AVOCOR VTF-6500 User manual

VTF-6500
Super-slim FHD LED Display
Model VTF-6500 Installation/Operation Manual

2
© Copyright 2016.This document contains proprietaryinformation protected bycopyright, trademark andother
intellectual propertylaws. All rights are reserved. Nopart ofthis manual maybereproduced byanymechanical,
electronicorother means, inanyform, withoutourprior written permission.
The trademarks reproduced inthis document andused onthe products are either owned or licensed byus,orby
their respective holders. You may notreproduce orusethetrademarks without ourprior written consent.
COPYRIGHT AND TRADEMARKS:

3
Important Safety Instructions
 Before using this display, please read this user manual thoroughly to help protect against property damage
and to ensure your personal safety and the safety of others.
 Be sure to observe the following instructions.
 For your safety, be sure to observe the warnings located in this manual.
 For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified
service personnel.
Safety Precautions
 If smoke or a peculiar smell comes from the display, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 If the display has been turned on but there isn’t a picture, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 If water is spilled or objects are dropped inside the display, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 If the display is dropped or the cabinet is damaged, remove the power plug from the outlet immediately.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 To turn off the power of the display, press “O” on the main power switch at side of display.
 The power standby/on indicator will go off and the display cannot to be turned on/off by using the POWER button
on the remote control. (To turn on/off the display by the remote control, press the main power switch again and
light the power standby/on indicator.)
 When turning off the display by pressing the POWER button on the remote control, the main power
of the display is not turned off completely.
 To disconnect power completely, remove the power plug from the outlet.
 If the power cord or plug is damaged or becomes hot, turn off the main power switch of the display, make
sure the power plug has cooled down and remove the power plug from the outlet.
 If the display is still used in this condition, it may cause fire or electrical shock. Contact your dealer for replacement.
Installation
 Don't install in a high-temperature environment.
 If the display is used in high-temperature or in direct sunlight, it may cause the case or other parts to
become distorted or damaged, resulting in overheating or electrical shock.
 Don't install in a high-humidity environment.
 This may cause overheating or electrical shock.
 Don't install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
 This may cause fire or electrical shock.
 Don't overload outlets or cables beyond electrical capacity.
 Don't use extension cords asitmay cause fire orelectrical shock.

4
 Don't insert the power plug into an outlet other than 100~240V AC.
 This may cause fire or electrical shock.
 Don’t use a damaged power plug or worn outlet.
 Don’t insert an improper power plug it may cause fire or electric shock.
 Don't place the display on an unstable shelf or surface.
 The display may fall, causing injury. Please install on a horizontal, stable, level surface.
 Don't place objects on the display.
 If the display is covered or the vents are blocked, the display could overheat and cause a fire.
 If metal or liquid gets into the display, it may cause fire or electrical shock.
 Do not put heavy objects on the display as they may fall, causing injury.
 Please keep a 10 cm minimum distance between the display and the wall for sufficient ventilation.
 Don't move the display when it is connected to the power cord and AV cables.
 When moving the display, make sure to remove the power plug and cables from the outlet or source.
 When unpacking or carrying the display, at least 2 people are needed. Make sure the display is
carried upright.
 Transport the display upright. Avoid placing the display face up or down .
Use
 Handle the display gently. Do not drop .
 If you encounter a problem during installation, please contact your dealer for assistance. Don’t repair or
open the display by yourself.
 Failure to do so may result in fire or electrical shock. Contact your dealer for inspection.
 Protect and correctly use the power cord/plug.
 Don't pinch the power cord/plug between hard surfaces.
 Don't step on the power cord/plug.
 Before inserting the power plug into the wall outlet, connect the power cord to the display.
 Don't operate the display with a damaged power cord or it may damage the display.
 Using extension cords (not recommended)
 If an extension cord must be used, ensure the voltage rating exceeds the max power consumption of the
display. If the voltage rating is less than the display, it will cause the extension cord to overheat.
 If there is thunder or lightning, don’t touch the display or the power plug.
 This may cause an electric shock.
 Don’t use any kind of liquid on the display.
 If liquid is spilled on the display, remove the power and ask qualified service personnel to
check the display.
 If the liquid gets on the display’s screen, please clean it with a dry and soft cloth immediately.
 Don’t use any harsh chemical on the display.

5
 If metal or liquid gets into the display, it may cause a fire or an electrical shock.
 Don’t install or remove the power plug with wet hands.
 This may cause an electrical shock.
 If the display will not be used for a long period of time, unplug the display.
 This may cause premature wear of electrical components or fire.
 Don’t press on the LCD panel.
 This may cause personal injury or panel damage.
 Don't push or shake the display.
 This may cause damage or injury.
 If the glass of the display panel is broken, liquid may escape. Please don't touch the liquid.
 If liquid get into your eyes or touches your skin, wash with the clean water and seek medical
attention immediately.
 Precautions with the remote control batteries
 Please only use approved AAA type batteries.
 Please be sure to insert batteries by matching the + and -.
 Don’t recharge, heat, disassemble, short or throw batteries into a fire.
 Don’t mix a new battery with a used one.
 Don’t mix different types of batteries together (only use the specified type). it may cause burn and injury.
Cleaning
 If dust has collected on the power plug, removed the plug from the outlet and clean off the dust.
 Dust build-up may cause a fire.
 Take off the power plug before cleaning.
 Failure to do so may result in electrical shock or damage.
 Cleaning the surface of the display
 When the surface of the display becomes dirty, please wipe the surface lightly with a soft clean cloth.
 If the surface requires additional cleaning, lightly moisten the cloth.
 Do not to let any kind of liquid enter the display as it may cause electrical shock or damage.
 Do not clean the display with alcohol, solvents or ammonia, as this could damage the display.

