AWA JTM19F22-D User manual

M6601-19F211002R
JTM19F22-D
ENGLISH

1
Dear Customers,
May we take this opportunity to thank you for purchasing this LCD TV. We strongly recommend
that you read the safety and operation instructions throughly before operating your LCD TV.
FOLLOW ALL INSTRUCTIONS AND WARNINGS on your LCD TV and in this manual.
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 3
PACKAGE CONTENTS 5
CONTROL BUTTONS AND TERMINALS 6
REMOTE CONTROL 7
8
BASIC OPERATION
9
SWITCHING THE LCD TV ON/OFF 9
SELECTING INPUT SOURCE
CHOOSING A TV CHANNEL 9
ADJUSTING THE VOLUME 9
FRONT PANEL CONTROLS 6
BASIC CONNECTION
BATTERY INSTALLATION 8
9
REAR PANEL TERMINALS 6
MENU OPERATIONS
10
INPUT PC MODE 10
INPUT TV MODE 11
INPUT AV/SCART/S-VIDEO MODE 12
13
TELETEXT FUNCTIONS(OPTION)
14
ABOUT THE DISC
DISC HANDING 14
DVD OPERATION 14

TABLE OF CONTENTS
2
27
SUPPORTED OPERATING MODES
TROUBLESHOOTING 28
SPECIFICATIONS 30
15
BASIC OPERATING INSTRUCTIONS
PLAY THE DISC 15
MENU PLAYBACK 15
TITLE PLAYBACK 16
SEQUENTIAL PLAYBACK 16
PROGRAM PLAYBACK 16
SIDE VIEW 17
18
LOCATION OF CONTROLS FOR DVD OPERATION
19
FUNCTIONS OPERATING INSTRUCTIONS
24
DISC MENU
SYSTEM SETUP 24
LANGUAGE SETUP 25
AUDIO SETUP 26
DIGITAL SETUP 26
23
MP3/JPEG PLAYBACK

IMPORTANT SAFETY INSTRUCTIONS
This symbol indicates
“dangerous voltage”
inside the product that
presents a risk of electric
shock or personal injury.
This symbol indicates
important instructions
accompanying the
product.
RISK OF ELECTRIC
SHOCK DO NOT
OPEN
CAUTION
TO REDUCE THE RISK OF
ELECTRIC SHOCK.
DO NOT REMOVE COVER.
NO USER-SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read this Manual
Read this manual throughly before operating the unit.
Keep this manual
Keep this manual for future reference.
Observe all warnings
All warnings on the product and in the manual must be observed closely.
Follow all instructions
All operating instructions in the manual must be followed.
Do not insert liquids or objects
Liquids or objects could result in fire or electrical shock. Use special caution in households where
children are present. If liquids or objects should enter the LCD TV, immediately turn off the power
switch, disconnect the power plug from the AC outlet and contact the qualified service personnel.
● Do not place the LCD TV near the bathtub, bathroom, kitchen sink, wet basement or swimming
pool , and the like.
● Do not expose the LCD TV to rain or moisture.
● Do not place flower vases, pots, cups, cosmetics, liquids as water, etc on or around the LCD TV.
● Do not place metals, combustibles, etc on or around the LCD TV.
● Do not drip or splash liquid of any kind on the LCD TV.
Do not give the LCD TV any shock or impact
If the LCD TV should be dropped and/or broken, it could result in an injury, and continued use could
result in fire or electrical shock.
If the glass panel is broken or damaged, immediately turn off the power switch, disconnect the power
plug from the AC power outlet and contact the qualified service personnel.
Prevent the unit from falling
● Do not allow children to climb on the LCD TV.
● Do not place the LCD TV on a bed, sofa, rug, similar surface. Do not place the LCD TV on an un-
stable cart, stand or table. The LCD TV may fall, causing serious damage to the LCD TV and/or
serious personal injury, death.
● When the product is used on a trolley, care should be taken to avoid quick stops, excessive force,
and uneven surfaces that may cause the product and trolley to overturn.
3

