AVPro Edge AC-DA18-AUHD User manual

pg. 1
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
User)Manual)
AC-DA18-AUHD)
A!full!4K60!4:4:4!(Up!to!18GBPS)!
Distribution!Amplifier!with!advanced!EDID!management!
*Available!in!1x2,!1x4,!and!1x8
AC-DA18-AUHD)

Introduction
AC-DA18-AUHD is an 18GBPS, full bandwidth HDMI2.0a (HDR) with
HDCP2.2 eight-way HDMI splitter. Functionally, distributes the input HDMI
signal to four identical HDMI outputs. These four outputs are synchronized.
AC-DA18-AUHD has the ability of pre-emphasis and equalization. Multiple
cascaded AC-DA18-AUHD achieves long distance transmission of HDMI
signal of more than 15 meters even in 4K (HDR) resolution.
The outstanding and proprietary clock jitter cleaner enable this splitter to out
preform the competition when in cascading mode no matter the signal is 4K or
1080P.
AC-DA18-AUHD offers solutions for usage as a component of digital HDMI
distributions and entertainment systems also UHDTV/4K retail and general
show sites. Use in conjunction with UHDTV, UHD Projector, STB, UHD-BD,
UHD Media Player and in environment where noise, space and security are
concerns. Fits perfectly in data center control rooms, information distribution
premises, conference and presentation rooms, school educational facilities
and corporate training environments.
AC-DA18-AUHD)
pg. 2
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

Contents
HDMI Splitter ......................................................................................................... 2
Product Overview .................................................................................................. 4
Features ................................................................................................................ 4
Package Contents ................................................................................................. 6
Connections and Operations ................................................................................ 6
Specifications ........................................................................................................ 6
Panel Descriptions ................................................................................................ 7-8
Typical Application ................................................................................................... 15
Maintenance ......................................................................................................... 11
Product Service ..................................................................................................... 11
Mail-In Service ...................................................................................................... 12
Warranty ................................................................................................................ 12
Warranty Limits And Exclusions ........................................................................... 13
AC-DA18-AUHD)
pg. 3
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

Full 4K 60 (4:4:4) HDMI Splitter &
Distribution Amplifier
■Product Overview ( Model Number: AC-DA18-AUHD)
■
Features
lEasy to Use: Install in seconds, no need for setting.
lDistribution: One HDMI input, four identical HDMI outputs.
lSupports up to 18GBPS with resolutions of 4K60(YUV444), 4K30, 1080p,
1080i, 720p and other standard Video formats, PAL and NTSC.
lCustomer can configure EDID function to enable the best compatibility.
lSupports HDCP2.2
lHDMI 2.0(a) w/ HDR.
lMounting ears are included for easy fixation on wall, furniture or ceiling.
?Notice
AVProEdge reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
AC-DA18-AUHD)
pg. 4
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of el e c t r i c
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
AC-DA18-AUHD)
pg. 5
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

■
Package Contents
①Main unit. P/N: AC-DA18-AUHD
②12VDC Power Supply.
③Operating Instructions. (Digital @ www.avproedge.com)
④Mounting Ears
■
Connections and Operations
1) Connect the HDMI input source into AC-DA18-AUHD
2) Connect the HDMI output equipment (Displays) into AC-DA18-AUHD
3) Insert the DC side of 12V power supply into AC-DA18-AUHD and then
connect the AC side of the Power supply into the wall outlet.
4) Plugging in the unit automatically powers up the device.
&NOTE: Insert / Extract cables gently.
■
Specifications
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Video Amplifier Bandwidth Up to 18.0 GBPS
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
HDCP version HDCP2.2 /HDCP1.4
Maximum Format Support 4K60Hz 4:4:4 / 8K24Hz 4:2:0
AC-DA18-AUHD)
pg. 6
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

Other Video Formats
Supported
VESA: 640x480, 800x600, 1024x768,
1280x1024, 1600x1200, 1920x1200
DTV/HDTV:
480i/576i/480p/576p/720p/1080i/1080p/4K
Output Video HDMI 2.0, HDCP 2.2, HDR Compatible
Power Consumption 6 Watts (max.)
Power Supply 12V DC/3A
Dimensions 150mm (W) x 81mm (H) x 25mm (D)
Mass 0.5 KGS
■
Panel Descriptions
Front Panel
Activity Display (Front):
a) When Power is applied all lights flash RED and the machine begins
to function. If no devices are plugged in, you can verify power by
looking inside the vent on the right side of the unit.
b) When the INPUT device is plugged in, the light blink RED while
“handshaking” is occurring, and goes SOLID once communication is
complete and signal is good.
c) When a sink (display) is plugged into an OUTPUT, the
corresponding light blinks RED until the “handshake” is complete.
Once the connection is made the OUTPUT lights will go SOLID (If a
sink or display is plugged in).
AC-DA18-AUHD)
pg. 7
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

Back Panel
①Power input.
②HDMI input.
③HDMI outputs (x8).
Device Top Cover
Device cover is labeled for DIP Switch (EDID setting) and ISP mini USB port
and for easy HDMI port recognition especially useful when Mounting Ears are
used for fixation.
&NOTE: DIP Switch EDID setting index on next page.
AC-DA18-AUHD)
pg. 8
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

