AWA MSDV3203-F4 User manual

USER MANUAL
Please read this User Manual carefully to ensure use of this product and keep this
manual for future reference
MSDV3203-F4
32"(81cm)HD READY LCD Television
N294

SAFETY INSTRUCTIONS.................................................................................................2
INSTALLATION......................................................................... ......................................3
REMOTE CONTROL................................................................ ........................................8
OPERATION..................................................................................................................... 9
TROUBLESHOOTINGS....................................................................................................14
TECHNICAL SPECIFICATION.........................................................................................15
WALL MOUNTING INSTALLATION GUIDLINES.............................................................3
ACCESSORIES.................................................................................................................4
FRONT PANEL.................................................................................................................4
KEY BOARD(RIGHT SIDE)..............................................................................................4
REAR PANEL...................................................................................................................4
ANTENNA CONNECTION................................................................................................5
CONNECTING TO PC.......................................................................................................5
PC PRESET.......................................................................................................................6
CONNECTING TO AV EQUIPMENT..................................................................................7
BATTERY INSTALLATION...............................................................................................8
KEYS FUNCTION.............................................................................................................8
BASIC OPERATION..........................................................................................................9
TELETEXT.......................................................................................................................9
EPG..................................................................................................................................11
MENU OPERATION..........................................................................................................11
CONTENTS
-1-

SAFETY INSTRUCTIONS
-2-
1.Read these safety instructions.
2.Keep these safety instructions.
3.Heed all warnings.
4.Follow all safety instructions.
5.Do not use this apparatus near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings. Install in
accordance with the manufacturers instructions.
8.Do not install near any heat sources such as radiators ,
stoves, or other apparatus (including
9.Protect the power cord from being walked on or
pinched particularly at power outlets, and the point
where they exit from the apparatus.
10.Only use attachments/accessories specified by the
manufacturer.
11.Unplug this apparatus during lightning storms or
when unused for long periods of time.
12.Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as the power-supply cord
or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture , does not operate n
13.Apparatus must not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, should
amplifiers)that
produce heat.
ormally,
or has been dropped.
be placed on the apparatus.
IMPORTANT SAFETY INSTRUCTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN!
CAUTION
CAUTION
The symbol indicates that dangerous voltages
constituting a risk of electric shock are present
within this unit.
The symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
To prevent fire or shock hazard, do not expose this
appliance to rain or moisture.
WARNING:
Thank you very much for purchasing this TV. To enjoy
your product from the very beginning, read this manual
carefully and keep it handy for easy reference.
INSTALLATION
CAUTION
Locate the TV in the room where light does not strike
the screen .
Total darkness or a reflection on the picture screen can
cause eyestrain. Soft and indirect lighting is recommended
for comfortable viewing.
Allow enough space between the TV and the wall to
permit ventilation.
Avoid extremely warm locations to prevent possible
damage to the cabinet or premature component failure.
This TV can be connected to AC 100-240 Volts. 50/60 Hz.
Never connect to a DC supply or any other power supply.
Do not cover the ventilation openings when using the TV.
directly
Never tamper with any components inside the TV, or any
other adjustment controls not mentioned in this manual.
All LCD-TVs are high voltage instruments. When you
clean up dust or water drops on the LCD PANEL or
CABINET, the power cord should be pulled out from the
receptacle, then wipe the TV with a dry soft cloth. During
thunder and lighting, unplug the power cord and antenna
cord to prevent damage to your TV. All repairs to this TV
should only be performed by qualified TV service personnel.
Warning: Change or modifications to this unit not expressly
by the part responsible for compliance could void the user 's
authority to operate the Equipment.
a. Do not expose to dripping or splashing.
b. No objects filled with liquids, such as vases, shall be
placed on the apparatus.
c. The mains plug of this device is used as the disconnect
device and shall remain readily accessible and operable.
d. No naked flame sources, such as lighted candles, should
be placed on the apparatus.
e. Allow suitable distances around the apparatus for sufficient
ventilation. Ventilation should not be impeded by covering
ventilation openings with items such as newspapers, table
cloths, curtains and such like.
This symbol indicates that this productincorporates
double insulation between hazardous mains voltage
and user accessible parts. When servicing use only
identical replacement parts.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or cords.

