AVOCOR AVW-5555 User manual

Revision Date: 9/10/2020
AVW-5555
All-in-One Display
Model AVW-5555 Installation and OperationManual

Revision Date: 9/10/2020
2
© Copyright 2020. This document contains proprietary information protected by copyright, trademark and
other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without our prior written permission.
The trademarks reproduced in this document and used on the products are either owned or licensed by us, or
by their respective holders. You may not reproduce or use the trademarks without our prior written consent.
COPYRIGHT AND TRADEMARKS:

Revision Date: 9/10/2020
3
Important Safety Instructions
 Before using this display, please read this user manual thoroughly to help protect against property
damage and to ensure your personal safety and the safety of others.
 Be sure to observe the following instructions.
 For your safety, be sure to observe the warnings located in this manual.
 For installation or adjustment, please follow the instructions in this manual and refer all servicing to
qualified service personnel.
Safety Precautions
 If smoke or a peculiar smell comes from the display, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 If the display has been turned on but there isn’t a picture, remove the power plug from the outlet
immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 If water is spilled or objects are dropped inside the display, remove the power plug from the outlet
immediately.
 Failure to do so may result in fire or electrical shock. Con tact your dealer for inspection.
 If the display is dropped or the cabinet is damaged, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 To turn off the power of the display, press “O” on the main power switch at side of the display.
 The power standby/on indicator will go off and the display cannot be turned on/off by using the POWER
button on the remote control. (To turn on/off the display by the remote control , press the main power
switch again and light the power standby/on indicator.)
◆ When turning off the display by pressing the POWER button on the remote control, the main
power of the display is not turned off completely.
◆ To disconnect power completely, remove the power plug from the outlet.
 If the power cord or plug is damaged or becomes hot, turn off the main power switch of the display,
make sure the power plug has cooled down and remove the power plug from the outlet.
 If the display is still used in this condition, it may cause fire or electrical shock. Contact your dealer for
replacement.

Revision Date: 9/10/2020
4
Installation
 Don't install in a high-temperature environment.
◆ If the display is used in high-temperature or in direct sunlight, it may cause the case or other
parts to become distorted or damaged, resulting in overheating or electrical shock.
 Don't install in a high-humidity environment.
◆ This may cause overheating or electrical shock.
 Don't install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
◆ This may cause fire or electrical shock.
 Don't overload outlets or cables beyond electrical capacity.
 Don't use extension cords as it may cause fire or electrical shock.
 Don't insert the power plug into an outlet other than 100~240V AC.
◆ This may cause fire or electrical shock.
 Don’t use a damaged power plug or worn outlet.
 Don’t insert an improper power plug; it may cause fire or electric shock.
 Don't place the display on an unstable shelf or surface.
◆ The display may fall, causing injury. Please install on a horizontal, stable, level surface.
 Don't place objects on the display.
◆ If the display is covered or the vents are blocked, the display cou ld overheat and cause a fire.
◆ If metal or liquid gets into the display, it may cause fire or electrical shock.
◆ Do not put heavy objects on the display as they may fall, causing injury.
◆ Please keep a 10 cm minimum distance between the display and the wall for sufficient
ventilation.
 Don't move the display when it is connected to the power cord and AV cables.
◆ When moving the display, make sure to remove the power plug and cables from the outlet or
source.
◆ When unpacking or carrying the display, at least 2 people are needed. Make sure the display
is carried upright.
◆ Transport the display upright. Avoid placing the display face up or down.
◆ Handle the display gently. Do not drop.

Revision Date: 9/10/2020
5
Use
 If you encounter a problem during installation, please contact your dealer fo r assistance. Don’t repair or
open the display by yourself.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 Protect and correctly use the power cord/plug.
◆ Power cord should be connected to a socket-outlet with a ground connection.
◆ Ensure that any external equipment is properly grounded d before connecting to the display
device.
◆ Don't pinch the power cord/plug between hard surfaces.
◆ Don't step on the power cord/plug.
◆ Before inserting the power plug into the wall outlet, connect the power cord to the display.
◆ Don't operate the display with a damaged power cord or it may damage the display.
 Using extension cords (not recommended)
◆ If an extension cord must be used, ensure the voltage rating exceeds the max power
consumption of the display. If the voltage rating is less than the display, it will cause the
extension cord to overheat.
 If there is thunder or lightning, don’t touch the display or the power plug.
This may cause an electric shock.
 Don’t use any kind of liquid on the display.
 If liquid is spilled on the display, remove the power and ask qualified service personnel to check the
display.
 If the liquid gets on the display’s screen, please clean it with a dry an d soft cloth immediately.
 Don’t use any harsh chemical on the display.
 If metal or liquid gets into the display, it may cause a fire or an electrical shock.
 Don’t install or remove the power plug with wet hands.
 If the display will not be used for a long period of time, unplug the display.
This may cause premature wear of electrical components or fire.
 Don't apply excessive pressure on the LCD panel. This may cause personal injury or panel damage.
 Don't push or shake the display.
◆ This may cause damage or injury.
 If the glass of the display panel is broken, liquid may escape. Please don't touch the liq uid.
◆ If liquid gets into your eyes or touches your skin, wash with the clean water and seek medical
attention immediately.
 Precautions with the remote control batteries
◆ Please only use approved AAA type batteries.
◆ Please be sure to insert batteries by matching the + and -.

