Avtech DCCS BOX User manual

306Z
KT1_V0.9
SPECIFICATIONS
Power DC 7.5V ~ 12V
Video Input DCCS Camera
Video Output 1.0 Vp-p Composite, 75Ω
Alarm Output 1 Alarm Output
Remote Control I/O RS-485
OSD YES
Dimensions (mm) 95 (W) x 57 (H) x 24 (D)
REAL PANEL
CONNECTORS ON REAL PANEL
To know which device is compatible to this product, please check with your distributor or retailer.
CONNECTOR DESCRIPTION
VIDEO OUT Connect to DVR or monitor video input based on your needs.
VIDEO IN Connect to a compatible device, for example, a zoom lens control camera.
RS485-A & B Connect to an external device, for example, a keyboard controller, to transmit control commands
to control the connected DCCS camera via this product.
ALARM out Connect to a DVR alarm input. When an alarm is triggered, the signals will transmit to this product
first, and then transmit to an alarm device, for example, a siren, connected to the DVR (Drive
capacity of this product: 5V / 100uA).
GND Ground.
DC 12V Connect to the regulated power adapter.

OPERATION
Take operating and controlling zoom lens control cameras as an example:
BUTTON FUNCTION DESCRIPTION
MENU Press to enter the camera setting menu.
/ ZOOM IN / OUT Press to adjust the zoom radio of the lens.
In the camera menu, press to adjust the parameter value.
SELECTION In the camera menu:
Press UP / DOWN to select the item you want.
Press LEFT / RIGHT to go to the previous / next page.
SYSTEM CONNECTION EXAMPLE