INSTALLATION
-3-
High voltages are used in the operation of this television
receiver. Do not remove the cabinet back from your set.
Refer servicing to qualified service personnel.
To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of
electrical components.
Do not trap the power supply cord under the television
receiver.
Never stand on, lean on, or suddenly push the television or
its stand. You should pay special attention to children.
Serious injury may result if it falls.
Do not place your television on an unstable cart, stand,
shelf or table. Serious injury to an individual , and damage
to the television, may result if it falls.
When the television receiver is not used for an
extended period of time, it is advisable to disconnect
the AC power cord from the AC outlet.
Avoid exposing the television receiver to direct sunlight
and other sources of heat. Do not stand the television
receiver directly on other products which give off heat,
e.g. video cassette players and audio amplifiers. Do not
place naked flame sources, such as lighted candles on
the television.
Dim:515*320mm(
If the television is to be built into a compartment or similar
enclosure, the minimum distances must be maintained. Heat
build-up can reduce the service life of your television, and
can also be dangerous.

INSTALLATION
-4-
Front panel
1 2 3
4 5 6
7 8 9 0
+
CH
_
+
_
VOL
1: Remote control sensor.
2: Indicator LED: GREEN POWER ON.
RED STANDBY.
3: Key board
4: Power: Press this button to turn the unit
ON from STANDBY mode.
Press it again to turn the set back to
STANDBY.
5: AC power switch.
SOURCE
MENU
CH+
CH-
VOL+
VOL-
KEYBOARD
1 SOURCE
Display the input source menu.
CH+ or CH- to select
items .
press CH+ or CH- to
press VOL+ or VOL- to
2MENU
D
3 CH+/CH-
4 VOL+/VOL-
isplay main MENU.
In TV mode press CH+ or CH- to change
the channel up and down.
In MENU mode, press
In standby mode, turn
on the TV.
Adjust sound level.
In MENU mode,
adjust the item that you selected.
REAR AV Connection
30 30
3
5
2
1
NOTE:
1.AV1 and S-VIDEO1 share one audio channel.
2.When HDMI1 port get DVI signal, the PC Audio channel will change to
receive the audio from HDMI1 port
3.When HDMI2 port get DVI signal, the YPbPr Audio channel will change to
receive the audio from HDMI2 port.
4.AV OUTPUT
It works only at input sources: TV,DTV,S-Video1,S-Video2,AV1,AV2.
1. ANT
2. AUDIO OUTPUT
3. OUTPUT
4. VIDEO OUTPUT
5. AV1/S-VIDEO1 AUDIO INPUT
SPDIF
11. VGA INPUT
12. HDMI2 INPUT
13. HDMI1 INPUT
14. AC POWER INPUT
12 45678 9
10 11 12 13
3
6. YPbPr AUDIO INPUT
7. PC AUDIO INPUT
8. YPbPr INPUT
9. AV1 INPUT
10. S-VIDEO1 INPUT
14
4

INSTALLATION
-5-
ANTENNA CONNECTION
Note:
Aerial connections:IEC(female).
Input impendance:75 unbalanced.

INSTALLATION
-6-
STEPS:
CONNECTING TO PC
Be sure both the TV and computer are set to Power off.
1.Connect VGA and audio cable.
2.Connect the power cord.
3.Power on the TV, switch the input source to VGA mode.
4.Power on the PC.
This sequence is very important.
8
PC Audio
Power cord
VGA cable
21

