AXIOMTEK MANO310 Series User manual

MANO310 Series
Intel®Pentium®N4200/ Celeron®
N3350 Processor Mini ITX
Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2017 Axiomtek Co., Ltd.
All Rights Reserved
December 2017, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Chapter 1 Introduction............................................. 1
1.1Features................................................................................................1
1.2 Specifications........................................................................................2
1.3 Utilities Supported.................................................................................3
1.4 Block Diagram.......................................................................................4
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................7
2.3 Jumper Settings....................................................................................9
2.3.1 Clear CMOS (JP1) .................................................................................... 10
2.3.2 AT/ATX Power Mode Select (JP2) ............................................................ 10
2.3.3 COM1 RS-232/422/485 Mode Select (JP3, JP4, JP5) ............................. 10
2.3.4 COM2 RS-232/422/485 Mode Select (JP6, JP7, JP8) ..............................11
2.3.5 COM3 Data/Power Select (JP9) ................................................................11
2.3.6 LVDS Backlight PWM/CCFL Select (JP10)................................................11
2.3.7 LVDS VDD Select (JP11)...........................................................................11
2.4 Connectors..........................................................................................12
2.4.1 Internal USB 2.0 Connector (CN1)............................................................ 13
2.4.2 Micro SD Card Slot (CN4)......................................................................... 13
2.4.3 Front Panel Connector (CN5) ................................................................... 14
2.4.4 SIM Card Socket (CN6) ............................................................................ 15
2.4.5 PCI-Express Mini Card Connector (CN7) ................................................. 15
2.4.6 M.2 Key B Slot (CN8)................................................................................ 16
2.4.7 DC Power Input Connector (CN10)........................................................... 17
2.4.8 Power Status Connector (CN11)............................................................... 17
2.4.9 Digital I/O Connectors (CN12 and CN13)................................................. 17
2.4.10 Fan Connectors (CN14 and CN34)........................................................... 18
2.4.11 PS/2 Keyboard and Mouse Connector (CN15)......................................... 19
2.4.12 COM Connector (CN16)............................................................................ 19
2.4.13 Internal COM Connectors (CN17~CN20) ................................................. 19
2.4.14 LAN and USB 3.0 Connectors (CN21 and CN22) .................................... 20
2.4.15 PCI-Express x1 Slot (CN23) ..................................................................... 21
2.4.16 Audio Jack (CN24).................................................................................... 21
2.4.17 Front Audio Connector (CN25).................................................................. 21
2.4.18 HDMI Connector (CN26)........................................................................... 22

v
2.4.19 LVDS Connector (CN27)........................................................................... 22
2.4.20 LVDS Backlight Control Connector (CN28)............................................... 23
2.4.21 VGA Connector (CN30)............................................................................. 23
2.4.22 DC Jack Power Input Connector (CN31).................................................. 23
2.4.23 SATA 3.0 Connector (CN32) ..................................................................... 24
2.4.24 SATA Power Connector (CN33)................................................................ 24
2.4.25 eDP Connector (CN35) (Optional) ............................................................ 25
Chapter 3 Hardware Description ........................... 27
3.1 Microprocessors..................................................................................27
3.2 BIOS....................................................................................................27
3.3 System Memory..................................................................................27
Chapter 4 AMI BIOS Setup Utility .......................... 29
4.1 Starting................................................................................................29
4.2 Navigation Keys..................................................................................29
4.3 Main Menu ..........................................................................................31
4.4 Advanced Menu..................................................................................32
4.5 Chipset Menu......................................................................................42
4.6 Security Menu .....................................................................................46
4.7 Boot Menu...........................................................................................47
4.8 Save & Exit Menu................................................................................50
Appendix A Watchdog Timer................................... 53
A.1 About Watchdog Timer........................................................................53
A.2 Watchdog Timer Programming............................................................53
Appendix B Digital I/O ............................................. 55
B.1 About Digital I/O..................................................................................55
B.2 Digital I/O Programming......................................................................55
Appendix C BIOS Flash Utility ................................ 57

vi
This page is intentionally left blank.