Do not block any ventilation openings
● The vents and other openings in the cabinet are designed to let hot air escape from the LCD TV.
Do not cover or block these vents and openings since insufficient ventilation can cause over-
heating. Do not place the LCD TV on a bed, sofa, rug or other similar surface, since they can block
ventilation openings, it may overheating and result in fire.
● Do not cover the LCD TV with cloth, such as curtains, or items such as news paper, etc.
● This unit is not designed for built-in installation, do not place the product in an enclosed place such
as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are
followed.
Avoid high temperature environment
The heat could adversely affect the LCD TV and other parts, and could result in serious overheating or
risk of fire.
● Do not place the LCD TV, the remote control and other parts in direct sunlight or near a hot object
such as heater, etc.
● Do not put the LCD TV in a place where the temperature is widely changing.
Avoid oils
Do not install the LCD TV in a place that uses oil. Dust absorbing oil may enter into the unit and damage
the unit.
Power cord protection
Incorrect connection of the power cord could result in fire or electrical shock.
● Do not connect too many appliances to the same mains socket as this could result in fire or electrical
shock.
● The apparatus shall be connected to a mains socket outlet with a protective earthing connection.
● The socket outlet for connecting mains plug shall be easily accessible and remain readily operable.
● Do not overload wall outlet as this can result in fire or electrical shock.
● Check that the connecting portion of the AC power cord is clean (with no dust), before using. Use a
soft and dry cloth to clean the power plug.
● AC power cord should be routed so that they are not likely to be walked on or pinched by items
placed upon or against it. Also do not put any heavy objects on the AC power cord.
● Do not touch the AC power cord with a wet hand.
● Pull out the AC power cord by the plug. Do not pull on the power cord.
● Insert the power plug into a power outlet firmly. Avoid using a loose or damaged outlet.
● Do not pinch, bend, or twist the cable excessively. The core lines may be bared or cut, causing a
short-circuit which may induce fire or electrical shock.
● For your own safety, do not touch any part of the unit, power cord or aerial lead during lightning
storms.
● Do not modify the AC power cord.
● Disconnect the power cord if the LCD TV is not used for a long time.
● Switch off and withdraw the power plug before making or changing connections.
Handing and cleaning the screen surface of display unit
To avoid screen degradation, follow points mentioned below. Do not push on or scratch with
hard objects, or throw anything at the screen. The screen may be damaged.
● Be sure to unplug the power cord from outlet before cleaning.
● Do not touch the display panel after operating continuously for a long period as the display panel
becomes hot.
● We recommend that the screen surface is touched as little as possible.
● To remove dust from the screen surface, wipe gently with a clean, soft and cotton-free dry cloth.
● Do not use any type of abrasive pad, alkaline/acid cleaner or strong solvent such as alcohol, thinner
or benzene etc, as the surface may be impaired.
Cleaning the cabinet
● Be sure to unplug the power cord from the outlet before cleaning.
● Clean the cabinet with a soft cloth.
● Note that material deterioration or screen coating degradation may occur if the display unit is ex-
posed to a volatile solvent, such as alcohol, thinner, benzine or insecticide, or if prolonged contact
is maintained with rubber or vinyl materials.
IMPORTANT SAFETY INSTRUCTIONS
4

PACKAGE CONTENTS
Your LCD TV package includes:
1. LCD TV
2. Remote Control
3. RCA Cable (3 Pin)
4. Operation Manual
5. Power Cord
Note:
Your product may also include various other accessories depending on region of purchase.
5
Carrying and moving
● Be sure to always carry the LCD TV carefully holding it with two hands, one hand on each side of the
LCD TV. If you carry the unit in a manner other than that specified, it may drop and a serious injury
may be caused.
Servicing
Do not open the cabinet or remove the rear cover of the unit. If any of the following conditions occurs,
unplug the AC power cord from the AC outlet, and contact qualified service personnel.
● When the power cord or plug is damaged.
● When the LCD panel is damaged.
● When the liquid is spilled on the unit or when objects have fallen into the unit.
● When the unit has been exposed to rain or water.
● If the unit has been dropped or the cabinet has been damaged in any way.
● If the unit does not work properly even after you have referred to the TROUBLESHOOTING section.
Replacement parts
● In case the unit needs replacement parts, make sure that the service personnel uses replacement
parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electrical shock and/or other danger.
● Upon completion of service or repair work, request the service technician to perform safety checks
to ensure that the unit is in proper operating condition.
Other notices
● Sometimes, the image may have some tiny red, green, blue, white or black spots. This is normal
and does not affect the performance of the LCD TV.
● Due to advanced technology of the LCD TV, giving you fine picture details. Occasionally, a few non-
active pixels may appear on the screen as a fixed point of blue, green, or red. Please note that this
is does not affect the performance of your LCD TV.
● If the unit is used in a cold place, a smear may occur in the picture or the picture may become dark.
This does not indicate a failure. These phenomena improve as the temperature rises.
● In some case, residual images may remain after the short-term display of still images is displayed.
These will disappear in a few minutes, and the display will return to normal. However, if used in high
temperatures, it sometimes spends some tens of minutes to return to normal. Please note that this
is not a malfunction.
● LCD panel are made of finely processed glass, Avoid pushing or hands or a strong impact on the
panel. It may cause damage to the LC cells, and/or there is danger of glass breakage.
● Do not use immediately after moving from a low temperature to a high temperature environment,
as this causes condensation, which may result in fire, electrical shock or other danger.
IMPORTANT SAFETY INSTRUCTIONS

