AWA JTM19T212-TD User manual

JTM19T212-TD

1
Dear Customers,
May we take this opportunity to thank you for purchasing this LCD TV. We strongly recommend
that you read the safety and operation instructions throughly before operating your LCD TV.
FOLLOW ALL INSTRUCTIONS AND WARNINGS on your LCD TV and in this manual.
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 3
PACKAGE CONTENTS 5
CONTROL BUTTONS AND TERMINALS
FRONT PANEL
REAR PANEL
REMOTE CONTROLLER
6
6
7
8
BASIC CONNECTIONS
BATTERY INSTALLATION
10
10
BASIC OPERATION
SWITCHING THE LCD TV ON/OFF
ADJUSTING THE VOLUME
USING MUTE
SELECTING INPUT SOURCE
CHOOSING A TV CHANNEL
11
11
11
11
11
12
USING THE MENUS
CHANNEL SETUP
PICTURE SETUP
SOUND SETUP
TIME SETUP
OPTION SETUP
13
13
14
15
15
16
LOCK SETUP 16
TELETEXT FUNCTION (OPTIONAL) 18

TABLE OF CONTENTS
27
SUPPORTED OPERATING MODES
TROUBLESHOOTING 28
SPECIFICATIONS 30
21
BASIC PLAYBACK
BASIC PLAYBACK 21
STOP PLAYBACK 21
FAST FORWARD AND FAST REVERSE 21
PREVIOUS AND NEXT 21
PAUSE PLAYBACK 21
SIDE VIEW 20
24
SYSTEM SETUP
22
ADVANCED PLAYBACK
23
SPECIAL FUNCTION PLAYBACK
AUDIO CD PLAYBACK 23
JPEG DISC PLAYBACK 23
20
CONTROL BUTTONS
19
ABOUT THE DISC
DISC HANDING 19
DVD OPERATION 19
2

IMPORTANT SAFETY INSTRUCTIONS
Read this Manual
Read this manual throughly before operating the unit.
Keep this manual
Keep this manual for future reference.
Observe all warnings
All warnings on the product and in the manual must be observed closely.
Follow all instructions
All operating instructions in the manual must be followed.
Do not insert liquids or objects
Inserting liquids or objects into the unit could result in fire or an electrical shock. If liquids or objects
should enter the LCD TV, immediately turn off the power switch, disconnect the power plug from the
AC outlet and contact qualified service personnel.
● Do not place the LCD TV near a bathtub, sink or swimming pool, in the bathroom, a wet basement
or similar.
● Do not expose the LCD TV to rain or moisture.
● Do not place flower vases, pots, cups, cosmetics, liquids such as water, etc on or around the LCD TV.
● Do not place metals, combustibles, etc on or around the LCD TV.
● Do not drip or splash liquid of any kind on the LCD TV.
Be particularly careful if there are children present near the unit
● Please ensure that children do not hang on the LCD TV.
Do not subject the LCD TV to any shocks or impact
If the LCD TV should be dropped and/or broken, it could result in an injury, and continued use could
result in fire or electrical shock.
If the glass panel is broken or damaged, immediately turn off the power switch, disconnect the power
plug from the AC power outlet and contact qualified service personnel.
Ensure that the unit is stable
● If the LCD TV is mounted on a wall, please ensure that it is fastened securely.
● Do not place the LCD TV on a bed, sofa, rug or similar surface. Do not place the LCD TV on an un-
stable cart, stand, or table. The LCD TV may fall, causing serious damage to the LCD TV and/or
may seriously injury someone.
● When the product is on a trolley, it should be moved with caution. Avoid quick stops, and moving
the unit across uneven surfaces that may cause the product and trolley to overturn.
This symbol indicates
“dangerous voltage”
inside the product that
presents a risk of electric
shock or personal injury.
This symbol indicates
important instructions
accompanying the
product.
RISK OF ELECTRIC
SHOCK DO NOT
OPEN
CAUTION
TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT
REMOVE COVER.NO
USER-SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
3

