Axess SPBT1032 User manual

Copyright © 2014 Axess Products Corporation. All Rights Reserved

Copyright © 2014 Axess Products Corporation. All Rights Reserved
SPBT1032 Manual
For proper operation, please read this manual carefully before using. Any content
revisions of the manual will not be declared, and we are not responsible for any
consequences caused by fault or oversight of this manual.
FEATURES:
1. 2.1 Indoor/Outdoor Passive Hi-Fi Bluetooth Speaker with 5¼inch Subwoofer.
2. Output has very clear sound and heavy bass, dynamic sound effect.
3. With A2DP Bluetooth, wirelessly stream music from any Bluetooth-enabled device
such as your mobile phone, notebook, iPhone or iPad.
4. Secure simple pairing for user-friendly operating.
5. 10 meter operating range.
6. With USB and SD card support.
7. With FM radio.
8. With EQ function (compatible with USB and SD card only)*.
9. With LED display - can show the digital number & working status.
10. With Line-in function, suitable for PC, MID, TV and other audio device.
11. Two gear control for volume and tone.
12. Built-in lithium rechargeable battery (1000 mAh).
13. With handle & strap for easy portability.
*The Equalizer (EQ) function is not compatible with external audio devices, such as Bluetooth, FM and Line-in. It is only
compatible with internal audio signals from the USB and SD card reader. This is due to chipset coding, so the EQ can be
controlled by its internal software. For Bluetooth and Auxiliary Line-in functions, you will need to adjust the EQ via the settings
on your external device.
SPECIFICATION:
Horn Size: 3 inches Subwoofer Size: 5 ¼ inches
Horn output: 3W x 2, 4Ω Subwoofer output: 12W, 4Ω
Battery Capacity: 1000 mAh Frequency Response: 100-20Khz
Power Supply: DC 3.7V
Accessories:
USB Charging Cable, Audio Cable, User Manual, Carrying Strap

Copyright © 2014 Axess Products Corporation. All Rights Reserved
APPEARANCE AND KEY INSTRUCTIONS:
1. USB port 2. Charging jack 3. LED indicator
4. LED screen 5. SD slot 6. Speaker
7. ON/OFF button 8. Aux-in jack 9. Forward
10. Play/Pause 11. Backward
12. Mode (Bluetooth switch, USB, SD, FM and AUX-IN modes)
13. EQ 14. Tone Adjustment Gear 15. Volume Gear
Bluetooth:
1. Turn the power button to “ON”. The LED screen will display “bt” and beep twice,
flashing quickly.
2. Activate Bluetooth on your mobile device and search for device name “BT
speaker”, and then connect it. The “bt” on the screen will stop flashing and beep
three times once connected successfuly.
3. Play the music from your mobile device and enjoy.
4. Press LAST or NEXT button on the device or mobile device to select songs.
5. Press PLAY/PAUSE button on the device or Mobile device to PLAY/STOP the music.

Copyright © 2014 Axess Products Corporation. All Rights Reserved
6. Use the “Volume Gear “to adjust the volume up and down. Or you can adjust the
volume from your mobile device.
7. Use the “Tone Adjustment” to adjust the tone. Or you can adjust the tone from
your mobile device.
Playing music from USB disk & SD card:
1. Turn the Power button to “ON”.
2. Insert SD card or USB flash disk into slot, the music stored will be played
automatically and LED screen display the songs playing.
3. Under playing mode, short press Forward or Backward button to select songs you
like, long press to fast forward or backward the song.
4. Press PLAY/PAUSE to play or pause.
5. Please turn the Power button to “OFF” while without use.
Note: In Bluetooth PLAY mode, inserting a SD card or USB device will automatically
disconnect the Bluetooth and switch to the USB device or SD card. You can press the
MODE button to switch back to Bluetooth mode.
FM Radio:
1. In FM radio mode, the audio cable provided serves as an antenna.
Please insert the audio cable to get the best FM radio signal before use.
2. Turn the ON/OFF button to “ON” and press the “MODE” button to switch to FM
radio mode.
3. In PLAY mode, tap the “PLAY/PAUSE” button to auto-search the FM stations and
store them automatically.
4. Press the LAST or NEXT buttons to change the stored FM stations.
AUX-IN:
For all other compatible external music devices or MP3/MP4 players: Please use the
supplied audio line cable to connect from your external device’s “LINE OUT” jack to
the “AUX IN” jack of this device. Then press the “MODE” button to switch to the
AUX-IN state. Enjoy!
When using an external device, all functions will be controlled by the external device
except for the “PLAY/PAUSE” button.
Notes:
1. Press the MODE button to toggle between different modes: Bluetooth, SD, USB,
FM radio, and AUX-IN.
2. Turn the ON/OFF button to “OFF”, to shut off the power supply while not in use.
Charging Instructions:
1. Power off the unit, and put the provided charge cable into the charge slot of unit.
Connect the other end to a PC or other charger with 5V output (not included). Once
connected properly, the red charging indicator light should keep flashing.
2. Charge time is approximately 3-5 hours. When fully charged, the red charging
indicator light will switch off.

Copyright © 2014 Axess Products Corporation. All Rights Reserved
3. In order to prolong the life of the battery, please do not charge more than 8 hours.

Copyright © 2014 Axess Products Corporation. All Rights Reserved
