Avitech Sequoia UHD User manual

User Manual
Sequoia UHD / UHD+ / UHD/T / UHD/T+
Simplified UHD Multi-viewer Solution for Multiple Computer and Video
System
Revision 1.0.1, (April, 2018)

User Manual
ii
ABOUT THIS MANUAL
This manual contains information on how to use the Avitech Sequoia UHD / UHD+ / UHD/T / UHD/T+ keyboard
mouse controller. There are six chapters in this manual.
Getting Started introduces features and specifications as well as external components of the Avitech Sequoia
UHD / UHD+ / UHD/T / UHD/T+.
System Configuration discusses the process of setting up your Sequoia UHD / UHD+ / UHD/T / UHD/T+.
Basic Operations introduces the two types of operating modes and demonstrates the keyboard and mouse
hot-keys to perform basic operations, as well as using the on-screen pop-up menu to configure your Sequoia
UHD / UHD+ / UHD/T / UHD/T+.
Using the Mouse Right-click Menu, Changing the Background Image and Salvo discusses display and
feature settings for the Sequoia UHD / UHD+ / UHD/T / UHD/T+ such as customization of the user interface,
presets save/load, alarm setup, audio routing, file transfer, and hot-key hint. It also touches on setting the
background image of the preview area of the in-system GUI as well as configure salvo to map sources and
destinations (routings).
Video Wall Management provides the steps necessary to setup 1×1 and 2×2 and 2×3 and 3×4 wall display.
Using the Touch-screen discusses the process of using the touch-screen feature.
The following conventions are used to distinguish elements of text throughout the manual.
provides additional hints or information that require special attention.
identifies warnings which must be strictly followed.
Any name of a menu, command, icon or button displayed on the screen is shown in a bold typeset.
For example: On the Start menu select Settings.
Any name that refers to a mode is underlined.
For example: Windows can be adjusted by the Host cursor when the Sequoia UHD / UHD+ / UHD/T / UHD/T+ are in
Host mode.
To assist us in making improvements to this user manual, we welcome any comments and constructive criticism.
Please email us at: [email protected].
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Do not attempt to disassemble the Sequoia UHD / UHD+ / UHD/T / UHD/T+. Doing so may void the warranty. There
are no serviceable parts inside. Please refer all servicing to qualified personnel.
WARNING
Hazardous moving parts
Keep away from moving fan blades
TRADEMARKS
All brand and product names are trademarks or registered trademarks of their respective companies.
COPYRIGHT
The information in this manual is subject to change without prior notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical for any purpose, without the
express written permission of Avitech International Corporation. Avitech International Corporation may have
patents, patent applications, trademarks, copyrights or other intellectual property rights covering the subject matter
in this document. Except as expressly written by Avitech International Corporation, the furnishing of this document
does not provide any license to patents, trademarks, copyrights or other intellectual property of Avitech International
Corporation or any of its affiliates.
TECHNICAL SUPPORT
For any questions regarding the information provided in this guide, call our technical support help line at
425-885-3863, or our toll free help line at 1-877-AVI-TECH, or email us at: [email protected].

iii
Contents
About This Manual.......................................................................................................................ii
Trademarks...................................................................................................................................ii
Copyright ......................................................................................................................................ii
Technical Support........................................................................................................................ii
Warranty......................................................................................................................................vii
Limitation of Liability.................................................................................................................vii
Extended Warranty Options......................................................................................................vii
Services and Repairs Outside the Warranty Period...............................................................vii
Regulatory Information..............................................................................................................vii
Federal Communications Commission (FCC) Statement......................................................vii
European Union CE Marking and Compliance Notices .........................................................vii
Australia and New Zealand C-Tick Marking and Compliance Notice ...................................vii
1. Getting Started............................................................................................................ 1
1.1 Package Contents.................................................................................................................2
1.2 Product Features ..................................................................................................................3
1.3 Specifications .......................................................................................................................4
1.4 Connections to the Sequoia UHD / UHD+ / UHD/T / UHD/T+............................................6
2. System Configuration............................................................................................... 11
2.1 Installing aNew Module on aBlank Slot..........................................................................11
2.2 Removing aPreviously Installed Module.........................................................................12
2.3 Getting the Sequoia UHD Ready.......................................................................................14
2.3.1 Basic Setup...............................................................................................................14
2.3.2 Sequoia UHD/T with Pacific X-IPT / X-IPTR (RX) / X-IPRW / X-IPRG
Connected via Gigabit IGMP Switch......................................................................16
Connections to the Pacific X-IPT.........................................................................................17
Connections to the Sequoia UHD/T.....................................................................................17
Connections to the Pacific X-IPTR (RX) and Pacific X-IPRW Workstation.......................18
Connections to the Pacific X-IPTR (RX)..............................................................................19
Connections to the Pacific X-IPRG......................................................................................20
Powering Up the Devices.....................................................................................................20
Configuring the Pacific X-IPRG ...........................................................................................20
Configuring the Pacific X-IPT...............................................................................................21
Configuring the Pacific X-IPTR Workstation ......................................................................22
Configuring the Pacific X-IPTR............................................................................................23
Configuring the Pacific X-IPRW...........................................................................................23
Configuring the Sequoia UHD/T...........................................................................................23
Routing TX to RX...................................................................................................................24
EDID Read..............................................................................................................................24
Sequoia UHD “Surfer” Mode Limitation..............................................................................24