Do not block any ventilation openings
● The vents and other openings in the cabinet are designed to let hot air escape from the LCD TV.
Do not cover or block these vents and openings since insufficient ventilation can cause over-
heating. Do not place the LCD TV on a bed, sofa, rug or other similar surface, since this can block
ventilation openings, causing the TV to overheat, which may result in fire.
● Do not cover the LCD TV with cloth, such as curtains, or items such as newspaper, etc.
● This unit is not designed for built-in installation, do not place the product in an enclosed place such
as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are
followed.
Avoid high temperature environments
The heat may adversely affect the LCD TV and other parts, and could result in serious overheating or risk
of fire.
● Do not place the LCD TV, the remote control and other parts in direct sunlight or near a hot object
such as heater, etc.
● Do not place the LCD TV in a place where the temperature varies widely.
Avoid oils
Do not place the TV near a kitchen or a cooking appliance. Dust saturated with oil may enter into the unit
and damage it.
Power cord protection
Incorrect connection of the power cord could result in fire or electrical shock.
● Do not connect too many appliances to the same mains socket as this could result in fire or electrical
shock.
● The apparatus must be connected to a mains socket outlet with a protective earthing connection.
● The socket outlet for connecting mains plug must be easily accessible and remain readily operable.
● Do not overload wall outlet as this can result in fire or electrical shock.
● Check that the connecting portion of the AC power cord is clean (with no dust), before using. Use a
soft and dry cloth to clean the power plug.
● The AC power cord should be routed so that it is not likely to be walked on or pinched by items
placed upon or against it. Also do not put any heavy objects on the AC power cord.
● Do not touch the AC power cord with a wet hand.
● Pull out the AC power cord by the plug. Do not pull on the power cord.
● Insert the power plug into a power outlet firmly. Avoid using a loose, or damaged outlet.
● Do not pinch, bend, or twist the cable excessively. The core lines may be bared or cut, causing a
short-circuit which may induce fire or electrical shock.
● For your own safety, do not touch any part of the unit, power cord or aerial lead during lightning
storms.
● Do not modify the AC power cord.
● Disconnect the power cord if the LCD TV is not used for a long time.
● Switch off and withdraw the power plug before making or changing connections.
Handling and cleaning the screen surface of display unit
To avoid screen degradation, follow the points mentioned below. Do not push on the screen or scratch
it with hard objects, or throw anything at the screen. The screen may be damaged.
● Be sure to unplug the power cord from outlet before cleaning.
● Do not push on the surface of the screen or scratch it with hard objects, as this may damage it.
● We recommend that the screen surface is touched as little as possible.
● To remove dust from the screen surface, wipe gently with a clean, soft and cotton-free dry cloth.
● Do not use any type of abrasive pad, alkaline/acid cleaner or strong solvent such as alcohol, thinner
or benzene etc, as this may damage the surface.
Cleaning the cabinet
● Be sure to unplug the power cord from the outlet before cleaning.
● Clean the cabinet with a soft cloth.
● Note that material deterioration or screen coating degradation may occur if the display unit is ex-
posed to a volatile solvent, such as alcohol, thinner, benzine or insecticide, or if prolonged contact
is maintained with rubber or vinyl materials.
IMPORTANT SAFETY INSTRUCTIONS
4

