Otherwise, tap the “+” button at the top left corner
of the interface.
• Tap “connexion de ma caméra” [connect my
camera] and follow the on-screen instructions.
Enter the password for the WiFi network to which
your smartphone or tablet is connected, then
tap “Suivant” [Next]. Turn the volume on your
smartphone or tablet up to maximum and place it
within 20 cm of the camera. Tap “Envoi Message
Sonore” [Send Sound Message] to configure and
add your camera. If the device hasn’t been added
at the end of the countdown, but the green LED
on your camera remains on for between 30 and
60 seconds, tap “Envoi Message Sonore” [Send
Sound Message] again.

11 EN
ROTATING 720P IP WIFI CAMERA
D - CONFIGURATION
Your camera will appear in the list and you can
access its video and settings. If it does not appear
right away, refresh the camera list by sliding your
finger down the screen.
Note: Your camera is now linked to your user
account, it cannot be added to another account
until you remove it from your list.
If you want to use the camera on several devices,
you will need to either use the main account on
your various devices, or allow another account to
access your camera through the management
menu “Gestion compte invité” [Guest account
management]
2 - ACCESS TO ALL SETTINGS
2.1 - Configuration
From the list of cameras, click the icon to display
the configuration menus:
3
2
5
7
9
10
4
1
6
8
1Return to the list of cameras
2Accessing camera information (name, IP,
MAC, Version, etc.)
3Enables/disables the green status LED on
the camera
4Enables image inverting
5Configuration menu for movement detection
alerts
6Configuration menu for recording quality on
the micro SD card
7
Implementing a locking scheme to protect
your camera's live viewing and recordings.
8Allows you to add a guest account on your
camera to permit others to access your
camera
9Changing the camera's WiFi network: to add
a new WiFi network, you must first connect
to the new network with your smartphone
(the camera must be within reach of the old
and the new WiFi network)
10 Remove the camera from your Avi-cam IP
account
2.2 - Information and changing the camera name
To change your camera's display name, or access
your camera's information, click on the icon on
the camera, and press the “nom actuel” [Current
name] of your camera.
You will receive the following information:

12
ROTATING 720P IP WIFI CAMERA
EN
D - CONFIGURATION
2
4
6
8
1
3
5
7
1Return to the list of cameras
2Menu to rename your camera
3
Allows you to add information about your
camera, location, owner, (useful if you share
your camera with a guest account)
4Displays your camera's current IP address
5Displays your camera's current MAC address
6Displays the name of the WiFi network the
camera is connected to
7Displays your camera's Firmware version
8Displays information about the micro SD
card if present
2.3 - Movement detection and alerts
To access the movement detection and alerts
menu, click on the icon on the camera, and
press “alerte” [Alert].
Note: If a micro SD card is inserted and you enable
alerts, a 30 second recording will automatically be
triggered when movement is detected.
2
3
5
9
1
4
67 8
(iOS)
(Android)
1Return to the list of cameras
2Enabling/disabling movement detection
3
Enabling/disabling the sound alert on your
smartphone: push notification
4Selecting the sound to play when receiving
push notifications on your smartphone
5Selecting the detection sensitivity: Low/
normal/high
6Selecting the movement detection start time
7Activation range
8Selecting the movement detection end time
9Android only: OK button to save time slot

13 ENEN
ROTATING 720P IP WIFI CAMERA
D - CONFIGURATION
2.4 - Settings for recording on the
micro SD card
To access the recording on the micro SD card
menu, click on the icon on the camera, and
press “Stockage vidéo” [Video storage].
2
4
1
3
5
1Return to the list of cameras
2Enable/disable continuous recording on
micro SD card (not included)
Recording quality selection:
3
Fluid = 50KB/s (~2GB/day)
4LD = 100KB/s (~3GB/day)
5HD = 200KB/s (~6GB/day)

14
ROTATING 720P IP WIFI CAMERA
EN
E - OPERATION
1 2 3
1List of cameras
2Alerts
3
Profiles menu and local recording
1 - LIVE VIDEO
From the list of cameras , click the image or the
name of your camera to display the live video:
2
3
8
1
5
6
4
7
1Return to the list of cameras
2Enables full-screen mode
3
Enables the camera's microphone to listen to
the surroundings
4Selection of display quality
5Turn on your smartphone/tablet's microphone
so you can talk through the camera
6Triggers video recording (stored on your
smartphone)
7Not available on this model
8Trigger taking a picture (stored on your
smartphone)
2 - PLAYING CAMERA RECORDINGS
From the list of cameras , click on the “relecture”
[playback] button under the camera name.
Select the date and time to view the corresponding
video.
*Confirm with OK (android)
or
*Confirm with Select (iOS)
If a video is available at the selected date and time,
playback will start automatically.
2
3
4
7
1
5
6

15 ENEN
ROTATING 720P IP WIFI CAMERA
E - OPERATION
1Return to the list of cameras
2Enables full-screen mode
3
Video viewing
4Video progress bar
5Triggers video recording (stored on your
smartphone)
6Starts playing the alert recording
7Trigger taking a picture (stored on your
smartphone)
Note: During live viewing, you can
take photos or record the video on your Smartphone.
You will find them
in the “Mon compte” [My account] section.
3 - PLAYING ALERT VIDEOS
Press on the Alert menu at the bottom of the
interface .
This menu will show the different alerts your camera
will display when motion detection is enabled and
your camera has a micro SD card.
3
4
1
2
1Displaying the date and time of alert
2Name of the camera that raised the alert
3
New message indicator:
UNREAD = video not viewed
No red triangle = video already viewed
4Tap the camera image to start playing the
alert
Note: When playing back an alert recording, you
can take photos or save the clip to store them locally
on your Smartphone. You will find them in the “Mon
compte” [My account] section.
2
3
4
7
1
5
6
1Return to the list of cameras
2Enables full-screen mode
3
Video viewing
4Video progress bar
5Triggers video recording (stored on your
smartphone)
6Starts playing the alert recording
7Trigger taking a picture (stored on your
smartphone)
4 - ACCOUNT AND LOCAL STORAGE OF
YOUR PHOTOS/VIDEOS
Press on the “Mon compte” [My account] menu
at the bottom of the interface.
This menu displays your account management
details: password and recovery options, access to
videos and photos stored in the avi-cam IP app, as
well as information about the app version.