MANO310 Mini ITX Motherboard
Introduction 1
Chapter 1
Introduction
The MANO310 is a Mini ITX board based on Intel®Pentium®N4200/ Celeron®N3350
processor. It delivers outstanding system performance through high-bandwidth interfaces,
multiple I/O functions for interactive applications and various embedded computing solutions.
There are two 204-pin DDR3L SO-DIMM sockets for DDR3L 1866MHz memory with maximum
capacity up to 8GB. This Mini ITX board features two Gigabit Ethernet ports, one SATA 3.0 port
with maximum transfer rate up to 6Gb/s, four USB 3.0 (rear I/O) and two USB 2.0 (internal)
high speed compliant ports that can achieve the best stability and reliability for industrial
applications.
1.1 Features
Intel®Pentium®quad core N4200 (1.1 ~2.5GHz) and Celeron®dual core N3350
(1.1~2.4GHz)
2 DDR3L 1866MHz memory with maximum capacity up to 8GB
1 PCI-Express x1
1 PCI-Express Mini Card
1 SATA-600, 1 M.2 and 1 SDXC
4 USB 3.0 and 2 USB 2.0 ports
6 COM ports supported
Triple view displays
Display: VGA/HDMI/LVDS

MANO310 Mini ITX Motherboard
2 Introduction
1.2 Specifications
CPU
Intel®Pentium®quad core N4200 1.1GHz up to 2.5GHz.
Intel®Celeron®dual core N3350 1.1GHz up to 2.4GHz.
Chipset
SoC integrated.
BIOS
AMI BIOS.
System Memory
Two 204-pin SO-DIMM sockets. The upper socket must be installed.
Maximum up to 8GB DDR3L memory.
Support 1866MHz memory.
Note
If only one memory module is used, please install in DIMM1 (the upper SO-DIMM
socket).
Onboard Multi I/O
Controller: ITE8786.
One PS/2 keyboard and mouse on the rear I/O.
Six serial ports:
- COM1~COM2 support RS-232/422/485 (rear I/O).
- COM3~COM6 support RS-232 only (internal).
16-bit programmable Digital I/O.
USB Interface
Four USB 3.0 ports (rear I/O).
Two USB 2.0 ports (internal).
Ethernet
Two Realtek RTL8111F GbE LAN ports.
Support 1000/100/10Mbps Gigabit/Fast Ethernet with Wake-on-LAN and PXE Boot
ROM.
Serial ATA
One SATA 3.0 port (6Gb/s).
One M.2 Key B.
Audio
Realtek ALC662 5.1 channel HDA codec.
Support line-out/MIC-in.
Display
One 15-pin D-Sub as VGA connector. Resolution max. up to 1920x1200.
One HDMI with resolution max. up to 3840x2160 @ 30Hz or 2560x1600 @ 60Hz.
One 24-bit dual channel LVDS and one 8-pin inverter connector. LVDS resolution is
max. up to 1920x1200.
One Embedded DisplayPort (eDP) with resolution max. up to 4096x2304 @60Hz;
co-layout with LVDS connector (Optional).

MANO310 Mini ITX Motherboard
Introduction 3
Expansion Interface
One PCI-Express x1 slot.
One PCI-Express Mini Card.
One SIM card slot.
SSD
One SD card slot.
Power Input
One 12V~24V 4-pin ATX power input connector.
One 12V~24V DC jack power input connector.
Note
Please plug either one of power input interfaces when power on.
Operating Temperature
0~60°C.
Storage Temperature
-20~60°C.
Form Factor
Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset driver
Ethernet driver
Graphics driver
Audio driver

MANO310 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO310 Mini ITX Motherboard
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Layout
Top View