Carrying and moving
● Be sure to always carry the LCD TV by two people holding it with two hands, one hand on each side
of the LCD TV. If you carry the unit in a manner other than that specified, it may drop and a serious
injury may be caused.
Servicing
Do not open the cabinet or remove the rear cover of the unit. If any of the following conditions occurs,
unplug the AC power cord from the AC outlet, and contact qualified service personnel.
● When the power cord or plug is damaged.
● When the LCD panel is damaged.
● When liquid is spilled on the unit or when objects have fallen into the unit.
● When the unit has been exposed to rain or water.
● If the unit has been dropped or the cabinet has been damaged in any way.
● If the unit does not work properly even after you have referred to the TROUBLESHOOTING section.
Replacement parts
● If the unit needs replacement parts, make sure that the service personnel use replacement
parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. The use of non-compliant parts can result in malfunction, fire, an electrical shock and/
or other accidents.
● Upon completion of service or repair work, request the service technician to perform safety checks
to ensure that the unit is in proper operating condition.
Other notices
● Sometimes, the image may have some tiny red, green, blue, white or black spots. This is normal
and does not affect the performance of the LCD TV.
● The advanced technology of this LCD TV gives you detailed pictures. Occasionally, a few non-
active pixels may appear on the screen as a fixed point of blue, green, or red. Please note that this
does not affect the performance of your LCD TV.
● If the unit is used in a cold place, a smear may occur in the picture or the picture may become dark.
This does not indicate a failure. These phenomena improve as the temperature rises.
● In some cases, residual images may remain after the short-term display of still images is displayed.
These will disappear in a few minutes, and the display will return to normal. However, if the unit is
used in high temperatures, it sometimes takes ten minutes or more to return to normal. Please note
that this is not a malfunction.
● LCD panels are made of finely processed glass, so please avoid pushing the panel with your hands
or subjecting it to a strong impact.
● Do not use immediately after moving from a low temperature to a high temperature environment,
as this causes condensation, which may result in fire, electrical shock or other danger.
IMPORTANT SAFETY INSTRUCTIONS
5
PACKAGE CONTENTS
Your LCD TV package includes:
1. LCD TV Display
2. Remote Control
3. Power Cord
4. RCA Cable (3 Pin)
5. Operation Manual
Note:
Your product may also include various other accessories depending on region of purchase.

CONTROL BUTTONS AND TERMINALS
6
Press to display “Input Source” menu, then press p/qbutton to
select input sources: DVB-T TV, Analogue TV, Composite Video,
S-Video, Component Video, VGA , HDMI and DVD.
CH.vvWhen you are watching the TV program, press this button to
increase channel number.
4
VOL +/- Increase or decrease the volume.
Adjust the values of the selected menu item in the OSD menu.
3
Button NameButton Name DescriptionDescription
ItemItem
Power Indicator
Remote Sensor
Switch on the LCD TV when at standby mode or vice versa.
Illuminates red in standby mode.
Illuminates green when the LCD TV is switched on.
Infrared sensor for the remote control.
7
8
6
INPUT
1
MENU
2Enter or exit from the menu.
9
8877
44
66
112233
AC Input Socket
55
CH.ww
When you are watching the TV program, press this button to
decrease channel number.
In the main-menu, press to select lower menu item.
5
99
STANDBY
Connect the power cable.

CONTROL BUTTONS AND TERMINALS
7
Precautions when connecting to other equipment
1. When using external equipment with this LCD TV/monitor, please read the instruction
manual of the external device.
2. Always ensure that the input and output terminals are correctly connected.
3. Whenever you connect external device to your LCD TV, ensure that all elements
are switched off.
4
3
29
8
7
6
5
Connectors descriptions:
1 :
2 ：75 Ω aerial input, connect antenna connector or aerial interface here to
receive cable / aerial signal.
3 ：Headphone jack, connect to your headphone.
4 ：Audio input for VGA mode, connect to your PC audio output.
5 ：Audio Channel input for Composite video & S-video mode.
6 ：CVBS / Composite video inputs, connect your AV system.
7 ：S-VIDEO input, connect video input from external device here.
8 ：YPbPr Component Video Input Terminals, connect them to the video output terminal of
DVD or other equipment.
9 ：VGA input interface, connect the D-Sub 15 pins analog output connector of the PC.
10 : HDMI connector, connect HDMI signal input.
10
COAX
OUT RF IN LINE
IN
R
(AV)
L
(AV)
VIDEO
IN
S-VIDEO
IN Pr Pb YVGA
IN
HDMI
IN
1
Coaxial Output, connecting to Coaxial input of your Amplifier.