iv
2.3.3 Sequoia UHD to 2×2 Video Wall with Pacific X-IPT Connected via Gigabit
IGMP Switch .............................................................................................................26
Connections to the Pacific X-IPT.........................................................................................27
Connections to the Sequoia UHD........................................................................................28
Powering Up the Devices.....................................................................................................29
Configuring the Pacific X-IPT...............................................................................................29
Configuring the Sequoia UHD..............................................................................................31
Routing TX to RX...................................................................................................................31
2.3.4 Two Sequoia UHD/T+ to 2×3 Video Wall with Two Pacific X-IPT Connected
via Gigabit IGMP Switch..........................................................................................32
Connections to the Two Pacific X-IPT.................................................................................33
Connections of the Two Sequoia UHD+ Connect to Wall Display....................................33
On the Sequoia UHD+ 1........................................................................................................34
On the Sequoia UHD+ 2........................................................................................................34
Connections to the Controlling Sequoia UHD/T+...............................................................34
Powering Up the Devices.....................................................................................................35
Configuring the Two Pacific X-IPT.......................................................................................35
Configuring the Controlling Sequoia UHD/T+ as well as Sequoia UHD+ 1and 2............37
Routing TX to RX...................................................................................................................37
3. Basic Operations ...................................................................................................... 38
Host Mode..............................................................................................................................38
Remote Mode ........................................................................................................................38
Tips on Navigating the Sequoia UHD..................................................................................38
3.1 Host Mode ...........................................................................................................................39
3.1.1 Pop-up Selections....................................................................................................39
3.1.2 Functions (multiview display).................................................................................39
3.1.3 Hot-keys....................................................................................................................40
3.2 Remote Mode......................................................................................................................41
4. Using the Mouse Right-click Menu, Changing the Background Image and Salvo43
4.1 Mouse Right-click Menu.....................................................................................................43
Layout preset ........................................................................................................................44
Save preset............................................................................................................................44
Load preset............................................................................................................................44
Delete preset by name..........................................................................................................45
Display...................................................................................................................................45
Change output resolution ....................................................................................................45
Keep aspect ratio..................................................................................................................45
Flip..........................................................................................................................................45
Display mode.........................................................................................................................45
Display mode background color..........................................................................................45
Label.......................................................................................................................................46
Display label..........................................................................................................................46
Display IP UMD......................................................................................................................46

v
Define label............................................................................................................................46
Label outside video...............................................................................................................47
Blending.................................................................................................................................47
Label auto-hide......................................................................................................................47
Display label when full screen.............................................................................................47
Border....................................................................................................................................47
Border color ..........................................................................................................................47
Border width..........................................................................................................................48
Active window border...........................................................................................................48
Display active window border..............................................................................................48
Active window border color (Surfer mode) / (Normal mode) ............................................48
Video alarm............................................................................................................................49
Display signal format............................................................................................................49
Display signal format............................................................................................................49
Signal format auto-hide........................................................................................................49
Blending.................................................................................................................................49
Tally........................................................................................................................................49
HDMI tally color.....................................................................................................................49
Headphone tally color...........................................................................................................50
Full screen control................................................................................................................51
Automatically enter Remote mode......................................................................................51
Apply previous layout upon leaving Remote mode...........................................................51
Fading level ...........................................................................................................................51
Audio routing ........................................................................................................................52
Marquee.................................................................................................................................54
Window drag/resize preview frame .....................................................................................56
Show IP TX/RX list ................................................................................................................56
Show IP salvo list..................................................................................................................60
IP card setup .........................................................................................................................60
Video wall management .......................................................................................................60
File transfer ...........................................................................................................................60
Set copy file via USB ............................................................................................................60
Terminate copy file ...............................................................................................................60
System ...................................................................................................................................60
Network..................................................................................................................................61
Power / Fan / Thermal alarm ................................................................................................62
Export to USB disk................................................................................................................62
Language...............................................................................................................................63
USB device path....................................................................................................................63
Mouse setup..........................................................................................................................63
KM assign..............................................................................................................................63
Reset factory defaults...........................................................................................................63
Read EDID from screen........................................................................................................63