6
CONTROL BUTTONS AND TERMINALS
This TFT-LCD TV/monitor allows you to easily adjust the characteristics of the image being displayed.
While you use these buttons to adjust the controls, the OSD (on-screen-display) will show you their
numeric values as they change.
FRONT PANEL CONTROLS
Note:
If no signal inputs for 15 minutes, the unit will switch to standby mode automatically.
VOL-
Button NameButton Name DescriptionDescription
VOL+
MENU Enter or exit from the menu.
SOURCE Select TV, SCART, AV, S-VIDEO, PC-RGB or DVD mode.
CH-
When you watch the TV program, push this button to
decrease channel number. In the main-menu, push this
button to select the downward menu item.
CH+
When you watch the TV program, push this button to
increase channel number. In the main-menu, push this
button to select the upward menu item.
Decrease/adjust the values of the selected menu item,
or decrease the level of audio volume.
Increase/adjust the values of the selected menu item,
or increase the level of audio volume.
POWER Switch on the LCD TV/monitor when at standby mode
or vice versa.
POWER INDICATOR Illuminates red in standby mode.
Illuminates green when the LCD TV is switched on.
REMOTE SENSOR Infrared sensor for the remote controller.
REAR PANEL TERMINALS
Connectors descriptions:
① ：AC power input for the LCD TV.
② ：DVD Coaxial Output, connecting to Coaxial input of your Amplifier.
③ ：Scart input interface, connect your AV system with SCART output.
④ ：Audio input for VGA mode, connect to your PC audio output.
⑤ ：DB15 VGA interface, connect power supply adaptor here.
⑥ ：Right Audio Channel input for Composite video & S-video mode.
⑦ ：Left Audio Channel input for Composite video & S-video mode.
⑧ ：CVBS / Composite video inputs, connect your AV system.
⑨ ：S-VIDEO input, connect video input from external device here.
⑩ : 75 Ω aerial input, connect antenna connector or aerial interface here to
receive cable / aerial signal.
LINE IN
R L
AUDIO IN VIDEO IN S-VIDEO
6 7
38 49 510
COAXIAL
2
1
AC IN SCART
VGA IN
(D-SUB 15PIN) ANT.75Ω

REMOTE CONTROLLER
CONTROL BUTTONS AND TERMINALS
7
POWER
To switch on the LCD TV/monitor
when in standby mode or vice versa.
NUMBER BUTTONS
To directly select program
number.
RETURN
To return the last view TV
channel.
-/--
To select one or two digital TV
channel.
SLEEP BUTTON
To select the sleep time to
automatically to standby.
PMODE
To select the picture mode.
INPUT
To select TV, SCART, AV, S-VIDEO
PC-RGB or DVD monitor mode.
SMODE
To select the sound mode.
MUTE
To switch the sound on or off.
◄►▲▼and ENTER
To select on the screen menu items
and change the item values.
TELETEXT BUTTONS (OPTIONAL)
These buttons are used for certain
models with Teletext functions only.
For further details, refer to the
TELETEXT FUNCTION.
All the functions can be control with the remote control. Some functions can also be adjusted with the
buttons on the front panel of the set.
Note:
Some buttons are supply for DVD operation use. For further details, refer to the "Location of
controls for DVD operation".
CH+/CH-
To select the program in
ascending or descending.
VOL+/VOL-
To increase or decrease the volume.
DISPLAY
Display current TV channel
information
LCD MENU
To enter or exit from the TV menu.
SLEEP

BATTERY INSTALLATION
Insert the batteries while observing the correct (+) and (-) polarities as illustrated below.
About the batteries
● If the remote control unit fails to work even when it is operated near the LCD TV, please
replace the batteries.
● Use size UM-4 (AAA) batteries.
Note:
● Do not use rechargeable (Ni-Cd) batteries.
● Do not attempt to recharge, short circuit, disassemble, heat or throw the batteries into the fire.
● Do not splash the remote control with water or put it on a wet object .
● Do not drop, step on or cause any impact to the remote control unit. This may damage it,
resulting in malfunction.
● Do not mix old and new batteries.
● If the remote control unit is not going to be used for a long time, remove the batteries.
● Strong light such as direct sunlight falling on the remote sensor can cause operational
failure. Place the remote control to avoid direct contact with sunlight.
Batteries should never be thrown away or incinerated but disposed of in accordance with your
local regulations concerning chemical wastes.
Caution
Keep batteries out of children’s reach. If batteries are swallowed, contact a physician
immediately.
BASIC CONNECTION
8
++
__
__
++
RO3,1.5V X2
UM-4(AA A)
++
++
--
--