MANO310 Mini ITX Motherboard
6 Board and Pin Assignments
Bottom View

MANO310 Mini ITX Motherboard
Board and Pin Assignments 7
2.2 Rear I/O
1
Front Audio Connector (CN25)
17
PCI-Express Mini Card Connector (CN7)
2
AT/ATX Power Mode Select Jumper
(JP2)
18
PCI-Express x1 Slot (CN23)
3
SATA Power Connector (CN33)
19
SATA 3.0 Connector (CN32)
4
Internal USB 2.0 Connector (CN1)
20
eDP Connector (CN35) (Optional)
5
Internal COM3~COM6 Connectors
(CN17~CN20)
21
DDR3L SO-DIMM Connectors
(DIMM1~DIMM2)
6
LVDS Backlight PWM/CCFL Select
Jumper (JP10)
22
DC Power Input Connector (CN10)
7
LVDS Backlight Control Connector
(CN28)
23
M.2 Key B Slot (CN8)
8
LVDS Connector (CN27)
24
SIM Card Socket (CN6)
9
LVDS VDD Select Jumper (JP11)
25
Micro SD Card Slot (CN4)
10
Clear CMOS Jumper (JP1)
26
DC Jack Power Input Connector (CN31)
11
COM3 Data/Power Select Jumper (JP9)
27
PS/2 Keyboard and Mouse Connector (CN15)
12
Digital I/O Connectors (CN12~CN13)
28
COM1 and COM2 Connector (CN16)
13
CPU Fan and System Fan Connectors
(CN14, CN34)
29
VGA Connector (CN30)
14
Front Panel Connector (CN5)
30
HDMI Connector (CN26)
15
Power Status Connector (CN11)
31
LAN and USB 3.0 Connectors (CN21~CN22)
16
COM1/COM2 RS-232/422/485 Mode
Select Jumpers (JP3~JP8)
32
Audio Jack (CN24)

MANO310 Mini ITX Motherboard
8 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
Usually, there is a thick line or a triangle near the header or jumper pin 1.
Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.

MANO310 Mini ITX Motherboard
Board and Pin Assignments 9
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO310 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
Jumper
Description
Setting
JP1
Clear CMOS
Default: Normal
1-2 Close
JP2
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
JP3
COM1 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP4
3-5, 4-6 Close
JP5
3-5, 4-6 Close
JP6
COM2 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP7
3-5, 4-6 Close
JP8
3-5, 4-6 Close
JP9
COM3 Data/Power Select
Default: RS-232 Data
COM3 Pin 1: DCD#
3-5 Close
COM3 Pin 8: RI#
4-6 Close
JP10
LVDS Backlight PWM/CCFL Select
Default: PWM
1-2 Close
JP11
LVDS VDD Select
Default: +3.3V
1-2 Close

MANO310 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.1 Clear CMOS (JP1)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing the
CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS,
which includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.2 AT/ATX Power Mode Select (JP2)
This 3-pin (pitch=2.54mm) jumper allows you to select AT or ATX power mode.
2.3.3 COM1 RS-232/422/485 Mode Select (JP3, JP4, JP5)
Use these jumpers (3x2-pin pitch=2.54mm) to set COM1 port to operate as RS-232,
RS-422 or RS-485 communication mode.
JP3JP4 JP5
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close
Function
Setting
RS-232 mode
(Default)
JP3 1-2 close
JP4 3-5, 4-6 close
JP5 3-5, 4-6 close
RS-422 mode
JP3 3-4 close
JP4 1-3, 2-4 close
JP5 1-3, 2-4 close
RS-485 mode
JP3 5-6 close
JP4 1-3, 2-4 close