vi
Firmware version ..................................................................................................................64
Hot-key overview...................................................................................................................64
4.2 Changing the Background Image .....................................................................................64
4.3 Salvo ....................................................................................................................................66
4.3.1 Configure aSalvo ....................................................................................................66
5. Video Wall Management........................................................................................... 69
5.1 Basic Video Wall Management Setup...............................................................................69
Set Genlock Source..............................................................................................................76
5.2 Additional Adjustments For 1×1 Wall Display.................................................................89
6. Using the Touch-screen ........................................................................................... 98
Host Mode..............................................................................................................................98
Remote Mode ........................................................................................................................98
Tips on Navigating the Touch-screen Monitor Using the Sequoia UHD / UHD/T ............98
6.1 Pop-up Selections ..............................................................................................................99
6.1.2 Functions (multiview display).................................................................................99
6.2 Drop-down Auto-hide Menu ............................................................................................100
6.3 Lock/Unlock Window Layout...........................................................................................101
6.4 Audio Controls..................................................................................................................102
6.5 Move/Resize/Close Window ............................................................................................103
6.6 Exit from Remote Operation Mode to Host Operation Mode .......................................103
6.7 Switch Control (Cycle) Between Full Screen Windows................................................104
Appendix AUsing the GO! Bridge Utility .................................................................. 106
Appendix BUsing the “Surfer” Feature .................................................................... 113
B.1 “Surfer”Feature on Uniform Quad Layout That Fills Entire Screen...........................114
B.2 “Surfer”Feature on Non-adjoining Quad Layout..........................................................116
B.3 “Surfer”Feature on Full Screen “Image”Window........................................................116
B.3.1 “Image” Window Control Switching ....................................................................116
B.3.2 Monitor Control Switching (Dual Display Setup)................................................117
Appendix CUsing the Auto-hide Menu ..................................................................... 118
Appendix DResetting to the Factory-Default State.................................................. 119

vii
Warranty
Avitech International Corporation (herein after referred to as “Avitech”)
warrants to the original purchaser of the products manufactured in its
facility (the “Product”), that these products will be free from defects in
material and workmanship for a period of 1 year or 15 months from the
date of shipment of the Product to the purchaser. There is a 3 month
grace period between shipping and installation.
If the Product proves to be defective during the 1 year warranty period,
the purchaser’s exclusive remedy and Avitech’s sole obligation under
this warranty is expressly limited, at Avitech’s sole option, to:
(a) repairing the defective Product without charge for parts and labor;
or (b) providing a replacement in exchange for the defective Product;
or (c) if after a reasonable time is unable to correct the defect or
provide a replacement Product in good working order, then the
purchaser shall be entitled to recover damages subject to the limitation
of liability set forth below.
Limitation of Liability
Avitech’s liability under this warranty shall not exceed the purchase
price paid for the defective product. In no event shall Avitech be liable
for any incidental, special, or consequential damages, including
without limitation, loss of profits for any breach of this warranty.
If Avitech replaces the defective Product with a replacement Product
as provided under the terms of this Warranty, in no event will the term
of the warranty on the replacement Product exceed the number of
months remaining on the warranty covering the defective Product.
Equipment manufactured by other suppliers and supplied by Avitech
carries the respective manufacturer’s warranty. Avitech assumes no
warranty responsibility either expressed or implied for equipment
manufactured by others and supplied by Avitech.
This Warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty of merchantability or
fitness for a particular purpose, all of which are expressly disclaimed.
This Hardware Warranty shall not apply to any defect, failure, or
damage: (a) caused by improper use of the Product or inadequate
maintenance and care of the Product; (b) resulting from attempts by
other than Avitech representatives to install, repair, or service the
Product; (c) caused by installation of the Product in a hostile operating
environment or connection of the Product to incompatible equipment;
or (d) caused by the modification of the Product or integration with
other products when the effect of such modification or integration
increases the time or difficulties of servicing the Product.
Any Product which fails under conditions other than those specifically
covered by the Hardware Warranty, will be repaired at the price of
parts and labor in effect at the time of repair. Such repairs are
warranted for a period of 90 days from date of reshipment to customer.
Extended Warranty Options
Avitech offers OPTIONAL Extended Warranty plans that provide
continuous coverage for the Product after the expiration of the
Warranty Period. Contact an Avitech sales representative for details
on the options that are available for the Avitech equipment.
Services and Repairs Outside the Warranty Period
Avitech makes its best offer to repair a product that is outside the
warranty period, provided the product has not reached its end of life
(EOL). The minimum charge for such repair excluding shipping and
handling is $200 (US dollars).
AVITECH INTERNATIONAL CORPORATION
● 15377 NE 90th Street Redmond, WA 98052 USA
● TOLL FREE 1 877 AVITECH
● PHONE [phone]
● FAX [phone]
●[e-mail]
● http://avitechvideo.com
Regulatory Information
Marking labels located on the exterior of the device indicate the
regulations that the model complies with. Please check the marking
labels on the device and refer to the corresponding statements in this
chapter. Some notices apply to specific models only.
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense. Properly
shielded and grounded cables and connectors must be used in order
to meet FCC emission limits. Avitech is not responsible for any radio or
television interference caused by using other than recommended
cables and connectors or by unauthorized changes or modifications to
this equipment. Unauthorized changes or modifications could void the
user's authority to operate the equipment. Operation is subject to the
following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
European Union CE Marking and Compliance Notices
Statements of Compliance
English
This product follows the provisions of the European Directive
1999/5/EC.
Dansk (Danish)
Dette produkt er i overensstemmelse med det europæiske direktiv
1999/5/EC.
Nederlands (Dutch)
Dit product is in navolging van de bepalingen van Europees Directief
1999/5/EC.
Suomi (Finnish)
Tämä tuote noudattaa EU-direktiivin 1999/5/EC määräyksiä.
Français (French)
Ce produit est conforme aux exigences de la Directive Européenne
1999/5/EC.
Deutsch (German)
Dieses Produkt entspricht den Bestimmungen der Europäischen
Richtlinie 1999/5/EC.
Ελληνικά (Greek)
To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας
1999/5/EC.
Íslenska (Icelandic)
Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer
1999/5/EC.
Italiano (Italian)
Questo prodotto è conforme alla Direttiva Europea 1999/5/EC.
Norsk (Norwegian)
Dette produktet er i henhold til bestemmelsene i det europeiske
direktivet 1999/5/EC.
Português (Portuguese)
Este produto cumpre com as normas da Diretiva Européia 1999/5/EC.
Español (Spanish)
Este producto cumple con las normas del Directivo Europeo
1999/5/EC.
Svenska (Swedish)
Denna produkt har tillverkats i enlighet med EG-direktiv 1999/5/EC.
Australia and New Zealand C-Tick Marking and
Compliance Notice
Statement of Compliance
This product complies with Australia and New Zealand's standards for
radio interference.