SWITCHING THE LCD TV ON/OFF
BASIC OPERATION
9
1. Press the button on the front panel or the STANDBY button on the remote controller to
switch it on or to standby mode.
2. If the unit is in standby mode, press the STANDBY button on the remote controller to switch
it on.
3. Press the STANDBY button on the remote controller, the unit will revert to standby mode.
Note:
If, while the unit is switched on, the mains plug is disconnected, the unit will switch to standby
when the mains plug is replaced in the mains power socket again.
CHOOSING A TV CHANNEL
Using the CH+/CH-button on the front panel, or the p/q button on the remote control.
Press the CH+ or pbutton to increase channel number.
Press the CH- or q button to decrease channel number.
Using 0-9 digital buttons
You can select the channel number directly by pressing 0 to 9 buttons .
Example:
To select 1-digit channel (e.g. Channel 5):
● Press the -/-- button repeatedly to display “-” then press 5 button.
To select 2-digit channel (e.g. Channel 20):
● Press the -/-- button repeatedly to display “--” then press 2, follow by 0.
ADJUSTING THE VOLUME
Press the VOL+/- button to increase or decrease the volume
The volume indicator appears and the volume changes as you press the VOLUME +/- buttons.
Using Mute
At any time, you can temporarily cut off the sound using the MUTE button.
1. Press the MUTE button and the sound cuts off. The icon will appear in the low-left corner of
the screen.
2. To turn mute off, press the MUTE button again or simply press either the VOL+ button .
SELECTING INPUT SOURCE
Repeatedly press the SOURCE button on your front panel or on the remote control, the source
sequence is as follows:
TVZSCARTZAVZS-VIDEOZPC-RGBZDVD

MENU OPERATIONS
10
You can modify certain parameters of the LCD-TV in the menu system. Please read the following
descriptions to get an understanding of each adjustable parameter.
1. Press LCD-MENU button to either display the “PC” or “GENERAL” or “AUDIO” menu.
2. Press ▲ / ▼ buttons to scroll through the parameters
3. Press ◄ / ► buttons to make changes to the parameters
4. Press the LCD-MENU button to exit the menu .
INPUT PC MODE
PC MENU
BRIGHTNESS 50
CONTRAST 50
COLOR SETTING USER
AUTO CONFIG "
H-POSITION 50
V-POSITION 50
PHASE 50
CLOCK 50
640X480 60Hz
BRIGHTNESS: Adjust the brightness of the picture, the
image becomes brighter as the number increase.
CONTRAST: Adjust the contrast of the picture, the image
becomes higher as the number increase.
COLOUR SETTING: Select between 9300k/6500k/user
define.
AUTO CONFIG: Adjust the H-POSITION,V-POSITION,
PHASE and CLOCK automatically. Adjust the
H-POSITION, V-POSITION, PHASE and CLOCK
automatically.
H-POSITION: Picture horizontal position adjust.
V-POSITION: Picture vertical position adjust.
PHASE: Removes any horizontal distortion and clears
or sharpness the displayed characters.
CLOCK: Adjust the TFT-LCD to match the video input
source.
Name of menu Picture of menu Instructions
PC MENU
VOLUME: Adjust the volume.
BALANCE: Adjust the balance of the audio output from
left to right.
AUDIO PRESET: Four different settings: Personal,
Voice, Music and Theater.
TREBLE: Adjust the treble of the sound, can only be
adjust under Personal mode
BASS: Adjust the bass of the sound, can only be adjust
under Personal mode
AUDIO MENU
VOLUME
BALANCE
AUDIO PRESET PERSONAL
TREBLE
BASS
50
50
50
50
AUDIO MENU
GENERAL MENU
LANGUAGE ENGLISH
BLUE SCREEN ON
NOISE REDUCE ON
INPUT SOURCE PC-RGB
RESET "
LANGUAGE: Change the language of the menu, choose
between ENGLISH and FRENCH.
BLUE SCREEN: Display the blue screen when no signal.
NOISE REDUCE: Reduce the noise of the picture,
provide clearer picture.
INPUT SOURCE: Display the current mode.
ZOOM: To select a display mode between Full and 4:3.
RESET: Resets picture settings to the factory default .
GENERAL
MENU
ZOOM 4:3

