AVIO Intelligent Projector iP-60E
A Proposal for New
Presentations
Intelligent Projector
User’s Manual
iP-60E
7000547-R01C
Information on the included manuals
These manuals have been prepared to allow you to take full advantages of the set’s
functions.
Select the manual suited to your purpose.
⦁ iP-60E manual (this manual)
Includes information on the operation and handling of the projector.
⦁ iP Viewer Software Quick Reference
Includes a concise description of handling of the “iP Viewer” presentation software.
⦁ iP Viewer Software Manual (PDF format)
Includes more detailed instructions than the Quick Reference. Select according to
your purpose.

A Proposal for New
Presentations
Intelligent Projector
User’s Manual
iP-60E
English

E-2
Thank you for your purchase of an AVIO product.
Please read this manual carefully in order to use the projector properly.
After reading this, please keep it in a safe place together with the warranty sheet.
Features of the iP-60E
• Very versatile five-in-one projector. A projector for the multimedia age.
1. Projection of documents, catalogs, and other printed materials. Printed materials can be projected directly without the
creation of OHP film.
2. Projection of personal computer screen images
Detailed presentations can be made using a personal computer.
3. The video images of video tape decks, DVDs and other equipment can be projected. This permits the creation of pre-
sentations that are visually appealing.
4. Projection images can be imported to a personal computer connected via USB.
5. An image that has been scanned to a personal computer can be written on as one pleases using a tablet or another de-
vice and while doing so the image can be projected.
• Easily understood, simple operation for everyone
One button operation simply switches the projection of printed material, personal computer screen, and video image.
• Designed for a conservation of resources which offers excellent cost performance
The creation of OHP film is not required. This allows a reduction of wasteful time and costs.
• Super-thin, stylish body
The iP-60E features a super-thin body for a projector having a built-in OHP function which reflects the advanced technology
inherent in the design. Offers an easy fit when in use or when stored.
• Expressive color pictures
High-resolution, single-board CCD camera is built in. It provides faithful and clear reproduction of the detailed neutral tones
of color documents with its full-color 16.77 million colors.
• Enlarged display without changing the screen size
When projecting documents having small characters that were not created for presentations, such as catalogs and word-
processed documents, the iP-60E can enlarge the document without changing the screen size to provide an easy-to-view
display.
• Provided with display functions for compressed or enlarged PC screen
Screens of resolution more than 1024 768 dots are displayed compressed to 1024 768 dots without any loss in char-
acter quality. Such as 640 480 resolution screens can also be enlarged to 1024 768 dots.
About Trademarks
IBM and PC/AT are trademarks or registered trademarks of International Business
Machines Corporation.
Macintosh and Power Book are trademarks of Apple Computer Inc.
Windows is a trademark of U.S. Microsoft Corporation.
Warnings and Safety Precautions
Warning Symbols
To alert the user to important safety precautions, the following symbols are used
in this manual and on the product. Make sure you understand what these sym-
bols mean before operating the projector.
WARNING Death or serious injury may result if this warning is ignored.
CAUTION Injury or damage to the equipment may result if this warning is ignored.
NOTE This indicates an item that you should take care of when handling your projector.
This symbol alerts the user to high voltage that could cause electric shock.