MANO310 Mini ITX Motherboard
Board and Pin Assignments 11
2.3.4 COM2 RS-232/422/485 Mode Select (JP6, JP7, JP8)
Use these jumpers (3x2-pin pitch=2.54mm) to set COM2 port to operate as RS-232,
RS-422 or RS-485 communication mode.
JP6 JP7 JP8
2.3.5 COM3 Data/Power Select (JP9)
This is a 3x2-pin (pitch=2.54mm) jumper. The COM3 port has +5V power capability on
DCD and +12V on RI by setting JP9.
2.3.6 LVDS Backlight PWM/CCFL Select (JP10)
This 3-pin (pitch=2.54mm) jumper enables you to select PWM or voltage control mode
for LVDS backlight control header (CN28). These two control modes are for adjusting
the brightness of LVDS panel.
2.3.7 LVDS VDD Select (JP11)
This motherboard supports voltage selection for flat panel displays. Use this 3x2-pin
(pitch=2.54mm) jumper to set up VDD power of the LVDS connector. To prevent
hardware damage, before connecting please make sure that the input voltage of LVDS
panel is correct.
Function
Setting
RS-232 mode
(Default)
JP6 1-2 close
JP7 3-5, 4-6 close
JP8 3-5, 4-6 close
RS-422 mode
JP6 3-4 close
JP7 1-3, 2-4 close
JP8 1-3, 2-4 close
RS-485 mode
JP6 5-6 close
JP7 1-3, 2-4 close
Function
Setting
Power: Set COM3 pin 1 to +5V
1-3 close
Data: Set COM3 pin 1 to DCD (Default)
3-5 close
Power: Set COM3 pin 8 to +12V
2-4 close
Data: Set COM3 pin 8 to RI (Default)
4-6 close
Function
Setting
Controlled by PWM (Default)
1-2 close
Controlled by DC Voltage
2-3 close
Function
Setting
+3.3V (Default)
1-2 close
+5V
3-4 close
+12V
5-6 close

MANO310 Mini ITX Motherboard
12 Board and Pin Assignments
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
Description
CN1
Internal USB 2.0 Connector
CN4
Micro SD Card Slot
CN5
Front Panel Connector
CN6
SIM Card Socket
CN7
PCI-Express Mini Card Connector
CN8
M.2 Key B Slot
CN10
DC Power Input Connector
CN11
Power Status Connector
CN12~CN13
Digital I/O Connectors
CN14, CN34
CPU and System Fan Connectors
CN15
PS/2 Keyboard and Mouse Connector
CN16
COM1 and COM2 Connector
CN17~CN20
Internal COM3~COM6 Connectors
CN21~CN22
LAN and USB 3.0 Connectors
CN23
PCI-Express x1 Slot
CN24
Audio Jack
CN25
Front Audio Connector
CN26
HDMI Connector
CN27
LVDS Connector
CN28
LVDS Backlight Control Connector
CN30
VGA Connector
CN31
DC Jack Power Input Connector
CN32
SATA 3.0 Connector
CN33
SATA Power Connector
CN35 (Optional)
eDP Connector
DIMM1~DIMM2
DDR3L SO-DIMM Connectors

MANO310 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.1 Internal USB 2.0 Connector (CN1)
This is a 5x2-pin (pitch=2.54mm) connector for USB 2.0 interface.
2.4.2 Micro SD Card Slot (CN4)
The micro Secure Digital (SD) is a flash memory card format used in portable device
including notebook and digital camera.
Pin
Signal
Pin
Signal
1
+5V
2
+5V
3
USB1-
4
USB2-
5
USB1+
6
USB2+
7
GND
8
GND
9
N/C
10
N/C
Pin
Signal
Pin
Signal
1
DAT2
5
CLK
2
DAT3
6
GND
3
CMD
7
DAT0
4
+3.3V
8
DAT1

MANO310 Mini ITX Motherboard
14 Board and Pin Assignments
2.4.3 Front Panel Connector (CN5)
This is a 7x2-pin (pitch=2.54mm) connector for front panel interface.
Power LED
Pin 1 connects anode(+) of LED and pin 5 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
External Speaker and Internal Buzzer
Pin 2, 4, 6 and 8 connect the case-mounted speaker unit or internal buzzer. While
connecting the board to an internal buzzer, please set pin 2 and 4 closed; while
connecting to an external speaker, you need to set pins 2 and 4 opened and connect the
speaker cable to pin 8(+) and pin 2(-).
Power On/Off Button
Pin 9 and 10 connect the power button on front panel to the board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 11 and 12 connect the case-mounted reset switch that reboots your computer
without turning off the power switch. It is a better way to reboot your system for a longer
life of system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 13 and 14 connect the hard disk drive to the front
panel HDD LED, pin 13 is assigned as cathode(-) and pin 14 is assigned as anode(+).
Pin
Signal
1
Power LED+
2
SPK-
3
GND
4
BUZZER
5
Power LED-
6
N/C
7
N/C
8
SPK+
9
PWR-
10
PWR+
11
RESET-
12
RESET+
13
HD LED-
14
HD LED+
