Avtech AVT583 User manual

702z
t583_V0.9
Speed Dome Camera User Manual
The product image shown above may differ from the actual product.
Please use this camera with a DVR which supports HD video recording.
Please read the instructions thoroughly before using the product.
C
CA AU UT TI IO ON N
R
RI IS SK K O OF F E EL LE EC CT TR RI IC C S SH HO OC CK K
C
CA AU UT TI IO ON N: :
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
Only operate this apparatus from the type of power source indicated on the label.
The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of
such damages.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
This exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
ROHS Announcement
All lead-free products offered by the company comply with the requirements of the European law on the Restriction
of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly
“lead-free” and without the hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected
separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do
not dispose of these products as unsorted municipal waste.
CE Mark
This apparatus is manufactured to comply with the radio interference.
The company does not warrant that this manual will be uninterrupted or error-free. We reserve the right to revise or
remove any content in this manual at any time.

TABLE OF CONTENTS
SPECIFICATIONS*..............................................................................................................1
PACKAGE CONTENT.........................................................................................................2
INSTALLATION ...................................................................................................................2
CONNECTION.....................................................................................................................3
PTZ CONTROL ...................................................................................................................3
CAMERA PARAMETERS ...................................................................................................4
AUTO PAN SETUP .............................................................................................................6
CRUISE SETUP ..................................................................................................................7
SEQUENCE SETUP............................................................................................................8
CAMERA GUARD .............................................................................................................10
AUTO TRACKING SETUP................................................................................................12

1
FEATURES
1. 1/2.8” CMOS Sensor with 1080P video output
2. Zoom lens of f4.7 ~ 94mm with 20x optical zoom and auto focus, suitable for various monitoring
environments
3. PTZ control for seamless monitoring
- Capable of 360° pan rotation continuously, allowing quick and smooth action of the camera lens
- Auto Tracking to follow moving objects
- Up to 256 preset points & four sequence groups programmable for multiple points monitoring, and auto pan
4. External alarm I/O device connection
5. WDR to increase image recognizability in overexposure and dark areas
SPECIFICATIONS*
General
Pick-up Element 1/2.8" SONY CMOS image sensor
Number of Pixels 1936(H) × 1096(V)
Video Frame Rate 1080P@30fps / 1080P@25fps
Min. Illumination 0.1 Lux / F1.6
S/N Ratio More than 48dB (AGC OFF)
Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.
Lens f4.7 ~ 94mm / F1.6 (Wide) ~ 3.5(Tele)
Lens Angle Horizontal 1X: 60.8° / 20X: 3.4°
Vertical 1X: 35.3° / 20X: 1.9°
Diagonal 1X: 68.3° / 20X: 3.8°
IRIS Mode Auto
White Balance Auto / 2500K / 3200K / 4200K / 5800K / 9500K
AGC YES
Sharpness YES
WDR YES (120dB)
External alarm I/O YES (1 input / 1 output)
IP Rating IP66
Operating Temperature -20℃~ 50℃
Operating Humidity 90% or less relative humidity
Power Source (±10%) DC12V / 1.5A
Current consumption (±10%) 800mA
Power Consumption (±10%) 9.6W
Optional Peripherals USB Joystick
PTZ Mechanism
Pan Range 360° endless
Max. Pan Speed 180º/s
Tilt Range -10° ~ 190°
Max. Tilt Speed 100º/s
Zoom Ratio 20X Optical Zoom
Max. Zoom Speed Approx. 3s (Tele ~ Wide)
Preset Points Up to 256 preset points
Sequence Group 1. Up to four groups can be set
2. One group can include up to 16 preset points
Auto Tracking YES
* The specifications are subject to change without notice.

2
PACKAGE CONTENT
Camera User manual Bracket (w/carabiner)
INSTALLATION
Step1: Loosen the screws on the dome cover to remove it (as shown in Figure 1), and take all EPE foam rolls off in the
camera.
NOTE: When you remove the EPE foam rolls, please be careful not to damage the inner mechanism
of the camera.
Then, replace the cover back.
NOTE: Make sure the dome cover is clean without fingerprints before replacing it back.
Step2: Pass the cables to be connected through the bracket, and fasten the bracket to the wall (ash shown in Figure 2).
Figure 1 Figure 2
Step3: Hook the camera and the bracket together with the supplied carabiner, and connect the cables. Then, pull the
cables from the other side of the bracket to hide the connectors in the bracket (as shown in Figure 3).
Step4: Insert the camera to the bracket, and roate the camera a little bit to hook it. Then, use a wretch to fasten the
screws on the two sides of the bracket to secure the connection (as shown in Figure 4).
Figure 3 Figure 4

