Awoco FM-3509-L User manual

USER’S GUIDE
Version: FM35-202009M
AIR CURTAINS
Elegant Models: FM-3509-L/Y, FM-3510-L/Y,
FM-3512-L/Y, FM-3515-L/Y, FM-3518-L/Y
STOP and Read! Test before installing
1. Do NOT plug in power cord to power source, check if any loose parts.
2. Plug in 120V power source (some old air curtains might use 240V, verify
the power voltage if not sure); press the front switch to H or L to turn on.
If the air curtain works normally, refer to section 3 through 7 to install
the air curtain. Refer to section 10 for technical support.
3. After installation, if the air curtain doesn’t run, first step is to check the
magnetic switch. Refer to section 7 for troubleshooting.
Thanks for purchasing this Air Curtain.
PLEASE READ AND SAVE THESE INSTRUCTIONS.
Strongly recommend to test the unit before installation for any
defective or damage during shipment.

1
WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS, READ THE FOLLOWING CAREFULLY before attempting to
assemble, install, operate or maintain the product.
A. Always disconnect, lock and tag power source before installing or servicing. Failure to
disconnect power source can result in fire, shock or serious injury.
B. Installation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards, including fire-rated construction.
C. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other
hidden utilities.
D. To reduce the risk of fire or electric shock, do not use this fan with any solid-state
speed control device
E. Repair and maintenance operations can only be performed by qualified personnel.
F.
Verify and ensure the rated voltage and frequency (please refer to the rating label) of
the air curtain is in compliance with the mains supply.
G.
Make sure the air curtain is securely mounted on the wall; otherwise, the air curtain
may fall and injury to persons.
CONTENTS
1. PRODUCT INTRODUCTIONS................................................................................................1
2. INSTALLATION CAUTIONS....................................................................................................2
3. INSTALLATION INSTRUCTIONS............................................................................................3
4. TECHNICAL PARAMETER.....................................................................................................4
5. WIRING DIAGRAM.................................................................................................................5
6. OPTIONAL MAGNETIC SWITCH INSTALLATION .................................................................5
7. TROUBLESHOOTINGS..........................................................................................................7
8. OPERATING INSTRUCTIONS................................................................................................7
9. MAINTENANCE AND CLEANING...........................................................................................8
10. SUPPORTAND CONTACT .................................................................................................8
1.PRODUCT INTRODUCTIONS
Air curtains are widely installed at the entrances of supermarket, theater, meeting room, hotel,
office room, storeroom etc. They can reduce penetration of insects, dust, and unconditioned air
into a conditioned space by forcing an air stream over the entire entrance to create a comfortable
environment for you.

2
2.INSTALLATION CAUTIONS
Must observe the following when installing air curtains:
Strongly recommend to test the unit before installation for any
defective or damage during shipment.
2.1 Please install the unit on a sturdy
supporting structure to avoid
shaking and
ensure its security (because the unit running
may cause the wall to become loose or
shake and make noise).
2.2 Please install the unit inside the room.
Require 2 inches clearance to the ceiling.
2.3 Install the unit between 7 feet to 7.5 feet
from the ground.
ATENCIÓN
:
Instalar la unidad entre los 7
a 7.5 pies desde del suelo.
2.4 When the entrance is wider than the
unit, it is recommended to install two or
more units in parallel. In this case, provide
3/4” to 1-1/2” gaps between the units.
2.5 Don’t allow gaps between the unit and
the wall.
2.6 Don’t install the unit at a place where it
is splashed by water, exposed to excessive
steam, explosive gas or corrosive gas.
7’ – 7.5’

