AVteq UM-1T Quick start guide

UM - 1
Toll Free: 800 285 8315 Telephone: [phone] Facsimile: 214 905 9666

ABD
EFGH
IJK
L
O
N
M
C
P
1
O
PO
Itemsincluded
M6X35
M6X12
Black Spacer
M8X16 M8X40
M10X50
Square spacer
M8 & M6
M5X12 M5X30
Iron Spacer
Left Monitor Bracket
Wall Plate (x1)
Concrete anchor
M8 X 50
M8 X 70 outside
the hexagonal
Mansory Wall
OR
Right Monitor Bracket
Timber Stud Wall
MOUNTING THE WALL PLATE
Note: Ensure the Wall
Plate in mounted with
the folded tabs pointing
upwards
TIPS: Use a spirit level to ensure the Wall Plate is horizontal
Note: Ensure the Wall
Plate in mounted with
the folded tabs pointing
upwards
Spacer M10
Spacer M8
M4X12 M4X30

2
3
4
L
L
M/N
NOTE:
When attaching the mounting
screws to the display, make
sure the direction of Brackets
is right and ensure that both
brackets are vertically aligned
Recessed mounting
holes.
If the mounting holes
are recessed into the
back of the display, use
the supplied spacers to
pack the recessed hole.
MOUNTING THE DISPLAY
BRACKETS
ATTACHING THE DISPLAY TO
THE WALL PLATE
SECURITY OPTION
Note: This procedure will require two persons
With the Brackets attached
to the display, lift the
display and hook the
brackets onto the Wall Plate
as shown.
Note: For demonstration purposes, the wall
has been omitted from the above images.
Note: For demonstration purposes, the wall has been
omitted from the above Images.

Can be adjusted freely

Mounting screw
BACK OF
DISPLAY