3
CONNECTION
1. DC12V Input Terminal
Connect the power terminal of the camera to a DC 12V regulated power supply.
NOTE: Please use the correct power adaptor, DC12V (regulated), to operate this unit. The power
tolerance of this unit is DC12V ± 10%. Over maximum DC 12V power input will damage this
unit.
2. Video Output Connector (VIDEO OUT)
Connect the camera video output to the video input of a DVR with 75Ωcoaxial cable.
NOTE: To ensure the camera has sufficient protection against moisture, an extra waterproof
measure, such as by using an insulating tape, must be used to cover the power and video
connectors after connection.
PTZ CONTROL
NOTE: The panel below is available only when the camera is used with our brand’s HD CCTV DVR,
and not all functions in the panel are supported for this camera.
Right-click to return to the live view, and click the channel with this speed dome camera connected. Then,
click on the bottom left side of the screen to show the PTZ control panel.
/ / / Up / Down / Left / Right Click the arrow keys ( / / / ) to move the
camera lens up / down / left /right.
＋/ －Zoom in / out max Click to zoom in on the image to the largest / zoom out
on the image to its original size.
/ Zoom in / out Click to zoom in / out the image.
/ Focus near / far Click to adjust the focus of the image.
Auto mode
Click to activate the auto function.
Before using it, you need to assign a specific function
that will be enabled when “ ” is clicked.
For details, please see “CAMERA PARAMETERS”.
Auto tracking Click to start auto tracking, and click again to stop.
Preset point Click to configure or go to the preset point you want to
see. For details, please see “SEQUENCE SETUP”.
Auto Focus Click to automatically adjust the focus of the camera.
NOTE: PTZ control is also available via the optional USB joystick and EagleEyes. For details, please
check their respective user manuals.

4
CAMERA PARAMETERS
NOTE: The method below is available only when the camera is used with our brand’s HD CCTV DVR.
On the DVR live view, right click to show the DVR main menu, and select “ADVANCED CONFIG” 
“DCCS”. Then, select the channel which connects this camera, and click “SETUP” to enter the menu of
camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DEVICES F.W. 1016
DCCS DEVICE AVTXXX
NOTIFY CONNECTION OK
EXIT
Item Description
BRIGHTNESS Click the current value to manually adjust the brightness of the image. The higher the value,
the brighter the image.
CONTRAST Click the current value to manually adjust the contrast of the image. The higher the value,
the higher the contrast ratio.
HUE Click the current value to manually adjust the hue of the image.
SATURATION Click the current value to manually adjust the saturation of the image. The higher the value,
the more saturated the image.
CAMERA GUARD Enable “GUARD LOCK” to temporarily disable the pan function of this camera and fix the
camera surveillance area.
For details, please refer to the section “CAMERA GUARD”.
CRUISE MODE Select the cruise mode when the is selected in the PTZ mode. There are three
options: AUTO PAN, SEQUENCE and CRUISE.
AUTO PAN – Pan within the range specified in CRUISE CONFIG.
SEQUENCE – Patrol based on the sequence group specified in CRUISE CONFIG.
CRUISE – Patrol based on the route recorded in CRUISE CONFIG.
CRUISE CONFIG The setting shown here depends on what you selected in CRUISE MODE:
AUTO PAN – Specify the range for auto pan to run.
For details, please refer to the section “AUTO PAN SETUP”.
SEQUENCE – Configure a sequence group for area patrol.
For details, please refer to the section “SEQUENCE SETUP”.
CRUISE – Customize the patrol route in 200 seconds.
For details, please refer to the section “CRUISE SETUP”.
AUTO TRACKING Set the surveillance area for auto tracking, and the tracking timeout.
For details, please refer to the section “AUTO TRACKING SETUP”.
DISPLAY ZOOM RATIO Select “ON” to show the zoom ratio on the live view.
ENABLE TILT LIMIT When this function is set to “OFF”, the tilt angle is just as the specifications said, but it has
the possibility to see a little bit edge of the lens shield during camera tilting.
When this function is set to ”ON”, the tilt angle is slightly smaller than what’s said in the
specifications, but no lens shield edge is seen during camera tilting.
PAN SPEED Set the speed for pan movement.
TILT SPEED Set the speed for tilt movement.
VIDEO FORMAT Select the video format: NTSC / PAL.