3
3.INSTALLATION INSTRUCTIONS
A. Installing on the concrete wall:
3.1.1 Unscrew the fixing screws to remove
the mounting plate from the back of the main
body.
3.1.2 Determine the mounting location with
the mounting plate. Drill holes and insert the
Zinc-Plated Steel Hex-Nut-Head Sleeve
Anchor (not included).
3.1.3 Tighten the nuts to secure the
mounting plate to the wall (use the washers
and nuts as the Fig shows).
3.1.4 Hang the main body onto the upper
end of the mounting plate, and then tighten
the bottom fixing screws
back to the
mounting plate.
B. Installing on the wooden wall: (Note: Make sure the screws are secured in the wood
studs, drill holes on mounting plate to align to the wood studs, and attach an extra
wood frame to the wall if needed.)
3.2.1 Refer to step 3.1.1 and determine the
mounting location, use a stud finder if needed,
and then mount the mounting plate to the wood
studs securely with tapping screws.
3.2.2 Hang the main body onto the upper end
of the mounting plate, and then tie the bottom
fixing screws back to the mounting plate.

4
C. Ceiling mount or side mount: (Note: The mounting brackets are available to purchase.)
3.3.1 Ceiling mount - mount the threaded rods
securely to the studs in the ceiling.
3.3.2 Securely mount the mounting brackets
and the mounting plate.
3.3.3 Side mount – mount to the top door
frame securely.
3.3.4 Securely mount the mounting brackets
and the mounting plate.
Note: The air curtain should be installed indoor, should not have moisture, water, rain, or
snow reachable. Consult with your electrical professional for 120V electrical hard wiring.
WARNING: Make sure the air curtain is securely mounted on the wall; otherwise, the air
curtain may fall and injury to persons.
4.TECHNICAL PARAMETER
Model
No.
Max
entry
opening
(Inch)
Voltage
(V~Hz) Power
(W)
Max
Current
(A)
Max air
velocity
(FPM)
Air volume
(CFM)
Noise
level
(dB)
Net
weight
(Lb)
H L H L
FM-3509-L/Y 38
120V,
60Hz
300 3.13
3150 (H),
2559 (L)
907 742 52 49 28.7
FM-3510-L/Y
44
320
3.33
989
824
52
49
30.9
FM-3512-L/Y
50
400
4.17
1236
989
53
50
34.2
FM-3515-L/Y
62
500
5.21
1566
1236
55
52
44.1
FM-3518-L/Y
74
600
6.25
1878
1482
55
52
51.8
Note: ETL certified models have 1 speed only, which is the High speed. The data are
subjected to change without notice due to product development.

5
5.
WIRING DIAGRAM
6.OPTIONAL MAGNETIC SWITCH INSTALLATION
This air curtain comes with a magnetic door switch, contact seller or Awoco if you are missing a
magnetic switch. The dedicated 2 wires (Yellow) are to connect to the magnetic switch.
Note: Keep the 2 wires connected (closed) if the magnetic switch is not used.
Connect the magnetic door switch:
Cut the nut off the 2 yellow wires, and connect the 2 yellow wires to the magnetic switch one by one. Use the
black electrical tape to seal the connection. Don’t place the magnetic switch close to existing alarm sensors.

6
Mount the 2 pieces magnetic switch to the door/window edge and frame; keep them close when the
door/window is closed. If needed, apply a metal “Z” bracket to raise the magnet to the same position. Note: Do
NOT use big screws!!! Oversized screws will damage the magnetic switch internally.
Note: Don’t place the magnetic switch close to existing alarm sensors. The existing alarm sensor
magnet will interfere with this magnetic door sensor.