6
Warnings
Use
 Do not use the display lying flat on its back.
 Transport the display upright with proper packaging. Avoid placing the display face up or down. Be careful
not to bump into the display.
 Do not send a static (non-moving) image to the display, or it may cause image ‘burn-in’ or image retention.
 “Burn in” and/or image retention is not covered under warranty.
 Make sure to change the image on the display periodically. It is recommended to (1) turn off the display for at
least 6 hours after 18 hours of usage in a 24 hour period to help avoid image retention and (2) to turn the “IRFM”
function to “ON” in the OSD menu (under “Advanced Settings”).
Exemptions
 This product isn’t warranted for any damage caused by natural disaster (such as earthquake, thunder, etc.),
fire, acts by third parties, accidents, owner’s intentional misuse and fault, or use in other improper conditions.
 This product isn’t warranted for incidental damages (such as profit loss or interruption in business,
modification or erasure of record data, etc.) caused by use or inability to use of this product.
 This product isn’t warranted for any damage caused by inappropriate operation, or from not following the
user manual.
 This product isn’t warranted for any damage caused by misuse or malfunction through simultaneous use
of this product and the connected equipment or software.
 This product isn’t warranted for any damage caused by neglect of the instructions described about installation.
 This product isn’t warranted for any damage caused by improper installation.
 This product isn’t warranted for any damage caused by disassembly, modification or repair by non-
authorised service centre or people.

7
Compliance Information
Avocor hereby declares that the Products’ Model Number:
VTF-6500
Conform with the provisions of:
• FCC: FCC CFR Title 47 Part 15 Subpart B Class A, CISPR 22:2008
• ICES-003 Issue 5: 2012 Class A (For Canada)
•CE: EN 55022: 2010 + AC: 2011
•EN 55024: 2010
•EN 61000-3-2: 2006 + A2: 2009
•EN 61000-3-3: 2008
•cTUVus: UL 60950-1:2007
•CB: IEC 60950-1: 2005 + A1
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to
operate the equipment.
RF exposure warning:
This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-
located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with
antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
DECLARATION OF CONFORMITY:
FCC PART 15:

8
CAN ICES-3 (A)/NMB-3(A)
The Product contains small amounts of tin, lead and / or mercury. Disposal of these materials maybe regulated due to
environmental considerations.
This symbol found on your product or on its packaging, indicates that this product should not be treated
as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable
collection point for the recycling of electric al and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences to the environment and
human health, which could otherwise be caused by inappropriate disposal of this product.
The recycling of materials will help to conserve natural resources. This symbol is only valid in the
European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the
correct method of disposal.
INDUSTRY CANADA (ICES-003):
PRODUCT DISPOSAL:
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (Applicable throughout the European
Union and other European countries with separate collection programs)

6
Notes

7
TableofContents
Important Safety Instructions............................................................................................................3
Safety Precautions....................................................................................................................................... 3
Installation.................................................................................................................................................... 3
Use................................................................................................................................................................ 4
Cleaning........................................................................................................................................................ 5
Warnings..............................................................................................................................................6
Use................................................................................................................................................................ 6
Exemptions .................................................................................................................................................. 6
Compliance Information.....................................................................................................................7
Table of Contents................................................................................................................................7
List of Figures .....................................................................................................................................9
1. Introduction ...................................................................................................................................11
About This Manual.....................................................................................................................................11
Target Audience....................................................................................................................................... 11
Textual and Graphic Conventions.............................................................................................................11
Using This Manual .....................................................................................................................................12
Description, Features and Benefits ..........................................................................................................13
Key Features and Benefits ....................................................................................................................... 13
Touch Capability....................................................................................................................................... 13
Parts List.................................................................................................................................................. 13
2. Controls and Functions................................................................................................................ 15
Display at a Glance....................................................................................................................................15
Input Panel .................................................................................................................................................17
Remote Control Unit..................................................................................................................................19
3. Installation ..................................................................................................................................... 21
Remote Control..........................................................................................................................................21
Notes on Batteries.................................................................................................................................... 21
Notes on Remote Control Operation......................................................................................................... 21
Quick Setup................................................................................................................................................22
Installation Considerations.......................................................................................................................22
Ambient Light ........................................................................................................................................... 22
Ambient Heat............................................................................................................................................ 22
Ventilation ................................................................................................................................................ 23
Mounting the Display.................................................................................................................................24
Connections to the Display.......................................................................................................................24
Connecting a Control System or PC......................................................................................................... 25
Connecting Source Components to the Display........................................................................................ 27
Turning on the Power ................................................................................................................................29
Changing the OSD Language....................................................................................................................30
Enabling the Touch Screen.......................................................................................................................30
Connecting the TouchScreen Controller Host Computer to the Display....................................................30
Software Installation................................................................................................................................. 31
4. Operation ....................................................................................................................................... 35
Using the On-Screen Menus .....................................................................................................................35
Video Settings.......................................................................................................................................... 37
