Avue AV666EW User manual

1&2.Ring-formEnclosure to protect camera body: .
3 Base.
5 wire out hole.
1
2
3
45
DESCRIPTION
PRECAUTIONS
FEATURES
PARTS INSTRUCTION
(at bottomof thebase)
6
4 lens.
AV666EW
Thank you for purchasing this product. Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
1. 1/3” Sony 960H CCD
2. High resolution, 700TVL, true color reducibility
3. Support 2DNR
4. WDR
5. IR SMART control
6. Weatherproof IP66
7. simple operation
8. OSD menu
.
6. fore install screws holes
1 Use the Appropriate Power Supply. .
The input power for AV666EW is DC 12V and 200mA (IR Off)/450mA (IR On). Be sure to connect
2 Do not attempt to disassemble the camera. .
, .To prevent electric shock do not remove screws or covers There no user serviceableis
. . parts inside Ask a qualified service person for servicing
3 Handle the camera with care. .
. , , .Do not abuse the camera Avoid striking shaking etc The camera could be damaged ...
.by improper handling or storage
4.
:Do not place the camera in the following locations
-Locations where temperature is lower than 20 C or higher than 55 C
%Locations where humidity is higher than 90
PRECAUTIONS
5 Clean the CCD faceplate with care. .
, . When cleaning the CCD panel do not use strong or abrasive detergents Use a piece
. of lens tissue or cotton tipped applicator and ethanol
6 Do not attempt to aim the camera at the sun. .
Do not attempt to aim the camera at the sun or other extremely bright objects that cause
( ). damage the CCD Charge Coupled Device
7 Do not put the camera in a place with interference. .
When this camera is installed near the equipment like wireless communication device
, which emits strong electromagnetic field some irregularity such as noise on monitor
.screen may happen
it to the appropriate power. Wrong connection may cause malfunction and /or damage to the video
camera.
AV666EW has advanced image technology with resolution as highas 700TVL, true color
reducibility; Support 2DNR, WDR, IR SMART control, AV666EW comes with a powerful OSD menu
that include motion detection, privacy mask, HLC, BLC, multiple languages, and other functions
that makes the AV666E suitable for various special environment.

Appearance size
Menu operation
Specifications
Ø120.0
VIDEO OUTPUT
POWER INPUT
DC 12V
◆DC
◆AGC
◆WDR ◆RETURN
◆ATW ◆ANTI.CRL
◆AWB ◆MANUAL
◆AWC→SET
◆HLC ◆BLC
◆OFF
DAY&NIGHT ◆AUTO ◆COLOR
◆EXT ◆B/W
DPC
◆START ◆DPC VIEW
◆LS VALUE ◆DIFF
◆AREA HS ◆AREA HE
◆AREA VS ◆AREA VE
◆RETURN
SPECIAL
◆CAM TITLE ◆MOTION
◆PRIVACY ◆PARK.LINE
◆IMAGE ADJ. ◆COMM ADJ.
◆LANGUAGE ◆VERSION
◆SAVE ◆NOT SAVE
◆RESET
◆MANUAL
EXPOSURE ◆SHUTTER
WHITE BAL
BACKLIGHT
LENS
EXIT
1
2 Using the foam pat to locate holes in the wall
3
Drill 4 holes in the position needed in accordance with the installation hole on the base ,
, push the Expansion Bolt inside then tighten the screws make the installation hole aim at the
.three screws and fix it
4
Camera installation
.Get the wire out from the wire out hole
Setup
Main menu
Unscrewthering-form ,takethering-formout.Enclosure
*Specifications are subjected to change without notice.
Pick up device
Effective pixels
Scanning system
Sync. System
Resolution
Lens
O.S.D
White balance
AGC
HLC/BLC
NR
Mirror function
Image adjustment
Motion detection
Privacy zones
Day & night
S/N ratio
Electronic shutter
Video output
Min. Illumination
Power supply
Current consumption
Operation temperature
Dimension
Weight
Contrast/Sharpness
2:1 interlaced
Internal
Built-in
ATW/AWB/AWC (ANTI-CRL/MANUAL)
ON/OFF/AUTO
2D noise reduction
ON/OFF
ON OFF/(4 areas)
Auto / B/W / Exton / Color
more than 52dB (AGC off)
Auto(1/60 (1/50) ~ 1/100,000)/Fixed/Manual
1.0Vp-p composite video output, 75Ω
0 Lux (IR on)
ON OFF/(8 areas)
High, Middle, Low, Off
IR distance
WDR ON/OFF
95 (H) 120 (D)mmmm x
NTSC: 976 (H)*494 (V)
700 TV Lines
PAL: 976 (H)*582 (V)
1/3" Sony 960H CCD
2.8-12mm
Weatherproof IP66
200mA IR Off and 450mA IR On( ) ( )
20~30M 36 Units infrared LED 5mm 850nm/ ( / )Φ
*
*1
1ANTI CRL is ANTI Color Rolling- - .
**
1180 Miraloma Way Suite C
Sunnyvale, CA 94085
TEL: [phone], FAX: [phone]
www.avueinc.com