1
1. Getting Started
The Avitech Sequoia UHD is a highly innovative device that comes with its own embedded operating
system and graphic engines. The Sequoia UHD integrates functions of a KVM (keyboard video mouse)
switch and a robust multi-viewer into one enclosure, providing a simple multi-viewing solution for any
user who works in an environment with multiple computer and video systems. With a single Sequoia
UHD being able to connect up to four-plus-one computers and instantly switch inputs among them,
users can monitor and remotely control any four computers at the same time on a single display plus a
fifth computer on a full-screen display with just one set of keyboard and mouse. With the added option of
IP-based remote control, this ensures intuitive user experience at the router’s destination over an
extended distance from source devices, and allowing streamlined access to a bank of computers by a
single keyboard/mouse. The Sequoia UHD also supports a variety of video formats from HDMI to DVI-D.
With the SUHD-IP module installed in your Sequoia UHD, intuitive signal switching and routing can be
achieved through the in-system GUI. The IP TX/RX list panels provide full configurations for switching/
routing of video signals. User can freely switch a detected TX source to any of the four built-in RX ports
in the SUHD-IP module, or route a TX source to any of the detected Avitech RX devices in the same
network mask through the IP TX/RX list panels, performing centralized management over all connected
devices.
The Sequoia UHD features an on-screen pop-up selection plus mouse right-click menu that allows
handy operation and control of the device. By clicking the relevant pop-up selections’ icon or pressing
the hot-keys through the keyboard, users can easily convert monitoring styles to various layouts, and
adjust windows to any size and position on the display. The mouse right-click menu allows users to
freely set up or configure numerous features for different applications; including audio source routing.
In addition to its interface and features, the Sequoia UHD can enter Remote mode to transfer keyboard
and mouse control from the Sequoia to the connected computer systems. Users can then remotely
control any of the connected computers with the set of keyboard and mouse on the Sequoia. The
“Surfer”feature, along with other user-friendly commands supported by the Sequoia UHD allows users
to freely switch control between the computers and the host Sequoia in an intuitive manner.
This chapter will continue to introduce more features and specifications as well as external components
of your Sequoia UHD / UHD+ / UHD/T / UHD/T+.
The information appearing in this manual applies to Sequoia UHD / UHD+ / UHD/T / UHD/T+, as well as the
IP receiver modules (Sequoia UHD-IPc / UHD-IPf), UHD to HD converter module (Sequoia UHD2HD) and
the KM card (Sequoia UHD-KM)), which can be ordered to create highly customized systems. All of the
Sequoia series add-on cards are compatible with either of the Sequoia UHD models.
To get the best results from Sequoia UHD, we recommend the following:
When using your mouse with a 4K display, select a mouse that has a 2000 dpi setting.
In industrial environments, use shielded Ethernet cables (shielded Ethernet cables are often marked
F/UTP or FTP).

2
1.1 Package Contents
The following standard items are included in the shipping package:
Avitech Sequoia UHD / UHD+ /
UHD/T / UHD/T+
Utility Disc (user manual)
12 VDC Power Adapter (optional)
Standard Power Cord (USA customer only)
HDMI to DVI Adapter (optional)
Ear with Screw
(installed on Sequoia UHD upon order for
assembly on to rack mount)
USB A/B Cable (length 1.8 m –optional)
HDMI®Cable (length 1.8 m –optional)
Male to Dual Male YSplitter Audio Cable
(length 1.8 m –optional)
D
Table 1-1 Package Contents