CONTROL BUTTONS AND TERMINALS
All the functions can be controller with the remote controller. Some functions can also be adjusted
with the buttons on the front panel of the set.
1. STANDBY
To switch on the LCD TV/monitor when at standby
mode or vice versa.
2. DISPLAY
To display setup information of channel.
3. NICAM (OPTIONAL)
To switch among NICAM,A2 and mono sound
output.
In DVD mode, press to eject the disc.
4. NUMBER BUTTONS
To directly select program number.
Note: the -/--button is disabled.
5. LCD-MENU
To enter the TV menu, or exit from the TV menu .
6. t/u
To adjust menu settings.
p/q
To select a menu item.
ENTER
Execute a command.
7. VOL-/+ (VOLUME UP/DOWN)
To increase or decrease the volume.
8. PMODE
To select the picture mode.
9. SOURCE
To select a input signal.
10. HOLD/A-B
Teletext hold. Hold or carry on.
In DVD mode, repeat play from A to B.
11. TEXT/AUDIO
Teletext text. TV/Teletext select.
In DVD mode, to select DVD - Audio channel.
12. GREEN button/ZOOM
In DVD mode, enlarge the picture of views.
In DVB mode, summon some DVB functions.
13. RED button/ REPEAT
In DVD mode, Select repeat mode.
In DVB mode, summon some DVB functions.
14. SIZE/
Teletext size selection, Double height rendering.
In DVD mode, press to stop the play.
15. INDEX/
Teletext index button. Go to index.
In DVD mode, press to select the anterior chapter or song.
16. LANG/MENU
In DVB mode, to show the list of audio language available for
the current channel.
In DVD mode, press to display the DVD Disc Menu.
17. TV/RADIO/
In DVB mode, press to select TV or Radio mode.
In DVD mode, press to select backwards play.
18. EPG/PROGRAM
In DVB mode, press to show the Electronic Program Guide menu.
In DVD mode, Press to enter the Edit window.
19. SUBTITLE
In DVB/DVD mode, press to display the caption.
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
8
TEXT/AUDIO HOLD/A-B

CONTROL BUTTONS AND TERMINALS
9
20. MUTE
To switch the sound on or off.
21. ASPECT
To select a display mode between FULL and 4:3.
22. SLEEP
To set the sleep timer.
23. RETURN
To return to previously selected program number.
Note: In DVD mode, this button is disabled.
24.DVB-MENU/DVD-MENU
To enter or exit from the DVD/menu in DVD mode.
25. CH-/+ (PROGRAM UP/DOWN)
To select the program in ascending or descending order.
26. SMODE
To select a sound mode.
27. EXIT
To exit the menu.
Note: In DVD mode, this button is disabled.
28. PIP
This button is disabled.
29. DIGEST
This button is disabled.
30. YELLOW button/ ANGLE
In DVD mode, select different angle to view.
In DVB mode, summon some DVB functions.
31. CYAN button/GOTO
In DVD mode, press to activate the on screen
scroll-down menu for edit.
In DVB mode, summon some DVB functions.
32. REVEAL/
Teletext reveal button. Reveal any hidden text.
In DVD mode, press to play or pause movies and music.
33. SUBPAGE/
Teletext sub page. Come into subpage, and again to cancel.
In DVD mode, For select the next chapter or song.
34. PAGE-/
In DVB mode, press to decrease the program which
you favourite.
In DVD mode, press to select slow play mode.
35. PAGE+/
In DVB mode, press to increase the program which
you favourite.
In DVD mode, press to select forwarding play.
36. FAV/PREVIEW
This is a hot button for displaying the favourite list
defined by your self in DVB mode.
Note: In DVD mode, the PREVIEW function is disabled.
37. INFO/TITLE
In DVB mode, display the information of digital channel
(e.g. channel No., sound mode, signal strength etc.).
In DVD mode, press to display the DVD title menu.
20
21
22
23
25
26
27
29
30
24
37
35
33
31
32
34
36
28
TEXT/AUDIO HOLD/A-B

++
__
__
++
RO3,1.5V X2
UM-4(AA A)
++
++
--
--
Insert the batteries while observing the correct (+) and (-) polarities as illustrated below.
About the batteries
● If the remote control unit fails to work even when it is operated near the LCD TV, please replace
the batteries.
● Use size UM-4 (AAA) batteries.
Note:
● Do not use rechargeable (Ni-Cd) batteries.
● Do not attempt to recharge, short circuit, disassemble, heat or throw the batteries into fire.
● Do not splash the remote control with water or put it on a wet object .
● Do not drop, step on or cause any impact to the remote control unit. This may damage it, resulting
in malfunction.
● Do not mix old and new batteries.
● If the remote control unit is not going to be used for a long time, remove the batteries.
● Strong light such as direct sunlight falling on the remote sensor can cause operational failure.
Avoid placing the remote control in direct sunlight.
Caution
Keep batteries out of children’s reach.
BASIC CONNECTION
10