7
7.TROUBLESHOOTINGS
Failure symptom
Possible causes
Troubleshoot and solution
Fan blower is
broken
Damaged during
shipment
If the fan blower is broken and your purchase is from
an authorized seller, contactAwoco to get a fan wheel
replacement.
Fan blower is stuck
or generates
strange noise
The fan blower is
damaged during
shipment
ContactAwoco for instruction on changing the fan
blowers.
The magnetic
switch isn’t function
correctly
sometimes.
The magnetic
switch is defective
or close to an
alarm sensor
Don’t place the magnetic switch close to an alarm
sensor. The alarm sensor magnet will interfere with it.
Remove the magnetic switch connection and test if
the magnetic switch is defective.
The air curtain
doesn’t turn on.
(Make sure your
power outlet is
120V before
plugging in. Some
old air curtains
might use 240V)
The magnetic
switch is defective
or loosen
connection
Remove the magnetic switch connection, directly
connect the 2 yellow wires together then test the air
curtain. 80% of the failure is due to the magnetic
switch setup. Don’t use oversize screws, and make
sure the connection is secure.
Check if the front
switch is function
After a long period of time, the L/Off/H (or On/Off)
switch might be burnt out. Please test the switch.
Circuit board
failure or no power
to circuit board
Toggle the magnetic switch and the front switch; hear
if “Tic-Tac” sounds from the relay on the circuit board.
No sound means no power to motors.
Motor rotates slowly
Startup capacitor
is not connected
securely or
defective
Check if the 2 yellow/orange wires securely connect
to the capacitor under the motor. Remove the motor to
get access if needed.
After above
troubleshoot
processes, motor
still doesn’t turn on
Motor is defective
This chance is very low but it might happen.
Use Ohm meter to measure the continuity between
motor’s black wire and the white wire to check if it is
open. Open means defective.
Note: This air curtain requires technique/skills to open the cover to service, and changing
the blower requires some special tools. If you are a technician, please contact Awoco
technical support for repair instructions. Return/exchange is always the option.
Feel free to contactAwoco technical support at 1-888-412-3428 if you need help.
Awoco has all the parts for 1 year limited warranty, including fan wheels, magnetic switches,
circuit boards, motors, etc.
8.OPERATING INSTRUCTIONS
8.1 Connect power (120V 60Hz) to the unit.
8.2 Press the switch to the left or right to turn on the unit. [L] - Low speed, [H] - High speed.
8.3 Adjust the air deflector to slightly outward at about 10 to 15 degrees to obtain optimum effect.

8
9.MAINTENANCE AND CLEANING
WARNING:
A. Any service is to be performed only by qualified personnel who are familiar with local
codes and regulations and are experienced with this type of product.
B. Always unplug or disconnect the appliance from the power supply before servicing or
cleaning the unit.
C. Never use petrol, benzene, thinners or any other such chemicals for cleaning the unit.
D. Don’t allow water or any liquid to enter the motor.
9.1.Use the unit at the rated voltage and frequency indicated on the rating label.
9.2.Disconnect power source before unit installation or maintenance service.
9.3.Routine maintenance must be done every year.
9.4.Plastic parts should be cleaned with mild soap water, thoroughly remove soap film with a
clean damp cloth.
9.5.Wipe the exterior surfaces of the fan with a moistened cloth with a solution of mild detergent
and water.
9.6.Dry the case with a soft dry cloth before operating the unit.
10.SUPPORTAND CONTACT
Contact your local seller for exchange or repair.
Visit www.awoco.com for most updated information.
Email to sales@awoco.com or call 1-888-412-3428 for technical support and sales activity.
This manual suits for next models
9
Table of contents
Other Awoco Heater manuals
Popular Heater manuals by other brands

Haverland
Haverland Compact Series Instruction & installation manual

Purmo
Purmo RADSON MINORCA Installation & maintenance

ADEO Services
ADEO Services HHAD03-10C instruction manual

Jindara
Jindara Riverina SRS3 Insert installation instructions

EUROM
EUROM 322125 instruction manual

NERI
NERI Latina INFORMATIVE NOTE

Vaillant
Vaillant VEI 300/1 MW Operating and installation instructions

Tutco SureHeat
Tutco SureHeat Max Air F074723 operating manual

Jaga
Jaga IGUANA ARCO ARCW Mounting instructions

Dimplex
Dimplex LPC Series installation instructions

Sentiotec
Sentiotec TH6-VR Instructions of installation

Powrmaster
Powrmaster TE21 User, installation and servicing instructions