16
ROTATING 720P IP WIFI CAMERA
EN
E - OPERATION
1
2
3
4
1Changing your password and configuring
password recovery options in case of
forgotten password (security question,
emergency e-mail)
2Album containing your manually taken
photos and videos while playing back a
camera
3
Information on the application
4Logs out of your account
5 - ALBUM MANAGEMENT
5.1 - iOS
2
4
1
3
1Return to previous menu
2Enables content management
3
Creation date of the album files
4Displays your photos and videos stored in
the app, tapping on a photo or video will start
playback.
Pressing “gestion du contenu” [content
management] displays new Options
2
5
3
1
4
1Exits the content management menu
2Selects all available content
3
Pressing an image or video selects or
deselects it
4Displays the export to iOS photo album
menu (click on “Stockage smartphone”
[Smartphone storage] to start exporting the
selected items)
5Delete the selected photos and videos
5.2 - Android
2
3
4
1
1Return to previous menu
2Enables content management
3
Creation date of the album files
4Displays your photos and videos stored in
the app, tapping on a photo or video will start
playback

17 ENEN
ROTATING 720P IP WIFI CAMERA
E - OPERATION
Pressing “Editer” [Edit] displays new Options
2
3
4
1
1Exits the content management menu
2Selects all available content
3
Pressing an image or video selects or
deselects it
4Delete the selected photos and videos
Note: With an Android smartphone or tablet, your
photos or videos can be accessed directly from your
device's file browser in the following location:
- If your Android device has an SD card:
SD card / Avidsen / screenshot / name of your
account /
- If your Android device doesn't have an SD card:
Internal SD / Avidsen / screenshot / name of your
account /

18
ROTATING 720P IP WIFI CAMERA
EN
F - RESETTING
If a problem occurs, the WiFi configuration can be
reset by holding the SET button for 3 to 5 seconds.
Once reset, the camera will start up again. After 30
seconds, it is available for reconfiguration.
Note: Pressing the SET button does not delete the
camera pairing from your account.

19 ENEN
ROTATING 720P IP WIFI CAMERA
G - FAQ
Symptoms Possible causes Solutions
Unable to install the avi-cam IP
app from my Android device
You have an out-of-date or
incompatible version of Android
on your device
Please contact the technical
support of your device's
manufacturer in order to obtain a
recent Android version.
Google Play checks all the key
components needed to run
the application properly. If your
equipment does not meet the
necessary criteria, the installation
will not complete
Try the installation on a different
Android device.
Unable to install the avi-cam IP
app on my Apple device
The version of iOS on your device
is not up to date
Update the operating system on
your device.
Your device is not supported.
Avi-cam IP is compatible
with iPhone 4S, iPad 2 and
subsequent models (iOS 8)
The app freezes or there are
bugs
You experience problems
configuring the app or accessing
your camera(s).
Please uninstall the app and
reset your camera(s)
To complete the installation,
please now add your camera(s).
Failure to configure your camera
using a WiFi network from your
smartphone or tablet
Connection to the camera is too
slow or the device is too far from
the internet hub
Move the camera and
smartphone closer to the box/
modem/router
The smartphone/tablet are linked
to an incompatible WiFi network
Please ensure that your
smartphone/tablet is linked to a
2.4GHz network
Cannot connect to camera over
local network
Network/power supply issue Check your network and
electrical connections.
Network configuration problem
Check your camera's network
connection settings. Reset
your camera if it is no longer
accessible.
Cannot connect to camera over
a 3G or 4G Internet link but it
works when connected to a
local network
Network configuration problem Check your device settings (box,
router, firewall)
Incorrect video settings Check the video settings and
reduce the quality if necessary
Your home Internet speed
is insufficient to support
the connection from your
smartphone/tablet
Check that the available
bandwidth exceeds 0.5M
bits per second (upload and
download) in the case of low-
quality display; or that it exceeds
2.0M bits per second in the case
of high-quality HD

EN 20
ROTATING 720P IP WIFI CAMERA
G - FAQ
Symptoms Possible causes Solutions
Poor quality or shaky image Incorrect video settings
Check the video settings and
reduce/increase the quality if
necessary
Movement detection is triggered
unnecessarily
Unsuitable movement detection
settings
Reduce the sensitivity of
detection.
When movement is detected, no
Push alert is received.
Unsuitable movement detection
settings
Please check the configuration
of the camera, the enabled alerts
and the motion sensitivity.
The application is not authorised
to send a Push alert
Please check your avi-cam IP
rights within your iOS application
Security and Privacy settings or
Android application settings
PUSH Notifications only work
when the app is displayed on
the Android screen
Avi-cam IP is not allowed to run
in the background, or has been
completely closed
Relaunch avi-cam IP. Make
sure that no other management
or power saving application
automatically closes the
application in the background.
Your Android device has reached
the maximum limit of applications
launched simultaneously
Close the applications or
increase the limit of simultaneous
applications in your device
settings.
Pairing issues The camera is already paired with
another user account.
You must log in to the account
shown in the error message to
delete the camera before you
can add it to your new account.
If the account shown does
not belong to you, please
contact our technical support
department.