INSTALLATION
-7-
CONNECTING TO AV EQUIPMENTS
This TV provides two groups of AV ,two S-Video,one group of YPbPr for convenient connection
to VCR,DVD or other video equipment,three group of HDMI for HD signal input Please refer to
the owner s manual of the equipment to be connected as well.
You can use the input terminals on TV set rear as follows.
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder, video game
or stereo system, etc.....
YPbPr can support these video fomats:480i,576i,480p,576p,720p,1080i,1080p.
NOTE:
AV2 and S-VIDEO2 share the audio input channel.
To au dio
outputs
VIDEO EQUIPMENT
VIDEO EQUIPMENT with YPbPr
To audio Input
with S-video
Terminal
With VIDEO Input Terminal
TO VIDEO
Iutput
Black (s-video)
White(audol L)
Red(audio R)
Y
W
R
Y
W R
R
W
W R
output
To s-video
G
B
R
GBR
Pr
Y
Pb
R
G
B
HDMI
Y
From Coaxial SPDIF
output
VIDEO RECORDER
Y
To audio
Output
With VIDEO
terminal
VIDEO EQUIPMENT
R
W
Y
output
To video
W R
21
W R
W R Y
WR
with SPDIF Input
term inal
Y
HEADPHONE
S-VIDEO2
VIDEO
L
R
HDMI3
AV2
HDMI
When HDMI3 port get DVI signal, the AV2 Audio channel will change to receive the audio
from HDMI3 port

REMOTE CONTROL
KEYS FUNCTION 1: :To set the TV to standby or
power on.
2: :
3: :To display TV menu.
4: :To move within the menu.
5: :To display the channels list.
6: :To adjust sound level.
7: :To switch picture mode.
8: :S
9: : To freeze the picture.
10: :T
11: :T
12: : See page 14.
13: :To disable or enable the sound
output.
14: :To select the available audio
language of TV programs
15: : To access the previously
viewed channel.
16: : To select input source.
17: :To confirm selection.
18: :
19: :To switch sound mode.
20: :To access the next or
previous channels.
21: : To change picture aspect
ratio.
22: :In DTV mode, it is u
23: :To enter or exit TELETEXT.
24: :T
25: :T
POWER
NUMERIC KEY
TV MENU
CURSOR
CH.LIST
VOL+/-
PIC
SLEEP
FREEZE
EPG
FAV
TELETEXT KEYS
MUTE
AUDIO
RECALL
SOURCE
OK
EXIT
SOUND
CH+/CH-
ASPECT
TV/RADIO
TEXT
INFO
SUBTITLE
For direct access to
channels.
ettimertoturnofftheTV.
o display information about the
program being viewed and what's on
Next inDTV mode.
o access your favourite
channels list
in TV or DTV mode.
sed to
switch between digital TV channels
and radio stations.
o display information about the
channel being viewed or further
information about the program when
in small EPG screen in DTV mode.
o switch betweend
ifferent subtitles in DTV mode.
or select
sound
channel.
To exit the menu.
1
OK
2 3
4 5 6
7 8 9 0
+
CH
_
+
_
VOL
POWER MUTE
AUDIO
RECALL
TV MENU SOURCE
CH.LIST SOUND EXIT
PIC
SLEEP ASPECT
TEXTTV/RADIOFREEZE
EPG FAV INFO
REVEAL HOLD LIST INDEX
SUBPAGE SIZE MIX SUBTITLE
25
14
15
20
18
16
13
17
19
21
23
24
22
8
2
3
4
5
7
12
1
6
9
10
11
-8-
Insert Batteries Into the Remote Control
123
Remark:
1. Remove the battery cover.
2. Inserting the 2 AAA 1.5V batteries making sure the
polarity (+ or -) of the batteries matches the polarity
marks inside the unit.
3. Mount the battery cover.
Replace with new batteries when the TV set begins
to show the following symptoms:
Operation is unsteady or erratic. Sometimes the TV
set does not function with Remote Control Unit.
1) Alkaline Battery Recommended.
2) Remove batteries when they are exhausted or if the
remote control is not to be used for long time.