Revision Date: 9/10/2020
6
◆ Don’t recharge, heat, disassemble, short or throw batteries into a fire.
◆ Don’t mix a new battery with a used one.
◆ Don’t mix different types of batteries together (only use the specified type). it may cause burn
and injury.
Cleaning
 If dust has collected on the power plug, remove the plug from the outlet and clean off the dust.
◆ Dust build-up may cause a fire.
 Take off the power plug before cleaning.
◆ Failure to do so may result in electrical shock or damage.
 Cleaning the surface of the display
◆ When the surface of the display becomes dirty, please wipe the surface lightly with a soft
clean cloth.
◆ If the surface requires additional cleaning, lightly moisten the cloth.
◆ Do not let any kind of liquid enter the display as it may cause electrical shock or damage.
◆ Do not clean the display with alcohol, solvents or ammonia, as this could damage the display.

Revision Date: 9/10/2020
7
Warnings
Use
 Do not use the display lying flat on its back.
 Transport the display upright with proper packaging. Avoid placing the display face up or down. Be
careful not to bump into the display.
 Do not send a static (non-moving) image to the display, or it may cause image ‘burn-in’ or image
retention.
 “Burn in” and/or image retention is not covered under warranty.
 Make sure to change the image on the display periodically. It is recommended to turn off the display for
at least 6 hours after 18 hours of usage in a 24 hour period to help avoid image retenti on
Exemptions
 This product isn’t warranted for any damage caused by natural disaster (such as earthquake, thunder,
etc.), fire, acts by third parties, accidents, owner’s intentional misuse and fault, or use in other improper
conditions.
 This product isn’t warranted for incidental damages (such as profit loss or interruption in business,
modification or erasure of record data, etc.) caused by use or inability to use of this product.
 This product isn’t warranted for any damage caused by inappropriate operati on, or from not following
the user manual.
 This product isn’t warranted for any damage caused by misuse or malfunction through simultaneous use
of this product and the connected equipment or software.
 This product isn’t warranted for any damage caused by neglect of the instructions described about
installation.
 This product isn’t warranted for any damage caused by improper installation.
 This product isn’t warranted for any damage caused by disassembly, modification or repair by a non-
authorised service center or people.

Revision Date: 9/10/2020
8
Compliance Information
AVOCOR hereby declares that the Product's Model Numbers:
AVW-5555
Conform with the provisions of:
 FCC:
FCC CFR Title 47 Part 15 Subpart B Class A, CISPR 22
ANSI C63.4
ICES-003
 CE:
EN 55032
EN 55024
EN 61000-3-2
EN 61000-3-3
 cTUVus:
UL 62368-1
CAN/CSA-C22.2 No. 62368-1
 CB:
IEC 62368-1
 CEC:
California Code of Regulations, Title 20:Division 2, Chapter 4, Article 4, Sections 1601 -1609
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CAUTION
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
DECLARATION OF CONFORMITY:
FCCPART15:

Revision Date: 9/10/2020
9
CAN ICES-3 (A)/NMB-3(A)
The Product contains small amounts of tin, lead and /or mercury. Disposal of these materials may be regulated
due to environmental considerations.
This symbol found on your product or on its packaging, indicates that this product should not be
treated as household waste when you wish to dispose of it. Instead, it should be handed over to
an applicable collection point for the recycling of electric al and electric al equipment. By
ensuring this product is disposed of correctly, you will help prevent potential negative
consequences to the environment and human health, which could otherwise be ca used by
inappropriate disposal of this product.
The recycling of materials will help to conserve natural resources. This symbol is only valid in the European
Union. If you wish to discard this product, please contact your local authorities or dealer and a sk for the
correct method of disposal.
INDUSTRYCANADA(ICES-003):
PRODUCT DISPOSAL:
DISPOSALOFOLDELECTRICALANDELECTRONICEQUIPMENT(ApplicablethroughouttheEuropeanUnion and
other European countries with separate collection programs)

Revision Date: 9/10/2020
10
Notes