BASIC OPERATION
Press the VOL+/- or t/u button to increase or decrease the volume.
1. Press the SOURCE button on the remote control or
press INPUT button on the rear panel of the LCD TV
to display the “ Input Source” menu.
2. Press the p/qbutton to select the input signal.
3. Press the t/ubutton to confirm your selection.
At any time, you can temporarily cut off the sound using the MUTE button.
1. Press the MUTE button and the sound cuts off.
2. Press the MUTE button again or press VOL+/- ort/u button to turn mute off.
11
36
EXIT ENTER
Input Source
DTV
TV
AV
S-Video
YPbPr
PC
HDMI
1. Press the POWER button or the STANDBY button to switch the unit on or to standby mode.
2. If the unit is in standby mode, press the POWER button or the STANDBY button to switch
it on.
3. Press the POWER button or the STANDBY button, the unit will revert to standby mode.
Note:
If, while the unit is switched on, the mains plug is disconnected, the unit will switch to standby
when the mains plug is replaced in the mains power socket again.
DVD

BASIC OPERATION
Use the CHp/CHqbutton on the front panel, or the CH+/CH-/p/q button on the
remote control.
Press the CHp or CH+ /pbutton to increase channel number.
Press the CHq or CH-/q button to decrease channel number.
Using 0-9 digital buttons
You can select the channel number directly by pressing 0 to 9 buttons.
Example:
To select 1-digit channel (e.g. Channel 5):
● Press the 5 button.
To select 2-digit channel (e.g. Channel 20):
● Press the 2 button, follow by 0.
12

USING THE MENUS
13
CHANNEL SETUP
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the CHANNEL menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
Auto Tuning:
This option allows you to tuning the TV and DTV channels stations that can be received automatically.
DTV Manual Tuning:
This option allows you to tuning the DTV channels stations that can be received by manual.
ATV Manual Tuning:
This option allows you to tuning the TV channels stations that can be received by manual.
Programme Edit:
This function allows you to delete, rename, move, skip and FAV for a selected channel.
Deleting Channel
1. In Program Edit, move the p/q button to select a channel which you want to delete.
2. Press the RED button twice to perform the deletion function.
Rename Channel
1. Press the p/q button to select a channel which you want to rename.
2. Press GREEN button to perform the rename function.
3. Press the p/q button to select the character.
4. Press the t/ubutton to move the cursor position.
Move Channel
1. In Program Edit, move the p/q button to select a channel which you want to moved.
2. Press the YELLOW button to summon the move function.
3. Press the p/q button to select a channel you want to move to.
4. Press the YELLOW button to perform the move function.
Skip Channel
1. Press the p/q button to select a channel which you want to skipped.
2. Press the CYAN button to perform the skip function.
Set FAV Channel
1. Press the p/q button to select a channel which you favorite.
2. Press the FAV button to perform the favorite function.
EXIT MENU ENTER
CHANNEL
Auto Tuning
DTV Manual Tuning
ATV Manual Tuning
Programme Edit

USING THE MENUS
14
Color Temperature:
Select a optimum color temperature level(Cool/
Medium/Warm) or Customize by selecting User.
The level of Red, Green and Blue are can be
adjusted separately in user mode.
Aspect Ratio:
Select a display mode.
Noise Reduction:
If the broadcast signal received is weak, you can select
this function to reduce the video noise if the option set
the “On”.
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the PICTURE menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
Picture Mode:
Select a desired picture mode among Dynamic, Standard,Mild and User.Dynamic, Standard and
Mild are the factory preset picture mode and the parameter of those modes can not be changed. If
you want to adjust any items (e.g. Contrast, Brightness ,Clour and sharpness etc), please select
User, and the settings will be stored in User mode.
CYou may select the picture mode directly by pressing the PMODE button on the remote control.
Contrast:
Adjust the color brightness of the image.
Brightness:
Adjust the darkness and lightness of the image.
Color:
Adjust the saturation level of color.
Sharpness:
Adjust the sharpness level of image.
Tint:
Adjust the tone of color when your system is in NTSC.
PICTURE SETUP
EXIT MENU ENTER
Colour Temperature
Noise Reduction
User
Red
Green
Blue
Aspect Ratio
........... 50
........... 50
........... 50
16:9
On
EXIT MENU ENTER
Picture Mode
Contrast
Brightness
Color
Sharpness
Tint
Standard
50
50
50
50
0