OPERATION
BASIC OPERATION
TURN ON THE UINT
CHANNEL SEARCH
WATCH TV PROGRAM
CHANGE VOLUME
PIC
CHANGE SOUND MODE
SOUND
VIEW CHANNEL INFORMATION
MUTE
MUTE
CHANGE INPUT SOURCE
SOURCE
Press the POWER button on the remote control to switch on the power. The power indicator will light up in
green colour, press the POWER button again to switch off the power, and the indicator will change to red.
Press the SOURCE button on the remote control to select the TV or DTV input mode, and press the OK button
to confirm.If you are using the unit for the first time, an Installation Guide menu will be displayed to guide you
through
Press the CH- or CH+ button to select the previous or next channels or press the 0-9 buttons to enter a channel
number directly.Press CH.LIST button to view the channels list and press the buttons to select the desired
TV programmes.
Press the VOL - or VOL + button to adjust the volume level. Press the VOL - button repeatedly to decrease the
volume; press the VOL + button repeatedly to increase the volume from 0 to 100.
Press the button repeatedly to cycle through the available video picture modes.
Press the button repeatedly to cycle through the available sound modes.
Press the INFO button to display the preset channel information.
Press the button to cut off the sound output, press this button again to resume sound output.
Press the button then press the buttons to select the input source and press the OK button to
confirm.
the channel scan,Use the remote control to finish channel scan (you can also refer to CHANNEL MENU
(page 11) in this manual for the channel scan operation).
CHANGE PICTURE MODE
-9-
EXIT MENU
OK
NEW INSTALLATION
Menu Language English
Auto Tuning

OPERATION
TEXT
SELECTING A PAGE
DIRECT ACCESS
TO THE ITEMS
INDEX
SUB PAGE
HOLD
REVEAL
Press:You Will obtain:
TELETEXT
Enter the number of the page required using the 0 to 9 up/down. Example: page
120, enter 120. The number is displayed top left, the counter turns and then the
page is displayed. Repeat this operation to view another page. If the counter
continues to search, this means that the page is not transmitted. Select another
number.
Coloured icons are displayed at the bottom of the screen. The 4 coloured buttons
on the remote control are used to access the items or corresponding pages. The
coloured icons flash when the item or the page is not yet available.
This returns to the contents page (usually page 100).
Certain pages contain subpages which are automatically displayed successively.
This key is used to stop or resume sub-page acquisition. The indication appears
top left.
To freeze the page.
To display or hide the concealed information (games solutions).
This is used to enter or exit teletext mode. The summary appears with a list of
items that can be accessed. Each item has a corresponding 3 digit page number.
If the channel selected does not broadcast teletext, the indication 100 will be
displayed and the screen will remain blank (in this case, exit teletext and select
another channel).
Teletext is an information system broadcast by certain channels which can be consulted like a newspaper.
It also offers access to subtitles for viewers with hearing problems or who are not familiar with the
transmission language (cable networks, satellite channels, etc.)
SIZE
To zoom the page.
LIST
To save and display your favourite pages.
-10-
MIX
To mix teletext with video pictures.

OPERATION
EPG (Electronic Programme Guide)
DTV
800 France 2
802 France 5
803 ARTE
804 LCP
805 France 3
801 France 4
PROGRAMME GUIDE DTV 801 France 4
1555.1625 Last Exit
20 Feb 2006 16:07
20 Feb
16:00 17:00
Information
Last Exit
Programme 2
Programme 3
Programme 4
Programme 5
EXIT Reminder
OK
INFO
Movie 1
DATE
Schedule
The EPG (Electronic Programme Guide) menu is
used to look at what is being broadcast on a DTV
or Radio channel at a later point in time.
he detailed
programme information of the channel currently
being viewed will be displayed.
Press the
EPG button to access the EPG menu, t
To see what is going to be broadcast after the
current programme, press the button to view
future programmes and press the button to
return towards the programmes televised at the
current time. To view a different channel, press
the or button. To book a wanted programme
for later watching, press the blue button to enter
Reminder menu. Press the green button to enter
the schedule list.
To exit the EPG menu and watch the selected
channel, press the or button.EPG EXIT
-11-
MENU OPERATION
EXIT MENU
OK
CHANNEL
Auto Tuning
DTV Manual Tuning
ATV Manual Tuning
Programme Edit
1.CHANNEL MENU
The first item of the menu is CHANNEL menu( for
TV source only).
You can search channels and edit programs here.
1).Auto Tuning: Search all the channels automatically
(ATV, DTV & Radio)
Press the buttons to select country then
press the buttons to select start or cancel.
Press the OK button to start or exit auto tuning .
NOTE: All the channels including ATV, DTV and
Radio can be tuned at the one time .
Please select country first
then select Start to update info
Country selection
Start Cancel
Australia
2).DTV Manual Tuning: You can select a DTV
channel then find the program in this channel
Pls press the buttons to select the channel , then
press the OK button to search the programs .
NOTE: Bad Normal Good refers to the signal intensity.
DTV Manual Tuning
UHF CH 30
Please select channel then
pressOKtosearch
Bad Nomal Good
EXIT MENU
OK
3). ATV Manual Tuning :You can change the
sound system to search the analog TV channels
and fine tune the channels, then store the channels
you selected.
ATV Manual Tuning
Storage To
EXIT SAVE
System BG
Current CH 1
Search
Fine-Tune
Skip Yes
Frequency 255.25MHz

