Avtech IC-YGN2003 User manual

y2003_manual_beta
User Manual
Panoramic Navigation 1080P Wi-Fi IP Camera

IMPORTANT SAFEGUARD
All lead-free products offered by the company comply with the requirements of the European law on the
Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and
products are strictly “lead-free” and without the hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product must be
collected separately at the product end-of-life. This applies to your product and any peripherals marked
with this symbol. Do not dispose of these products as unsorted municipal waste. Contact your local
dealer for procedures for recycling this equipment.
This apparatus is manufactured to comply with the radio interference requirements.
Disclaimer
any legal liability or responsibility for the accuracy, completeness, or usefulness of this manual. The content of this manual
is subject to change without notice.
This product doesn’t have a standby / off mode.
Trademark Acknowledgements
iPad® & iPhone® are the registered trademarks of Apple Inc.
Android™ is a trademark of Google Inc. Use of this trademark is subject to Google Permissions.

MPEG4 Licensing
THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4
VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A
VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE
IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL
INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, LLC. SEE
HTTP://WWW.MPEGLA.COM.
GPL Licensing
This product contains codes which are developed by Third-Party-Companies and which are subject to
the GNU General Public License (“GPL”) or the GNU Lesser Public License (“LGPL”).
The GPL Code used in this product is released without warranty and is subject to the copyright of the
corresponding author.
Further source codes which are subject to the GPL-licenses are available upon request.
We are pleased to provide our modifications to the Linux Kernel, as well as a few new commands, and
some tools to get you into the code.

TABLE OF CONTENT
CAMERA OVERVIEW ............................................................................................................. 1
Hardware .................................................................................................................................. 1
Package content........................................................................................................................ 2
Status indicator......................................................................................................................... 2
Default values ........................................................................................................................... 3
GETTING STARTED ................................................................................................................ 4
Getting camera ready ............................................................................................................... 4
Connecting camera to internet................................................................................................. 6
ADDRESS BOOK..................................................................................................................... 7
LIVE VIEW ............................................................................................................................. 8
Snapshot ................................................................................................................................... 9
Manual recording ..................................................................................................................... 9
Audio......................................................................................................................................... 9
Video resolution change......................................................................................................... 10
Pan / tilt control...................................................................................................................... 10

VIDEO SEARCH & BACKUP .................................................................................................. 12
Search by calendar.................................................................................................................. 13
Search by event ...................................................................................................................... 14
Video backup .......................................................................................................................... 15
PUSH VIDEO........................................................................................................................ 16
How to enable Push Video ..................................................................................................... 16
How to check Push Video ....................................................................................................... 17
ADVANCED CONFIGURATIONS ........................................................................................... 19
Menu ...................................................................................................................................... 20
Camera Configuration............................................................................................................. 22
Record Configuration.............................................................................................................. 24
Trigger..................................................................................................................................... 25
Audio Configuration................................................................................................................ 26
Time Configuration ................................................................................................................. 27
Wireless Configuration ........................................................................................................... 28
Account Configuration............................................................................................................ 29

APPENDIX............................................................................................................................ 32
Account user levels................................................................................................................. 32
Playing video footage saved in microSD card on PC............................................................... 33
MicroSD card compatible list.................................................................................................. 35
Specifications.......................................................................................................................... 36

1
CAMERA OVERVIEW
Hardware

CAMERA OVERVIEW 2
Package content
Camera Wall mount accessories
USB Charger USB Charger
Cable
Quick Start
Status indicator
Color Status Meaning
During network setup
Blue Flashing Setting camera…
Red Flashing Internet connection failed
Purple Flashing Wrong Wi-Fi password…
Blue Flashing
slowly
Connecting to Wi-Fi network
Wi-Fi signal strength*
Blue Stable Strong
Purple Stable Normal
Red Stable Weak
Others
Blue & red Flashing Resetting camera…
Red Flashing Internet connection failed
* When the signal strength is stable, the indicator will be off after
one minute. The indicator will be on again in the color
corresponding to its current signal strength when the signal
strength is changed.
Panora m ic Navig a tio n Pan/ T il t 1080P Ca m e ra
Pan / Ti lt
1080P

CAMERA OVERVIEW 3
Default values
Wired Wireless
IP address 192.168.1.10 192.168.2.10
Port number 88 88
User name admin Admin
Password Admin admin
SSID -- IPCAM-mac_address
SSID password -- no

GETTING STARTED 4
GETTING STARTED
Getting camera ready
Insert a microSD card (up to 128GB) and connect your camera to power.
NOTE
This camera doesn’t support plug and play. Please make sure the power is off before inserting or removing the microSD card.
NOTE
If you want to mount this camera to a wall or ceiling, please check the next section, “Wall-mount installation”, to know how to mount
the camera with the supplied accessories.