3
1.2 Product Features
Model
KM Module
IP Module
UHD2HD Converter
Module
Cascadable
REF I/O
IP Transmitter
Sequoia UHD
Optional
Optional
Optional
N/A
N/A
N/A
Sequoia
UHD+
Optional
Optional
Optional
√
BNC (2)
N/A
Sequoia
UHD/T
Optional
Optional
Optional
N/A
N/A
CAT-5e/6 /
SFP
Sequoia
UHD/T+
Optional
Optional
Optional
√
BNC (2)
CAT-5e/6 /
SFP
Table 1-2 Sequoia UHD Series Comparison
The Sequoia UHD is HDCP-compliant and capable of handling HDMI®and DVI-D inputs. Featuring four
HDMI input ports, and one HDMI output port, a single Sequoia UHD can connect up to four-plus-one
computers, four videos, or any combination of four inputs. It can simultaneously display four inputs on a
single display, and allows instant switching of inputs through its OSD.
The Sequoia UHD features automatic sensing of input signals, automatic detection and selection of
optimum display resolution; it also supports hot-swapping which allows addition and removal of any
input/output signals without powering down the device. Genlock capability supports synchronizing
multiviewer outputs to the reference signal and the rest of studio/production equipment.
For audio monitoring of the four remote computers, the Sequoia UHD features four 1/8 inch headphone
jack via the proprietary Sequoia male to dual male Y splitter audio cable. It also allows monitoring of the
fifth computer on another 1/8 inch headphone jack via the proprietary Sequoia male to dual male Y
splitter audio cable.It accepts embedded HDMI®audio (8ch-stereo). Instant switching of audio signal
source for audio routing including “mix” and “mute” is available through the right-click menu.
For operation, Sequoia UHD provides convenient on-screen pop-up selections
and right-click menu as well as easy to recall hot-keys that can be controlled by a set of keyboard and
mouse, allowing free switching of operating modes and adjustments for numerous behavior that suits
different applications.
In addition to monitoring, the Sequoia UHD can remotely control the connected computers through the
USB keyboard and mouse connected to its rear panel. Utilizing the “Surfer”feature –which allows users
to transfer keyboard and mouse control from one computer to another by simply moving the mouse
cursor to the window border of the targeted computer, the Sequoia UHD is able to seamlessly switch
between and control any of the four-plus-one computers connected to it with just one set of keyboard
and mouse. Up to two IP cards (SUHD-IP) used in conjunction with Avitech’s Pacific extenders allows
sources to be installed out-of-sight at central, air-conditioned equipment rack and accessed remotely.
What is a window?
A window is a container for an input source. You can have multiple windows playing the same source. You
can resize and move windows in the user interface.
The Sequoia UHD is also extremely scalable; users can easily expand the system by cascading up to 25
chassis which allows for the monitoring of up to 100 signal sources on multiple screens.
The maximum number of Sequoia UHD chassis that can be cascaded may be limited only by the minimum
Image size that user deems acceptable in the monitor display.
Integrated file and folder transfer across computers provides convenient file management. By selecting
an origin and a destination through the onscreen user interface, the Sequoia UHD allows simple copy/
cut and paste of files/folders across connected computers using its embedded file managing tool (Go!
Bridge Utility).

4
The Sequoia’s front panel features LED indicator for monitoring Power.
The temperature monitor with automatic PWM fan speed controls to protect against system failure. The
low noise and speed-varying fan along with the stand-alone and rack mountable module designs make
the Sequoia UHD suitable for various work environments.
1. Non-standard keyboards (i.e. keyboards with a USB hub, keyboards that need driver installation and
programmable keyboards, etc.) are not supported.
2. Compatibility between the computer and the Sequoia UHD may depend on the computer’s BIOS Setup.
If an incompatibility occurs, refer to the computer’s BIOS Setup and make sure USB port is enabled if this
item exists in the computer’s BIOS Setup (typically found in the "Advanced" or "Onboard Device
Configuration" menu).
1.3 Specifications
Supported HDMI /
DVI-D Input Format
Supported HDMI Output Format
4096×2160p
25Hz
4096×2160p
30Hz
3840×2160p
25Hz
3840×2160p
30Hz
1920×1080p
50Hz
1920×1080p
60Hz
3840×2160p 30Hz
√
√
√
√
√
√
3840×2160p 29.97Hz
√
√
√
√
√
√
3840×2160p 25Hz
√
√
√
√
√
√
3840×2160p 24Hz
√
√
√
√
√
√
2048×2048p 56.57Hz
√
√
√
√
√
√
1920×1200 60Hz
(Reduced Blanking)
√
√
√
√
√
√
1920×1200 50Hz
(Reduced Blanking)
√
√
√
√
√
√
1920×1080p 60Hz
√
√
√
√
√
√
1920×1080p 59.94Hz
√
√
√
√
√
√
1920×1080p 50Hz
√
√
√
√
√
√
1920×1080p 30Hz
√
√
√
√
√
√
1920×1080p 29.97Hz
√
√
√
√
√
√
1920×1080p 25Hz
√
√
√
√
√
√
1920×1080p 24Hz
√
√
√
√
√
√
1920×1080p 23.97Hz
√
√
√
√
√
√
1920×1080i 60Hz
√
√
√
√
√
√
1920×1080i 59.94Hz
√
√
√
√
√
√
1920×1080i 50Hz
√
√
√
√
√
√
1680×1050 60Hz
√
√
√
√
√
√
1680×1050 50Hz
√
√
√
√
√
√
1600×1200 60Hz
√
√
√
√
√
√
1600×1200 50Hz
√
√
√
√
√
√
1440×900 60Hz
√
√
√
√
√
√
1440×900 50Hz
√
√
√
√
√
√
1400×1050 60Hz
√
√
√
√
√
√
1400×1050 50Hz
√
√
√
√
√
√
1366×768 60Hz
√
√
√
√
√
√
1366×768 50Hz
√
√
√
√
√
√
1360×768 60Hz
√
√
√
√
√
√
1360×768 50Hz
√
√
√
√
√
√
1280×1024 75Hz
√
√
√
√
√
√
1280×1024 60Hz
√
√
√
√
√
√
1280×1024 50Hz
√
√
√
√
√
√
1280×960 60Hz
√
√
√
√
√
√
1280×960 50Hz
√
√
√
√
√
√
1280×720p 60Hz
√
√
√
√
√
√
1280×720p 59.94Hz
√
√
√
√
√
√

