Axent PRIMUS User manual

INSTALLATION INSTRUCTIONS
PRIMUS

Thank you for placing your confidence in us.
Thank you for buying AXENT products. You can learn from this
manual about installation steps before initial start-up.
Please follow the instructions in this manual carefully.
Please keep the manual properly stored for future reference.
Regarding future product updates, the product is subject to
change without prior notice.
Illustrations in this manual serve as visual demonstration.
We hope you can learn how to install the product through this
manual.
In order to guarantee that the Product will always function
optimally, and to ensure your personal safety, please do the
following:
Read these operating instructions carefully before initial
start-up and follow these instructions!

SAFETY
1
INSTALL PREPARATIONS
Safety
DANGER! High risk,
lethal hazards,
severe injuries
Low risk,
minor injuries,
damage to property
CAUTION!
Violation of the
relevant regulations
MANDATORY
DANGER! DANGER!
CAUTION!
PROHIBIT! Strictly avoided
The following warning signs warn you of dangerous situations and their severity. In order to avoid
harm to you and others, be sure to follow the list of items.
Sockets shall not be allowed too loose, and
the power plug should be completely
inserted to avoid electric shock or fire.
Please use the components attached to the
product, otherwise it may cause water
leakage, flood, electric shock.
The circuit construction should abide by the
rules of indoor wiring, otherwise it may
cause fire and electric shock.
Please do not install the product in the
damp place, which may cause fire or electric
shock.
Do not replace the power supply cord by
yourself which may lead to fire and
electric shock. If you need to replace
the power supply cord, it must be
replaced by the manufacturer, its
service agent or similar qualified
persons in order to avoid hazard.
Do not use a bidet seat with a damaged cord
which may cause electric shock, short circuit,
fire.
Do not allow to place open flames, candles,
cigarettes, or similar objects on or by the toilet.
Do not allow to use industrial water, circulating
water or waste water as the source of the
product. Please use the water source that
meets the standard of living and drinking.
Please comply with all local regulations on
water supply and drainage, otherwise it may
lead to a safety hazard.
Only use the new hose-sets supplied with
the product.
When moving the product, please hold the main
body. if only moving with the cover and the
seat, the components maybe separated from
the main body.
Please read theses instructions carefully before installation.
Installation should be based on the steps documented in this manual. AXENT will not take responsibility for
the negative consequences caused by the changed construction method without authorization.
It shall be confirmed that the distance between the pit center and the wall matches with the product.
Do the waterproofing for the ground and wall before installation.
Since ceramics can be easily damaged it should be handled with care during installation, also do not tighten
the nuts excessively to avoid damage to the product. The bottom part of the toilet shall not be fixed and
installed using cement.
The power voltage is AC 220-240 V~ , 50/60 Hz. Use the specified power supply only.
According to the length of the power supply cord documented in this manual, the electrical power supply
should be located close to the installation position of this product.
Hydrostatic Pressure Range: 0.14~0.75Mpa; Water Temperature Range: 4-35℃
Do not remove the static film on the product during installation to avoid scratching the surface of the product.
After the installation, water shall be supplied before power up.
Due to the water flow test in factory before delivery, a small amount of water may flow out when
taking the product out, which is normal.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.

PRE INSTALLATION CONFIRMATION
2
DIMENSION(Unit:mm)
A=1006
568
B=487
386
725
≥10
Please ensure that the distance
from the wall and the product meets
the requirements so that the repair
work can be carried out normally.
STANDARD DELIVERY CONTENTS
USER MANUAL

INSTALL PREPARATIONS
1.Ensure that the titles and wall bricks have been laid, at the same time the pipes in pit and water
supply pipes have been reserved before installation.
2.It shall be confirmed that the height of pipe 5-10 mm over the ground, and distance from its center
to the wall (distance between the pit center and the wall) matches with the product.
3.Open the angle valve, and clear the impurities and sludge in the embedded pipe before installation
to make sure the product is running normally.
4.Please refer to the size indicated in the figure below and reserve the installation position, to avoid
affecting the normal use of the inlet pipe and power supply line.
5.The socket circuit connected to the product must have residual current protective device with a
rated residual operating current not exceeding 30mA.
INSTALLATION TOOLS
Φ10 mm Φ6 mm
PRE INSTALLATION CONFIRMATION
3
200~300mm
100 ~150mm
≥ 1000 mm
≥ 1200 mm
Sewage drain outlet
angle valve
≥500mm
≥200mm
Distance between
the pit center
and the wall
Distance between
the pit center
and the wall
The height of pipe
5-10 mm over the ground
The height of pipe
5-10 mm over the ground

INSTALLATION STEPS
4
TOILET INSTALLATION
Please ensure that the distance from the
wall and the product meets the require-
ments so that the repair work can be
carried out normally.
1
2
3
5
6
4
ø10 mm 55 mm
≥70 mm
≥78 mm

7
8
9
11
12
10
5
INSTALLATION STEPS

6
INSTALLATION STEPS
REMOTE CONTROL INSTALLATION(TWO OPTIONS)
BATTERIES INSTALLATION
2
1
MODE A（RECOMMEND） MODE B

Reference range for convenient
use of position(Unit:mm)
750
1000
175 175
1
2
3
4
5
6
7
MODE A
ø 6 mm
35 mm
7
INSTALLATION STEPS

8
INSTALLATION STEPS
13 REMOTE CONTROL FIXED
(OPTIONAL)
2
1
8
10
11
12
9

9
INSTALLATION STEPS
MODE B
1 5
2
3 6
4

TEST
–
1)WATER SUPPLY
Turn on the angle valve.
2)POWER ON
Insert the power plug into the socket, and confirm that pushing the plug firmly in place.
3)FUNCTIONAL TEST
Touch the sensing area by hand to test the flushing and cleaning functions, and check the leakage.
Make sure the product and remote control are running normally.
CAUTION!
–This device is an electric appliance of class I and must be connected to a grounding system.
–
–Do not allow the power cord to be severely pinched or kinked to avoid affecting normal use.
NOTE!
–Please cover the spray arm during testing to avoid sprayed.
–Do not bend the pipe at large angle, to avoid affecting the service life of the water pipe.
TEST
10

P/N:224000015500 2018/04/28
