AVT MAGIC PhonerSet Series User manual

© AVT Audio Video Technologies GmbH
MAGIC PhonerSet
Quick Guide
Version: 1.001 (18. March 2020)
©2020, AVT Audio Video Technologies GmbH

2
Content
Overview
Configuration
▪MAGIC TH2plus
▪MAGIC TH6
▪MAGIC THipPro
MAGIC PhonerSet
▪Configuration
▪Operation
▪Update
Grandstream Telephone
▪Language, Network, Screen Lock, Web GUI
Support

MAGIC PhonerSet
3
Overview

Features
4
PhonerSet with MAGIC TH2plus
▪Operation of 1 or 2 lines.
▪Up to two PhonerSet phones per device.
▪Compatible with firmware versions from
3.100
PhonerSet with MAGIC TH6
▪Operation of individual lines.
▪Operation of all lines of a studio.
▪Coming soon:
Operation of all lines of two studios.
Switching between studios in the App.
▪Up to six PhonerSet phones per device.
▪Compatible with firmware versions from
3.110
PhonerSet with MAGIC THipPro
▪Operation of up to eight lines of a studio.
▪Switching between studios in theApp.
▪Up to six PhonerSet phones per device.
▪Compatible with firmware versions from
3.210

Grandstream GXV3350
5
5" touchscreen.
Pretalk per:
▪Telephone handset.
▪Loudspeaker and
microphone.
Keypad beneath the
screen.
Status LED to display:
▪Incoming calls.
▪Active pretalk.
▪Alarms of the hybrid.

Grandstream GXV3370
6
7" touchscreen.
Pretalk per:
▪Telephone handset.
▪Speaker and
microphone.
The dial pad is
permanently displayed
on the touchscreen.
Status LED to display :
▪Incoming calls.
▪Active pretalk.
▪Alarms of the hybrid.

MAGIC PhonerSet
7
Configuration MAGIC TH2plus

TH2plus System Settings
8
Open MENU –CONFIGURATION
–SYSTEM in the PC-software.
Select the PHONERSET /
REMOTE LIGHT page under
SYSTEM SETTINGS on the left.
Enable the PhonerSet feature via
ACTIVATE PHONERSET.
Select the LAN INTERFACE of
the device to which the PhonerSet
phones are connected.
Enter the local TCP/IP PORT to
which the PhonerSet phones
connect. (default: 10300)
Each PhonerSet phone
establishes an audio data stream
to the device. Enter a unique
AUDIO PORT for each PhonerSet
phone. (default: 5400, 5402)

TH2plus Operation Settings
9
Select the PHONERSET page
under OPERATION SETTINGS
on the left.
These settings are linked to the
PHONERSET WORKPLACE
setting in the PhonerSetApp.
Select which phone lines
should be displayed on the
respective PhonerSet phone:
▪ALL LINES
▪LINE 1
▪LINE 2
Activate ON AIR ACCESS if the
user should be able to switch
the call to ON AIR.

MAGIC PhonerSet
10
Configuration MAGIC TH6

TH6 System Settings
11
Open MENU –CONFIGURATION –
SYSTEM in the PC-software.
Select the PHONERSET / REMOTE
LIGHT page under SYSTEM
SETTINGS on the left.
Enable the PhonerSet feature via
ACTIVATE PHONERSET.
Select the LAN INTERFACE of the
device to which the PhonerSet
phones are connected.
Enter the local TCP/IP PORT to which
the PhonerSet phones connect.
(default: 10300)
Each PhonerSet phone establishes an
audio data stream to the device. Enter
a unique AUDIO PORT for each
PhonerSet phone. (default: 5400,
5402 , 5404 , 5406 , 5408 , 5410)

TH6 Operation Settings (1)
12
Select the PHONERSET page
under OPERATION SETTINGS
on the left.
These settings are linked to the
PHONERSET WORKPLACE
setting in the PhonerSetApp.

TH6 Operation Settings (2)
13
Select which phone lines
should be displayed on the
respective PhonerSet
phone:
▪LINE 1...6: individual lines
▪STUDIO 1: All lines of studio 1
in the 2-Studio mode.
▪STUDIO 2: All lines of studio 2
in the 2-Studio mode.
▪ALL STUDIO LINES: All active
lines in the 1-Studio mode.
Activate ON AIR ACCESS
if you want the user to be
able to switch the call to
ON AIR.

MAGIC PhonerSet
14
Configuration MAGIC THipPro

THipPro System Settings
15
Open MENU –CONFIGURATION –
SYSTEM in the PC-software.
Select the PHONERSET / REMOTE
LIGHT page under SYSTEM
SETTINGS on the left.
Enable the PhonerSet feature via
ACTIVATE PHONERSET.
Select the LAN INTERFACE of the
device to which the PhonerSet
phones are connected.
Enter the local TCP/IP PORT to which
the PhonerSet phones connect.
(default: 10300)
Each PhonerSet phone establishes an
audio data stream to the device. Enter
a unique AUDIO PORT for each
PhonerSet phone. (default: 5400,
5402 , 5404 , 5406 , 5408 , 5410)

THipPro Operation Settings (1)
16
Select the PHONERSET
page under OPERATION
SETTINGS on the left.
These settings are linked
to the PHONERSET
WORKPLACE setting in
the PhonerSetApp.
STUDIO ACCESS: The
PhonerSetApp displays
the first eight lines of the
assigned studio. You may
also assign multiple
studios. Switching between
the studios is then possible
in theApp.

THipPro Operation Settings (2)
17
FADER 1/ 2: Up to two buttons
for ON AIR are available in the
App. Each button can be
assigned an individual audio
line or the audio line of the
studio. The NOT USED setting
hides the button.
HOLD: An individual Hold
signal can be assigned to each
PhonerSet. The Hold signals of
the studios and PC clients are
available.
CONFERENCE: Check this box
to set several callers to
PRETALK or ONAIR at the
same time in the PhonerSet
App. All participants can then
talk to each other.

MAGIC PhonerSet
18
Configuration MAGIC PhonerSet App

Start-up
19
On startup, the phone
automatically starts the
PhonerSet app.
▪If Screen Lock is
enabled, the password
must be entered first.
You may also start the
PhonerSet app from
the phone's Home
screen.

Menu
20
Open the settings of
the PhonerSet app by
swiping the screen from
the left.
Press SETTINGS to
access the settings.
If there is no
connection to the
hybrid, CONNECTING
is displayed.
▪Tap SETTINGS to
access the
configuration.