EXIT MENU
OK
PC Setup
(3)
Press the red button to store the channel after
manual tuning .
4). Programme Edit: You can edit programs in
the following items.
Delete
Press the red button, it will shows a red delete
cursor.
Press the buttons to choose the program.
Press the red button again, the program will be
deleted.
Rename
You can only rename ATV programs.
Move the cursor to the program, press the green
button to rename the program.
Press the TV MENU button to exit edit , Press
the EXIT button to exit the menu.
Move
Move the cursor to the program, press the yellow
button, it will show a yellow cursor, Press the
buttons to move the program.
Skip
Press the buttons to choose the program,
then press the blue button to skip this program,
the icon will show on the right side of the
program.
Choose the skipped program and press the blue
button again to cancel skip, the icon will
disappear.
FAV
Press the buttons to choose the program,
press the FAV button, it will show on the right
side of the program.Choose the FAV program
and press the FAV button again to cancel FAV,
the icon will disappear .
SKIP
SKIP
OPERATION
Once your favourite group is created,you can
press the FAV button to quickly access your
favourite channel list.
Storage To:
System:
Current CH:
Search:
Fine-Tune:
Skip:
To select the channel number you want
to save to.
To select the TV sound system.
To select the current channel.
To search backward/forward.
To fine tuning when the signal level of
current channel is weak.
When it set to Yes, the current channel will
be skipped while you are changing channels by
pressing the CH+ or CH- buttons.
-12-
The second item of the menu is PICTURE menu.
You can adjust picture effect here, including contrast,
brightness and colour as well as other picture functions.
Press the buttons to select items and press the
buttons to adjust.
2. PICTURE MENU
EXIT MENU
OK
Picture Mode Dynamic
Contrast
Brightness
Colour
Sharpness
Tint
70
70
70
70
0
(1)
EXIT MENU
OK
Colour Temp Normal
Red
Green
Blue
Aspect Ratio 16:9
Noise Reduction ON
70
70
70
(2)
EXIT MENU
OK
Auto Adjust
H-Position
V-Position
Clock
Phase
70
70
70
70
(4)
NOTE:
1).Tint is available in NTSC system only.
2).PC Setup is available in VGA mode only.