E-3
WARNING
●If a fault occurs:
• If you detect smoke, or a strange smell or sound, immediately disconnect the power cable.
It is dangerous to continue using the projector after a fault occurs. Return the projector to the dealer where it was pur-
chased for repair.
●Avoid placing the projector near dangerous substances.
• Make sure that no metallic or flammable material can get into the projector through the air vents.
• Do not place any objects containing water on top of or next to the projector.
●If foreign matter gets inside the projector:
• If foreign matter such as water or metal gets inside, immediately disconnect the power cable.
It is dangerous to continue using the projector when foreign matter gets inside. Return the projector to the dealer where it
was purchased for servicing.
●Do not remove the cabinet.
• Do not remove the cabinet. There are high-voltage components inside and touching these parts could cause electric
shock, or damage the equipment.
●Handle the power cable safely.
• Do not place any heavy objects on top of the power cable.
Damage to the power cable can cause wire breakage, fire, or electric shock.
• Do not pull the power cable when disconnecting the power plug.
Pulling the cable may break the wires or cause fire or electric shock. Always hold the plug itself when pulling it out of the
power outlet.
• Do not damage the power cable. If the power cable is damaged (e.g. the core is exposed or cut), contact the sales office
of purchase. (charged) it could cause fire or electric shock if you continue using the damaged power cable.
• Do not peep into the lens.
• Do not peep into the lens of the projector during operation. The powerful rays passing through the lens could damage the
eyes.
• Do not put the projector in unstable places.
• Do not put the projector in unstable places such as on unstable desks or slopes.
Doing so could cause the projector to drop or turn over, resulting in injury.
• Do not use any voltages other than specified.
• Do not use any voltages other than specified. Doing so could cause fire or electric shock.
• Do not beat the glass surface
• Do not beat the glass surface over the scanner. Doing so may break the glass, resulting in injury.
• Do not touch the air vents or lamp cover
• The air vents, lamp cover, and peripheral surfaces may be high temperature during operation or just after the light is
turned off.
Do not touch those for a long time.
• Do not block the lens front
• Do not block the lens front during operation.
The powerful rays passing through the lens may cause fire or burns if you put anything in front of the lens or block the
lens with your hand during operation.
Warning
Please check the rating of the power cable.
Prior to using a power cable, please make sure that the cable is fully compliant with the power ratings and the type of the plug in
the area and, if not, purchase proper power cable for the area. Do not use the cables for 120V rating to 220V power source.
Using improper cable may cause re or electrical shock to human body.
Safety Precautions

E-4
CAUTION
• Installation
• Avoid installing the projector in places where it may be exposed to:
- Strong vibrations
- Soot or steam
- Direct sunlight or near a heater (35°C/95°F or higher)
- High humidity or dust
- Extreme cold (0°C/32°F or lower)
- Strong magnetic or electric field generated from a nearby appliance
- Wobbling on an unstable surface
• Do not block the air vents.
• Do not block the air vents with cloth or an object.
When you put anything around the unit, be sure to ensure a space of 10 cm/4 inches or more between the unit and the
air vent. Be sure to prevent paper or cloth from blocking the air vent at the bottom of the unit. If blocked, the internal tem-
perature may increase, resulting in malfunctions.
• Do not bump the projector.
• Avoid bumping the projector when moving or handling. Shocks can cause damage.
• Care of the projector
• To prevent risk of accidents, always disconnect the power plug before cleaning the projector.
• Clean the lens surface with a commercial blower or lens cleaning paper.
Wiping with tissue paper or a handkerchief can damage the lens.
• To clean the cabinet, operation panel, and glass surface, wipe gently with a soft cloth. For particularly dirty spots, soak
the cloth in a neutral detergent mixed in water, wring out well and wipe off the dirt, then use a dry cloth to wipe dry.
• Do not wipe the projector with any volatile solvent such as benzine or thinner.
Solvents can cause surface deformation or flaking of the paint.
If using an impregnated cloth, follow the instructions of the cloth.
• Avoid scratching the glass surface.
• Take care not to scratch the glass surface of the scanner with hard or pointed objects.
Scratches on the glass may distort the projected image.
• Battery
• When inserting battery in the remote control, note the polarity (plus and minus signs) and insert correctly as indicated. In-
serting a battery in a wrong direction can cause rupture or leakage, and could result in fire and injury or soil the surround-
ing area.
• Do not use coin battery other than the type specified for the equipment. Incorrect battery usage could result in rupture or
leakage, and could cause fire and injury.
• Do not heat, break open, burn, or immerse the battery. Battery rupture or leakage could cause fire and injury.
• Servicing and cleaning
• Have the internal components cleaned by a retailer about once a year. There is a risk of fire or faulty operation if the
inside of the projector gets dusty and is not cleaned for a long time. For best results, the projector should be serviced be-
fore the wet season brings damp conditions. Cleaning charges are at the discretion of the retailer.
• If not using the projector for a long period:
• If you do not plan to use the projector for a long time, disconnect the power cord for safety.
• Disposal
• Follow the recommendations of your local authority when disposing of the projector.
• Transporting the projector
• Use the special packaging when transporting the projector. The manufacturer cannot accept responsibility in the event of
damage or accident if other packaging is used.
• Use the special packaging no more than two times. Repeated usage reduces the shock absorbency of the packaging and
can lead to damage or accident.
• Contact the retailer if you require new packaging.
Safety Precautions