EDID Settings: The AC-DA18-AUHD uses a dual rotary style switch to house more EDID’s
and allow for future expansion. The dual rotary switches can be located on the side of the
device, and each rotary is representative of a number in the desired setting, (Left
Rotary=DIGIT ONE, Right Rotary=DIGIT TWO). The default mode is “00” which is both
rotary switches pointed to “0”, in this mode the device copies the EDID from the sink (display)
plugged into OUTPUT 1. Custom EDID settings are below.
EDID ROTARY Settings:
00: EDID COPY (See NOTE 1)
01: 1080P_2CH(PCM)
02: 1080P_6CH
03: 1080P_8CH
04: 1080P_3D_2CH(PCM)
05: 1080P_3D_6CH
06: 1080P_3D_8CH
07: 4K30Hz_3D_2CH(PCM)
08: 4K30Hz_3D_6CH
09: 4K30Hz_3D_8CH
10: 4K60Hz(Y420)_3D_2CH(PCM)
11: 4K60Hz(Y420)_3D_6CH
12: 4K60Hz(Y420)_3D_8CH
13: 4K60Hz_3D_2CH(PCM)
14: 4K60Hz_3D_6CH
15: 4K60Hz_3D_8CH
16: 1080P_2CH(PCM)_HDR
17: 1080P_6CH_HDR
18: 1080P_8CH_HDR
19: 1080P_3D_2CH(PCM)_HDR
20: 1080P_3D_6CH_HDR
21: 1080P_3D_8CH_HDR
22: 4K30Hz_3D_2CH(PCM)_HDR
23: 4K30Hz_3D_6CH_HDR
24: 4K30Hz_3D_8CH_HDR
25: 4K60Hz(Y420)_3D_2CH(PCM)_HDR
26: 4K60Hz(Y420)_3D_6CH_HDR
27: 4K60Hz(Y420)_3D_8CH_HDR
28: 4K60Hz_3D_2CH(PCM)_HDR
29: 4K60Hz_3D_6CH_HDR
30: 4K60Hz_3D_8CH_HDR
31: Cascading Mode (See NOTE 2)
AC-DA18-AUHD)
pg. 9
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

EDID Setting Cont. (Notes):
Note1: EDID Copy mode: EDID will be copied from sink on OUTPUT 1. The
AC-DA18-AUHD is set this way by default for maximum “Plug & Play”
Compatibility. If you change sink (Display) plugged into OUTPUT 1, please
follow the steps below if you wish to use the new sink’s EDID.
1. Start with power off
2. Set ROTARY SWITCHES to ‘00’.
3. Power on the unit
4. Power on the source device and connect the HDMI input port.
Note2:Cascading mode (Ideal for larger installations) Cascade mode does
not react to the EDID from the sink device. It sends the signal that you put in,
out. This is ideal for linking multiple units together. The method below is an
ideal way to use this function effectively.
To use cascading mode:
1. Start with power off
2. Fix an EDID on the FIRST unit in the series from the list above
(4K60, 4K30, 1080P, etc…)
3. Set the ROTARY SWITCHES on all subsequent units to “31”
4. Connect the source device
5. Power up the system
AC-DA18-AUHD)
pg. 10
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

AC-DA18-AUHD)
pg. 11
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]

•Use the power supplies provided. If an alternate supply is required,
check voltage, polarity and that it has sufficient power to supply the
device it is connected to.
•Do not operate these products outside the specified temperature
and humidity range given in the above specifications.
•Ensure there is adequate ventilation to allow this product to operate
efficiently.
•Repair of the equipment should only be carried out by qualified
professionals as these products contain sensitive components that
may be damaged by any mistreatment.
•Only use this product in a dry environment. Do not allow any liquids
or harmful chemicals to come into contact with these products.
•Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner
or benzene to clean this unit.
Maintenance
To ensure reliable operation of this product as well as protecting the
safety of any person using or handling this device while powered, please
observe the following instructions.
pg. 12
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [e-mail]
•The DC power supply cord or AC adaptor has been damaged
•Objects or liquids have gotten into the unit
•The unit has been exposed to rain
•The unit does not operate normally or exhibits a marked change in
performance
•The unit has been dropped or the housing damaged
Damage Requiring Service
The unit should be serviced by qualified service personnel if:

Support
Should you experience any problems while using this product, first, refer to the
Troubleshooting section of this manual before contacting Technical Support.
When calling, the following information should be provided:
pg. 13
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [e-mail]
•Product name and model number
•Product serial number
•Details of the issue and any conditions under which the issue is
occurring
Warranty
If your product does not work properly because of a defect in materials or
workmanship, AVProEdge (referred to as “the warrantor”) will, for the length
of the period indicated as below, (Parts/Labor (10) Years), which starts with
the date of original purchase (“Limited Warranty period”), at its option either
(a) repair your product with new or refurbished parts, or (b) replace it with a
new or a refurbished product. The decision to repair or replace will be made
by the warrantor. During the “Labor” Limited Warranty period there will be no
charge for labor. During the “Parts” warranty period, there will be no charge
for parts. You must mail-in your product during the warranty period. This
Limited Warranty is extended only to the original purchaser and only covers
product purchased as new. A purchase receipt or other proof of original
purchase date is required for Limited Warranty service.
This warranty extends to products purchased directly from AVPro or an
authorized dealer. AVPro is not liable to honor this warranty if the product has
been used in any application other than that for which it was intended, has
been subjected to misuse, accidental damage, modification or improper
installation procedures, unauthorized repairs or is outside of the warranty
period. Please direct any questions or issues you may have to your local dealer
before contacting AVPro.

_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
pg. 14
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [e-mail]

_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
pg. 15
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [e-mail]

AVProEdge
2222 E 52nd Street N ~ Sioux Falls, SD 57104
1-877-886-5112 ~ 605-274-6055
[e-mail]
Thank you for choosing AVProEdge!
Please contact us with any questions. We are happy
to be of service!
pg. 16
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [e-mail]