5
Item Description
WHITE BALANCE Process the current image to retain color balance over a color temperature range.
The options are: AUTO, 2500K, 3200K, 4200K, 5800K & 9500K.
SHARPNESS Sharpness enhances the clarity of image detail by adjusting the aperture and sharpening the
edges in the pictures.
Hold and drag the slider to adjust the level of sharpness. The higher the value, the sharper
the image.
SLOW SHUTTER Slow shutter is used to increase the exposure time to get clearer image, for example, at night.
The options are: AUTO, 1/15 and 1/6.
MIRROR Select “ON” to rotate the images horizontally based on your installation situation when
necessary.
FLIP Select “ON” to rotate the image 180° when necessary.
3D DENOISE Click and drag the slider to adjust the level from 0 ~ 5 to decrease the noise shown in the
dark environment.
3D denoise analyzes successive pictures to decrease the noise dramatically, but the moving
objects might be shown as blurred.
2D DENOISE Click and drag the slider to adjust the level from 0 ~ 5 to decrease the noise shown in the
dark environment.
2D denoise analyzes only a single picture to decrease the noise. The moving objects can
remain smooth edges, but the effect might be limited.
EXPOSURE VALUE Drag the slider to adjust the exposure level from 0 ~ 4.
WIDE DYNAMIC RANGE Wide Dynamic Range (WDR) is used when users need to increase image recognizability in
overexposure and dark areas.
The options are: LOW / MIDDLE / HIGH / OFF
FIXED SHUTTER Shutter Speed is a function that can adjust the duration of the electronic shutter to produce
optimum image quality. Select the shutter speed suitable for your environment.
EFLIP This function is used to keep the image upright always after pan / tilt movement.
The options are: OFF / DIGITAL / MECHANICAL.
DEFOG Select “ON” to enable the defog function in poor weather conditions such as fog, smog or
smoke. The captured image can be improved.
MIRIS CALIBRATION Select “START” to begin mechanical iris calibration.
RESET DEFAULT Click to reset all camera settings to their default values.
REBOOT THE SYSTEM Click to reboot the camera if necessary.

6
AUTO PAN SETUP
Step1: In the live view, right click to show the main menu.
Select ADVANCED CONFIG DCCS. Then, select the channel which connects this camera,
and click SETUP to enter the menu of camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DCCS F.W. 1016
NOTIFY DEVICE AVTXXX
MULTICASTING CONNECTION OK
EXIT
Step2: Select CRUISE MODE, and choose AUTO PAN. Then, go to CRUISE CONFIG to select
SETUP.
Step3: You’ll see the setting panel on the bottom left side of the screen:
Icon Function Description
Left limit Move the slider to where you want to set as the most left side of the surveillance
area, and click to set.
Right limit Move the slider to where you want to set as the most right side of the
surveillance area, and click to set.
-- Tilt angle Move the slider to the height you want.
Zoom ratio Move the slider to confirm the zoom ratio you need for the current area.
-- Pan speed Set the speed to pan.
Step4: Right-click to return to the live view, and click the channel with this speed dome camera
connected. Then, click on the bottom left side of the screen to show the PTZ control panel,
and select to start.
NOTE:To stop camera panning, click again to escape.

7
CRUISE SETUP
Step1: In the live view, right click to show the main menu.
Select ADVANCED CONFIG DCCS. Then, select the channel which connects this camera,
and click SETUP to enter the menu of camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DCCS F.W. 1016
NOTIFY DEVICE AVTXXX
MULTICASTING CONNECTION OK
EXIT
Step2: Select CRUISE MODE, and choose CRUISE. Then, go to CRUISE CONFIG to select
SETUP.
Step3: You’ll see the setting panel on the bottom right side of the screen:
a) Select the cruise group to which you want to record the route. There are 4 groups to be used.
b) Move to the scene you want the cruise to be started.
c) Click
(Record). Then, drag and hold the mouse to move the camera for route planning,
and scroll the mouse to zoom in / out. You’ll see and on the screen.
NOTE:The closer these two icons, the slower the camera moving; the farther these two icons, the
faster the camera moving.
NOTE:You have 200 seconds to customize the cruise route.
d) Click to stop route planning, and click to replay the route you just made. To discard the
route you just made, click .
Step4: Right-click to return to the live view, and click the channel with this speed dome camera
connected. Then, click on the bottom left side of the screen to show the PTZ control panel,
and select to start.
NOTE:To stop camera cruising, click again to escape.