11
MENU OPERATIONS
INPUT TV MODE
1. Press LCD-MENU button to either display the “VIDEO” or “TV” or “GENERAL” or “AUDIO” menu.
2. Press KEY ▲ / ▼ to scroll through the parameters.
3. Press ◄ / ► buttons to make changes to the parameters.
4. Press the LCD-MENU button to exit the menu .
Name of menu Picture of menu Instructions
VIDEO MENU
BRIGHTNESS : Adjust the brightness of the picture, the
image becomes brighter as the number increase.
CONTRAST: Adjust the contrast of the picture, the image
becomes higher as the number increase.
COLOR: Adjust the colour.
SHARPNESS: Adjust the amount of detail enhancement,
the image sharpness rises as the number increase.
TV MENU
CHANNEL 10
SYSTEM BG
SKIP ON
AFC ON
FINE TUNE 184.25MHz
DELETE °
SWAP °
MANUAL SEARCH °
AUTO SEARCH °
CHANNEL: Change the TV channel.
SYSTEM: Select the TV standard.
SKIP: If you want skip a channel, you can turn it on and
this channel will be skip in the next time.
AFC: Auto frequence control. Press the button improve
the image quality
FINE TUNE: If the image received is not very good, you
can press p/q to select Fine Tuning item in menu.
Then press t/u button to adjust and improve the
image quality.
DELETE: Delete the current program.
SWAP: SWAP function allows you to arrange the channel
numbers by exchanging between 2 preset channels. In the
sub-menu of SWAP, the following items can be selected:
FROM: To select the channel number that you want to
exchange from by using t/u button.
TO: To select the channel number that you want to
exchange to by using t/u button.
SWAP: Confirm to swap the channels by using t/u
button.
MANUAL SEARCH: Manual search the channel.
AUTO SEARCH: Auto search and save the channel.
TV MENU
VIDEO MENU
BRIGHTNESS 50
CONTRAST 50
COLOR 50
SHARPNESS 50
LANGUAGE: Change the language of the menu, choose
between ENGLISH and FRENCH.
BLUE SCREEN: Display the blue screen when no signal.
NOISE REDUCE: Reduce the noise of the picture,
provide clearer picture.
INPUT SOURCE: Display the current mode.
ZOOM: To select a display mode
RESET: Resets picture settings to the factory default .
between Full and 4:3.
GENERAL
MENU
GENERAL MENU
LANGUAGE ENGLISH
BLUE SCREEN ON
NOISE REDUCE ON
INPUT SOURCE TV
RESET "
ZOOM 4:3
AUDIO MENU
VOLUME
BALANCE
AUDIO PRESET PERSONAL
TREBLE
BASS
50
50
50
50
AUDIO MENU
VOLUME: Adjust the volume.
BALANCE: Adjust the balance of the audio output from
left to right.
AUDIO PRESET: Four different settings: Personal,
Voice, Music and Theater.
TREBLE: Adjust the treble of the sound, can only be
adjust under Personal mode.
BASS: Adjust the bass of the sound, can only be adjust
under Personal mode.

12
MENU OPERATIONS
INPUT AV / SCART / S-VIDEO MODE
1. Press LCD-MENU button to either display the “VIDEO” or “GENERAL” or “AUDIO” menu.
2. Press ▲ / ▼ buttons to scroll through the parameters.
3. Press ◄ / ► buttons to make changes to the parameters.
4. Press the LCD-MENU button to exit the menu .
Name of menu Picture of menu Instructions
VIDEO MENU
VIDEO MENU
BRIGHTNESS 50
CONTRAST 50
COLOR 50
SHARPNESS 50
BRIGHTNESS : Adjust the brightness of the picture, the
image becomes brighter as the number increase.
CONTRAST: Adjust the contrast of the picture, the image
becomes higher as the number increase.
COLOR: Adjust the colour.
SHARPNESS: Adjust the amount of detail enhancement,
the image sharpness rises as the number increase.
VOLUME: Adjust the volume.
BALANCE: Adjust the balance of the audio output from
left to right.
AUDIO PRESET: Four different settings: Personal,
Voice, Music and Theater.
TREBLE: Adjust the treble of the sound, can only be
adjust under Personal mode
BASS: Adjust the bass of the sound, can only be adjust
under Personal mode
AUDIO MENU
VOLUME
BALANCE
AUDIO PRESET PERSONAL
TREBLE
BASS
50
50
50
50
AUDIO MENU
GENERAL MENU
LANGUAGE ENGLISH
BLUE SCREEN ON
NOISE REDUCE ON
INPUT SOURCE AV
RESET "
LANGUAGE: Change the language of the menu, choose
between ENGLISH and FRENCH.
BLUE SCREEN: Display the blue screen when no signal.
NOISE REDUCE: Reduce the noise of the picture,
provide clearer picture.
INPUT SOURCE: Display the current mode.
ZOOM: To select a display mode
RESET: Resets picture settings to the factory default .
between Full and 4:3.
GENERAL
MENU
ZOOM 4:3

