Axess SPBT1030 User manual

Copyright © 2014 Axess Products Corporation. All Rights Reserved

Copyright © 2014 Axess Products Corporation. All Rights Reserved
SPBT1030
BT Portable Speaker
USER GUIDE:
For correctly operating , please read this manual carefully before using. Any content revise of the
manual won’t declare again, and we are no responsible for consequence caused by fault or oversight of
this manual
FEATURES:
1. 2.1 outdoor Passive Bluetooth Speaker with 3 inch subwoofer
2. Output very clear sound and bass, dynamic sound effect
3.With A2DP Bluetooth, wireless stream music from any Bluetooth-enabled device such as your mobile
phone, notebook, iPhone or iPad
4.Secure simple pairing for user-friendly operating
5.10 meters operating range
6.With USB and Micro SD card supporting;
7.With FM radio
8.With Line-in function, suitable for PC,MID,TV and other audio device.
9.Built-in lithium rechargeable battery 1000mAh
10.With strap, easy to take out.

Copyright © 2014 Axess Products Corporation. All Rights Reserved
SPECIFICATION:
Horn Size:2 inch
Subwoofer Size:3 inch
Horn output: 2W*2,4Ω
Subwoofer output:5W,4Ω
Battery Capacity: 1000mAh
Frequency Response:100-20Khz
INSTRUNCTION FOR APPEARANCE AND KEY:

Copyright © 2014 Axess Products Corporation. All Rights Reserved
Bluetooth:
1. Turn the power button to “ON”, The LED light turn blue and twinkle quickly and beep twice.
2. Activate Bluetooth of mobile phone and search for device name “Axess SPBT1030” then connect it.
The blue LED light twinkles slowly and beep third times once connected successful.
3. Play the music from your mobile phone and enjoy.
4. Press LAST or NEXT button on the devices or on Mobile phones to select songs you like.
5. Press Play/pause button on the devices or on Mobile phones to play/stop the music
6. Use the Bluetooth device to adjust volume up and down. Or long press to fast forward or backward
to adjust volume up and down
Playing music from USB disk & Micro SD card:
1. Turn the Power button to “ON”.
2. Insert Micro SD card or USB flash disk into slot, the music stored will be played automatically and blue
LED light always keep lighting.
3. Under playing mode, short press Forward or Backward button to select songs you like, long press to
fast forward or backward to adjust volume up and down.
4. Press PLAY/PAUSE to play or pause.
5. Please turn the Power button to “OFF” while without use.
Remark: Under Bluetooth playing mode, insert Micro SD card or USB will disconnect the Bluetooth and
switch the playing from USB or Micro SD card. You can press the MODE button to swich to Bluetooth mode
again.
FM Radio:
1. Under FM radio state, the audio cable provided treat as antenal. Please Insert the audio cable to
get the best FM signal before using.
2. Turn the power button to “ON”, press the “MODE” button to switch to FM radio state.
3. Under playing mode, short press “Play/pause” button to auto search the FM Channel and store it
automatically.
4. Press LAST or NEXT button to change the stored FM channel.
AUX-IN:
For other compatible music devices or your MP3/MP4 players, use the supplied audio line cable to
connect from the device’s “Line Out” to the “Aux In” of this devices. Then press the “MODE” button to
switch to AUX-IN state. Enjoy…
When using an external device, all functions will be controlled by the external device except the
“Play/pause” button.
Remarks:
1. Press the MODE button to switch the different modes, the order is Bluetooth, Micro SD card, USB
disk, FM radio and AUX-IN.
2. Turn the power button to “off” to cut off the power supply while without use.
How to charge:
1. Power off the unit, put the provided charge cable into the charge slot of unit, connect the other end to
PC or other charger with 5V output (Not included),the red charging indicator keep lighting.
2. Charge time should be 3-5 hours. When charging full, the indicator light will switch off.
3. In order to prolong the life of battery, please do not charge more than 8 hours.

Copyright © 2014 Axess Products Corporation. All Rights Reserved
Axess Products Corporation
6639 ValjeanAve., Van Nuys, CA91406, USA
Tel: [phone] • Fax: [phone] • email: [e-mail]
Questions? Comments? Please Contact us at [e-mail]