USING THE MENUS
15
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the TIME menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
Clock:
Set the current time.
Off Time:
Set the TV to standby after the set time has elapsed.
On Time:
Set the TV from standby to on automatically after the set time has elapsed.
Sleep Timer:
Automatically switches the unit to standby after the preset time to elapsed.
Note: You may select the sleep time directly by pressing the SLEEP button repeatedly on the
remote control.
Auto Sleep:
If there is no signal input from VGA /HDMI mode for 1 minute, or no signal input from other video source
for 15 minutes, the LCD TV will switch to standby automatically when the Auto Sleep set the “On”.
Time Zone:
Press t/u button to select a time zone where you are.
TIME SETUP
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the SOUND menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
Sound Mode:
Press t/u button to select a sound mode among Standard, Music, Movie Sports and User.
Treble:
Adjusts the level of higher-pitched sounds.
Bass:
Adjusts the level of lower-pitched sounds.
Balance:
Adjusts the sound balance in left and right speakers.
Auto Volume:
If set “On”, it will adjust volume level automatically.
Surround Sound:
Creates a panoramic stereo audio image by producing deep and rich bass tones and clear treble
tones. This enables you to enjoy powerful sound effects like those in a movie theatre when it is
“Surround”.
SOUND SETUP
EXIT MENU ENTER
TIME
Clock
Off Time
On Time
Sleep Timer
Auto Sleep
Time Zone
Off
Off
Off
Off
EXIT MENU ENTER
SOUND
Sound Mode
Treble
Bass
Balance
Auto Volume
Surround Sound
Standard
Off
Off
........... 50
........... 50
........... 50
Victoria GMT+10

16
USING THE MENUS
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the LOCK menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
LOCK SETUP
1. Press the MENU button on the remote
controller to display the OSD main menu.
2. Press t/u button to select the OPTION menu.
3. Press p/q button to select each item.
4. Press the MENU or EXIT button to exit from the menu.
Language:
Selects your desired language for the OSD menu.
Note: If your unit does not support multi-language, this
item may not be selected by pressingt/u button.
Audio Language (for DTV):
Selects your desired language for the audio.
Note: If your unit does not support multi-language, this item may not be selected by pressing
t/u button.
Subtitle Language (for DTV):
Selects your desired language for the subtitle.
Note: If your unit does not support multi-language, this item may not be selected by pressing
t/u button.
Hearing Impaired (for DTV):
For Hearing Impaired people. The program can be displayed with recorded explanatory captions.
Note: This is valid for the program that has captions.
Country:
This function is disabled in this unit.
Restore Factory Default:
This function allows you to replace the settings with the factory default values.
EXIT MENU
OPTION SETUP
EXIT MENU
ENTER
ENTER
Language
Audio Language
Subtitle Language
Hearing Impaired
Restore Factory Default
English
Off
English
English
OPTION
Lock System
Set Password
Block Program
Parental Guidance
Off
No Block
LOCK
Country Australia

17
USING THE MENUS
Lock System:
Press t/u button to select On or Off.
Note: If the Lock System set the “On”, you will be prompted to input the password when you edit the
program and auto tuning (The factory initial password is “0000”)
Set Password:
It allows you to change the LOCK menu access password.
Block Program:
It allows you to block some program.
Parental Guidance ( for DTV mode only):
Press t/u button to select the different block rating or select no block item to ignore this function.
Please enter password
New
Confirm - - - -
- - - -
1. Enter a new 4-digital number as a code using 0-9.
2. Enter the same 4-digital number to confirm.
EXIT MENULOCK
Block Program
TV 31 S-26
TV 32 S-27
TV 33 S-28
TV 34 X-30
TV 35 S-31
TV 36 S-32
TV 37 S-35
TV 38 S-38
1. Press the p/q button to select a channel which you want to block.
2. Press the GREEN button to perform the block function.
ENTER