TELETEXT FUNCTION (OPTION)
13
Teletext is an optional function, therefore only certain models can receive the teletext broadcast.
Teletext is a free broadcast service by most TV stations which give up-to-the-minute information
on news, weather, television program, share prices and many other topics.
Display Teletext
1. Select a TV station with teletext signal.
2. Press the TEXT button to enter Teletext signal.
3. Press the TEXT button again to return to the normal TV mode.
Page Selection
1. Enter the desired page number (three digit) using the number buttons.
If you press a wrong number during input, you must complete the three digit number and then
re-enter the correct page number.
2. The p/q button can be used to select the preceding or following page.
MIX(optional)
This function enables you to superimpose the Teletext page over the TV program.
1.When a page is displayed, press the MIX button. The TV picture will appear with the TEXT page.
2.Press the MIX button again to return to the normal Text mode.
HOLD
You can press the HOLD button to hold a page, and press this button again to release the page.
INDEX
Press the INDEX button to enter the main index page directly.
You may enter the main index page number directly using the number buttons.
CANCEL
If you want to watch TV, but not cancel the TELETEXT mode completely, press the CANCEL
button. When the last selected page is updated, the page number is shown at the top of the TV
screen. Press the TEXT or CANCEL button to reveal the page.
Enlarging Text
When a page is displayed, you can double the size of the text to make it easier to read.
1. Press the SIZE button to enlarge the top half of the page.
2. Press the SIZE button again to enlarge the bottom half of the page.
3. Press this button once more to return to the normal display.
Reveal mode
You can display concealed teletext information (e.g. Answer to puzzles or riddles etc.) by pressing
this button. Press this button again to remove the information from the display.
SUBPAGE
Some teletext pages may contain several sub-pages which are automatically paged in a certain
cycle by the TV station.
1. You can enter to a certain sub page by pressing the SUBPAGE button directly and select the
page number with the number buttons. Enter the subpage number (e.g. 0003) for the third sub-
page.
2. Press the SUBPAGE button again to exit the sub page mode.
3. Press the TEXT button to return to the normal TV mode.
COLOR buttons (RED, GREEN, YELLOW, CYAN)
Press these buttons to access directly to the corresponding color pages displayed at the lower part
of the Teletext screen.

ABOUT THE DISC
DISC HANDLING
Handling precautions
● Hold the disc by the edges so the surface will not be
soiled with fingerprints. Fingerprints, dirt and
scratches can cause skipping and distortion.
● Do not write on the label side.
● When insert the Disc to the Disc slot, printed side of
the disc must in front of you.
● Do not use record cleaning sprays, benzine, thinner,
static electricity prevention liquids or any other solvent.
● Be careful not to drop or bens the disc.
● Do not install more than 1 disc.
● Store the disc in its case when not in use.
If the surface is soiled
● Wipe gently with a soft, damp(water only) cloth.
● When wiping discs wipe from the center toward the
outer edge.(If you wipe using a circular motion,
circular scratches can occur, which will cause noise.)
If the disc is brought from a cold to a warm environment,
moisture may form on the disc
● Wipe with a soft, dry, lint-free cloth before using the disc.
DVD OPERATION
14
This Product Can Play the following format of DVD Disc.
Disc type Disc Size
(Diameter)
Recorded Time Recorded Content Remarks
Single side:
120mins. Approx.
DVD 12cm
Double side :
240mins. Approx.
DVD format :
Compressed digital Audio and
Video
Super VCD 12cm 45mins. Approx. MPEG 2 Compressed Digital
Audio and Video
Included :
SVCD, CVD
VCD 12cm 74mins. Approx. MPEG 1 Compressed Digital
Audio and Video
Included :
VCD2.0, VCD1.1,
VCD1.0, DVCD
CD 12cm 74mins. Approx. CD-DA : Digital Audio
HD-CD 12cm 74mins. Approx. HD-CD : Digital Audio
MP3 / JPEG 12cm 600mins. Approx. Compressed digital Audio
Note: Also support DVD-R, CD-R, CD-RW playback.
(
'
Disc