GETTING STARTED 5
Wall-mount installation
1. 1. Fasten wall-mount adapter to wall.
Find the wall-mount accessories
in the sales package, and fasten
the black wall-mount adapter to
where you want to install the
camera.
2. 2. Attach camera to wall.
Align the bottom of the
camera with the wall-
mount adapter (a).
Then, rotate the camera 90o clockwise to secure (b).
3. 3. Power on & configure camera.
Follow the instructions in
“Quick Start” to power on the
camera and configure it via
your smart phone / tablet.

GETTING STARTED 6
Connecting camera to internet
By EaZy Networking (P2P cloud service)
Please check Quick Start or video demo to know more details.
Quick Start Video Demo
By configuring your router
Please check the advanced network setup to know more details.

ADDRESS BOOK 7
ADDRESS BOOK
For details about each element on this page:
1. Click on (Information), or
2. Scan the QR code below.

LIVE VIEW 8
LIVE VIEW
The functions available depend on the user level of your account.
There are four user levels: SUPERVISOR, POWER USER,
NORMAL and GUEST. Please check “Account user levels” at page
32 to know details.

LIVE VIEW 9
Snapshot
Click on to take a snapshot of the current live image. The image will be saved to (Media), accessible
from the address book.
NOTE
The resolution of the snapshot depends on the video profile you chose for live display. For details, please check “Video resolution
change” at page 10.
Manual recording
Click on to start recording the current live feed and click on again to stop. The footage will be saved to 
(Media) , accessible from the address book.
NOTE
The resolution of the footage depends on the video profile you chose for video recording. For details, please check “Record
Configuration” at page 24.
Audio
Click on to choose whether you want to hear the live audio ( ) or talk to someone there ( ).
If this function is not enabled in the live view, return to the address book, click on (Edit) and choose the camera to go
to the setting page. Check the OPTIONAL section and see if Audio is switched on.
If you think the audio volume is small or loud and want to adjust the volume, click on (Setting) on the top
toolbar in the live view, and choose Audio Configuration to change the volume setting.

LIVE VIEW 10
Video resolution change
Click on to show more operations for the camera, and choose to change the resolution of the live feed.
There are four default video profiles:
Profile1(H.265 / 1920 x 1080), Profile2 (H.265 / 704 x 480), Profile3 (H.265 / 352 x 240) and
Profile4 (JPEG / 352 x 240).
The more the resolution, the clearer the live feed but the more time you might need to wait for the live feed to show and
even get a little big lag.
Pan / tilt control
This camera supports 350° horizontal and 45° vertical rotations to allow you moving to any area you want to see remotely.
Click on to show more operations for the camera and choose the one you want to use.
Vertical / horizontal movement manually
Click on and start moving the camera view by tapping or swiping with your finger on the screen:
Tap once
Quickly move to and center the area you want to see.
Swipe left / right / up / down / left-up / right-up / left-down / right-down
Touch and swipe with your finger to continuously move the camera view to the direction opposite to the one you swipe.
For example, when you swipe left, the camera view will move to the right; when you swipe up, the camera view will
move down.

LIVE VIEW 11
Vertical / horizontal movement automatically
Auto pan
Click on to start panning 350° only once based on the current position.
Preset point
You can configure up to six preset points to move the camera view to the angles you specified.
How to set a preset point
Step1: Click on to move the camera view to the area you want.
Step2: Click on , press and hold a numbering from 1 ~ 6 till you see the message Set Success.
How to use a preset point
When the camera view has been moving to other area, click on and choose the numbering which has configured
a preset point.
Digital zoom
Click on to enable the digital zoom function.
Zoom-in
Place two fingers on the screen near each other to zoom in on the current view.
Then, tap or swipe with your finger on the screen to move to the area you want to see more clearly.
Zoom-out
Place two finger on the screen and spread them apart to zoom out on the current view.

VIDEO SEARCH & BACKUP 12
VIDEO SEARCH & BACKUP
NOTE
This function is available only for SUPERVISOR and POWER USER accounts. For details, please check “Account user levels” at
page 32.
NOTE
Before using this function, make sure you’ve enabled the recording function to get video footage. For details, please check “Record
Configuration” at page 24.
There are two ways to go to the event search and backup pages:
4. In the address book, click on (Play) at the bottom toolbar, and choose the camera you want to search for video
footage.
5. In the live view, click on (playback) on the top toolbar.

VIDEO SEARCH & BACKUP 13
Search by calendar
In the calendar view ( ):
1. Choose the date within which includes the video footage you need. The
date with video footage will be circled.
2. Tap and hold on the time bar to slide to the time you want.
3. Choose ►to start video playback.

VIDEO SEARCH & BACKUP 14
Search by event
In the list view ( ):
1. Choose from the two event types:
Type
Description
ALL All events List of all alarm and motion events
ER
Event Record
Record triggered by alarm detection
MT Motion Trigger Record triggered by motion detection
To narrow down the list, select on the top right corner to specify
the time and to specify the time.
2. Select one log from the list to start video playback.