5
Supported HDMI /
DVI-D Input Format
Supported HDMI Output Format
4096×2160p
25Hz
4096×2160p
30Hz
3840×2160p
25Hz
3840×2160p
30Hz
1920×1080p
50Hz
1920×1080p
60Hz
1280×720p 50Hz
√
√
√
√
√
√
1024×768 75Hz
√
√
√
√
√
√
1024×768 60Hz
√
√
√
√
√
√
1024×768 50Hz
√
√
√
√
√
√
800×600 75Hz
√
√
√
√
√
√
800×600 60Hz
√
√
√
√
√
√
800×600 50Hz
√
√
√
√
√
√
720×576p 50Hz
√
√
√
√
√
√
720×576i 50Hz
√
√
√
√
√
√
720×480i 60Hz
√
√
√
√
√
√
720×480i 59.94Hz
√
√
√
√
√
√
720×480p 60Hz
√
√
√
√
√
√
720×480p 59.94Hz
√
√
√
√
√
√
640×480p 60Hz
√
√
√
√
√
√
Table 1-2 Supported HDMI Output Format
Others
Peripheral / File
Sharing
Method:
USB type A port (for USB 2.0 hub)
GO! Bridge Utility software
Computer
Connection
Up to 5 units (maximum for single Sequoia UHD system)
Up to 25 units (maximum for cascaded Sequoia UHD systems)
Port Switching
Method:
Keyboard hot-keys (both in Host and Remote operation modes)
Mouse
OSD (pop-up menu –in Host operation mode)
Surfer feature (both in Host and Remote operation modes)
Operating System
Microsoft Windows 2000 Professional / XP / Vista / Server 2003 / Server
2008 / Windows 7 / Windows 8 / Windows 10
Mac (O/S X 10.5 or later version only)
Linux OS: Fedora 10, Ubuntu 8.1, Scientific 5.2, RedHat, Mint 6.0,
Debian 5.0, PC Linux OS 2009, SUSE 11.1, Mandriva 2009, CentOS
5.2, Raspbian
Android 4.4.2 / 6.0.1
Note: Windows NT is not supported
Power
Power consumption is 54 W (maximum)
Power Supply (adapter):
Input (AC): 100 to 240 V 50Hz / 60Hz
(DC): 12 V DC / 9 A
Dimensions/Weight
Dimensions: 39.40×43.90×4.44 cm (15.51×17.28×1.75 inch)
Weight: 4.43 kg (9.77 lb)
Environment/Safety
Temperature:
Operating: 0  C (32  F) to 40  C (104  F)
Storage: –10  C (14  F) to 50  C (122  F)
Humidity: 0 % to 80 % relative, non-condensing
Safety: FCC / CE / C-Tick / Class A
Table 1-3 Specifications

6
1. The Sequoia UHD supports DVI-D input(s) through the optional HDMI to DVI adapter.
2. The Sequoia UHD's HDMI input/output ports support HDMI revision 1.4 and HDCP revision 1.4.
3. For best results with HDMI/DVI, use cables under 15 m long, or shorter if you use connection adapters. If
you need to place your Sequoia UHD more than 15 m away from your sources, use a signal extender.
4. Use High Speed or Premium High Speed HDMI cables.
5. The 59.94Hz refresh rate is only supported during transmission of a genlock source to the REF IN port.
6. To prevent temporary image discoloration when switching 4K input sources in full screen mode, make
sure that the “Output color mode (color space)” setting of all four computer’s 4K display card connected
to the Sequoia UHD has the same “RGB” or “YCbCr422” or “YCbCr444” setting.
7. For monitors whose display mode can be set between “Graphic” and “Video”, select “Graphic”;
for those whose display color format can be set between “RGB” and “YPbPr”, select “RGB”;
for those whose display mode can be set between “PC” and “AV”, select “PC”
(selecting the other ones may lead to corrupted displays).
Other display modes not mentioned here can be tried when encountering display problems.
8. It is suggested to always reboot the Sequoia UHD after switching to a different monitor (especially one
that supports a different optimal resolution); this will ensure the Sequoia UHD to select the correct output
resolution and frame rate.
1.4 Connections to the Sequoia UHD/ UHD+ / UHD/T / UHD/T+
Figure 1-1 Sequoia UHD / UHD+ Components
Front Panel
Indicator
Glows green when the Sequoia UHD / UHD+ is connected to power.
SUHD-MB
PC
USB port connection to a fifth (local) computer and passes the
keyboard/mouse control from it.
IN
Connects to a fifth (local) computer’s audio connectors via the
proprietary Sequoia male to dual male Y splitter audio cable. Since this
audio port is bi-directional, depending on your setting in the right-click
menu item “Audio routing” (see chapter 4 for details), connect a set of
headphone or stereo speakers for audio output; or connect a
microphone for audio input.
IP
Ethernet connector for HTTP commands or third-party control as well
as for connecting to a gigabit IGMP switch for detecting TX
(transmitters) and RX (receivers) for use together with the SUHD-IP.
K/M
USB keyboard/mouse for KVM and in-system GUI operation.
Dip Switches
Resets the Sequoia UHD to factory-default settings.
REF IN
Future option –For Sequoia UHD+ only
For genlock signal input that supports:
Black Burst, Tri-level and Sequoia UHD+ proprietary.