E-5
• Lamp implosion
• A DC type Super High pressure lamp is used in this projector and it is rare for the lamp to explode during use. The unit is
also designed to forcibly turn off the lamp because there is a high possibility that the lamp will break if it is used beyond
the lamp usage of 1500 hours (Refer to pages E-42 and E-44).
Note the following things
• A sound occurs because the internal pressure of the Super High pressure lamp gets extremely high.
The unit is designed so that no pieces of glass come out of it when the lamp explodes.
• However, the gas inside of the lamp can escape and looks like white smoke.
It will not cause any fire.
Remedy
• If a lamp explodes in a product, there will be pieces of lamp inside. Do not replace the lamp. Return the product to the
sales office or agent of purchase.
Even though the lamp has exploded, never try to replace the lamp by yourself. The lamp pieces could cause injury.
• Replacing the lamp
• Be sure to turn the lamp off and disconnect the power cable when the fan stops, and wait an hour or more before replac-
ing the lamp.
Replacing the lamp during operation or just after the power is turned off may cause burns due to heat.
Refer to “Lamp Unit Replacement” on page E-42 for the procedure.
• Replacing / cleaning the air filter
• Be sure to disconnect the power cable when the cooling fan stops before removing the air filter.
Removing the air filter while the cooling fan is rotating could cause a accident.
Refer to “Cleaning the Air Filter” on page E-45 for the procedure.
• Avoiding malfunctions and accidents
• Adjust the Adjustable feet to keep the projector horizontally.
Using the projector in a tilted status may cause injury if it rolls over. Refer to
“Adjusting the Tilt” on page E-22 for the adjusting procedure.
• Do not do the followings
• Do not put anything heavy on the projector.
• Do not step on the projector, rack, or stand. Do not hold or hang on the projector.
Doing so could cause the projector to roll over or break, resulting in injury.
Especially be careful if small children are near.
• Do not use the rack unless the casters are locked when placing the projector on a rack with casters.
Doing so may cause the projector to move or roll over, resulting in injury.
• Do not turn the lamp on/off within one minute after it is turned off/on. Extremely high voltage is generated in the lamp just
after it is turned on. Turning the lamp on/off too frequently could cause the lamp to deteriorate or break, resulting in mal-
functions of the projector.
• Do not project an image with the lens cap attached.
• The cover that is attached to the bottom of the projector is strictly intended for maintenance purposes and should not be
opened by anyone except for service personnel
• Do not hold the projector by the focus adjustment ring. Doing so will cause an accident or damage.
• Moving the projector
• Be sure careful of the glass surface at moving the projector while holding the handles.
• If the document cover is not inserted enough, it may get loose and fall off while you carry it.
• Care of the power cable and plug
• Do not put the power cable near a heater.
Doing so could cause the sheath of the cable to melt down, resulting in fire or electric shock.
• Do not connect or disconnect the power cable with wet hands. Doing so could cause electric shock.
• Be sure to pull out the power cable and disconnect any cable connections between units and release the anti-theft lock
before moving the projector.
Moving the projector with cables connected may cause fire or electric shock if the cables are damaged.
• If you do not plan to use the projector for a long time, disconnect the power cable for safety.
• DO NOT REMOVE ANY SCREWS except the lamp cover screw and two lamp unit screws. Otherwise you could re-
ceive an electric shock.
• Light Polarizing Element
Light polarizing elements such as the light source lamp and the liquid crystal panel are parts that have a service life. When
used for a long time, repair and replacement will be necessary. Please contact a customer support center for details.
Safety Precautions