8
SEQUENCE SETUP
Step1: On the DVR live view, click the channel with this speed dome camera connected. Then, click
on the bottom left side of the screen to show the PTZ control panel.
Step2: Click to display the preset point panel, and click to go to the setting panel.
Step3: Click / to move to the point you want to configure as a preset point, and click the
numbering you want to appoint for this point. Then, wait till you see (command sending)
appearing and disappearing on the DVR status bar.
NOTE:Up to 256 preset points could be configured.
Step4: Repeat Step3 until you’ve added all the points you need, or click to return to the Goto
panel.
Step5: In the Goto panel, select the numbering you’ve appointed for the preset points to check if they’re
working properly.
Step6: Return to the live view, and right click to show the main menu.
Select ADVANCED CONFIG DCCS. Then, select the channel which connects this camera,
and click SETUP to enter the menu of camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DCCS F.W. 1016
NOTIFY DEVICE AVTXXX
MULTICASTING CONNECTION OK
EXIT

9
Step6: Select CRUISE MODE, and choose SEQUENCE. Then, go to CRUISE CONFIG to select
SETUP.
SEQUENCE
ACTIVE NO: 1 
ACTIVE TIME (MINUTES) 3 
No1 PRESET DWELL TIME PAN SPEED
No2 01 No2 600
0
255
No3 02 No4 600
0
255
No4 03 No5 600
0
255
No5 >> 04 No1 600
0
255
No6 << 05 No3 600
0
255
No7
No8
No9
No10
No11
No12
No13
No14 
EXIT
ACTIVE TIME (MINUTES) Select how long the area patrolling lasts in minute.
The options are 2, 3 and 5.
DWELL TIME Select the time in second after which to move to the next point. The
time ranges from 3 to 60.
PAN SPEED Select how fast to move the camera to the next point. The speed
ranges from 0 to 255.
Step6: Select EXIT, and right click to return to the live view.
Click the channel with this speed dome camera connected. Then, click on the bottom left
side of the screen to show the PTZ control panel, and select to start.
NOTE:To stop camera panning, click again to escape.

10
CAMERA GUARD
This function is used to lock the camera to a fixed point and no pan action could be made until the lock mode
is disabled. Before using this function, make sure:
You have an iOS or android mobile device with our free app, EagleEyes, installed.
Your HD CCTV DVR is connected to Internet, and registered in the address book of EagleEyes.
NOTE:To know how to connect the DVR to Internet, please refer to its user manual.
Step1: In the live view, and right click to show the main menu.
Select ADVANCED CONFIG DCCS. Then, select the channel which connects this camera,
and click SETUP to enter the menu of camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DCCS F.W. 1016
NOTIFY DEVICE AVTXXX
MULTICASTING CONNECTION OK
EXIT
Step2: Select CAMERA GUARD, and enable this lock function. Then, configure the timeout after
which the camera will be fixed to the current point and any attempt to pan the camera to another
point will be failed.
CAMERA GUARD
GUARD LOCK ON
TIMEOUT (SECS) 30 
Step3: Go to EagleEyes on your mobile phone or tablet, and access your HD CCTV DVR. Then, click on
the channel with this camera connected, and choose any of the following methods to move the
camera to the point you want:

11
Step4: Return to the address book of EagleEyes, and enable Guard. The camera will fix at the point
after the time specified in Step2 unless the Guard status is disabled.

12
AUTO TRACKING SETUP
Step1: In the live view, right click to show the main menu.
Select ADVANCED CONFIG DCCS. Then, select the channel which connects this camera,
and click SETUP to enter the menu of camera parameters.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DCCS F.W. 1016
NOTIFY DEVICE AVTXXX
MULTICASTING CONNECTION OK
EXIT
Step2: Go to AUTO TRACKING, and select SETUP.
Step3: You’ll see the setting panel on the bottom left side of the screen:
Icon Function Description
Left limit Move the slider to where you want to set as the most left side of the surveillance
area, and click to set.
Right limit Move the slider to where you want to set as the most right side of the
surveillance area, and click to set.
-- Tilt angle Move the slider to select the tilt range of the surveillance area.
Zoom ratio Move the slider to confirm the zoom ratio you need for the current area.
-- Time Set pre-defined tracking timeout of the camera from 5 ~ 60 seconds, or drag
directly to the right end for no time limit (INFINITE).
When the locked target stops moving longer than the pre-defined tracking
timeout, the camera returns to the point it originally monitors after the preset
tracking timeout.
Step4: Right-click to return to the live view, and click the channel with this speed dome camera
connected. Then, click on the bottom left side of the screen to show the PTZ control panel,
and select to start.
NOTE:To stop camera panning, click again to escape.