7
SUHD-MB
REF OUT
Future option –For Sequoia UHD+ only
For genlock signal output that supports Sequoia UHD+ proprietary.
HDMI IN 1~ 4
Four HDMI type A connectors for HDMI / DVI-D input sources (DVI to
HDMI adapters may be needed).
Note: Transmission of audio signal is not included when using the DVI
to HDMI adapter.
CASCADE IN
For Sequoia UHD+ only
BNC connector for externally cascaded SDI input signal from an
upstream Sequoia UHD+ / UHD/T+ (CASCADE OUT).
CASCADE OUT
For Sequoia UHD+ only
BNC connector for externally cascaded SDI output signal to a
downstream Sequoia UHD+ / UHD/T+ (CASCADE IN).
HDMI OUT
HDMI type A connector for HDMI/DVI monitor (HDMI to DVI adapters
may be needed).
Note: Transmission of audio signal is not included when using the DVI
to HDMI adapter.
SUHD-IP
HDMI OUT
(VIDEO 1/2)
HDMI type A connector for pass-through output from the RJ-45 input
source
KVMoIP
(VIDEO 1/2)
RJ-45 connectors for connecting Avitech’s Pacific X-IPT via CAT-5e/6
Ethernet cables.
Transmission of HDMI/DVI (with adapter) video, embedded audio
and USB keyboard/mouse control signals
“Link” LED indicator glows yellow when connection with Avitech’s
Pacific X-IPT is established
“Activity” LED indicator blinks green when data (signal) is
transmitted
SUHD-KM
CASCADE
USB type B port for externally cascaded keyboard/mouse control signal.
USB IN 1~ 4
Four USB type B ports for connecting the respective computers’USB
type A ports via standard USB A/B cables; and transmission of
keyboard/mouse control signals to source computers.
AUDIO
CASCADE IN
Audio connector for externally cascaded audio input signal from an
upstream SUHD-KM (AUDIO CASCADE OUT).
AUDIO
CASCADE OUT
Audio connector for externally cascaded audio output signal to a
downstream SUHD-KM (AUDIO CASCADE IN).
Connects to the red connector for microphone function.
Connects to the green connector for headphone function or set of
speakers (stereo).
1/ 2/ 3/ 4
Connects to the respective remote computer’s (1~4) audio connectors
(through the Sequoia male to dual male Y splitter audio cable). Since
these audio ports are bi-directional, depending on your setting in the
right-click menu item “Audio routing” (see chapter 4 for details), connect
a set of headphone or stereo speakers for audio output; or connect a
microphone for audio input.
Rear Panel
Power
(DC 12 V / 9 A)
Connects to the 12 V DC / 9 A power adapter for redundant power.
Power In
AC 100~240 V 50/60Hz
Table 1-4 Sequoia UHD / UHD+ Component Description

8
Figure 1-2 Sequoia UHD/T / UHD/T+ Components
Front Panel
Indicator
Glows green when the Sequoia UHD/T / UHD/T+ is connected to
power.
SUHD-MB/IP
PC
USB port connection to a fifth (local) computer and passes the
keyboard/mouse control from it.
IN
Connects to a fifth (local) computer’s audio connectors via the
proprietary Sequoia male to dual male Y splitter audio cable. Since this
audio port is bi-directional, depending on your setting in the right-click
menu item “Audio routing” (see chapter 4 for details), connect a set of
headphone or stereo speakers for audio output; or connect a
microphone for audio input.
IP
Ethernet connector for HTTP commands or third-party control as well
as for connecting to a gigabit IGMP switch for detecting TX
(transmitters) and RX (receivers) for use together with the SUHD-IP
module.
K/M
USB keyboard/mouse for KVM and in-system GUI operation.
Dip Switches
Resets the Sequoia UHD to factory-default settings.
REF IN
For genlock signal input that supports:
Black Burst, Tri-level and Sequoia UHD/T+ proprietary.
REF OUT
For genlock signal output that supports Sequoia UHD/T+ proprietary.
Connects to the red connector for microphone function.
Connects to the green connector for headphone function or set of
speakers (stereo).
SFP (slot)
Accepts one gigabit SFP (small form-factor pluggable) single-mode
transceiver module.