E-6
Table of Contents
Safety Precautions ................................................. E-3
A Check of the Supplied Items
and the Names of the Parts .............................. E-7
Supplied Parts Check............................................... E-7
Names and Functions of the Parts (Projector) ......... E-8
Names and Functions of the Parts (Input/Output Connectors) ...... E-10
Names and Functions of the Parts (Operation Panel) ............ E-11
Names and Functions of the Parts (Remote Control) ............ E-12
Operation of the Remote Control............................ E-13
Battery Replacement.............................................. E-13
Procedure Up to Projection................................. E-14
Projection Distance and Screen Size ................. E-15
Connections with the Personal Computer ................... E-16
Basic Connections.................................................. E-16
Connections with Personal Computers ................. E-16
Personal Computer Input Connector...................... E-17
When the Image of the Personal Computer
Screen Is Not Projected ................................... E-18
Table of Supported Input Signals
(Personal Computer Video Input Connector) .... E-19
Connections with Video Equipment ................... E-20
Connection of the Power Cable and
On/Off Switching ............................................. E-21
Switch On the Power.............................................. E-21
Switch Off the Power.............................................. E-21
Adjustment of the Projection Image ................... E-22
Adjusting the Projection Image............................... E-22
Making Focus/Zoom Adjustments .......................... E-22
Adjusting the Tilt (Slant) ......................................... E-22
Regular Operation ................................................ E-23
Select the Input....................................................... E-23
Changing the Orientation of the Projection Image.. E-23
Enlarging and Reducing the Projection Image ....... E-24
Adjusting the size of the projected image............... E-25
Adjusting the Brightness......................................... E-26
Capturing the Projection Image/ Still Image Display ..... E-26
Viewing OHP History Images ................................. E-27
Transferring Captured Images................................ E-28
Adjusting the Volume.............................................. E-28
Displaying the Pointer............................................. E-29
Deleting the Projection Image and Audio ............... E-29
Method of OHP Operation.................................... E-30
Attaching the Document Cover............................... E-30
Preparation of the Projection Document................. E-30
Reading Size of Projection Documents.................. E-30
Menu Configuration.............................................. E-31
Menu Operation Method ...................................... E-32
Names and Functions of the Buttons Used
in Menu Operation........................................ E-32
Names and Functions of the Menu Parts ............... E-32
Method of Menu Operation..................................... E-33
Menu Description ................................................. E-35
Pointer · Screen....................................................... E-35
Image adjustment................................................... E-36
Settings................................................................... E-38
Maintenance.......................................................... E-40
Fault Protection ...................................................... E-40
Replacement of the Lamp Unit............................... E-42
Cleaning the Air Filter............................................. E-45
Troubleshooting ................................................... E-46
Repair Service....................................................... E-47
Specifications ....................................................... E-48

E-7
User's manual
A Check of the Supplied Items and the Names of the Parts
Supplied Parts Check
Please check that the supplied parts are included.
Lens cap
iP-60E Projector
Power cable (3 m)
Remote control
iP-60E User’s Manual
PC connection cable (2 m)
Battery (AA x 2)
iP Viewer Software Quick Reference

E-8
󲻃
Document cover
The document or printed material to be read
is placed under this cover.
See Page E-30.
Operation panel
The buttons used for regular operation are
located here. See Page E-11.
Speaker
Air Vent A (air filter)
(side of main unit)
Air is taken in through this
vent. An air filter is provided
to prevent dust from getting
inside the projector.
See page E-45.
Theft prevention lock
Please see the Note below.
Tilt adjustment lever
Press here to adjust the tilt foot. See Page
E-22.
Tilt foot
This foot is used to adjust the vertical angle
of the projection as well as the left-right bal-
ance. Turning it to the left extends it and turn-
ing it to the right shortens it. See Page E-22.
Lens cap
Zoom lever
Turn this to adjust the screen size. See Page E-22.
Projection lens
The image is projected from
here.
* Be sure to remove the lens
cap before projecting.
Focus adjustment ring
Turn this to adjust the focus.
See Page E-22.
Tilt foot
Remote control IR sensor
A Check of the Supplied Items and the Names of the Parts
Names and Functions of the Parts (Projector)
Handle
• Extended
Press lightly on the left side
of the handle and it rotates
180˚ and comes out.
• Retracted
Rotate the handle while
pressing on its right side to
store it.
NOTE
About the anti-theft lock
The anti-theft lock is compatible with Kensington security cable lock.
Contact the following for more information about the products.
Kensington Technology Group
2000 Alameda de las Pulgas
Second Floor
San Mateo, California 94403-1289, U.S.A.
Phone: [phone]
Fax: [phone]
URL: http://www.kensington.com
7mm
3mm

E-9
Power input connector
Plug in the power cable
here. See Page E-21.
Speaker (1W Stereo)
Tilt foot
Input/Output connector panel
The connectors for the personal
computer, video, and other connec-
tions are located here.
See Page E-10.
Lamp unit cover (Underneath projector)
The projection lamp unit is located inside.
See Page E-42.
Remote control IR sensor
Tilt foot
Air Vent B
Air is discharged from the inside to
the outside through this vent.
Scanner
Place documents or printed matter here to
project images when OHP is selected.
See page E-30.
Document reading area
The document or printed material that you wish to
project in the OHP mode is placed here.
See Page E-30.
A Check of the Supplied Items and the Names of the Parts