1.DVD on
Turn on the LCD TV, switch to the DVD mode for the DVD operation.
2.Insert Disc
Insert the Disc to the Disc slot (printed side of the disc in front of you), the player will load the disc
automatically. There will have an on screen indication “CLOSE” then “READ”. After loading the
disc content, it will switch to play mode automatically. If the disc is already placed inside, the disc
will be read automatically.
Note 1: For some discs, after loading the content of the disc, need to press PLAY or select from the
disc menu to start.
2: Please make sure when inserting the Disc, the printed side of the disc should be facing you.
When inserting the Disc incorrectly, you may damage the DVD mechanism.
3.Play
According to the disc content, the disc menu will display for your selection. When playing the disc,
you may use PAUSE button to toggle between Play and Pause mode. This product also supports
Menu, Title, Sequential and Program playback.
PLAY THE DISC
MENU PLAYBACK
BASIC OPERATING INSTRUCTIONS
15
1.Menu Playback (For DVD, Super VCD and VCD2.0 discs)
<1> Press MENU button
● For DVD discs, the screen will display the DVD Disc Menu (Root Menu)
● For Super VCD & VCD2.0 discs, the screen will display the Super VCD, VCD2.0 Disc Menu
(PBC: [OFF]) (Press the MENU button to display the PBC status.)
● Playback the Super VCD & VCD2.0 discs, the default PBC status is ON.
<2> For DVD discs, use the navigation buttons to select and Play the highlighted contents;
For Super VCD & VCD2.0 discs, use the numeric buttons to play your favorite content directly.
(note: PBC should be OFF.)
<3> Press ENTER or PLAY button to start from the highlighted content.
<4> Return to the Root Menu when playing the disc
● For DVD discs, press MENU to display the Disc Menu.
● For Super VCD & VCD2.0 discs, when PBC is ON, press MENU to display the Disc Menu.
<5> STOP
● Press STOP button once to stop. Press PLAY button to resume from where you stopped.
● Press STOP button Twice to stop. Press PLAY button to start from beginning.
In order to protect the disc, press STOP button then press EJECT button to take the disc out. When
the disc is ejected, hold the disc edge slightly and take it from the eject direction to prevent scratches.
When not using the DVD function (in stand-by mode or using others modes for a long time), please
take out the disc to protect the DVD loader and the disc.

BASIC OPERATING INSTRUCTIONS
Sequential Playback for DVD, Super VCD, VCD, CD, CD-G, HD-CD, MP3/JPEG discs.
For Super VCD & VCD discs, if PBC is “ON” status, press PLAY button will enter the disc menu.
Press MENU button to turn PBC OFF. Press PLAY button to start in sequent.
For Others, while it stopped, press PLAY button to start in sequent.
SEQUENTIAL PLAYBACK
Program Playback for DVD, Super VCD, VCD, CD, CD-G, HD-CD, MP3/JPEG discs.
Using Program playback, you can select max. 16 tracks from the disc to playback in programmed
order.
PROGRAM PLAYBACK
Title Playback For DVD Disc only.
● Press TITLE button , there will have an on screen indication “TITLE”.
● Press the direction or numeric buttons to select your favorite title.
● Then will play from the first chapter of the selected title.
TITLE PLAYBACK
16
OSD for Program playback:
PROG
PLAY CLEAR
T C
1 ─ ─ : ─ ─
2 ─ ─ : ─ ─
3 ─ ─ : ─ ─
4 ─ ─ : ─ ─
T C
5 ─ ─ : ─ ─
6 ─ ─ : ─ ─
7 ─ ─ : ─ ─
8 ─ ─ : ─ ─
T C
9 ─ ─ : ─ ─
10 ─ ─ : ─ ─
11 ─ ─ : ─ ─
12 ─ ─ : ─ ─
T C
13 ─ ─ : ─ ─
14 ─ ─ : ─ ─
15 ─ ─ : ─ ─
16 ─ ─ : ─ ─
PROG
PLAY CLEAR
1 ─ ─ ─ ─
2 ─ ─ ─ ─
3 ─ ─ ─ ─
4 ─ ─ ─ ─
5 ─ ─ ─ ─
6 ─ ─ ─ ─
7 ─ ─ ─ ─
8 ─ ─ ─ ─
9 ─ ─ ─ ─
10 ─ ─ ─ ─
11 ─ ─ ─ ─
12 ─ ─ ─ ─
13 ─ ─ ─ ─
14 ─ ─ ─ ─
15 ─ ─ ─ ─
16 ─ ─ ─ ─
DVD, MP3/JPEG discs Super VCD, VCD, CD, CD-G, D-CD discs
If it is in PBC ON status, using program playback will turn to PBC OFF automatically.
According to the highlight area input the title and chapter number by numeric buttons, press PLAY
button to start; or move to the <PLAY> by navigation buttons, press ENTER button to start.
(Program up to 16 tracks)
While playing the program, you may press PROGRAM button to display the program menu for edit.
To clear the program by moving to <CLEAR> and press ENTER button. Or press STOP button to
end the program. When press PLAY button again, the disc will play by sequent.
While playing the program, there will have an on screen indication “PRG PLAY” and the current title
and chapter number.