9
SUHD-MB/IP
KVMoIP (RJ45)
RJ-45 connector for connecting with Avitech’s Pacific X-IPTR /
X-IPTRS / X-IPr (receiver) via CAT-5e/6 Ethernet cables.
Transmission of HDMI/DVI (with adapter) video, embedded audio,
USB keyboard/mouse control, UART, RS-232 and infrared signals
“Link” LED indicator glows orange when connection with another
Avitech’s Pacific X-IPTR / X-IPTRS / X-IPr (receiver) is established
“Activity” LED indicator blinks green on data (signal) transmission
HDMI IN
Accepts HDMI input source from the HDMI OUT port below it so that
image signal is also included when transmitting through the KVMoIP
port (previous port).
HDMI IN 1~ 4
Four HDMI type A connectors for HDMI / DVI-D input sources (DVI to
HDMI adapters may be needed).
Note: Transmission of audio signal is not included when using the DVI
to HDMI adapter.
CASCADE IN
For Sequoia UHD/T+ only
BNC connector for externally cascaded SDI input signal from an
upstream Sequoia UHD+ / UHD/T+ (CASCADE OUT).
CASCADE OUT
For Sequoia UHD/T+ only
BNC connector for externally cascaded SDI output signal to a
downstream Sequoia UHD+ / UHD/T+ (CASCADE IN).
HDMI OUT
HDMI type A connector for routing video signal to the HDMI IN port
above it.
Or, for connecting to a HDMI/DVI monitor (HDMI to DVI adapters may
be needed).
Note: Transmission of audio signal is not included when using the DVI
to HDMI adapter to connect to monitor.
SUHD-IP
HDMI OUT
(VIDEO 1/2)
HDMI type A connector for pass-through output from the SFP / RJ-45
input source
SFP (slot)
(VIDEO 1/2)
Accepts one gigabit SFP (small form-factor pluggable) single-mode
transceiver module.
Or
KVMoIP (RJ-45)
(VIDEO 1/2)
RJ-45 connector for connecting with Avitech’s Pacific X-IPT / X-IPTR /
X-IPTRS / X-IPt (transmitter) via CAT-5e/6 Ethernet cables.
Transmission of HDMI/DVI (with adapter) video, embedded audio
and USB keyboard/mouse control signals
“Link” LED indicator glows yellow when connection with Avitech’s
Pacific X-IPT / X-IPTR / X-IPTRS / X-IPt (transmitter) is established
“Activity” LED indicator blinks green on data (signal) transmission

10
SUHD-2HD
IN (UHD)
Accepts HDMI 4K30 video/audio input.
LOOP OUT
(UHD)
Connects to HDMI or DVI (via DVI to HDMI adapter) 4K30 monitor.
Audio out is available when connecting to HDMI monitor.
HD HDMI OUT
1~ 4
Four HD (1080p) HDMI type A connector of decoded output to video
wall (2×2) from the IN (UHD) input source (4K30).
REF IN
Future option
For genlock signal input that supports:
Black Burst, Tri-level and Sequoia UHD/T+ proprietary.
REF OUT
Future option
For genlock signal output that supports Sequoia UHD/T+ proprietary.
Rear Panel
Power
(DC 12 V / 9 A)
Connects to the 12 V DC / 9 A power adapter for redundant power.
Power In
AC 100~240 V 50/60Hz
Table 1-5 Sequoia UHD/T / UHD/T+ Component Description

11
2. System Configuration
This chapter provides information on installing and removing a modular card into and out of the Sequoia
UHD chassis. It also discusses the process of setting up your Sequoia UHD.
2.1 Installing aNew Module on aBlank Slot
The Sequoia UHD chassis accepts the following modules:
SUHD-MB Module (may be pre-installed from the dealer)
SUHD-MB/IPT Module (may be pre-installed from the dealer)
SUHD-IPc Module
SUHD-IPf Module
SUHD-2HD Module
Keyboard/Mouse Module:
SUHD-KM Module
1. Because the Sequoia UHD is available as a customizable system, the illustrations in this chapter and
those used throughout the manual may differ from the model(s) you purchased.
2. Keep a note of which transmitter/receiver is connected to which port. You can use this information later
when you rename transmitters/receivers in the IP TX List and IP RX List tables.
3. You do not have to use all the slots.
Installation and removal of the modules follow the same procedures. In this section, a SUHD-IP module
was used as an example.
To install a SUHD-IP module on a blank slot, perform the following steps:
Step 1. Remove the two screws securing the back plate.
Figure 2-1 Remove the Two Plate Screws
Step 2. Remove the back plate.
Figure 2-2 Remove the Back Plate

12
Step 3. Align both sides of the SUHD-IP module to the rails of the slot, and then slide it all the way into
the chassis.
Figure 2-3 Align the New Module to the Rail on Both Sides
Step 4. Tighten the screws on both sides to secure the newly installed module to the chassis.
Figure 2-4 Tighten the Module Screws on Both Sides
2.2 Removing aPreviously Installed Module
To remove or replace an installed module, perform the following steps:
Step 1. Use a slot head screwdriver to unscrew both puller screws from the right-most module (installed
from the dealer).
Figure 2-5 Remove Puller Screws from the Module
Step 2. Use the just-removed puller screws and screw them to both sides of the module to be removed.

13
Step 3. Remove the two screws securing the module to the chassis.
Figure 2-6 Remove the Two Module Screws
Step 4. Grasp both left and right puller screws and pull the module away from the chassis.
Step 5. Install another module (or a back plate cover) to the chassis and tighten both screws.