Teletext is an optional function, therefore only certain models can receive the teletext broadcast.
Teletext is a free service broadcast by most TV stations which gives up-to-the-minute information
on news, weather, television programs, share prices and many other topics.
Display Teletext
1. Select a TV station with teletext signal.
2. Press the TEXT button to enter Teletext signal.
3. Press the TEXT button again to display the TV picture with the Text page.
4. Press the TEXT button to again to display the teletext page superimposed over the TV image.
5. When the mix page is display, press the TEXT button to return to the normal Teletext mode.
6. When the Teletext page is displayed, press the TEXT button to return to the normal TV mode.
Page Selection
1. Enter the page number (three digit) using the number buttons.
If you press the wrong number during input, you must complete the three digit number and then
re-enter the correct page number.
2. The PAGE+/PAGE- button can be used to select the preceding or following page.
HOLD
You can press the HOLD button to hold a page, and press this button again to release the page.
INDEX
Press the INDEX button to enter the main index page directly.
You may enter the main index page number directly using the number buttons.
Enlarging Text
When a page is displayed, you can double the size of the text to make it easier to read.
1. Press the SIZE button to enlarge the top half of the page.
2. Press the SIZE button again to enlarge the bottom half of the page.
3. Press this button once more to return to the normal display.
Reveal mode
You can display concealed teletext information (e.g. Answer to puzzles or riddles etc.) by pressing
this button. Press this button again to remove the information from the display.
SUBPAGE
Some teletext pages may contain several sub-pages which are automatically set in a certain order
by the TV station.
1. You can enter to a certain sub page by pressing the SUBPAGE button directly and select the
page number with the number buttons. Enter the subpage number (e.g. 0003) for the third sub-
page.
2. Press the SUBPAGE button again to exit the sub page mode.
3. Press the TEXT button to return to the normal TV mode.
COLOR buttons (RED, GREEN, YELLOW, CYAN)
Press these buttons to access directly to the corresponding color pages displayed at the lower
part of the Teletext screen.
TELETEXT FUNCTION (OPTIONAL)
18

ABOUT THE DISC
DISC HANDLING
Handling precautions
● Hold the disc by the edges so the surface will not be
soiled with fingerprints. Fingerprints, dirt and
scratches can cause skipping and distortion.
● Do not write on the label side.
● When insert the Disc to the Disc slot, printed side of
the disc must in front of you.
● Do not use record cleaning sprays, benzine, thinner,
static electricity prevention liquids or any other solvent.
● Be careful not to drop or bens the disc.
● Do not install more than 1 disc.
● Store the disc in its case when not in use.
If the surface is soiled
● Wipe gently with a soft, damp(water only) cloth.
● When wiping discs wipe from the center toward the
outer edge.(If you wipe using a circular motion,
circular scratches can occur, which will cause noise.)
If the disc is brought from a cold to a warm environment,
moisture may form on the disc
● Wipe with a soft, dry, lint-free cloth before using the disc.
DVD OPERATION
19
Playback side
This produce can play the following format of DVD Disc.
Note: Also support DVD-R, DVD-RW, CD-R, CD-RW playback.
Disc Type Disc Size
(Diameter)
Recorded Time Recorded Content Remarks
DVD
Super VCD
VCD
CD
HD-CD 12cm
12cm
12cm
12cm
12cm
45mins. Approx.
74mins. Approx.
74mins. Approx.
74mins. Approx.
Double side:
240mins. Approx.
Single side:
120mins. Approx.
HD-CD : Digital Audio
CD-DA : Digital Audio
MPEG 1 Compressed
Digital Audio and Video
MPEG 2 Compressed
Digital Audio and Video
DVD format:
Compressed digital
Audio and Video
Included:
SVCD, CVD
Included:
VCD2.0, CVD1.1,
VCD1.0, DVCD
