AVPro Edge AC-DA14-AUHD User manual

User Manual
AC-DA14-AUHD
A full 4K60 4:4:4 (Up to 18GBPS)
Distribution Amplifier with advanced EDID management
**Available in 1x2, 1x4, and 1x8
AC-DA14-AUHD
Page 1

Introduction
AC-DA14-AUHD is an 18GBPS, full bandwidth HDMI2.0a (HDR) with
HDCP2.2 four-way HDMI splitter. Functionally, distributes the input HDMI
signal to four identical HDMI outputs. These four outputs are synchronized.
AC-DA14-AUHD has the ability of pre-emphasis and equalization. Multiple
cascaded AC-DA14-AUHD achieves long distance transmission of HDMI signal of
more than 15 meters even in 4K (HDR) resolution.
AC-DA14-AUHD offers solutions for usage as a component of digital HDMI
distributions and entertainment systems also UHDTV/4K retail and general show
sites. Use in conjunction with UHDTV, UHD Projector, STB, UHD-BD, UHD Media
Player and in environment where noise, space and security are concerns. Fits
perfectly in data center control rooms, information distribution premises,
conference and presentation rooms, school educational facilities and
corporate training environments.
AC-DA14-AUHD
Page 2

Contents
HDMI Splitter .................................................................................................................... 2
Product Overview ............................................................................................................ 4
Features ............................................................................................................................. 4
Package Contents ............................................................................................................. 6
Connections and Operations ........................................................................................ 6
Specifications ................................................................................................................... 6
Panel Descriptions ........................................................................................................7-8
Typical Application .........................................................................................................15
Maintenance ................................................................................................................... 11
Product Service ..............................................................................................................12
Mail-In Service ............................................................................................................... 12
Warranty .......................................................................................................................... 12
Warranty Limits And Exclusions ................................................................................. 13
AC-DA14-AUHD
Page 3

Full 4K 60 (4:4:4) HDMI Splitter & Distribution Amplifier
■Product Overview ( Model Number: AC-DA14-AUHD)
■ Features
lEasy to Use: Install in seconds, no need for setting.
lDistribution: One HDMI input, four identical HDMI outputs.
lSupports up to 18GBPS with resolutions of 4K60(YUV444), 4K30, 1080p, 1080i, 720p and
other standard Video formats, PAL and NTSC.
lCustomer can configure EDID function to enable the best compatibility.
lSupports HDCP2.2
lHDMI 2.0(a) w/ HDR.
lMounting ears are included for easy fixation on wall, furniture or ceiling.
?Notice AVProEdge reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
AC-DA14-AUHD
Page 4

AC-DA14-AUHD
Page 5

■ Package Contents
①Main unit. P/N: AC-DA14-AUHD
②5VDC Power Supply.
③Mounting Brackets
■ Connections and Operations
1) Connect the HDMI input source into AC-DA14-AUHD
2) Connect the HDMI output equipment (Displays) into AC-DA14-AUHD
3) Insert the DC side of 5v power supply into AC-DA14-AUHD and then
connect the AC side of the Power supply into the wall outlet.
4) Plugging in the unit automatically powers up the device.
&NOTE: Insert / Extract cables gently.
AC-DA14-AUHD
Page 6

■ Specifications
AC-DA14-AUHD
Page 7

①Power input.
②HDMI input.
③HDMI outputs (x4).
Device Top Cover
Device cover is labeled for DIP Switch (EDID setting) and ISP mini USB port and for
easy HDMI port recognition especially useful when Mounting Ears are used for
fixation. &NOTE: DIP Switch EDID setting index on next page.
Back Panel
AC-DA14-AUHD
Page 8

EDID Settings: The 5 DIP switches are located on the side of the device, and each switch
has two settings, 0 & 1 (UP=0, DOWN=1). The default mode is “00000” which is all up, in
this mode the device copies the EDID from the sink (display) plugged into OUTPUT 1.
Custom EDID settings are below.
10000: 1080P_2CH(PCM)_HDR
10001: 1080P_6CH_HDR
10010: 1080P_8CH_HDR
10011: 1080P_3D_2CH(PCM)_HDR
10100: 1080P_3D_6CH_HDR
10101: 1080P_3D_8CH_HDR
10110: 4K30Hz_3D_2CH(PCM)_HDR
10111: 4K30Hz_3D_6CH_HDR
11000: 4K30Hz_3D_8CH_HDR
11001: 4K60Hz(Y420)_3D_2CH(PCM)_HDR
11010: 4K60Hz(Y420)_3D_6CH_HDR
11011: 4K60Hz(Y420)_3D_8CH_HDR
11100: 4K60Hz_3D_2CH(PCM)_HDR
11101: 4K60Hz_3D_6CH_HDR
11110: 4K60Hz_3D_8CH_HDR
11111: Passthrough
EDID DIP Settings:
00000: EDID COPY (See NOTE 1)
00001: 1080P_2CH(PCM)
00010: 1080P_6CH
00011: 1080P_8CH
00100: 1080P_3D_2CH(PCM)
00101: 1080P_3D_6CH
00110: 1080P_3D_8CH
00111: 4K30Hz_3D_2CH(PCM)
01000: 4K30Hz_3D_6CH
01001: 4K30Hz_3D_8CH
01010: 4K60Hz(Y420)_3D_2CH(PCM)
01011: 4K60Hz(Y420)_3D_6CH
01100: 4K60Hz(Y420)_3D_8CH
01101: 4K60Hz_3D_2CH(PCM)
01110: 4K60Hz_3D_6CH
01111: 4K60Hz_3D_8CH
AC-DA14-AUHD
Page 9

Note1: EDID Copy mode: EDID will be copied from sink on OUTPUT 1. The
AC-DA14-AUHD is set this way by default for maximum “Plug & Play” Compatibility. If you
change sink (Display) plugged into OUTPUT 1, please follow the steps below if you wish to use
the new sink’s EDID.
1. Start with power off
2. Set DIP to ‘00000’ (all up).
3. Power on the unit
4. Power on the source device and connect the HDMI input port.
When Changing EDIDs, please follow the steps below
1. Start with power off
2. Set DIP to ‘00000’ (all up).
3. Power on the unit
4. Power on the source device and connect the HDMI input port.