OPERATION
-13-
3.SOUND MENU
The third item of the menu is the SOUND menu.
You can adjust the sound effect here, including
treble, bass and balance as well as other sound
functions.
Press the buttons to select and press the
buttons to adjust.
EXIT MENU
OK
SOUND
Sound Mode Standard
Treble
Bass
Balance
Surround Sound Off
50
50
0
4.TIME MENU
The forth item of the menu is the TIME menu.
You can adjust the clock, power on/off time, sleep
timer and time zone as well as other time clock
functions.
Press the buttons to select and press the
buttons to adjust.
EXIT MENU
OK
TIME
Clock
Off Time Off
On Time Off
Sleep Timer Off
Auto Sleep Off
Time Zone New South Wales GMT +10
NOTE:
When the Auto Sleep is set to ON, the unit will turn
to standby mode automatically if there is no signal
input for a period of about 15 minutes.
5.DEFAULT MENU
The fifth item of the MENU is the DEFAULT menu.
EXIT MENU
OK
DEFAULT
Menu Language English
Audio Language English
Subtitle Language English
Hearing impaired Off
Country Australia
Note:
1). Menu Language, Audio Language, Subtitle
Language are optional.
Time Zone:
Press the buttons to adjust the Time Zone.
6.LOCK MENU
ThesixthitemofthemenuistheLOCKmenu.
You can lock system, set password, block program,
set parental guidance, restore factory default and set
maximum volume control.
To enter the LOCK menu, password will be requested,
the default password is 6666.
The master password is 9527 and may be entered if
the user set password is lost or forgotten (in order to
program a new password). Please note this master
over-ride password does not change and therefore
should not be given to people you do not wish to allow
access to your locked settings.
1. The super password cannot be erased, it will always
remain operational
2. If you forget the password, enter the super password.
And then modify your password, enter the new password
twice to confirm that success.
Press the buttons to turn ON or OFF. If it is set to
ON, you will be asked to enter password when searching
the channels .
Press the or OK button and enter the new password.
Press the or OK button to enter the program list.
Press the buttons to select the channel you want
to lock then press the green button to lock, the lock
icon will appear behind the locked channel. To unlock
the channel, select the locked channel and press the
green button again,the lock icon will disappear.
Press the buttons to set the program rating to
block some programs.
Note:
1). Parental Guidance is optional.
Press the or OK button to restore, this operation
will reset the unit to factory default and all the
settings and stored channels will be cleared.
Press the buttons to set the maximum volume.
Note:
1). Max Volume is optional.
LOCK System:
Change Password:
Block Programme:
Parental Guidance:
Restore Factory Default:
Max Volume:
EXIT MENU
OK
LOCK
Lock System Off
Change Password
Block Programme
Parental Guidance Off
Restore Factory Default
Max Volume 100

Picture Audio
Snow Noise
antenna position, direction
or connection
Check
Interference Noise electronic equipment,car/
motorcycle,fluorescent light
Normal Picture Mute
Volume(check if mute is
activated or if the audio system
connections are not correct)
No picture Mute
Power cord is not inserted
Power switch is not opened
Contrast and brightness/volume
setup
Press standby key on the remote
control for inspecting
No colour Normal audio Colour control
breaking up
Normal audio
or weak
Retune channel
No colour Noise TV system
Normal audio
antenna position, direction
or connection
Problem
Ghost
-14-
TROUBLESHOOTING

TECHNICAL SPECIFICATIONS
-15-
Viewing Picture Size(diagonal)
Resolution
Aspect Ratio
Digital TV: DVB-T
Analog TV: PAL/SECAM
Input P
Power consumption
Audio O
31.5 (80cm)
1366x768
16:9
Analog RGB(VGA) Input
Rear HDMI Input
Rear Composite Video Input
Rear Audio Input
Rear S-Video Input
Side Composite Video Input
Side S-Video Input
Side HEAD PHONE Output
Rear Composite Video Output
Analog Audio Output
Side HDMI Input
1
2
1
1
1
3
Coaxial SPDIF Output
1
1
1
1
1
1
1
LCD :
Display colours
Brightness
Contrast ratio
Response time
Viewing angle
16.7M
500 CD/M
1500:1
6.5 ms
176(H)/176(V)
TV:
DVB-T decode
DVB-T de-modulation
Audio: MPEG2 Audio Layer I&II
Video: MPEG2 Transport MP@HL
Demodulator : COFDM
OFDM Mod.: 2K, 8K FFT, SFN and MFN
Packed Carries: 2K/8K
Guard Interval: 1/4, 1/8, 1/16, 1/32
Terminals:
ower Voltage
utput Power THD 7%
100V-240V~ 50/60Hz
170W
2x8W
Others:
TV system
)
Y Cb(Pb) Cr(Pr) Input
2