BASIC OPERATING INSTRUCTIONS
SIDE VIEW
6
Button NameButton Name DescriptionDescription
DVD slit Insert and exit the disc place.
ItemItem
5
4
3
2
6
Press to stop the play when the DVD is playing .
Switch the DVD purch and play.
To select the anterior chapter or song.
To select the next chapter or song.
To eject the disc.
17
1
2
3
4
5

BASIC OPERATING INSTRUCTIONS
LOCATION OF CONTROLS FOR DVD OPERATION
Note:
The prompt message ‘‘INVALID KEY’’ will appears on the screen when a button is pressed, that is
the operation is prohibited by the player or disc.
18
EJECT
Used to eject DVD or CD.
TITLE
Press to display the DVD title menu. MENU
Press to display the DVD Disc Menu.
STOP
To stop the play.
PLAY/PAUSE
Play or Pause movies and music or
forwards frames.
For select forwarding or backwards
or slow play.
For select the anterior or next
chapter or song.
PROGRAM
Press to enter the Edit window.
PREVIEW
Press to intro or scan 9 picture
display of CD or VCD.
DVD-SETUP
Press to display the DVD OSD
menu.
SLOW
To select slow motion function.
GOTO
Press to activate the on screen
scroll-down menu for edit.
NICAM/AUDIO
To select NICAM / DVD - Audio
channel.
SUBTITLE
Select different subtitle mode.
ANGLE
Select different angle to view.
ZOOM
Enlarge the picture of views.
AB
Repeat play from A to B.
REPEAT
Select repeat mode.
SLEEP

FUNCTIONS OPERATING INSTRUCTIONS
Play (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, MP3/JPEG discs.)
● For DVD disc, press PLAY button from root or title menu; while playing the DVD, you may play
your favorite title directly with title selection by pressing the TITLE button.
● For Super VCD & VCD discs, while playing the disc, you may play your favorite tracks by numeric
buttons. (Note: When using the Program playback or when it is PCB ON status, you can only use
PREV or NEXT buttons to change the track)
● For CD, CD-G & HD-CD discs, while playing the disc, you may play your favorite tracks by
numeric buttons.
● For MP3 / JPEG disc, you may play your favorite tracks by numeric buttons from the content menu.
Note: From track 1-10, use numeric buttons directly; For tracks over 10, press - / -- button first.
(e.g. Track 15, press - / -- then 5)
If input track number is not valid, it will not function.
Previous( )/ Next ( ) (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, MP3/JPEG discs.)
While playing the disc:
● Press PREVIOUS ( ) button to play to the last Title / Chapter / track.
● Press NEXT ( ) button to play to the next Title / Chapter / track.
For super VCD & VCD discs, in PBC OFF status:
● If the current track is the first one, press PREVIOUS ( ) button will stop the playback.
● If the current track is the last one, press NEXT ( ) button will stop the playback.
For DVD discs, the above functions may vary due to different DVD disc's structure.
Forward( ) / Backward( ) (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, MP3/JPEG
discs.)
While playing the disc, you may use forward or backward function.
● There are 4 speeds for forward. Press forward button to toggle between different speeds in
sequent. (FORWARDx2jFORWARDx4j FORWARDx8j FORWARDx20j Play)
1. While in forward, you may press PLAY to resume normal speed.
2. For CD, HD-CD, MP3, forward also have audio output.
For DVD discs, if forward to last title / chapter, it will start from the beginning.
For Super VCD & VCD discs, in PBC ON status, if forward to the last track, it will start from the
beginning.
● There are 4 speeds for backward. Press backward button to toggle between different speeds in
sequent. (BACKWARDx2j BACKWARDx4j BACKWARDx8j BACKWARDx20j Play)
1. While in backward, you may press PLAY to resume normal speed.
2. For CD, HD-CD, MP3, backward also have audio output.
For DVD discs, if backward to first title / chapter, it will start from the beginning.
For Super VCD & VCD discs, in PBC ON status, if backward to the first track, it will start from the
beginning.
Note: During Forward or Backward, the sound will be off.
19
